Objects Session Notes
Bullet NGC 1275 - Spiral Galaxy (Perseus A / Caldwell 24))
Bullet NGC 1268 - Spiral Galaxy
Bullet NGC 6946 - Spiral Galaxy (Caldwell 12)
Bullet NGC 7139 - Planetary Nebula
Bullet NGC 7354 - Planetary Nebula
Bullet NGC 7635 - "Bubble Nebula"  (Caldwell 11)
Bullet M52 - Open Cluster
Bullet NGC 2371 - Planetary Nebula (Double Bubble Nebula)
Bullet NGC 2797 - Spiral Galaxy & Supernovae 2010Z
Bullet NGC 3423 - Spiral Galaxy & Supernovae 2009ls
Bullet MACSJ0717 - Massive Galaxy Cluster
Bullet PGC 28913 - Local Group Galaxy (Sextans B)
Bullet NGC 3394 - Spiral Galaxy
Bullet NGC 3392 - Elliptical Galaxy & Supernovae 2010Y
Bullet PGC 34176 - Local Group Galaxy (Leo II / Leo B)
Bullet NGC 3299 - Spiral Galaxy
Bullet Saturn
Bullet Saturn Moons (including Enceladus & Hyperion)
Bullet NGC 3377 - Elliptical Galaxy
Bullet NGC 3412 - Spiral Galaxy
Bullet 81P/Wild - Comet
Bullet Photometric Monitoring - Variables
- RX And, U and, W And, Z And, HR Aur, KR Aur
- R CrB, AM CVn, RS CVn, CI Cyg, S Cyg
- SS Cyg, U Gem, AM Her, U Her, BL Lac,
- RZ LMi, CY Lyr, CN Ori, FO Ori, FU Ori,
- NV Ori, DY Per, GK Per, RR Tau


U And. GK Per attempts (failed due to sky/cloud)
Bullet Astrometric Monitoring - Nearby Stars
Ross 248 (HH And), Barnards Star,  61 Cyg, Gliese 412, Groombridge 34, Groombridge 1830, Lalande 21185

Spectra
81/P Wild, RS CVn, U Her, Regulus
- Long Evening/Night session  with 12" LX200 (11 hrs), clear & frosty
- Session operated in observatory for first hour and then under semi-automated control, with remote monitoring from indoors computer.
- Ambient Temperature:  -8 deg C  (minimum)
- CCD operation -30 degC (at 50% average cooling).
- main objectives of the session was to acquire images of selected project stars for ongoing photometric and astrometric analysis
- opportunity taken to acquire several deep sky targets
- Notes from 2010-02-20

NGC 1275 - Spiral Galaxy (Perseus A / Caldwell 24)

NGC 1275 and surrounding galaxies (Perseus)
Part of Perseus A Galaxy Cluster / Caldwell 24


CCD Image  (60% size)
5 x 90s exposure (median combine), 2x2 binning, C filter,
2010-02-20 19:07h UT (#414101-05)
12" LX200R  (at f/9.7) + ST-10XME

 NGC 1275
CCD Image (100% size, cropped)
Image details as above

 NGC 1275  & NGC 1268  - chain of galaxies
Composite CCD Image (50% size, cropped)
   Left : 5 x 90s exposure,  2x2 binning, C filter,  2010-02-20 19:07h UT (#414101-05)
Right : 5 x 90s exposure,  3x3 binning, C filter,  2010-02-20 19:20h UT (#414108-12)
12" LX200R  (at f/9.7) + ST-10XME
[larger size, 75%]

Back to Top


NGC 1268 -  Spiral Galaxy

NGC 1268 and surrounding galaxies (Perseus)
Lies just west of Perseus A Galaxy Cluster


CCD Image  (75% size)
5 x 90s exposure (median combine), 3x3 binning, C filter,
2010-02-20 19:20h UT (#414108-12)
12" LX200R  (at f/9.7) + ST-10XME

 NGC 1268 - detail
CCD Image (100% size, cropped)
Richardson-Lucy Sharpened
Image details as above

Back to Top


NGC 6946 - Spiral Galaxy (Caldwell 12)

NGC 6946 / Caldwell 12 (Cygnus)

