CCD Images - Session 283 (2008-04-17)

Previous Imaging Session
Images
(S282)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images (S284)

Objects Session Notes
Bullet Star Spectra - Planetary Nebula
Bullet SAO 49491 - Wolf Rayet Star (WR 140)
Bullet M57 - Planetary Nebula
Bullet NGC 6572 - Planetary Nebula ("Emerald Nebula")
Bullet NGC 6826 - Planetary Nebula ("Blinking Planetary")
Bullet NGC 7662 - Planetary Nebula ("Blue Snowball")

Bullet Astrometric & Photometric Monitoring
- SS Cyg, U Gem (dwarf nova)
- SS Her (mira variable)
- BL Lac (blazar)
- KR Aur, SY Cnc, AM Her, SZ Her, RZ LMi, TZ Lyr (variables)
- V2491 Cyg (nova)
- Ross 248, Barnard's Star, 61 Cyg, Gliese 1245, Groombridge 34 (Nearby Stars)



- All night session (7.2hr)
- CCD operation of -20 degC
(at 64% average cooling).
- main objective to try out acquisition of stellar spectra using recently purchased Star Analyser 100.
- secondary objective was to acquire images of certain selected stars for ongoing photometric and astrometric analysis
- opportunity was also taken to acquire images of selected planetary nebula, including acquisition of nebula spectra using Star Analyser 100.

Star Spectra

Star Name
(designation)
Spectra Type
(catalog)

Star Spectra  (Star Analyser 100)


Image details
(1x1 binning)
SAO 49491
WR 140, Cyg
WR - WC7pd
Wolf Rayet
Image 5 x 60s
2008-04-18 03:09hUT
(#283378-82)
Regulus
Alpha Leo

B7
Image 3 x 1s
2008-04-17 21:50hUT (#283073-75)
Albireo(B)
Beta2 Cyg
B8  Image 7 x 5s
2008-04-18 02:02hUT (#283311-17)
Vega
Alpha Lyr
A0 Image 7 x 0.5s
2008-04-18 01:56hUT (#283304-10)
Castor
Alpha Gem
A2 Image 2 x 1s
2008-04-17 21:45hUT (#283070-72)
Procyon
Alpha CMi
F5 Image 3 x 1s
2008-04-17 21:33hUT (#283058-60)
Pollux
Beta Gem

K0
Image 3 x 0.5s
2008-04-17 21:38hUT (#283064-66)
Albireo(A)
Beta1 Cyg
K3  Image 7 x 5s
2008-04-18 02:02hUT (#283311-17)
61 Cyg K5  Image 3 x 10s
2008-04-18 01:18hUT (#283268-70)
Betelgeuse
Alpha Ori
 M2
Image 5 x 60s
2008-04-20 21:01hUT (#283506-11)
U Her M6-M9 Image 3 x 60s
2008-04-17 23:24hUT (#283143-45)

NGC 6572
Pl. Neb
Pl. Neb
Image 3 x 45s
2008-04-18 01:01hUT (#283245-47)
NGC 6826
Pl. Neb
Pl. Neb
Image 3 x 60s
2008-04-18 02:28hUT (#283337-39)
NGC 7662
Pl. Neb
Pl. Neb
Image 3 x 60s
2008-04-18 02:239hUT (#283346-48)
M57
Pl. Neb
Pl. Neb
Image 3 x 30s
2008-04-18 01:46hUT (#283301-03)


Star Name
(designation)
Spectra Type
(catalog)

Spectra Lines  ( Star Analyser 100)


Image Date/No. & Notes

SAO 49491
WR 140, Cyg
WR - WC7pd
Wolf Rayet
Image 2008-04-18 (#283378-82)
Regulus
Alpha Leo
B7 Image 2008-04-17 (#283073-75)
Albireo(B)
Beta2 Cyg
B8 Image 2008-04-18 (#283311-17)
Vega
Alpha Lyr

A0
Image 2008-04-18 (#283304-10)
Castor
Alpha Gem
A2 Image 2008-04-17 (#283070-72)
Procyon
Alpha CMi
F5 Image 2008-04-17 (#283058-60)
Pollux
Beta Gem
K0 Image 2008-04-17 (#283064-66)
Albireo(A)
Beta1 Cyg
K3  Image 2008-04-18 (#283311-17)
61 Cyg K5 Image 2008-04-18 (#283268-70)
Betelgeuse
Alpha Ori
M2 Image 2008-04-20 (#283506-11)
U Her M6-M9 Image 2008-04-17 (#283143-45)

