Objects Session Notes
Bullet C/2006 M4 (Swan) - Comet
Bullet NGC 7243 - Open Cluster
Bullet Nearby Stars
- Barnard's Star
- SO025300.5+165258 ("Teegarden's Star")
- HIP 67593
Bullet Variable Star Monitoring
- U Her, W And, U And, EZ And (Mira variables)
- R CrB
- SS Cyg, HD 5501
- 3.3/4 hr session.
- CCD operation of -15 degC
- main objectives where to acquire images of variables stars and nearby stars for photometric and astrometric studies.
- opportunity was taken to acquire image of new comet C/2006 M4 (Swan) and a mosaic of NGC 7243.
- Low Haze /heavy dew developed during the session and prevented recording some mosaics that had been planned.
- More Notes
-

C/2006 M4 (Swan) - Comet

Comet C/2006 M4 (Swan)
(passing through starfield on border between Ursa Major and Coma Berenices)


CCD Image
2 x 60s exposure, 2x2 binning (average combine), C Filter
2006-09-30 19:19h UT (#144015-16)




False Colour CCD Image
Log brightness scaling (3000 ADU range)
(details as above)




False Colour CCD Image
Log brightness scaling
(details as above)




CCD Image
Square root brightness scaling
(details as above)




CCD Image
rotated , North lies the Right
(image details as above)

Back to Top


NGC 7243 - Open Cluster

NGC 7243 / Caldwell 16 (Lacerta)


CCD Image Mosaic,  3 x 4 frames  (75% size & cropped)
30 sec exposure, 2x2 binning, C Filter
2006-09-30 22:00 h UT (#144184-95)
[ Full Size ]

Back to Top


Nearby Stars

Set of images (7 x 10s exp, C Filter) acquired for astrometric measurements.
Part of a ongoing study to attempt to measure proper motion and annual parallax of Barnard's Star.  (Barnards Star Project).

Set of images (7 x 60s exp, C Filter) acquired for astrometric measurements.
Part of a ongoing study to attempt to measure proper motion and annual parallax of "Teegarden's star" (official name SO025300.5+165258)    ("Teegarden's Star" project).

Set of images (7 x 60s exp, C Filter) acquired for astrometric measurements.
Part of a ongoing study to attempt to measure proper motion and annual parallax of HIP 67593 (Bootes)     (HIP 67593 project).

Back to Top


Variable Stars

Set of BRV Images collected as part of an ongoing study of this new variable [HD 5501 project

Set of BRV Images collected as part of am ongoing study of this variable [SS Cyg project]

Set of BRV images collected as part of an ongoing study to develop a light curve for this Mira variable [U Her project

Set of BRVI Images collected as part of an ongoing study to develop a light curve for this Mira variable [W And project

Set of BRVI Images collected as part of an ongoing study to develop a light curve for this Mira variable [EZ And project

Set of BVRI Images collected as part of an ongoing study to develop a light curve for this Mira variable [U And project

Series of images of R CrB and a reference star (HIP 77373) were taken through B, V, R & I bands, as part of an ongoing study of this star

Back to Top
