Objects Session Notes
Bullet 103P/Hartley - Comet
Bullet Uranus - Planet
Bullet Neptune - Planet
Bullet Abell 43 - Planetary Nebula (PLN 36+17.1)
Bullet Pease 1 - Planetary Nebula in M15
Bullet NGC 1501 - Planetary Nebula (PLN 144+ 6.1)
Bullet Mayall II - Globular Cluster in M31
Bullet Sharpless 2-155 - Emission Nebula, "Cave Nebula"
Bullet Variable Stars
Bullet Photometric Monitoring - Variables
- RX  And, U And, W And, Z And, CI Cyg, SS Cyg, BL Lac, CY Lyr, TZ Lyr, RU Peg, DY Per, GK Per
Bullet Astrometric Monitoring - Nearby Stars
- Barnards Star, Ross 248 (HH And), Groombridge 34

- Late evening  session (3.8 hrs),
- Session operated under semi-automated control, with remote monitoring from indoors computer.
- Ambient Temperature:  5 deg C  (minimum)
- CCD operation -20 degC (at 64% average cooling).
- main objectives of the session was to acquire images of selected project stars for ongoing photometric analysis.
-

103P/Hartley - Comet

Comet  103P/Hartley
passing through starfield in Andromeda

Annotated CCD Image (75% size, log scale)
CCD Image - average stack processed in CCDSoft - manually aligned on comet
20  x 30s exposure (average combine), 3x3 binning, C Filter
2010-09-10 23:03 hUT (#427003-22)
12" LX200R  (at f/9.7) + ST-10XME




CCD Image - average stack processed in AIP4WIN
Image details as above



Comet  103P/Hartley -  motion over 99 minute period

Animated CCD Image
2 frames each  3  x 30s exposure (average combine), 3x3 binning, C Filter , cropped
1) 2010-09-10 22:58 hUT (#427003-05)
2) 2010-09-10 00:37 hUT (#427145-47)
12" LX200R  (at f/9.7) + ST-10XME



Comet  103P/Hartley -  (2010-09-10)

Annotated CCD Image (cropped)
3  x 30s exposure (average combine), 3x3 binning, C Filter
2010-09-10 22:58 hUT (#427003-05)
12" LX200R  (at f/9.7) + ST-10XME



Comet  103P/Hartley - previous image (2010-08-26)

Annotated CCD Image (cropped)
4  x 30s exposure (average combine), 3x3 binning, C Filter
2010-08-26 21:34 hUT (#425016-20)
12" LX200R  (at f/9.7) + ST-10XME



Comet  103P/Hartley - previous image (2010-08-20)

Annotated CCD Image (cropped)
5  x 30s exposure (average combine), 3x3 binning, C Filter
2010-08-20 21:32 hUT (#423018-22)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


Uranus - Planet

Uranus
(Uranus sitting in starfield of faint stars in Pisces)

CCD Image (50% size)
3 x 5s exposure (average combine), 3x3 binning, C Filter
2010-09-10 23:49hUT (#427073-75)
12" LX200R  (at f/9.7) + ST-10XME


Uranus and moons

Annotated CCD Image (cropped)
6 x 3s exposure (average combine), 1x1 binning, C Filter
2010-09-10 23:56hUT (#427085-90)
12" LX200R  (at f/9.7) + ST-10XME


Uranus - spectra

CCD Image Spectra (rotated, cropped)
5 x 20s exposure (average combine), 1x1 binning, Star Analyser 100 Filter
2010-09-10 23:52hUT (#427076-81)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


Neptune - Planet

Neptune
(Neptune sitting in starfield in Aquarius)

CCD Image (50% size)
3 x 5s exposure (average combine), 3x3 binning, C Filter
2010-09-10 23:59hUT (#427094-96)
12" LX200R  (at f/9.7) + ST-10XME


Neptune and Triton (largest moon)

Annotated CCD Image (cropped)
6 x 3s exposure (average combine), 1x1 binning, C Filter
2010-09-11 00:04hUT (#427102-04)
12" LX200R  (at f/9.7) + ST-10XME