Colour CCD Image (LRGB, 75% size)
3x3 binning, average combine
L :  8 x 90s  (C Filter),  B : 8 x 90s (B Filter),
G : 5 x 60s (V Filter), R : 6 x 60s (R Filter)
2010-02-20 19:44h UT (#414129-56)
12" LX200R  (at f/9.7) + ST-10XME
[larger image]

CCD Image (50% size)
8 x 90s (average combine), 3x3 binning, C Filter
2010-02-20 19:44h UT (#414129-36)
12" LX200R  (at f/9.7) + ST-10XME


Earlier image of NGC 6946 taken in 2007

CCD Image
4 x 120s exposure (average combine),
2x2 binning, C Filter, Linear brightness scaling
2007-09-11 00:26 hUT (#216017-20)
8" LX200 Classic + ST-7E

Earlier image of NGC 6946 taken in 2004
CCD Image
3 x 5min (average combine),  C Filter, Autoguided
2004-11-02 00:41 h UT (#74015-17)
8" LX200 Classic + ST-7E

Back to Top


NGC 7139 - Planetary Nebula

NGC 7139 (Cepheus)

CCD Image (cropped)
9 x 30s (average combine), 2x2 binning, C Filter
2010-02-20 20:27 h UT  (#414159-67)
12" LX200R  (at f/9.7) + ST-10XME



NGC 7139 - wider view

CCD Image (full frame, 35% size)
Image details as above

Back to Top


NGC 7354 - Planetary Nebula

NGC 7354 (Cepheus)

Annotated CCD Image (cropped)
5 x 30s (median combine), 2x2 binning, C Filter
2010-02-20 20:33 h UT  (#414169-73)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


NGC 7635 - Bright Nebula ("Bubble Nebula", Caldwell 11)

NGC 7635 / Caldwell 11 / Bubble Nebula (Cassiopeia)


False Colour CCD Image (75% size, square root scale)
6x60 sec, 3x3 binning, C Filter
2010-02-20  21:39hUT (#414252-58)
12" LX200R  (at f/9.7) + ST-10XME



NGC 7635 (Cassiopeia)


CCD Image (50% size, linear scale)
6x60 sec, 3x3 binning, C Filter
2010-02-20  21:39hUT (#414252-58)
12" LX200R  (at f/9.7) + ST-10XME
[larger image]



NGC 7635 - detail


CCD Image (50% size, log scale)
Image details as above



Earlier Image of NGC 7635 - 2007-12-06


CCD Image (linear scale)
5 x 180 sec (average combine), 2x2 binning, C Filter
2007-12-06 00:24hUT (#240064)
8" LX200 Classic + ST-7E

Back to Top


M52 - Open Cluster

M52 (Cassiopeia)

CCD Image (75% size)
3 x 30s (median combine), 3x3 binning, C Filter
2010-02-20 21:45 h UT  (#414261-63)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


NGC 2371 - Planetary Nebula (Double Bubble Nebula)

NGC 2371  (Gemini)
[ Herschel H316-2 ]
Distance 4400 light years
CCD Image (35% size)
4 x 60s (average combine), 2x2 binning, V Filter
2010-02-20 21:59 h UT  (#414277-81)
12" LX200R  (at f/9.7) + ST-10XME

NGC 2371  - detail
CCD Image (cropped, linear scale)
Image details as above

False Colour CCD Image (cropped, log scale)
Image details as above

Earlier Image of NGC 2371 - 2005-03-13
CCD Image
5 x 15 sec exposure (sum combine), C Filter
2005-03-13 21:27 h UT (#83122-26)
8" LX200 Classic + ST-7E

Back to Top


NGC 2797 - Spiral Galaxy & Supernovae 2010Z

NGC 2797 (Cancer)

CCD Image (cropped)
4 x 60s exposure (average combine), 3x3 binning, C Filter
2010-02-20 22:31hUT (#414328-31)
12" LX200R  (at f/9.7) + ST-10XME


NGC 2797 detail with SN 2010Z
SN 2010Z (Type II) was discovered 2010/02/03.34 by Lick Observatory Supernova Search; Simone Leonini
Magnitude at discovery +15.6
(Rochester Supernova site | Loss Discovery Image | Leonini Discovery Image | )

