CCD Images - Session 109 (2006-01-03)

Previous Imaging Session
Images
(S108)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images (S110)

Objects Session Notes
Bullet PGC 73329 - Galaxy & Attempt at MPL 2005 YO128
Bullet UGC 155 - Spiral Galaxy with Supernova 2005mg
Bullet M74 - Spiral Galaxy
Bullet UGC 934 - Spiral Galaxy
Bullet IC 221 - Spiral Galaxy
Bullet UGC 3634 - Spiral Galaxy with Supernova 2005na
Bullet UGC 4414 - Spiral Galaxy
Bullet UGC 4614 - Spiral Galaxy with Supernova 2005mc
Bullet NGC 890 - Spiral Galaxy
Bullet NGC 750 / NGC 751 - Spiral Galaxy Pair
Bullet IC 405 - Flaming Star Nebula
Bullet IC 417 - Nebula
Bullet NGC 1985 - Nebula
Bullet Barnards B34 - Dark Nebula
- 5 hour session, frosty
- main aim was to record passage of near earth asteroid 2005 YO128 (however it was too faint & moving too fast to detect).
- opportunity taken to image variety of galaxies, including 3 with recent supernova.
- three mosaic sets taken (IC 405, IC 417, B34)
- variable star measurements on Delta Cepheid,  Algol
More Notes

PGC 73329 - Galaxy & Attempt at MPL 2005 YO128

PGC 73329 (Orion)
PGC 73329 (catalog mag +16.8), PGC 17041 (catalog mag +16.8),
PGC 75310 (catalog mag +17.0), PGC 75320 (catalog mag +17.2),
PGC 213310 (catalog mag +17.5), PGC 142814 (catalog mag  +17.5)

 CCD Image
11 x 2 min (average combine), clear filter
2006-01-03 19:16h UT (#109064-74)

 Images of area near PGC 73329 were taken in an attempt to record
passage of a ~ 60 m diameter near earth asteroid 2005 YO128 which
was passing at ~ 7 lunar distances from earth on 2006-01-03.

Expected magnitude was +16.9, however, despite and a
magnitude limit down to +17.6, the asteroid proved too faint
and too fast moving to record a visible trace along the expected path
 CCD Image with expected position of 2005 YO128 at
1 minute intervals overlaid onto stacked image  (11 x 2 minutes)

11 x 2 min (average combine), clear filter
2006-01-03 19:04 to 19:28h UT (#109064-74)

Back to Top


UGC 155 - Spiral Galaxy with Supernova 2005mg

UGC 155 (Pisces) with supernova 2005mg, 7 days after discovery
2005mg, IAUC 8648 discovered 2005/12/27.08
by Jack Newton and Tim Puckett
(Rochester Supernova site | Discovery Image | Reference Image)

 CCD Image
5 x 2 min (average combine), clear filter (1x1 binning)
2006-01-03 19:46h UT (#109080-84)

 CCD Image (negative)
details as above


UGC 155 (Pisces)

 CCD Image
5 x 2 min (median combine), clear filter (2x2 binning)
2006-01-03 21:08h UT (#109120-24)

Back to Top


M74 - Spiral Galaxy

M74 (Pisces)

 CCD Image
5 x 2 min (average combine), clear filter
2006-01-03 22:04h UT (#109168-72)



 M74 - False Colour Image

 CCD Image - Log brightness scaling, False Colour
Image details as above



M74 detail - false colour

CCD Image - Log brightness scaling, False Colour
(2x2 binning, enlarged)

5 x 2 min (average combine), clear filter
2006-01-03 22:04h UT (#109168-72)

Back to Top


UGC 934 - Spiral Galaxy

UGC 934 (Pisces)
(Catalog Mag +15.3, Alt Name PGC 5085)
Supernova 2005ly discovered on 2005/12/21.12 by
Tim Puckett and G. Sostero is not sufficiently bright to be visible

 CCD Image
11 x 2 min (average combine), clear filter, 1x1 binning
2006-01-03 20:09h UT (#109090-94)

Back to Top


IC 221 - Spiral Galaxy

IC 221 (Triangulum)
(Catalog Mag +13.1)
Supernova 2005lx discovered on 2005/12/19.667 by
Tom Boles & Yoshimi Ichimura is not sufficiently bright to be visible

