Objects Session Notes
Bullet Jupiter & moons
Bullet 136199 Eris - Dwarf Planet (2003 UB313)
Bullet IC 10 - Irregular Galaxy, Local Group
Bullet Photometric Monitoring - Variables
- U And, W And, SS Cyg, CY Lyr, DY Per
- GK Per, FG Sge, U Sge, V Sge

- RX And attempt (failed due to cloud)

Bullet Astrometric Monitoring - Nearby Stars
- 61 Cyg

- Night session (1.9 hr).
- Operated in Observatory under manual and semi-automated control. Later operated under automated control with remote monitoing
- Ambient Temperature  10 deg C
- CCD operation -20 degC (at 73 % average cooling).
- main objective of the session was to acquire images of key selected stars for ongoing photometric and astrometric analysis.

Jupiter & Moons

Jupiter with Moons
Annotated CCD Image (cropped)
0.12s sec exposure, 3x3 binning, V Filter
2009-09-18 00:48 h UT (#388052)
12" LX200R  (at f/5.7) + ST-10XME

Jupiter
CCD Image (cropped)
10 x 0.2s sec exposure (average combine), 1x1 binning, B Filter
2009-09-18 00:52  h UT (#388076-85)
Unsharp Masked
12" LX200R  (at f/5.7) + ST-10XME

Jupiter - detail
CCD Image (200 % size)
Image details as above

Back to Top


136199 Eris - Dwarf Planet ( 2003 UB313)

MPL 2003 UB313 attempt
(Cetus, altitude 23 deg, airmass 2.5)
With predicted magnitude of 18.7, Eris would have been too faint
to seen in this image (mag limit +18).
Glare from mag 9 star would also have been a problem
CCD Image (cropped to central area)
12 x 60 sec (average combine),  3x3 binning, C Filter
2009-09-18 00:08 h UT  (#388100-12)
12" LX200R  (at f/5.8) + ST-10XME

Back to Top


IC 10 - Irregular Galaxy, Local Group

IC 10 (Cassiopeia)
image affected by poor sky transparency


CCD Image (75% size, cropped)
4 x 90 min exposure (average combine), 3x3 binning, C Filter
2009-09-18 00:55h UT (388175-78)
12" LX200R  (at f/5.8) + ST-10XME



Previous Image of IC 10 (Cassiopeia)
taken with 8" LX200 & ST-7


CCD Image
6 x 2 min exposure (average combine), 2x2 binning, C Filter
2006-10-28 (#150113-15 & #150238-40)
