Images - Session 600 (2017-01-18)

Objects Session Notes
Bullet TS Photoline 80mm APO - First Light Image (M42)

Bullet Moon
Bullet Venus - Planet
Bullet C/2015 V2 (Johnson) - Comet

Bullet M1 - Supernova Remnant (Crab Nebula)
Bullet M3 - Globular Cluster
Bullet M31 - Spiral Galaxy (Andromeda Galaxy)
Bullet M33 - Spiral Galaxy (Pinwheel Galaxy)
Bullet M34 - Open Cluster
Bullet M35 - Open Cluster
Bullet M42 - Nebula (Great Nebula in Orion)
Bullet M44 - Open Cluster (Beehive Cluster)
Bullet M45 - Open Cluster with Nebulosity (Pleiades)
Bullet M51 - Spiral Galaxy (Whirlpool Galaxy)
Bullet M65 & M66 - Spiral Galaxies

Bullet NGC 1981 - Open Cluster
Bullet NGC 2024 - Nebula (Flame Nebula)
Bullet NGC 2392 - Planetary Nebula (Eskimo Nebula)

Bullet SharpCap Files (S600)

Bullet Photometric Monitoring - Variables
  - None

Bullet Astrometric Monitoring - Nearby Stars
  - None
- Evening/Night session (9 hrs duration).
Clear skies. Wind 0-5 mph.
- Session operated mainly from the observatory
- First Light for new TS Photoline 80mm f/6 APO refractor / imaging with ZWO ASI178MC

- Ambient Temperature:  -0.5d°C (minimum)
- CCD operation -25 and -30°C (at 65% average cooling).
- CMOS operation (ASI178): 9-17°C (non-cooled)
(16-17°C during Venus Imaging,  exp 2-5 ms
( 9-11°C during Deep Sky Objects, exp 10s)
(14-15°C during Lunar Imaging, exp 3-16 ms)

- Notes from 2017-01-18 >>
including more details on new 80mm APO refractor


 TS Photoline 80mm APO - First Light Image (M42)

 ZWO ASI178MC colour camera and Orion XY Guidestar Finder
connected to new TS Photoline 80mm f/6 APO refractor
(mounted on top of 12" LX200R)

First Light Image - M42
CMOS Colour Image (Full Area, 16% size)
5s exposure, 300 gain, 1x1 binning, RAW16
2017-01-18 18:57h UT (#18_57_41Z / 0001)
ZWO ASI178MC camera taken through TS 80mm f/6 APO

Back to Top


Moon

Moon


Image   CMOS Colour Image (17% size)
P10 stacking of best 10 frames from 100 frames

10 x 16ms exposure, 1x1 binning
Gain 0, Raw16, ROI 3096x2080 (cropped to 2205x1917)
2017-01-19 02:27h UT
(#02_27_00Z / AS P10 Conv)

ASI178MC + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames Acquired using SharpCap (SER file)
Processed using Autostakkert 2
[ 50% Size ImageFull Size Image ]

Image   CMOS Image (17% size)
P10 stacking of best 3 frames from 31 frames

3 x 16ms exposure, 1x1 binning
Gain 0, Raw16, ROI 3096x2080 (cropped)
2017-01-19 02:28h UT
(#02_28_06Z / AS P10 Conv)

ASI178MC + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames Acquired using SharpCap (SER file)
Processed using Autostakkert 2
[ 50% Size Image ]

Image   CMOS Colour Image (48% size)
P10 stacking of best 51 frames from 512 frames

51 x 3ms exposure, 1x1 binning
Gain 200, Raw16, ROI 800x600
2017-01-19 02:37h UT
(#02_37_38Z / AS P10 Conv)

ASI178MC + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames Acquired using SharpCap (SER file)
Processed using Autostakkert 2
[ Full Size Image ]

Image   CMOS Colour Image (48% size)
P10 stacking of best 20 frames from 204 frames

20 x 2.5ms exposure, 1x1 binning
Gain 200, Raw16, ROI 800x600
2017-01-19 02:31h UT
(#02_31_00Z / AS P10 Conv)

ASI178MC + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames Acquired using SharpCap (SER file)
Processed using Autostakkert 2
[ Full Size Image ]

Image   CMOS Colour Image (48% size)
P10 stacking of best 51 frames from 510 frames

51 x 3ms exposure, 1x1 binning
Gain 200, Raw16, ROI 800x600
2017-01-19 02:35h UT
(#02_35_38Z / AS P10 Conv)

