Images - Session 515 (2012-10-15)

Objects Session Notes
Bullet Abell 39 - Planetary Nebula (PLN 47+42.1)
Bullet Abell 70 - Planetary Nebula (PK 38-25.1)
Bullet Abell 82 - Planetary Nebula (PLN 114- 4.1)

Bullet Jones 1 - Planetary Nebula (PK 104-29.1)
Bullet M101 - Spiral Galaxy with Supernova 2011fe

Bullet NGC 1 - Spiral Galaxy
Bullet NGC 6058 - Planetary Nebula
Bullet NGC 7000 - Nebula ("North America Nebula")
Bullet Photometric Monitoring - Variables
- U And, W And, Z And, TT Ari, R CrB, CI Cyg, SS Cyg, U Her, BL Lac, DY Per, GK Per, FG Sge, U Sge, V Sge, WZ Sge

Bullet Astrometric Monitoring - Nearby Stars
- Barnard's Star, 61 Cyg, Groombridge 34, And, EV Lac, Teegardens Star
- Evening session (6.0 hrs duration).
Good conditions
- Session operated under semi-automated control, with remote monitoring from indoors computer.
Successful first use of Power-Line networking (no drops out for whole of session)
- Ambient Temperature: -3.0°C (minimum)
Dew/Frost requiring corrector plate to be cleared with hair dyer on 3-4 occasions.
- CCD operation -25°C (at 55% average cooling).
- main objectives of the session were to acquire images of selected project stars for ongoing photometric and astrometric analysis, and to image a number of planetary nebula
-

Abell 39 - Planetary Nebula (PLN 47+42.1)

Abell 39 / PLN 47+42.1 (Hercules)
CCD Image (slight smoothed, 50%, )
8 x 90s sec exposure (average combine), 3x3 binning, C Filter
2012-10-15 21:18 h UT (#515213-20)
12" LX200R  (at f/9.7) + ST-10XME
[ internet picture showing Abell 39 for reference, by Capella Observatory ]

Negative CCD Image (Gamma adjusted)
Image details as above

Abell 39 - detail
Annotated CCD Image (80% size, cropped)
Image details as above

Earlier attempt to imaging Abell 39 / PLN 47+42.1  (2012-10-10)
Planetary Nebula (expected extent shown by grey circle) is not visible
in this 20s image taken under poor quality skies
Central star is just visible
CCD Image (50% size)
20s sec exposure (single frame), 3x3 binning, C Filter
2012-10-10 21:09 h UT (#514035)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


Abell 70 - Planetary Nebula (PK 38-25.1)

Abell 70 / PK 38-25.1 (Aquila)
CCD Image (cropped)
6 x 90s sec exposure (average combine), 3x3 binning, C Filter
2012-10-15 22:26 h UT (#515281-89)
12" LX200R  (at f/9.7) + ST-10XME

Abell 70 - detail
Negative CCD Image (cropped, gamma adjusted)
Image details as above

Back to Top


Abell 82 - Planetary Nebula (PLN 114- 4.1)

Abell 82 / PLN 114- 4.1 (Cassiopeia)
CCD Image (50%, )
3 x 45s sec exposure (average combine), 3x3 binning, C Filter
2012-10-15 21:18 h UT (#515119-21)
12" LX200R  (at f/9.7) + ST-10XME

Abell 82 - detail
Negative CCD Image (Gamma adjusted)
Image details as above

Back to Top


Jones 1 - Planetary Nebula (PK 104-29.1)

Jones 1 /  PK 104-29.1 (Pegasus)

CCD Image (60% size, cropped)
9  x 90s exposure (average combine), 3x3 binning, C Filter
2010-10-15 22:07 hUT (#515268-76)
12" LX200R  (at f/9.7) + ST-10XME



Jones 1 - earlier image ( 2010-08-20)

CCD Image (60% size, cropped)
6  x 90s exposure (average combine), 3x3 binning, C Filter
2010-08-20 22:35 hUT (#424026-34)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


M101 - Spiral Galaxy with Supernova 2011fe

M101 with SN 2011fe  (Ursa Major)
SN 2011fe (= PTF11kly) (Type Ia) was discovered
2011/08/24.00 by Palomar Transient Factory
Discovery Magnitude 17.2
( Rochester Supernova site | Discovery Image | TNS 2011fe )

SN 2011fe is reported as being the
nearest Type Ia supernova
seen in decades
M101 with SN 2011fe (fading slowly)
Image M101 with SN 2011fe (T+419d)
2012-10-15
419 days after SN discovery
SN Est. Mag
 only just visible, ~ 17.2

Annotated CCD Image
(58% size, cropped)
10 x 60 sec exposure (average combine),
3x3 binning, C Filter
2012-10-15 19:49 h UT  (#515124-33)
12" LX200R  (at f/9.7) + ST-10XME

M101 with SN 2011fe - Earlier Image (2011-10-03)
Image Earlier Image (T+41d)
2011-10-03.85
41 days after SN discovery
SN Est. Mag
+10.5

Annotated CCD Image
(58% size, cropped)
11 x 60 sec exposure (average combine),
3x3 binning, C Filter
2011-10-03 20:28 h UT  (#479003-14)
12" LX200R  (at f/9.7) + ST-10XME



Images of SN 2011fe (in M101) on Supernova 2011 Page >>

Back to Top


NGC 1 - Spiral Galaxy

NGC 1 & NGC 2 (Pegasus)
Annotated CCD Image (cropped)
5 x 90s sec exposure (average combine), 3x3 binning, C Filter
2012-10-15 22:41 h UT (#515292-96)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


NGC 6058 - Planetary Nebula

NGC 6058  (Hercules)
CCD Image (cropped)
3 x 45s sec exposure (average combine), 2x2 binning, C Filter
2012-10-15 19:40 h UT (#515094-96)
12" LX200R  (at f/9.7) + ST-10XME

NGC 6058 - earlier attempt (2012-10-10)
CCD Image (cropped)
3 x 20s sec exposure (average combine), 3x3 binning, C Filter
2012-10-10 21:32 h UT (#514026-28)
12" LX200R  (at f/9.7) + ST-10XME


Back to Top


NGC 7000 - Nebula ("North America Nebula" / Herschel V-37?)

Part of NGC 7000  (Cygnus)
Approx Colour


LRGB CCD Image  (50% size)
L : 5 x 90s exposure, Ha filter
R: 90s, R Filter / G: 90s, V Filter /  B : 90s, B filter
3x3 binning
2012-10-16 00:03 h UT (#515377-85)
12" LX200R  (at f/9.7) + ST-10XME



Part of NGC 7000  in Ha


H-alpha CCD Image (50% size)
5 x 90s exposure, 3x3 binning, Ha filter
2012-10-16 00:03 h UT (#515377-85)
12" LX200R  (at f/9.7) + ST-10XME




False Colour H-alpha CCD Image  (50% size)
Image details as above



Part of NGC 7000  - detail


H-alpha CCD Image (cropped)
Image details as above



A second part of NGC 7000


False Colour CCD Image (cropped)
R :: 3 x 90s, 3x3 binning, Ha filter
G & B:: 3 x 20s, 3x3 binning, C filter
2012-10-15 23:42 h UT (#515362-67)
12" LX200R  (at f/9.7) + ST-10XME



Earlier Image of Southern Part of NGC 7000  (2006-12-08)


CCD Image Mosaic-  4x4 frames (50% size)
180s exposure, 2x2 binning, C filter,  Linear scale. Slight Smoothing
2006-12-08 19:10h UT (#160077-92)
[larger image, 75% size]