NGC 6572
Pl. Neb
Pl. Neb
Image 2008-04-18 (#283245-47)
NGC 6826
Pl. Neb
Pl. Neb
Image 2008-04-18 (#283337-39)

Back to Top


SAO 49491 - Wolf Rayet Star (WR 140)

SAO 49491 / WR 140 (Cygnus)

Annotated CCD Image
3 x 30s exposure (average combine), 2x2 binning, C Filter
2008-04-18 03:02hUT (#283375-77)


SAO 49491 / WR 140 - Spectra

Spectrographic CCD Image (50% size)
5 x 60s exposure (average combine), 1x1 binning,
Star Analyser 100 Filter
2008-04-18 03:09hUT (#283378-82)
SAO 49491 / WR 140 - spectral lines
Image details as above

Back to Top


M57 - Planetary Nebula

M57 (Lyra) - enlarged view

CCD Image (300% size)
3 x 30s exposure (average combine), 2x2 binning, C Filter
2008-04-18 01:46hUT (#283296-98)

M57 (Lyra) - normal view

CCD Image
(Image details as above)

M57 - view through slitless diffraction grating

Spectrographic CCD Image
3 x 30s exposure (average combine), 2x2 binning,
Star Analyser 100 Filter Cell
2008-04-18 01:46hUT (#283301-03)

M57 - zero order (left) and first order diffractions (right)

Spectrographic CCD Image (rotated, 200% size)
3 x 30s exposure (average combine), 2x2 binning,
Star Analyser 100 Filter Cell
2008-04-18 01:46hUT (#283301-03)

Back to Top


NGC 6572 - Planetary Nebula ("Emerald Nebula")

NGC 6572 (Ophiuchus)
Hidden Treasures catalog object 90
 [ Planetary Nebula ]  [ Hidden Treasures ]

CCD Image
5 x 30s exposure (average combine), 2x2 binning, C Filter
2008-04-18 00:55hUT (#283237-41)
8" LX200 Classic + ST-7E

NGC 6572 - normal view

CCD Image (cropped)
3 x 45s exposure (average combine), 1x1 binning, C Filter
2008-04-18 01:07hUT (#283251-53)
8" LX200 Classic + ST-7E

NGC 6572 - view through slitless diffraction grating

Spectrographic CCD Image
3 x 45s exposure (average combine), 1x21 binning,
Star Analyser 100 Filter Cell
2008-04-18 01:01hUT (#283245-47)

Back to Top


NGC 6826 - Planetary Nebula ("Blinking Planetary")

NGC 6826 (Cygnus)

CCD Image (200% size, cropped)
6 x 30s exposure (average combine), 1x1 binning, C Filter
2008-04-18 02:21hUT (#283329-36)


NGC 6826 - detail

Annotated CCD Image (300% size, cropped)
Image details as above


NGC 6826 - Spectra

Spectrographic CCD Image (cropped)
3 x 60s exposure (average combine), 1x1 binning,
Star Analyser 100 Filter
2008-04-18 02:28hUT (#283337-39)

Back to Top


NGC 7662 - Planetary Nebula ("Blue Snowball", Caldwell 22)

NGC 7662 / Caldwell 22 (Andromeda)

Annotated CCD Image (50% size, cropped)
3 x 30s exposure (average combine), 1x1 binning, C Filter
2008-04-18 02:35hUT (#283343-45)


NGC 7662 - detail

Annotated CCD Image (300% size, cropped)
Image details as above


NGC 7762 - Spectra

Spectrographic CCD Image (cropped)
3 x 60s exposure (average combine), 1x1 binning,
Star Analyser 100 Filter
2008-04-18 02:239hUT (#283346-48)

Back to Top


M57 - Planetary Nebula

M57 (Lyra) - enlarged view

CCD Image (300% size)
3 x 30s exposure (average combine), 2x2 binning, C Filter
2008-04-18 01:46hUT (#283296-98)

M57 (Lyra) - normal view

CCD Image
(Image details as above)

M57 - view through slitless diffraction grating

Spectrographic CCD Image
3 x 30s exposure (average combine), 2x2 binning,
Star Analyser 100 Filter Cell
2008-04-18 01:46hUT (#283301-03)

M57 - zero order (left) and first order diffractions (right)

Spectrographic CCD Image (rotated, 200% size)
3 x 30s exposure (average combine), 2x2 binning,
Star Analyser 100 Filter Cell
2008-04-18 01:46hUT (#283301-03)

Back to Top


Astrometric and Photometric Monitoring
