David's Astronomy Pages
CCD Images - Session 359 (2009-03-29)

Previous Imaging Session
Images
(S358)
  Home
Images
Sessions
  Home
Home
Page
  Next Imaging Session
Images
 (S360)

Objects Session Notes
Bullet Regulus - Star
Bullet M13 - Globular Cluster
Bullet Astrometric & Photometric Monitoring
- None

- Night time session (2.7 hrs), PEC Training
(Attempt to run session remotely failed - network issues as Daylight Savings Time kicked in at 02:00 h
- Ambient Temperature  initially -3 deg C, but gradually rose to 0 deg as cloud developed.
- CCD operation -25 degC (at 55% average cooling).
- main objective of the session was to perform PEC Re-Training and try out an evaluation copy of PEMPro v2.6
- opportunity taken to acquire images of M13 and test out automated focuser adjustments according to filter / focus offset table.
-
- Notes from 2009-03-29

Regulus - Star

Regulus (Leo)
Snap Shot Image. The vertical blooming  streak is normal feature
associated with imaging a bright star with Non-ABG CCD camera


CCD Image (52% size reduction)
3s (single frame), 3x3 binning, C Filter
2009-03-29 01:40 h UT (#snap 0140-54)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


M13 - Globular Cluster

M13 (Hercules)


CCD Image (cropped to central area)
10s (single frame), 3x3 binning, C Filter
2009-03-29 04:22 h UT (#359022)
12" LX200R  (at f/5.7) + ST-10XME




Colour CCD Image
 (cropped to central area)
Red : 10s, Green 10s, Blue 20s,  3x3 binning
2009-03-29 04:18 h UT (#359017-19)
12" LX200R  (at f/5.7) + ST-10XME



M13 taken through different Filters using CFW10 Filter Wheel

Focus position is automatically adjusted between frames by
sending appropriate focus step offsets to the Optec TCF-S focuser.

CCD Image Montage
10-45s exposures (single frames), 3x3 binning, Various Filters
2009-03-29 (#359012-29), 12" LX200R  (at f/5.8) + ST-10XME

Back to Top


Astrometric and Photometric Monitoring

Back to Top
