CCD Images - Session 145 (2006-10-05)

Previous Imaging Session
Images
(S144)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images (S146)

Objects Session Notes
Bullet RV Ari - Variable Star
Bullet RW Ari - Variable Star
Bullet 4P/Faye - Comet
Bullet M33 - Attempted Observation of Extragalactic Nova: M33 2006 1
Bullet Nearby Stars
- Barnard's Star
- 61 Cygni
Bullet Variable Star Monitoring
- W And & U And (Mira variables)
- RV Ari, RW Ari, GRB 34,
- SS Cyg, HD 5501
- 3.3/4 hr session.
- CCD operation of -15 degC (at 50% cooling)
- main objectives where to acquire images of variables stars and nearby stars for photometric and astrometric studies.
-
-
- More Notes
-

RV Ari - Variable Star

RV Ari is a RR Lyra class variable with with a GCVS catalog period of 0.093128264 days (2 hr 14m) and magnitude min/max of 11.85 to 12.26.
Baseline images acquired in R,V and C Filters, as preparation for a future observing project.

RV Ari - Variable Star (Aries)
RR Lyrae like star
[ PGC 8616, Catalog +15.1 ]


CCD Image
2 x 30 sec, 2x2 binning (average combine), C Filter
2006-09-04 22:18 h UT (#145055-57)




Negative CCD Image
(image details as above image)

Back to Top


RW Ari - Variable Star

RW Ari is a RR Lyra class variable with a GCVS catalog period of 0.354341 days (8 hr 30m) and magnitude min/max of 12.12 to 12.60.
Baseline images acquired in B, R,V and C Filters, as preparation for a future observing project.

RW Ari - Variable Star (Aries)
RR Lyrae like star


Annotated CCD Image
3 x 30 sec, 2x2 binning (average combine), C Filter
2006-09-04 22:32 h UT (#145067-69)

Back to Top


4P/Faye - Comet

Comet 4P/Faye
(passing through starfield in Aries)


CCD Image
3 x 3 min exposure, 2x2 binning (average combine), C Filter
2006-09-04 23:05 h UT (#145106-08)

Back to Top


M33 - Attempted Observation of Extragalactic Nova : M33 2006 1

M33 part (Triangulum)
An extragalactic nova was discovered in M33 on 2006/09/28.20
by University of Texas & Koichi Itagaki (CBET 655)
having a magnitude of +16.5
(Extragalactic Novae page at Rochester Supernova site | Discovery Image 1 | Discovery Image 2)

Image below (2006-10-05.013) was taken 7 days after discovery.
No sign of nova is seen in image (mag limit c. +16.6)
(recorded Nova location indicated by white circle)


CCD Image
2 x 3 min exposure (average combine), 2x2 binning, C Filter
2006-10-05 00:18h UT (#145178-79)

Back to Top


Nearby Stars

Set of images (7 x 10s exp, C Filter) acquired for astrometric measurements on previous evening (2006-10-03).
Part of a ongoing study to attempt to measure proper motion and annual parallax of Barnard's Star.  (Barnards Star Project).

Set of images (7 x 5s exp, C Filter) acquired for astrometric measurements.
Part of an ongoing study to attempt to measure proper motion and annual parallax of 61 Cygni  ( 61 Cygni Project )

Back to Top


Variable Stars

Set of BRV Images collected as part of an ongoing study of this new variable [HD 5501 project

Set of BRV Images collected as part of am ongoing study of this variable [SS Cyg project]

Set of BRVI Images collected as part of an ongoing study to develop a light curve for this Mira variable [W And project

Set of BVRI Images collected as part of an ongoing study to develop a light curve for this Mira variable [U And project

Back to Top