Uranus - spectra

CCD Image Spectra (rotated, cropped)
5 x 20s exposure (average combine), 1x1 binning, Star Analyser 100 Filter
2010-09-10 23:52hUT (#427076-81)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


Abell 43 - Planetary Nebula (PLN 36+17.1)

Abell 43 / PLN 36+17.1 (Ophiuchus)

CCD Image (Linear Brightness Scale, cropped)
3 x 90s exposure (average combine), 3x3 binning, C Filter
2010-09-10 23:33hUT (#427052-56)
12" LX200R  (at f/9.7) + ST-10XME


Abell 43 - detail

Negative CCD Image (cropped)
Image details as above

Back to Top


Pease 1 - Planetary Nebula in M15

Pease I (Pegasus)
Pease I - a planetary nebula in the globular cluster M15 - is the
small 'red' object whose position is indicated by the white cross-hairs
This false colour image uses Ha filter frame for red,
and V filter frame for blue and green.
The Pl. Neb. is highlighted due to its high excess of light at Ha wavelengths,
and appears 'red' compared to normal stars which appear whitish in this image.

False Colour CCD Image (cropped)
Blue & Green : 3 x 45s exposure (average combine), 2x2 binning, V Filter
Red : 6 x 60s exposure (average combine), 2x2 binning, Ha Filter
2010-09-11 00:53hUT (#427158-66)
12" LX200R  (at f/9.7) + ST-10XME
[wider view]


M15 with Pease I - wider view

False Colour CCD Image
Image details as above

Back to Top


NGC 1501 - Planetary Nebula (PLN 144+ 6.1)

NGC 1501 (Camelopardalis)
Alias: Herschel IV-53 / PLN 144+ 6.1
 [ Hidden Treasures ]

CCD Image (Linear Brightness Scale, cropped)
6 x 30s exposure (average combine), 3x3 binning, C Filter
2010-09-11 01:03hUT (#427169-75)
12" LX200R  (at f/9.7) + ST-10XME


NGC 1501  - detail (spectra)

CCD Image Spectra (rotated, cropped)
6 x 30s exposure (average combine), 3x3 binning, S Filter
2010-09-11 01:18hUT (#427191-96)
12" LX200R  (at f/9.7) + ST-10XME



NGC 1501  - detail at 1x1 binning
sky conditions deteriorating ?

CCD Image Spectra (rotated, cropped)
3 x 90s exposure (average combine), 1x1 binning, S Filter
2010-09-11 01:24hUT (#427197-99)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


Mayall II - Globular Cluster in M31

Mayall II  (Andromeda)

Annotated CCD Image (cropped)
4 x 10s exposure (average combine), 1x1 binning, C Filter
2010-09-11 01:09hUT (#427178-81)
12" LX200R  (at f/9.7) + ST-10XME


Mayall II  - Hubble Image

HST Hubble Image (from Wikipedia, rotated)


Mayall II  - earlier image
Globular Cluster indicated by white cross hairs

Annotated CCD Image (cropped)
2 x 60s exposure (average combine), 3x3 binning, C Filter
2010-08-30 22:28hUT (#426108-09)
12" LX200R  (at f/9.7) + ST-10XME


Mayall II  - surrounding star field

CCD Image
Image details as above

Back to Top


Sharpless 2-155 - Emission Nebula, "Cave Nebula"

Sharpless 2-155 / Caldwell 9 - part  (Cepheus)


CCD Image
3 x 90s exposure (average combine), 3x3 binning, R Filter
2010-09-11 01:33hUT (#427202-04)
12" LX200R  (at f/9.7) + ST-10XME



Sharpless 2-155 / Caldwell 9 - earlier image (2007-12-22)
new 2010-09-11 frame area outlined in white
old 2007-12-06 frame area outlined in grey


CCD Image Mosaic
60 sec, 2x2 binning, C Filter
2007-12-22 21:02hUT (#245673-84)
8" LX200 Classic + ST-7E

Sharpless 2-155 - earlier detail (2007-12-06)


CCD Image
3 x 180 sec (average combine), 2x2 binning, R Filter
2007-12-06 00:45hUT (#239142-44)
8" LX200 Classic + ST-7E

Back to Top


Variable Stars

Back to Top
