CCD Images - Session 155 (2006-11-26)

Previous Imaging Session
Images
(S154)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images (S156)

Objects Session Notes
Bullet C/2006 M4 (Swan) - Comet
Bullet TrES-2 - Parent Star to exosolar planet
Bullet M31 - Extragalactic Nova: M31 2006 14
Bullet Globular clusters in M31
Bullet BL Lac - Active Extragalactic Object (Blazer)
Bullet 4P/Faye - Comet
Bullet Astrometric & Photometric Monitoring
- Barnard's Star (nearby star)
- SS Cyg (dwarf novae)
- HD 5501/5513 (eclipsing variables)
- Z And (variable)
- BL Lac (BL Lac blazer)
- U And, W And (Mira variables)
- 3.3 hr session, largely operated under automated control
- CCD operation of -25 degC (at 87% average cooling). Ambient temperature rising during session, due to advance of warm front /developing cloud. (CCD camera cooling 80% at start of session, increasing to 90-95% by end)
- main objectives where to a acquire sequence of images of HD 5501/HD 5513 and SS Cyg as part of ongoing photometric studies, and to acquire baseline images of GSC 3549:2811 (extrasolar planet sol to TrES-2)
- opportunity was also taken to acquire images of newly discovered nova in M31 (2006 14)
-
- More Notes
-

C/2006 M4 (Swan) - Comet

Comet C/2006 M4 (Swan)
(passing through starfield in Hercules)


CCD Image
5 x 60s exposure (average combine, aligned on comet),
2x2 binning, C filter, Linear scale
2006-11-26 18:54h UT (#155034-38)




False Colour CCD Image
Log brightness scaling (3000 ADU range)
(details as above)

Back to Top


TrES-2 - Parent Star to Exosolar Planet

Baseline images of TrES-2 parent star (GSC 3549:2811) were acquired as part of a project to detect the transit of an exosolar planet, that is known to orbit this star  (exosolar planet project).

TrES-2 Parent Star / GSC 3549:2811 (Draco)
CCD Image
3 x 60 sec exposure (average combine), 2x2 binning, C Filter
2006-11-26 19:30h UT (#155074-82)

Colour Images
Approximate Colour CCD Image
BVR, 2x2 binning
Red 3x60s (R Filter),
Green 3x60s (V Filter), Blue 3x120s (B Filter)
2006-11-26 19:30h UT (#155075-85)
Approximate Colour CCD Image
CBVR, 2x2 binning
Luminance : 3 x 60s (C Filter), Red 3x60s (R Filter),
Green 3x60s (V Filter), Blue 3x120s (B Filter)
2006-11-26 19:30h UT (#155075-85)
Reference Stars
CCD Image
3 x 60 sec exposure (average combine),
2x2 binning, C Filter
2006-11-26 19:30h UT (#155074-82)

Back to Top


M31 - Extragalactic Nova : M31 2006 14

M31 part (Andromeda)
An extragalactic nova (M31 2006 14) was discovered in M31 on 2006/11/25.468
by Koichi Itagak, with an apparent magnitude of +17.5
(Extragalactic Novae page at Rochester Supernova site | Discovery Image | Reference: 2006-11a)

Image below (2006-11-26.841) was taken 1.37 days after discovery.
Location of object, shown by white marker, is consistent with nova recorded by K.Itagaki
Estimated magnitude (+17.1).


CCD Image
5 x 3 min exposure (median combine), 2x2 binning, C Filter
2006-11-26 20:11h UT (#155108-12)

Nova M31 2006 14 - Detail
position of recorded Nova maked by white markers


CCD Image (200% size & cropped)
Image details as above

Back to Top


Globular Clusters in M31

Globular Clusters in M31 (Andromeda)
16 globular clusters visible in image marked by white markers
,together with nova M31 2006-14
165-218 (catalog mag +16.5), 182-233 (catalog mag +15.4),
180-231 (catalog mag +16.0), 158-213 (catalog mag +14.7),
177-228 (catalog mag + 18.0), 155-210 (catalog mag +17.9),
160-214 (catalog mag + 18.0), 156-211 (catalog mag +16.8),
108-167 (catalog mag + 17.5), 101-164 (catalog mag +16.9),
092-152 (catalog mag + 16.9), 125-183 (catalog mag +16.5),
110-172 (catalog mag + 15.2), 095-157 (catalog mag +15.8),
VB 234 (catalog mag  ??), 082-144 (catalog mag +15.5),


Annotated CCD Image
5 x 3 min exposure (median combine), 2x2 binning, C Filter
2006-11-26 20:11h UT (#155108-12)

Back to Top


BL Lac - Active Extragalactic Object (Blazer)

Baseline images (3 x 180s, R Filter) acquired for photometric monitoring.

Reference image shown below. (reference stars:  C2 and C12, check stars : K20,K25).   Calculated magnitude of BL Lac +13.74 (R).

[Reference magnitude data for stars C2 and C12 from OPTICAL AND NEAR-INFRARED CALIBRATION OF AGN FIELD STARS by GONZÁLEZ-PÉREZ et al, The Astronomical Journal, volume 122 (2001),   large size reference picture ]

BL Lac (Lacerta)


CCD Image
3 x 120 sec exposure (median combine), 2x2 binning, R Filter
2006-11-26 20:24h UT (#155116-18)

BL Lac monitoring

Back to Top


4P/Faye - Comet

Comet 4P/Faye
(passing through starfield in Cetus)


CCD Image
3 x 2 min exposure, 2x2 binning (average combine), C Filter
2006-11-26 20:33 h UT (#155122-24)

Back to Top


Astrometric and Photometric Monitoring

Back to Top