 CCD Image
3 x 2 min (average combine), clear filter (1 x 1 binning)
2006-01-03 20:19h UT (#109096-98)
(Previous Image of IC 221 from 2005-12-22 00:38h UT)

Back to Top


UGC 3634 - Spiral Galaxy with Supernova 2005na

UGC 3634 (Gemini) with supernova 2005na, 3 days after discovery
(Catalog Mag +14.9, Alt Name PGC 20020)
Supernova 2005na (CBET 350) discovered on 2005/12/31.35 by
 Jack Newton, D. Ceravolo, and Tim Puckett is just visible,
approximately 7 arc sec south of UGC 3634 centre

 CCD Image
5 x 2 min (average combine), clear filter
2006-01-03 20:34h UT (#109102-06)

250% Enlarged Image of UGC 3634
Supernova 2005na is indicated by cross-hairs.
Estimated magnitude +15.5 to +16.0
 CCD Image
(details as above)
(Rochester Supernova site | 2005na Discovery Image | Reference Image)

Back to Top


UGC 4414 - Spiral Galaxy

UGC 4414 (Cancer)
(Catalog Mag +14.5, Alt Name PGC 23700)
Supernova 2005mc discovered on 2005/12/23.73 by
THCA Supernova Survey (Discovery Image) is too close to the
galaxy centre and not sufficiently bright to be visible

 CCD Image
5 x 2 min (average combine), clear filter
2006-01-03 20:34h UT (#109102-06)

Back to Top


UGC 4614 - Spiral Galaxy with Supernova 2005mc

UGC 4614 (Lynx)  with supernova 2005mc, 7 days after discovery
(Catalog Mag +15.1, Alt Name PGC 24788)
Supernova 2005mc (IAUC 8651) discovered on 2005/12/27.30 by
 Tim Puckett and A. Kroes is just visible,
approximately 43 arc sec northwest of UGC 4614 centre

 CCD Image
5 x 2 min (median combine), clear filter
2006-01-03 20:56h UT (#109114-18)

250% Enlarged Image of UGC 4614
Supernova 2005mc is indicated by cross-hairs.
Estimated magnitude +16.1
 CCD Image
(details as above)
(Rochester Supernova site | 2005mc Discovery Image | Reference Image)

Back to Top


NGC 890 - Spiral Galaxy

NGC 890 (Triangulum)
(Catalog Mag +13.1)

 CCD Image
5 x 2 min (median combine), clear filter
2006-01-03 22:17h UT (#109174-78)


NGC 890 - False Colour Image

 CCD Image - Log brightness scaling, False Colour
Image details as above

Back to Top


NGC 750 / NGC 751 - Spiral Galaxy Pair

NGC 750 / NGC 751 (Triangulum)
(Catalog Mag +12.0 / +12.2)

 CCD Image (60% size)
5 x 2 min (median combine), clear filter (1x1 binning)
2006-01-03 22:29h UT (#109180-84)


NGC 750 / NGC 751 - False Colour Image

 CCD Image - Log brightness scaling, False Colour
Image details as above

Back to Top


IC 405 - Flaming Star Nebula

IC 405 (Auriga)

 CCD Image Mosaic (3 x 4), size reduced by 50%
30s exposure, clear filter
2006-01-03 22:50h UT (#109190-201)
[ Full Size Image ]

Back to Top


IC 417 - Nebula

IC 417 (Auriga)

 CCD Image Mosaic (3 x 4), size reduced by 50%
30s exposure, clear filter
2006-01-03 23:04h UT (#109207-18)
[ Full Size Image ]

Back to Top


NGC 1985 - Nebula

NGC 1985 (Auriga)

 CCD Image
3 x 30s (median combine), clear filter
2006-01-03 23:11h UT (#109220-22)

Back to Top




Barnards B34 - Dark Nebula

B34  (Auriga)

 CCD Image Mosaic (4 x5), size reduced by 50%
30s exposure, clear filter
2006-01-03 23:24h UT (#109224-43)
[ Full Size Image ]

Back to Top