Image below (2010-02-20.94) was taken 17.5 days after discovery.
SN 2010Z is still just visible, marked by white cross hair

CCD Image (Linear Scale, 250% size, cropped)
Image details as above

Back to Top


NGC 3423 - Spiral Galaxy & Supernovae 2009ls

NGC 3423 with SN 2009ls (Sextans)
SN 2009ls (Type II) was discovered 2009/11/23.779 by Koichi Nishiyama and Fujio Kabashima
Magnitude at discovery +xx.x
(Rochester Supernova site | Discovery Image | Reference Image)

Image below (2010-02-20.95) was taken 89 days after discovery.
SN 2009ls is still easily visible - Estimated Magnitude +15.9 (C)

Annotated CCD Image (Linear Scale, cropped)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2010-02-20 22:50 hUT (#414350-54)
12" LX200R  (at f/9.7) + ST-10XME



NGC 3423 - earlier image  (2009-12-11.16)
Image below (2009-12-11.16) was taken 17.4 days after SN 2009ls discovery.
SN is marked by white cross-hairs. Estimated Magnitude +14.6 (C)

Annotated CCD Image (Linear Scale, 200% size, Cropped)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2009-12-11 03:52 hUT (#403383-87)
12" LX200R  (at f/5.7) + ST-10XME


NGC 3423 - earlier image (2009-11-27.18)
Image below (2009-11-27.18) was taken 3.4 days after SN 2009ls discovery.
SN is marked by white cross-hairs. Estimated Magnitude +14.3 (C)

CCD Image (Linear Scale, 200% size, Cropped)
3 x 60s exposure (average combine), 3x3 binning, C Filter
2009-11-27 04:18 hUT (#400089-112)

Back to Top


MACSJ0717 - Massive Galaxy Cluster

MACSJ0717 (Gemimi)
MACSJ0717.5+3745 (MACSJ0717 for short) is a 5.4 billion light years from Earth
and is one of the most complex galaxy clusters ever seen
http://chandra.harvard.edu/photo/2009/macs

A well publicised composite Chandra X-ray & HST Optical Image of MACSJ0717
shows the location of hot gas produced by multiple collisions from four separate galaxy clusters

The CCD Image below (total exposure 14 min) taken through 12" LX200 scope shows the
location of the massive galaxy cluster MACSJ0717 with at least
10 ?members of the galaxy cluster visible
(with area of Chandra/HST image marked by white square)

Annotated CCD Image (cropped)
7 x 120s exposure (average combine), 3x3 binning, C Filter
2010-02-20 23:02 hUT (#414357-63)
12" LX200R  (at f/9.7) + ST-10XME


HST Optical Image of MACSJ0717 reduced to same scale
(click on image to see larger image of this HST image)



Chandra + HST Composite Image
(click on image to see larger image on Chandra website)



Earlier Image of MACSJ0717 area - taken with 8" LX200 -  2010-01-19
Whilst foreground stars (mag +14.4 to mag 17.0) and one very dim foreground galaxy (mag +17.0)
are visible in the square below, no detail of the MACSJ0717 super cluster itself can be seen

Annotated CCD Image (normal scale, cropped)
7 x 120s exposure (average combine), 3x3 binning, C Filter
2010-01-19 00:16 hUT (#411472-78)
8" LX200 Classic (at f/10) + ST-10XME


Back to Top


PGC 28913 - Local Group Galaxy (Sextans B)

PGC 28913 / Sextans B (Sextans)
4.7 million light years distance

Annotated CCD Image (cropped)
4  x 120s exposure (average combine), 3x3 binning, C Filter
2010-02-20 23:17 hUT (#414367-70)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


NGC 3394 - Spiral Galaxy

NGC 3394 (Ursa Major)

CCD Image (cropped)
3  x 60s exposure (average combine), 3x3 binning, C Filter
2010-02-20 23:46 hUT (#414385-87)
12" LX200R  (at f/9.7) + ST-10XME



NGC 3394 - detail

Negative CCD Image (cropped)
Image details as above

Back to Top


NGC 3392 - Elliptical Galaxy & Supernovae 2010Y

NGC 3392 with SN2010Y (Ursa Major)

