Objects Session Notes
Bullet C/2006 W3 (Christensen) - Comet
Bullet IC 10 - Spiral Galaxy (Local Group)
Bullet IC 1525 - Spiral Galaxy
Bullet P Cyg - Star
Bullet 22/P Kopff - Comet
Bullet M57 - Planetary Nebula
Bullet PGC 54 - Galaxy Group (Hickson 99)
Bullet AE And - variable star in M31
Bullet HY And - variable star in M31
Bullet AF And - variable star in M31
Bullet M110 - Elliptical Galaxy (Local Group)
Bullet M32 - Elliptical Galaxy (Local Group)
Bullet NGC 253 - Spiral Galaxy (Caldwell 65)
Bullet NGC 288 - Globular Cluster
Bullet NGC 247 - Spiral Galaxy (Caldwell 62)
Bullet NGC 246 - Planetary Nebula (Caldwell 56, Skull Nebula)
Bullet M74 - Spiral Galaxy
Bullet M77 - Spiral Galaxy
Bullet 136199 Eris - Dwarf Planet (2003 UB313)
Bullet Satellite or plane
Bullet NGC 404 - Elliptical Galaxy (Mirach's Ghost)
Bullet M1 - Supernova remnant (Crab Nebula)
Bullet CM Tau - Pulsar Star in M1
Bullet Photometric Monitoring - Variables
- RX And, U And, W And, Z And, TT Ari,  HR Aur,
- KR Au, R CrB, AM CVn, CI Cyg, SS Cyg, U Her,
- BL Lac, CY Lyr, CN Ori, FO Ori, FU Ori, NV Ori,
- DY Per, GK Per,  FG Sge, U Sge, V Sge,
- RR Tau, ER UMa, SU UMa
Bullet Photometric Monitoring - Nearby Stars
- Barnards Star, Gliese 412, Groombridge 1830, Groombridge 34, Ross 248 (HH And), EV Lac

- All night session (8.9 hr).
- Operated under automated control with remote monitoring.
- Ambient Temperature  10 deg C (minimum), rising to 11 deg.
- CCD operation -20 degC (at 58% average cooling).
- main objective of the session was to acquire images of key selected stars for ongoing photometric and astrometric analysis.
- secondary objective of the session became the acquisition of images from a number of deep sky targets including Caldwell 56, 62 & 65
- Notes from 2009-09-19

C/2006 W3 (Christensen) - Comet

C/2006 W3 (Christensen)
passing through star field in Aquila


CCD Image (cropped to central area)
3 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-09-19 20:48 h UT (#389071-73)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


IC 10 - Spiral Galaxy (Local Group)

IC 10 (Cassiopeia)
CCD Image (50% size, Linear Scale)
5 x 90 sec (average combine),  3x3 binning, C Filter
2009-09-19 21:05 h UT  (#389076-80)
12" LX200R  (at f/5.7) + ST-10XME

IC 10
False Colour CCD Image (50% size, Log Scale)
Image details as above

IC 10 - detail
False Colour CCD Image (Cropped to Central Area, Square Root Scale)
Image details as above
False Colour CCD Image (Cropped to Central Area, Log Scale)
Image details as above

Back to Top


IC 1525 - Spiral Galaxy

IC 1525 (Andromeda)
Annotated CCD Image (cropped, linear scale)
90 sec exposure,  3x3 binning, C Filter
2009-09-19 21:45 h UT  (#389138)
12" LX200R  (at f/5.7) + ST-10XME

IC 1525 - detail
CCD Image (200% size, cropped, linear scale)
Image details as above

Back to Top


P Cyg - LBV Star

P Cyg (Cygnus)
CCD Image
3 x 3 sec (average combine),  1x1 binning, C Filter
2009-09-19 22:11 h UT  (#389172-74)
12" LX200R  (at f/5.7) + ST-10XME
Earlier Spectra of P Cyg (2008)
CCD Spectra
3 x 10s
2008-05-08 01:16hUT
(#286177-79)
8" LX200 + ST-7e

Back to Top


22/P Kopff - Comet

22/P Kopff
passing through star field in Aquarius


CCD Image (cropped to central area)
3 x 20s sec exposure (average combine), 3x3 binning, C Filter
2009-09-19 22:34 h UT (#389210-12)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


M57 - Planetary Nebula

M57 (Lyra)
CCD Image
15 x 20 sec (average combine),  3x3 binning, C Filter
2009-09-19 22:40 h UT  (#389215-29)
Unsharp Masked
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


