Objects Session Notes
Bullet NGC 7492 - Globular Cluster
Bullet Hickson 93 - Galaxy Group (NGC 7549 et al)
Bullet UGC 12613 - Irregular Galaxy (Pegasus Dwarf, Local Group)
Bullet NGC 7814 - Spiral Galaxy (Caldwell 43)
Bullet NGC 1491 - Nebula
Bullet PGC 69457 - Galaxy with Gravitational Lensed Quasar (Einstein's Cross)
Bullet NGC 7331 - Spiral Galaxy (Deer Lick Group, Caldwell 30)
Bullet Photometric Monitoring - Variables
- RX And, U And, W And, Z And, T Cr, S Cyg, SS Cyg, BL Lac, CY Lyr, GK Per, FG Sge, U Sge, V Sge
Bullet Astrometric Monitoring - Nearby Stars
- Ross 248 (HH And), Barnards Star 61 Cyg, Groombridge 34

- Evening session (6.2 hr). Moderate conditions cold
- Session operated under semi-automated control with remote monitoring
- Ambient Temperature:  Unstable: Initial 4 degC falling to 0.0 degC then climbed to f2.5 degC, falling to 0.5 degC, then climbing 4.5 deg before end of session
- CCD operation -25 degC (at 62% average cooling).
- main objective of the session was to acquire images of key selected stars for ongoing photometric and astrometric analysis.
- opportunity taken to acquire images of a number of deep sky objects
-
- Notes from 2009-12-04 (Polar Alignment adjustment)

NGC 7492 - Globular Cluster

NGC 7492 (Aquarius)

CCD Image (cropped)
10 x 30 sec exposure (average combine), 3x3 binning, C Filter
2009-12-04 18:43 h UT  (#402103-07 & 402221-25)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


Hickson 93 - Galaxy Group (NGC 7549 et al)

Hickson 93 / NGC 7549 & adjacent galaxies (Pegasus)

Annotated CCD Image (cropped)
2 x 60 sec exposure (average combine), 3x3 binning, C Filter
2009-12-04 20;14 h UT  (#402240-43)
12" LX200R  (at f/5.7) + ST-10XME
[larger image, 75% size]



Hickson 93 - detail

Negative CCD Image (cropped)
Image details as above



NGC 7549 - detail

CCD Image (200% size, cropped)
Image details as above

Back to Top


UGC 12613 - Irregular Galaxy (Pegasus Dwarf, Local Group)

UGC 12613 (Pegasus)
Irregular galaxy 3.0 million light years distance

CCD Image (cropped)
6 x 45 sec exposure (average combine), 3x3 binning, C Filter
2009-12-04 20:25 h UT  (#402248-57)
12" LX200R  (at f/5.7) + ST-10XME

Back to Top


NGC 7814 - Spiral Galaxy (Caldwell 43)

NGC 7814 (Andromeda)
Edge on Spiral Galaxy, Dust Lane Prominant
CCD Image (Linear Scale, 50% size)
 4 x  60s exposure (average combine), 3x3 binning, C Filter
2009-12-04 20:25 h UT  (#402260-64)
12" LX200R  (at f/5.7) + ST-10XME

NGC 7814 - detail
CCD Image (Linear Scale, 100% size, cropped)
Image details as above

CCD Image (Square root scaling, 100% size, cropped)
Image details as above

NGC 7814 - earlier image (2004)
Other galaxies visible are
PGC 259 (catalog mag 15.3), PGC 1500064 (catalog mag 17.6)
plus several other suspected faint 'uncatalogued' galaxies
Annotated CCD Image
5x60s exposure (average combine), C Filter
2004-09-07  21:52 h UT (#71051-55)
8" LX200 Classic + ST-7E

Back to Top


NGC 1491 - Nebula

NGC 1491 (Perseus)

CCD Image
3 x 180s exposure (average combine), 3x3 binning, C Filter
2009-12-04 21:45 h UT  (#402289-91)
12" LX200R  (at f/5.7) + ST-10XME

CCD Image  (Square root scaling, Smoothed (blur), cropped)
Image details as above


NGC 1491 - detail

CCD Image (Linear Scale, 200% size, cropped)
Image details as above

NGC 1491 - earlier image (2006)

CCD Image
3 x 180s exposure (average combine), 2x2 binning, C Filter
2006-12-15 23:46h UT (#163226-28)
8" LX200 Classic + ST-7E

Back to Top


PGC 69457 - Galaxy with Gravitational  Lensed Quasar (Einstein's Cross)

PGC 69457 (Pegasus)
Star-field showing the lensing galaxy PGC 69457.
PGC 69457 is located at a distance of 400 million light years, whilst the quasar
sitting behind the foreground galaxy is located about 8 billion light years from Earth

Annotated CCD Image  (35% size, full frame)
3 x 180s exposure (average combine), 2x2 binning, C Filter
2009-12-04 21:45 h UT  (#402292-94)
12" LX200R  (at f/5.7) + ST-10XME

CCD Image  (100% size, cropped)
Image details as above


PGC 69457 - detail
Resolution (even at 1x1 binning) is not sufficient to show the
gravititional lensed detail of the background quasar (Einstein's Cross) through 12" scope.
However it is probable that some of the photons recorded by image are
from the distant quasar

CCD Image (Linear Scale, 400% size, cropped)
Image details as above

Back to Top


NGC 7331 - Spiral Galaxy (Deer Lick Group, Caldwell 30)

NGC 7331 (Pegasus)
CCD Image  (50% size, full frame)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2009-12-04 22:45 h UT  (#402303-05)
12" LX200R  (at f/5.7) + ST-10XME

NGC 7331 - detail
CCD Image (100% size, cropped)
Image details as above

NGC 7331 - earlier images (2003)
Other members of Deer Lick Group : NGC 7335 (catalog mag +14.5),
 NGC 7337 (catalog mag +15.2)
Annotated CCD Image
  5 x 20s (median), unfiltered
2003-10-17  22:08 to 22:10 h UT (#53125-29)
8" LX200 Classic + ST-7E

CCD image,
7 x 300 sec exposures (average combine)
2003-08-08  23:41 to 2003-08-09  00:25 h UT (#50026-35)
11.4 x 7.6 arc mins
8" LX200 Classic + ST-7E

Back to Top