SN 2010Y (Type Ia) was discovered 2010/02/08.87 by Giancarlo Cortini
Magnitude at discovery +15.1??
(Rochester Supernova site | Discovery Image | Leonini Discovery Image | )

Image below (2010-02-20.99) was taken 12 days after discovery.
SN 2010Y is marked by white cross hair (est. mag +14.0)

CCD Image (cropped)
3  x 60s exposure (average combine), 3x3 binning, C Filter
2010-02-20 23:46 hUT (#414385-87)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


PGC 34176 - Local Group Galaxy (Leo II / Leo B)

PGC 34176  (Leo)
0.75 million light years distance

CCD Image (50% size)
5  x 120s exposure (average combine), 3x3 binning, C Filter
2010-02-21 00:05 hUT (#414417-21)
12" LX200R  (at f/9.7) + ST-10XME
[larger image, 75%]

Back to Top


NGC 3299 - Spiral Galaxy

NGC 3299  (Leo)
Member of M96 Galaxy Group

CCD Image (cropped)
4  x 120s exposure (average combine), 3x3 binning, C Filter
2010-02-21 00:28 hUT (#414440-43)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


Saturn

Saturn

CCD Image (cropped)
0.2 sec exposure (single frame), 1x1 binning, R Filter
Unsharp Masked
2010-02-21 00:41 h UT  (#414465)
12" LX200R  (at f/9.7) + ST-10XME



Earlier Image of Saturn (LX200 at f/5.8)

CCD Image (cropped)
0.2 sec exposure (single frame), 1x1 binning, C Filter
2009-03-10 00:08 h UT  (#356183)
12" LX200R  (at f/5.8) + ST-10XME

Back to Top


Saturn Moons (including Enceladus & Hyperion)

Saturn Moons (Titan, Tethys, Enceladus & Rhea)

CCD Image (cropped)
0.3 sec exposure (single frame), 2x2 binning, C Filter
2010-02-21 00:44 h UT  (#414480)
12" LX200R  (at f/9.7) + ST-10XME



Rhea & Hyperion

CCD Image (cropped)
6 x 2 sec exposure (average combine), 3x3 binning, C Filter
2010-02-21 01:27 h UT  (#414496-501)
12" LX200R  (at f/9.7) + ST-10XME



Hyperion & Iapetus

CCD Image (cropped, 75% size)
20 sec exposure (single frame), 2x2 binning, C Filter
2010-02-21 01:25 h UT  (#414495)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


NGC 3377 - Elliptical Galaxy

NGC 3377  (Leo)
Member of M96 Galaxy Group

CCD Image (cropped)
3  x 120s exposure (average combine), 3x3 binning, C Filter
2010-02-21 00:57 hUT (#414488-91)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


NGC 3412 - Spiral Galaxy

NGC 3412 / Herschel I-27 (Leo)
Member of M96 Galaxy Group

CCD Image (cropped)
5  x 120s exposure (average combine), 3x3 binning, C Filter
2010-02-21 01:37 hUT (#414504-08)
12" LX200R  (at f/9.7) + ST-10XME



NGC 3412 - detail

False Colour CCD Image (Square Root Scaling, cropped)
Inverse Spectrum Colour Bar

Image details as above

Back to Top


81P/Wild  - Comet

Comet 81P / Wild  (passing through starfield in Virgo)

CCD Image (50% size)
3  x 45s exposure (average combine), 3x3 binning, C Filter
2010-02-21 01:37 hUT (#414534-36)
12" LX200R  (at f/9.7) + ST-10XME
[larger image]



 Comet 81P / Wild - detail

CCD Image (cropped)
Image details as above



 Comet 81P / Wild - detail

CCD Image (square root scaled, cropped)
10  x 45s exposure (average combine), 3x3 binning, C Filter
Aligned on combine
2010-02-21 02:05 hUT (#414539-48)
12" LX200R  (at f/9.7) + ST-10XME



False Colour CCD Image (square root scaled, cropped)
Inverse Spectrum Colour Bar
Image details as above

Back to Top


Variable Stars

Back to Top


This Web Page: CCD Images - Session 414  (2010-02-20)
Last Updated : 2020-12-01
Site Owner : David Richards
Home Page : David's Astronomy Web Site