PGC 54 - Galaxy Group (Hickson 99)

Hickson 99 and surrounding starfield (Pegasus)
Image of Hickson 99 & surrounding starfield with numerous faint galaxies
Limiting magnitude +18.7
Bright star is HIP 121 (mag +6.8)
CCD Image (75% scale)
9 x 30 sec (average combine),  3x3 binning, C Filter
2009-09-19 23:46 h UT  (#389308-15)
12" LX200R  (at f/5.7) + ST-10XME
[Negative, 100% size]

 Hickson 99 - galaxy group
Distance ~ 460 million light years
CCD Image (cropped to central area)
Image details as above

Hickson 99 - detail
PGC 54 - Edge on Spiral Galaxy (catalog mag +14.8)
PGC 58 - Face on Spiral Galaxy (catalog mag +15.6)
PGC 63 - Elliptical Galaxy (catalog mag + 14.7)
PGC 60 (catalog mag +17.1), PGC 57 (catalog mag +17.6)
Annotated CCD Image
(200% size, cropped to central area)
Image details as above

Back to Top


AE And - Variable Star in M31

AE And (Andromeda)
GCVS catalog data :
Type: SDOR.  Range: +15.1 to +17.6
Alt. designation M31 V1005
Est. Mag in image below +16.3
Annotated CCD Image (cropped)
3 x 90 sec (average combine),  2x2 binning, C Filter
2009-09-19 23:59 h UT  (#389333-35)
12" LX200R  (at f/5.7) + ST-10XME
AE And and HY And in M31
Satellite track caught in one of 3 frames
CCD Image (35% size, full frame)
Image details as above
[ 100% size ]

CCD Image (75% size, cropped)
Image details as above

Back to Top


HY And - Variable Star in M31

HY And (Andromeda)
GCVS catalog data :
Type: UV.  Range: +18.2 to +20
Alt. designation M31 V0830
Est. Mag in image below +17.5
Annotated CCD Image (cropped)
3 x 90 sec (average combine),  2x2 binning, C Filter
2009-09-19 23:59 h UT  (#389333-35)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


AF And - Variable Star in M31

AF And (M31, Andromeda)
Annotated CCD Image (Linear Scale, Cropped)
3 x 90 sec (average combine),  2x2 binning, C Filter
2009-09-20 00:08 h UT  (#389338-40)
12" LX200R  (at f/5.7) + ST-10XME
M31 - part  (Andromeda)
centered on AF And
CCD Image (35% size, Full Frame)
3 x 90 sec (average combine),  2x2 binning, C Filter
2009-09-20 00:08 h UT  (#389338-40)
Log Scale,
12" LX200R  (at f/5.7) + ST-10XME
M31 - detail
False colour CCD Image (35% size, Full Frame)
Log Scale - Inverse Spectrum

Image details as above

Back to Top


M110 - Elliptical Galaxy (Local Group)

M110 (Andromeda)
Elliptical Galaxy
Irregular dark dust clouds noted near nucleus
CCD Image (Linear Scale, Cropped)
5 x 60 sec (average combine),  3x3 binning, C Filter
2009-09-20 00:14 h UT  (#389343-47)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


M32 - Elliptical Galaxy (Local Group)

M32 (Andromeda)
Elliptical Galaxy
almost devoid of features apart from central condensation
CCD Image (Linear Scale, 50% size)
5 x 60 sec (average combine),  3x3 binning, C Filter
2009-09-20 00:23 h UT  (#389351-55)
12" LX200R  (at f/5.7) + ST-10XME

M32 - detail
False Colour CCD Image (Log Scale, 50% size)
Image details as above

Back to Top


NGC 253 - Spiral Galaxy (Caldwell 65)

NGC 253 / Caldwell 65 / Herschel I-5 (Sculptor)
Alias: UGCA 13
Declination -25 deg. Taken whilst at altitude of 7 deg (airmass 7.6)
Also known at the Silver Coin Galaxy
Annotated CCD Image (Linear scale, 50% size)
17 x 60 sec exposure,  3x3 binning, C Filter
2009-09-20 21:45 h UT  (#389358-74)
12" LX200R  (at f/5.7) + ST-10XME

NGC 253 - detail
CCD Image (200% size, cropped, linear scale)
Image details as above

