CCD Session S00096
Bullet Notes from CCD Session
Bullet Vega - Star
Bullet RR Lyrae - Variable Star
Bullet Delta Cepheid - Variable Star (Cepheid)
Bullet AXP Monitoring (4U 0142+615 & 1E 2259+586)
Bullet M56 - Globular Cluster

Notes (S00096)

- 2.9 hour session, calm (no wind)
- Sky conditions deteriorated after 2 hours and forced the session to eventually finish
- Aim of session was to record baseline images on RR Lyrae (RR Lyrae type variable) and Delta Cepheid (Cepheid variable)
 - Opportunity was taken to record images of M56 and monitor AXP stars in Cassiopeia
- An attempt was made to make a mosaic over part of Hydaes cluster (Taurus), but was unsuccessful due to developing cloud.
More Notes

Back to Top


Vega - Star



Vega (Lyra)
Mag +0.03
star shows significant glare
CCD  Image
20s exposure, C filter
2005-10-02  20:40h UT (#96002)

Back to Top


RR Lyrae - Variable Star



RR Lyrae (Lyra)
Approximate Colour CCD Image
Red 3 x 10s (av, R Filter),  Green 3x10s (V Filter), Blue 3x20s (B Filter)
2005-10-02  20:55h UT (#96020-28)

CCD  Image
20s exposure, C filter
2005-10-02  20:53h UT (#96018)
Reference Stars for Magnitude Estimation
CCD  Image
10s exposure, C filter
2005-10-02  21:08h UT (#96051)

Back to Top


Delta Cepheid - Variable Star (Cepheid)

Delta Cepheid (Cepheus)
[ Delta Cepheid is the brightest star , mag +3.6
SAO 34506 is located nearby (41 arc sec separation)  ]
CCD  Image
10s exposure, C filter
2005-10-02  21:41h UT (#96081)

Delta Cepheid through photometric filter (V)
CCD  Image
1s exposure, V filter
2005-09-30 21:54h UT (#96126)

Nearby Reference Star
SAO 34542, Alpha Lacertae (
Lacerta)
Mag +3.8
CCD  Image
10s exposure, C filter
2005-10-02  21:49h UT (#96108)

Back to Top


AXP Monitoring (4U 0142+615 & 1E 2259+586)

Two Anomalous X-ray pulsers (AXPs),  4U 0142+615 and  1E 2259+586 (both lying in Cassiopeia) were checked for brightening. No indication of activity was observed for either AXP.

Star field of 4U 0142+615 area
no sign of AXP (mag limit +17)
Image Image
CCD Image
2 min exposure,  C Filter
2005-10-02  22:32h UT (#96289)
Reference Image
(#81089)

Star field of 1E 2259+586 area
no sign of AXP (mag limit +17)
Image Image
CCD Image
2 min exposure,  C Filter
2005-10-02  22:37h UT (#96293)
Reference Image
(#81094)
[ Baseline Images and More Information ]

Back to Top


M56 - Globular Cluster

M56 (Lyra)
CCD  Image
8 x 20s exposure (average combine), C filter
2005-10-02   21:29h UT (#96063-79)

Approximate Colour CCD  Image
Luminance : 8 x 20s (av, C filter), Red : 3 x 30s (av, R Filter)
Green : 3 x 30s (av, V Filter), Blue: 3x60s (av B Filter)
2005-10-02  21:29h UT (#96063-79)

CCD  Image
60s exposure, C filter
2005-10-02 21:35h UT (#96080)
