Objects Session Notes
Bullet M93 - Open Cluster
Bullet M46 - Open Cluster
Bullet M47 - Open Cluster
Bullet C/2007 N3 (Lulin) - Comet
Bullet 144P/Kushida - Comet
Bullet NGC 3242 - Planetary Nebula
Bullet NGC 1555 - Reflection Nebula
Bullet M66 - Spiral Galaxy
Bullet M68 - Globular Cluster
Bullet M104 - Spiral Galaxy (Sombrero Galaxy)
Bullet Astrometric & Photometric Monitoring
- U Gem (dwarf nova)
- U And, W And (mira variables)
- Z And, RZ LMi
(variables)
- Evening session (6.7 hrs), PEC Training attempt followed by operation largely under automated control
- Ambient Temperature  initially 7 deg C, falling to 1 deg C after 2 hours , then gradually rising to 3 degC by of session as cloud developed.
- CCD operation -25 degC (at 64% average cooling).
- main objective of the session was  to acquire images of key selected stars for ongoing photometric and astrometric analysis.
- opportunity taken to acquire images of comet Lulin
- main objective of the session was  to further refine performance of new LX200R telescope under night sky conditions, take images of selected project stars for photometric analysis, and collect images of certain deep sky objects
-
- Notes from 2009-03-21

M93 - Open Cluster

M93 (Puppis)


CCD Image (53% size reduction)
3 x 20s sec exposure (average combine), 3x3 binning, C Filter
2009-03-21 21:25 h UT (#358023-25)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


M46 - Open Cluster

M46 (Puppis)


CCD Image (60% size reduction)
2 x 45 sec exposure (average combine), 3x3 binning, C Filter
2009-03-21 21:30 h UT (#358030-31)
12" LX200R  (at f/5.7) + ST-10XME



M46 - detail with NGC 2438


CCD Image (100% size, cropped to area surrounding Pl. Neb)
image details as above

Back to Top


M47 - Open Cluster

M47 (Puppis)


CCD Image (60% size reduction)
3 x 30 sec exposure (average combine), 3x3 binning, C Filter
2009-03-21 21:30 h UT (#358033-35)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


C/2007 N3 (Lulin) - Comet

C/2007 N3 (Lulin) passing through starfield in Gemini


CCD Image (Linear Scale)
5 x 90s sec exposure (median combine), 3x3 binning, C Filter
2009-03-21 21:52 h UT (#358043-47)
12" LX200R  (at f/5.7) + ST-10XME



Back to Top


144P/Kushida - Comet

144P/Kushida
 passing through starfield in Gemini


CCD Image (52% size reduction)
60s sec exposure (single frame), 3x3 binning, C Filter
2009-03-21 22:03 h UT (#358052)
12" LX200R  (at f/5.7) + ST-10XME



144P/Kushida - detail


CCD Image (100% size, cropped to central area )
image details as above

Back to Top


NGC 3242 - Planetary Nebula

NGC 3242 (Hydra)


Annotated CCD Image (53% size reduction)
3 x 20s exposure (average combine), 3x3 binning, C Filter
2009-03-21 22:16 h UT (#358071-73)
12" LX200R  (at f/5.7) + ST-10XME



NGC 3242 - detail


CCD Image (Log brightness scaling, cropped to central area)
Image details as above




CCD Image (cropped to central area)
3 x 20s sec exposure (average combine), 1x1 binning, C Filter
Frames aligned using AIP4WIN Planetary Align Function
2009-03-21 22:15 h UT (#358068-70)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


NGC 1555 - Reflection Nebula

NGC 1555 (Taurus)


CCD Image (cropped to central area)
3 x 90s sec exposure (average combine), 3x3 binning, C Filter
2009-03-21 22:59 h UT (#358121-23)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


M66 - Spiral Galaxy

M66 (Virgo)
CCD Image (Linear Scaling, 60% size)
70 x 10 sec exposure (average median combine), 3x3 binning, C Filter
2009-03-22 00:10 h UT  (#358150-219)
12" LX200R  (at f/5.6) + ST-10XME

M66 - detail
Image Image
Linear scaling
Square Root Scaling
False Colour (inverse spectrum)

Image Image
Log Scaling
Log Scaling
False Colour (cold)

CCD Images (cropped to central area)
70 x 10 sec exposure (average median combine), 3x3 binning, C Filter
2009-03-22 00:10 h UT  (#358150-219)
12" LX200R  (at f/5.6) + ST-10XME

Back to Top


M68 - Globular Cluster

M68 (Hydra)


CCD Image (cropped to central area)
5 x 30s sec exposure (median combine), 3x3 binning, C Filter
2009-03-22 00:24 h UT (#358222-26)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


M104 - Spiral Galaxy (Sombrero Galaxy)

M104 (Virgo)
CCD Image (Linear Scaling, 60% size)
7 x 90 sec exposure (average combine), 3x3 binning, C Filter
2009-03-22 00:56 h UT  (#358243-49)
12" LX200R  (at f/5.6) + ST-10XME

M104 - detail
CCD Image (100% size, square root scale, cropped)
Image details as above

False Colour CCD Image (Square root scaling, cropped)
Image details as above

CCD Image (Linear scaling, 100% size, cropped)
Image details as above

M104 - previous image (2004)
CCD Image (Linear scaling, 100% size)
3 x 2 min (average combine),  C Filter
2004-12-11 06:11 h UT (#79023-25)
8" LX200 Classic + ST-7E

Back to Top


Astrometric and Photometric Monitoring