ASI178MC + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames Acquired using SharpCap (SER file)
Processed using Autostakkert 2
[ Full Size Image ]

[ mp4 video of all 510 frames ,
shows poor seeing conditions ]

Image   CMOS Colour Image (48% size)
P10 stacking of best 20 frames from 205 frames

20 x 3ms exposure, 1x1 binning
Gain 200, Raw16, ROI 800x600
2017-01-19 02:33h UT
(#02_33_04Z / AS P10 Conv)

ASI178MC + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames Acquired using SharpCap (SER file)
Processed using Autostakkert 2
[ Full Size Image ]

Image   CMOS Colour Image (48% size)
P10 stacking of best 20 frames from 207 frames

20 x 2.5ms exposure, 1x1 binning
Gain 200, Raw16, ROI 800x600
2017-01-19 02:32h UT
(#02_31_50Z / AS P10 Conv)

ASI178MC + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames Acquired using SharpCap (SER file)
Processed using Autostakkert 2
[ Full Size Image ]





Back to Top


 Venus - Planet

Venus (passing through Aquarius)
Image    Image:

Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:

Software:

Other Formats:
Annotated CMOS Colour Image (16% size)

5 ms (0.005 sec)
1 x 5ms, 1x1 binning
Gain 0, Raw16, ROI 3096x2080 (Full)
2017-01-18 18:35h UT
(#18_35_05Z 0002). Non-Guided.

TS 80mm f/6 APO + ASI178MC (OSC)
Mounted on 12" LX200R
Frame acquired using SharpCap (PNG)

-

Venus (phase 47.7%)
Venus at 16deg altitude.
RGB Align used as part of stacking process to
 compensate for atmospheric dispersion (notes)

Image    Image:



Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:

Software:

CMOS Colour Image (100% size)
P20 Stacking, Best 62 frames from 311
With RGB Align

124 ms (0.12 sec)
62 x 2ms, 1x1 binning
Gain 0, Raw16, ROI 320 x 240 (Sub-Region)
2017-01-18 18:32h UT
(#18_32_24Z). Non-Guided.

TS 80mm f/6 APO + ASI178MC (OSC)
mounted on 12" LX200R
Frames acquired using SharpCap (SER)
Stacked using Autostakkert 2

Venus - detail
Image    Image:

Info:
CMOS Colour Image (200% size)

Image details as above


Back to Top


C/2015 V2 (Johnson) - Comet

C/2015 V2 (Johnson)
(passing through Bootes)
Sun distance 2.48 AU

Image   Image:


Exposure:
Details:
Image ID:

Date/Time:

Equipment:



Software:



Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 61 frames

10 min (61 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080
#01_56_24Z

2017-01-19 01:56h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Autoguiding using ST-10XME + 12" LX200R f/10

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Autoguiding using CCDSoft5

Larger Image (32% size)

C/2015 V2 (Johnson) - detail
Image   Image:

CMOS Colour Image (50% size, cropped)

Image details as above


Back to Top


M1 - Supernova Remnant (Crab Nebula)

M1 (Taurus)
Image   Image:

Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:

Software:

Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 73 frames
73 secs
73 x 1s, 1x1 binning
Gain 400, Raw16, ROI 3096x2080 (Full)
2017-01-18 21:54h UT
(#21_54_42Z). Non-Guided.

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames acquired using SharpCap
Processed using AIP4WIN
Larger Image (32% size)

M1 - closer view
Image   Image:

CMOS Colour Image (33% size, cropped)

Image details as above


M1 - detail
Image   Image:

CMOS Colour Image (75% size, cropped)

Image details as above

M1 - detail
Image   Image:

CMOS Colour Image (75% size, cropped)
Live Stacking of 73 frames
73 secs
73 x 1s, 1x1 binning
Gain 400, Raw16, ROI 3096x2080 (Full)
2017-01-18 21:54h UT
(#21_54_42Z). Non-Guided.

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames acquired using SharpCap
Processed using AIP4WIN

Larger Image (33% size)

M1 - detail
Image   Image:

Total Exposure:
Subs/Exposure

Date/Time:
Image Set:

Equipment:

Software:

CCD Image (100% size, cropped)

180 secs
8 x 20s, 3x3 binning, ROI Full

2017-01-18 22:09h UT
(#600082-99)

12" LX200R + ST-10XME

Frames acquired and processed
using CCDSoft



Back to Top


M3 - Globular Cluster

M3 (Canes Venatici)
Image   Image:


Exposure:
Details:
Image ID:

Date/Time:

Equipment:



Software:



Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 60 frames

10 min (60 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080
#01_40_56Z

2017-01-19 01:40h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Autoguiding using ST-10XME + 12" LX200R f/10

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Autoguiding using CCDSoft5

Larger Image (32% size)

M3 - detail
Image   Image:

CMOS Colour Image (50% size, cropped)

Image details as above


Back to Top


M31 - Spiral Galaxy (Andromeda Galaxy)

M31 (Andromeda)
Image   Image:

Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:


Software:


Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 182 frames
30 mins
182 x 10s, 1x1 binning
Gain 400, Raw16, ROI 3096x2080
2017-01-18 22:56h UT
(#22_56_43Z). Non-Guided.

