Bullet Comet 73/P Schwassmann-Wachmann 3-B (Fragment B)
Bullet Comet 73/P Schwassmann-Wachmann 3-C (Fragment C)
Bullet Moon
Bullet NGC 3953 - Spiral Galaxy & Supernova 2006bp
Bullet CGCG 108-13 - Spiral Galaxy with SN 2006bt
Bullet MPL 2006 GY2 - Near Earth Object
- 1.8 hour session
- main aim was to record further images of comet 73/P SW-3 and recent supernova - 2006bp, 2006bt.
- Opportunity was taken to acquire images of Moon (95% Phase)
- More Notes

Comet 73/P Schwassmann-Wachmann 3-B  (Fragment B)

Comet 73/P Schwassmann-Wachmann 3-B
(Fragment B passing through Star Field in Lyra)

CCD Image
4 x 1 min exposure, 2x2 binning, C Filter
Aligned on comet & Stacked (Average combine)
Linear Scale
2006-05-09 22:10h UT (#124055-58)


Comet 73/P Schwassmann-Wachmann 3-B
(Fragment B False Colour Image)

False Colour CCD Image
Image Details as above
Log Scale(1180-5000 ADU)
False Colour (inverse spectrum)


Comet 73/P Schwassmann-Wachmann 3-B
(Processed)

Specially processed CCD Image
Rotational Gradient (5 deg)
Image Details as above

Specially processed CCD Image
Rotational Gradient (5 deg)
False Colour (Inverse Spectrum)
Image Details as above


Back to Top


Comet 73/P Schwassmann-Wachmann 3-C  (Fragment C)

Comet 73/P Schwassmann-Wachmann 3-C
(Fragment C passing through Star Field in Cygnus)

CCD Image
4 x 1 min exposure, 2x2 binning, C Filter
Aligned on comet & Stacked (Average combine)
2006-05-09 22:14h UT (#124060)



Comet 73/P Schwassmann-Wachmann 3-C
(Fragment C , False Colour)

False Colour CCD Image
4 x 1 min exposure, 2x2 binning, C Filter
Aligned on comet & Stacked (Average combine)
Log Scale (1380-5500 ADU)
False Colour (Inverse Specturm)
2006-05-09 22:16h UT (#124060-63)

Back to Top


Moon

Moon (89% phase)

CCD Image Mosaic (25% size)
0.11 sec exposure, 1x1 binning, B Filter
2006-05-09 23:13h UT (#124103-14)
[ 50% size ]



Moon (Detail)


Back to Top


NGC 3953 - Spiral Galaxy & Supernova 2006bp

NGC 3953 (Ursa Major) with SN 2006bp
2006bp was discovered 2006/04/09.60 by Koichi Itagaki
(Rochester Supernova site | Discovery Image | Reference Image)

Image below (2006-05-09.940) was taken 31 days after discovery.
Estimated magnitude of 2006bp  is  +14.5 (C filter).

Annotated CCD Image
4 x 60s exposure (average combine), 2x2 binning, C Filter
2006-05-09 22:34 hUT (#124075-79)

Back to Top


CGCG 108-13 - Spiral Galaxy with Supernova 2006bt

CGCG 108-13  with SN 2006bt (Serpens Caput)
2006bt was discovered 2006-04-26.48 by Lick Observatory Supernova Search
(Rochester Supernova site | Discovery Image | Reference Image)

The image below (2006-05-09.956) was taken 13.5 days after discovery.
Estimated magnitude of 2006bt  is  +17.1 (C filter).
CCD Image
5 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-05-09 22:56 h UT (#124090-94)

Back to Top


MPL 2006 GY2 - Near Earth Object

2006 GY2  - Minor Planet
(passing through star field on border between Draco and Corona Borealis)
[ Due to pass by earth on 2006-05-16 at 6.7 Lunar Distance (LD) ]

Annotated CCD Image
60 sec exposure, 2x2 binning, C Filter
2006-05-09 22:42h UT (#124083)
Animated CCD Frames showing motion of 2006 GY2 over 2 minutes
Estimated Magnitude +15.1 (C Filter)
Animated CCD Images (200% size)
60 sec exposure, 2x2 binning, C Filter
2006-05-09 22:42h UT (#124083-84)
