Objects Session Notes
Bullet C/2006 M4 (Swan) - Comet
Bullet IC 10 - Irregular Galaxy, Local Group
Bullet 51 Cygni - Extrasolar Planet Star
Bullet HIP 3829 - Van Maanen's Star (Nearby Star)
Bullet M1 - Supernova Remnant
Bullet HD 5513 - Suspected Eclipsing Binary
Bullet Astrometric & Photometric Monitoring
- 61 Cyg, HIP 3829  (nearby stars)
- SS Cyg (dwarf novae)
- HD 5501/5513 (eclipsing variables)
- U And, W And (Mira variables)
- 3 3/4 hr session, cut short by deteriorating sky transparency and developing wind
- CCD operation of -15 degC (at 64% cooling)
- main objectives where to acquire sequence of images of HD 5501/HD 5513 and SS Cyg as part of ongoing photometric studies.
-
-
- More Notes
-

C/2006 M4 (Swan) - Comet

Comet C/2006 M4 (Swan)
(passing through starfield in Hercules)




CCD Image
5 x 60s exposure (average combine, aligned on comet),
2x2 binning, C filter
Linear scale with range adjusted to show detail in tail
2006-10-28 20:23h UT (#150012-16)




False Colour CCD Image
Log brightness scaling (3000 ADU range)
(details as above)




False colour CCD Image
Log Scale
(image details as above)





CCD Image
Rotational Gradient processed (15 deg)
(image details as above)

Back to Top


IC 10 - Irregular Galaxy, Local Group

IC 10 (Cassiopeia)


CCD Image
6 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-10-28 (#150113-15 & #150238-40)

Back to Top


51 Cygni - Extrasolar Planet Star

51 Cyg (Cygnus)
(WDS BU 675)


CCD Image
3 x 30s exposure (average combine), 2x2 binning, C Filter
2006-10-28 22:27h UT (#150128-30)




CCD Image (detail 200% size)
(image details as above)

Back to Top


HIP 3829 - Van Maanen's Star (Nearby Star)

HIP 3829 (Pisces)
Van Maanen's Star


CCD Image
30s exposure, 2x2 binning, C Filter
2006-10-28 23:40h UT (#150218)

Back to Top


M1 - Supernova Remnant

M1 (Taurus)


CCD Image
2 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-10-28 23:11h UT (#150180-82)

Back to Top


HD 5513 - Suspected Eclipsing Binary

HD 5513 (Cassiopeia)


Back to Top


Astrometric and Photometric Monitoring

Back to Top