Back to Top


NGC 288 - Globular Cluster

NGC 288 / Herschel VI-20 (Sculptor)
Declination -26 deg. Taken whilst at altitude of 6 deg
CCD Image (Linear scale, 75% size, cropped)
8 x 30 sec exposure,  3x3 binning, C Filter
2009-09-20 00:51 h UT  (#389377-81, 38900-02)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


NGC 247 - Spiral Galaxy (Caldwell 62)

NGC 247 / Caldwell 62 / Herschel V-20 (Cetus))
Alias : UGCA 11
Annotated CCD Image (Linear scale, 50% size)
10 x 60 sec exposure,  3x3 binning, C Filter
2009-09-20 01:31 h UT  (#389410-19)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


NGC 246 - Planetary Nebula (Caldwell 56) "Skull Nebula"

NGC 246 / Caldwell 56 / Herschel V-25 (Cetus)
Annotated CCD Image (Linear scale, cropped)
10 x 60 sec exposure,  3x3 binning, C Filter
2009-09-20 01:46 h UT  (#389421-30)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


M74 - Spiral Galaxy

M74 (Pisces)
CCD Image (Linear Scale, 50% size)
7 x 60 sec (average median combine),  3x3 binning, C Filter
2009-09-20 01:59 h UT  (#389434-40)
12" LX200R  (at f/5.7) + ST-10XME

M74 - face on spiral galaxy
CCD Image (Linear Scale, cropped)
Image details as above

M74 - detail
CCD Image (Square Root Scale, cropped)
Image details as above

False Colour CCD Image (Square Root Scale, cropped)
Inverse Spectrum
Image details as above

Back to Top


M77 - Spiral Galaxy

M77 (Cetus)
CCD Image (Linear Scale, 50% size)
10 x 60 sec (average combine),  3x3 binning, C Filter
2009-09-20 02:10 h UT  (#389443-52)
12" LX200R  (at f/5.7) + ST-10XME

M77 - face on spiral galaxy
with diffuse outer arms
CCD Image (Square root scaling, cropped)
Image details as above

M77 - inner arms detail
CCD Image (Log Scale, 200% size, cropped)
Unsharp masked
Image details as above

M77 - outer arms detail
False Colour CCD Image (Square Root Scale, cropped)
Inverse Spectrum
Image details as above

Back to Top


136199 Eris - Dwarf Planet (2003 UB313)

Dwarf Planet (136199) Eris
Observation of Eris on 2009-09-20, lying in starfield in Cetus

Faint object marked by cross-hairs lies at the forecast position of Eris on 2009-09-20
has approximately the correct magnitude (+18.3 measured vs. +18.7 predicted)
and is not present on a DSS Reference Image, or on image taken 18 days later.

Eris is the largest known object in the Kuiper Belt with estimated diameter of 2,500 km
(it was previously known at 2003 UB313)
The bright star in the image is HIP 7802 (mag  +8.8)
Annotated CCD Image (cropped)
18 x 60 sec (average median combine),  3x3 binning, C Filter
2009-09-20 00:08 h UT  (#389461-80)
12" LX200R  (at f/5.7) + ST-10XME

Negative CCD Image (cropped)
Image details as above

  136199 Eris - higher contrast image (sum combined)
Negative CCD Image (cropped)
18 x 60 sec (sum combine),  3x3 binning, C Filter
2009-09-20 00:08 h UT  (#389461-80)
12" LX200R  (at f/5.7) + ST-10XME


DSS Reference Image
Reference image for same area doesn't show any object
at the precise location of suspect dwarf planet Eris.
There are two nearby very faint objects but these are
sufficiently far away and are just about recognised in my
images on 2009-09-20. (see side by side comparison below)
[ http://archive.eso.org/dss/dss ]
(DSS-2-Red image / object HIP 7802)
DSS-2-Red Reference Image  (Negative)

136199 Eris - Image Detail (2009-09-20) DSS Reference Image
Image Image
CCD Image
(237% size, Negative, Cropped)
18 x 60 sec (sum combine),
3x3 binning, C Filter
2009-09-20 00:08 h UT  (#389461-80)
12" LX200R  (at f/5.7) + ST-10XME
Reference Image
(Negative, Cropped)
DSS-2-Red Survey
[ http://archive.eso.org/dss/dss ]


136199 Eris - Image Detail (2009-09-20) Later Image of same area (2009-10-08)
Image Image
CCD Image
(237% size, Negative, Cropped)
18 x 60 sec (sum combine),
3x3 binning, C Filter
2009-09-20 00:08 h UT  (#389461-80)
12" LX200R  (at f/5.7) + ST-10XME
CCD Image
(237% size, Negative, Cropped)
30 x 60 sec (average combine),
3x3 binning, C Filter
2009-10-08 00:11 h UT  (#392459-88)
12" LX200R  (at f/5.7) + ST-10XME



MPL 2003 UB313 earlier observation attempt
taken 2 nights before (2009-09-18)
Note : absence of any object the position of the later suspected object.
Expected position of Eris on 2009-09-18 is indicated by the black circle.

