David's Astronomy Pages
CCD Images - Session 123 (2006-05-08)

Previous Imaging Session
Images
(S122)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images (S124)

Objects Session Notes ++
Bullet Comet 73/P Schwassmann-Wachmann 3-B (Fragment B)
Bullet Comet 73/P Schwassmann-Wachmann 3-C (Fragment C)
Bullet Moon
Bullet M57 & M51
Bullet M3 - Globular Cluster
Bullet NGC 4631 - Spiral Galaxy (Whale Galaxy)
Bullet Tau Leo - Double Star (Struve 19)
Bullet Cor Caroli - Double Star (Struve 1692)
Bullet CVn Y - Variable Star
Bullet NGC 3953 - Spiral Galaxy & Supernova 2006bp
Bullet Comet C/2004 B1 (Linear)
Bullet CGCG 108-13 - Spiral Galaxy with SN 2006bt
- 4.1/4 hour session
- main aim was to record further images of comet 73/P SW-3 and recent supernova - 2006bp, 2006bt.
- Opportunity was taken to acquire colour images of Moon (83% phase)
- More Notes
-

Comet 73/P Schwassmann-Wachmann 3-B  (Fragment B)

Comet 73/P Schwassmann-Wachmann 3-B
(Fragment B passing through Star Field on
border between Hercules & Lyra)

Animated CCD Frame Sequence showing motion of
fragment B over a 26 minute period
  CCD Image (75% size)
8 frames, 30s exposures, 1x1 binning, C Filter
Linear Scale
2006-05-09 00:55h UT (#123203-37)



Comet 73/P Schwassmann-Wachmann 3-B

False Colour CCD Image
4 x 1 min exposure, 2x2 binning, C Filter
Aligned on comet & Stacked (Average combine)
Log Scale (645-4800 ADU)
2006-05-08 22:53h UT (#123104-07)

 Fragment B change from 3 day previous
showing that comet fragment has dramatically flared up,
and is now at around mag +5
 Image Image
False Colour CCD Image
4 x 60 sec exposure (#123104-07)
2006-05-08 22:53h UT
False Colour CCD Image
4 x 60 sec exposure (#122224-27)
2006-05-06 01:26h UT

Processed images showing Ion tail & 'bow front' details
 Log root Scale
Rotational Gradient
(5 deg)
 Image Image

Square root Scale
(false colour)
Rotational Gradient
(5 deg, false colour)
Image  Image
CCD Image (50% size)
36 x 30s, 1x1 binning, C Filter
Aligned on comet nucleus & stacked
2006-05-09 00:55h UT (#123201-37)

Comet 73/P Schwassmann-Wachmann 3-B
  CCD Image (75% size)
36 x 30s, 1x1 binning, C Filter
Aligned on comet nucleus & stacked, Linear Scale
2006-05-09 00:55h UT (#123201-37)

Back to Top


Comet 73/P Schwassmann-Wachmann 3-C  (Fragment C)

Comet 73/P Schwassmann-Wachmann 3-C
(Fragment C passing through Star Field in Lyra)

CCD Image
1 min exposure, 2x2 binning, C Filter
Linear Scale
2006-05-08 22:23h UT (#123082)



Comet 73/P Schwassmann-Wachmann 3-C

False Colour CCD Image
4 x 1 min exposure, 2x2 binning, C Filter
Log Scale. False Colour (Inverse Spectrum)
Aligned on comet & Stacked (Average combine)
(590-5500 ADU)
2006-05-09 00:35h UT (#123196-99)

Back to Top


Moon

Moon (83% phase)

CCD Image Mosaic (25% size)
0.11 sec exposure, 1x1 binning, B Filter
Unsharp Masked
2006-05-08 22:34h UT (#123087-98)
[ 50% sizeFull Size ]


Moon (colour mosaic)

Approximate Colour CCD Image Mosaic (25% size)
Red : 0.11 sec (R Filter), Green : 0.11 sec (V Filter), Blue : 0.2 sec (B Filter)
1x1 binning, Unsharp Masked
Colour Balance 150-20000 ADU (Red 1.0, Green 1.8, Blue 5.0)
2006-05-09 01:27h UT (#123250-85)
[ 50% size ]



Moon (Detail)


Approximate Colour CCD Image
Red : 0.11 sec (R Filter), Green : 0.11 sec (V Filter), Blue : 0.2 sec (B Filter)
1x1 binning, Unsharp Masked
2006-05-09 01:27h UT (#123250-85)



Moon (Detail)




Moon (Detail)




Moon (Detail)


Back to Top


M57 (Planetary Nebula) & M51 (Spiral Galaxy)

M57 (Lyra) & M51 (Canes Venatici)

CCD Images - Quick Snapshots

Back to Top


M3 - Globular Cluster

M3 (Canes Venatici)

Composite Image
(Top : CCD Image / Bottom : Approximate Colour CCD Image)
Luminance : 3 x 60s (Median Combine, 2x2 binning, C Filter)
Red : 60s (R Filter), Green: 60s (V Filter), Blue: 120s (B Filter)
2006-05-08 22:49 hUT (#123100-02  & 123108-10)

Back to Top


NGC 4631 - Spiral Galaxy (Whale Galaxy)

NGC 4631 (Canes Venatici)

CCD Image
6 x 2min (Average Combine, 2x2 binning, C Filter
2006-05-08 23:11 hUT (#123113-18)

Back to Top


Tau Leo - Double Star (Struve 19)

Tau Leo  (Leo) - Double Star (Struve 19)
90" Separation
A : Yellow white (mag +5.0), B : Blue white  (mag +8.1)

Approximate Colour CCD Image
Red : 10s exp (R Filter), Green : 10s exp (V Filter), Blue : 20s exp (B Filter)
2x2 binning
2006-05-08 23:23 hUT (#123126-30)

Back to Top


Cor Caroli - Double Star (Struve 1692)

Cor Caroli / Alpha CVn  (Canes Venatici) - Double Star (Struve 1692)
19" Separation
A : Blue white  (mag +2.9),    B : Yellow white (mag +5.6)

Approximate Colour CCD Image
Red : 3s exp (R Filter), Green : 3s exp (V Filter), Blue : 5s exp (B Filter)
2x2 binning
2006-05-08 23:30 hUT (#123136-38)
[ Insert at 200% size ]

Back to Top


CVn Y - Variable Star

CVn Y (Canes Venatici) - Red variable star
Large Carbon Star

CCD Image
3 x 20s (Median Combine, 2x2 binning, C Filter
2006-05-08 23:54 hUT (#123156-58)
[ Insert at 200% size ]



Colour Images showing CVn Y's red colouration

Approximate Colour CCD Image
Red : 1s exp (R Filter), Green : 1s exp (V Filter), Blue : 2s exp (B Filter)
2x2 binning
2006-05-08 23:55 hUT (#123159-67)
[ Insert at 300% size ]



Colour Image showing red colouration

Approximate Colour CCD Image (LRGB)
Luminance: 20s (C Filter), Red : 1s exp (R Filter),
Green : 1s exp (V Filter), Blue : 2s exp (B Filter)
2x2 binning
2006-05-08 23:55 hUT (#123156-67)

Back to Top


NGC 3953 - Spiral Galaxy & Supernova 2006bp

NGC 3953 (Ursa Major) with SN 2006bp
2006bp was discovered 2006/04/09.60 by Koichi Itagaki
(Rochester Supernova site | Discovery Image | Reference Image)

Image below (2006-05-09.00) was taken 30 days after discovery.
Estimated magnitude of 2006bp  is  +14.5 (C filter).

Annotated CCD Image
5 x 60s exposure (average combine), 2x2 binning, C Filter
2006-05-09 00:00 hUT (#123171-76)

Back to Top


Comet C/2004 B1 (Linear)

Comet C/2004 B1 (Linear)
passing through star field in Aquila

Annotated CCD Image
2 min exposure
2x2 binning, C Filter
2006-05-09 00:07h UT (#123179)

Animation showing movement over 4 minutes
Animated CCD Image
3 x 2 min exposure
2x2 binning, C Filter
2006-05-09 00:07 to 00:11h UT (#123179-81)

Back to Top


CGCG 108-13 - Spiral Galaxy with Supernova 2006bt

CGCG 108-13  with SN 2006bt (Serpens Caput)
2006bt was discovered 2006-04-26.48 by Lick Observatory Supernova Search
(Rochester Supernova site | Discovery Image | Reference Image)

Image below (2006-05-09.015) was taken 12.5 days after discovery.
Estimated magnitude of 2006bt  is  +17.1 (C filter).
CCD Image
5 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-05-09 00:21 h UT (#123185-89)

Back to Top