With predicted magnitude of 18.7, Eris is probably too faint
to seen in this image (mag limit +18), and in any case would also
almost certainly be lost in the glare from the adjacent mag +8.8 star.
Note : the absence of any star object at the position of suspected object
two days later.  However this is not definitive evidence since the magnitude limit of
the image is not quite sufficiently deep. It can be seen that there
are a number of other objects (star/faint galaxies) which can be seen in
the  2009-09-20 image but not in the earlier 2009-09-18 image.
Annotated CCD Image (cropped to central area)
12 x 60 sec (average combine),  3x3 binning, C Filter
2009-09-18 00:08 h UT  (#388100-12)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


Satellite or plane

Spinning/Flaring Satellite or Plane with Flashing Light passing across starfield in Cetus
CCD Image (Linear Scale)
2 x 60 sec (sum combine),  3x3 binning, C Filter
2009-09-20 02:40 h UT  (#389472-73)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


NGC 404 - Elliptical Galaxy (Mirach's Ghost)

NGC 404 / Herschel II-224 (Andromeda)
Common Name : Lost Pearl Galaxy, Mirach's Ghost

Spheroid Galaxy close to Mirach (mag +2)
It lies around 10.3 million light years away, just outside the Local Group
Annotated CCD Image (Linear Scale, cropped)
7 x 20 sec (average combine),  3x3 binning, C Filter
2009-09-20 03:00 h UT  (#389493-99)
12" LX200R  (at f/5.7) + ST-10XME

NGC 404 - detail
black strip is blooming spike from Mirach.
Negative CCD Image (200% size, cropped)
Image details as above

Back to Top


M1 - Supernova remnant (Crab Nebula)

M1 (Taurus)
CCD Image (Linear Scale, 50% size)
5 x 60 sec (average combine),  3x3 binning, C Filter
2009-09-20 03:45 h UT  (#389568-72)
12" LX200R  (at f/5.7) + ST-10XME

CCD Image (Linear Scale, cropped)
Image details as above

M1 - detail
CCD Image (Linear Scale, 100% size, cropped)
20 x 30 sec (average combine),  1x1 binning, C Filter
2009-09-20 03:51 h UT  (#389584-61)
12" LX200R  (at f/5.7) + ST-10XME
False Colour CCD Image (100% size, cropped)
Image details as above

Back to Top


CM Tau - Pulsar Star in M1

M1 with CM Tau Pulsar Star at centre (Taurus)
CCD Image (Linear Scale, 100% size, cropped)
20 x 30 sec (average combine),  1x1 binning, C Filter
2009-09-20 03:51 h UT  (#389584-61)
12" LX200R  (at f/5.7) + ST-10XME
CM Tau - pulsar star at centre of M1
CCD Image (Linear Scale, cropped)
image details as above
CM Tau - single frame taken from dataset of 20 best frames
CCD Image (Linear Scale, cropped)
30 sec, 1x1 binning, C Filter
2009-09-20 03:51 h UT  (#389597)
12" LX200R  (at f/5.7) + ST-10XME

CM Tau - 35 frames
(including both good & bad frames)
CM Tau - 35 frames
(best frames only)
Image Image
CCD Image Animation (35 frames)
30 sec frames, 1x1 binning, C Filter
2009-09-20 03:51 h UT  (#389584-618)
CCD Image Animation (20 frames)
30 sec frames, 1x1 binning, C Filter
2009-09-20 03:51 h UT  (#389584-618)

CM Tau - Average of 7 frames
CCD Image (Linear Scale, cropped)
7 x 30 sec (average combine), 1x1 binning, C Filter
2009-09-20 03:51 h UT  (#389584-98)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


This Web Page: CCD Images - Session 389  (2009-09-19)
Last Updated : 2023-01-24
Site Owner : David Richards
Home Page : David's Astronomy Web Site