TS 80mm f/6 APO + ASI178MC (OSC)
Mounted on 12" LX200R

Frames acquired using SharpCap (Live Stack)
Displayed using DeepSkyStacker

Larger Image (32% size)

M31 - detail (80mm APO + ASI178MC)
Image   Image:


Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:


Software:
CMOS Colour Image (54% size, cropped)
Live Stacking of 182 frames

30 mins
182 x 10s, 1x1 binning
Gain 400, Raw16, ROI 3096x2080
2017-01-18 22:56h UT
(#22_56_43Z). Non-Guided.

TS 80mm f/6 APO + ASI178MC (OSC)
Mounted on 12" LX200R

Frames acquired using SharpCap (Live Stack)
Processed using DeepSkyStacker

M31 - detail (12" LX200 + ST-10XME)
(recorded at the same time as the above image)

Image   Image:

Total Exposure:
Subs/Exposure

Date/Time:
Image Set:

Equipment:

Software:

CCD Image (70% size)

6.5 minutes
13 x 30s, 3x3 binning, ROI Full

2017-01-18 23:16h UT
(#600109-31). Non-Guided.

12" LX200R + ST-10XME

Frames acquired and processed
using CCDSoft.
Displayed using FV


Back to Top


M33 - Spiral Galaxy (Pinwheel Galaxy)

M33 (Triangulum)
Image   Image:

Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:

Software:

Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 182 frames
30 mins
182 x 10s, 1x1 binning
Gain 400, Raw16, ROI 3096x2080 (Full)
2017-01-18 20:09h UT
(#20_09_08Z). Non-Guided.

TS 80mm f/6 APO  + ASI178MC (OSC)
Mounted on 12" LX200R
Frames acquired using SharpCap
Processed using AIP4WIN
Larger Image (33% size)

M33 - detail
Image   Image:

CMOS Colour Image (23% size, cropped)

Image details as above

M33 - detail
Image   Image:

CMOS Colour Image (23% size, cropped)

Image details as above


Back to Top


M34 - Open Cluster

M34 (Perseus)
Image   Image:


Exposure:
Details:


Date/Time:

Equipment:



Software:



Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 72 frames

12 mins (72 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080
ID  #23_40_45Z). Guided

2017-01-18 23:41h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Autoguiding Using ST-10XME + 12" LX200 f/10

Frames acquired using SharpCap (Live Stack)
Displayed using DeepSkyStacker
Autoguiding using CCDSoft

Larger Image (32% size)

M34 - detail (12" LX200 + ST-10XME)
(recorded just before the above image)

Image   Image:

Total Exposure:
Subs/Exposure

Date/Time:
Image Set:

Equipment:

Software:

CCD Image (69% size)

4 seconds
2x 2s, 3x3 binning, ROI Full

2017-01-18 23:39h UT
(#600157-58)

12" LX200R + ST-10XME

Frames acquired and processed
using CCDSoft.
Displayed using FV


Back to Top


M35 - Open Cluster

M35 (Gemini)
Image   Image:


Exposure:
Details:


Date/Time:

Equipment:


Software:


Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 18 frames

3 mins (18 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080 (Full)
ID #22_43_46Z. Non-Guided

2017-01-18 22:43h UT

TS 80mm f/6 APO + ASI178MC (OSC)
Mounted on 12" LX200R

Frames acquired using SharpCap (Live Stack)
Displayed using DeepSkyStacker

Larger Image (32% size)


Back to Top


M42 - Nebula (Great Nebula in Orion)

M42 (Orion)
Image   Image:


Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:

Software:

Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 222 frames

222 secs (3.7 mins)
222 x 1s, 1x1 binning
Gain 300, Raw16, ROI 3096x2080 (Full)
2017-01-18 19:07h UT
(#19_07_02Z). Non-Guided.

TS 80mm f/6 APO + ASI178MC (OSC)
Mounted on 12" LX200R
Frames acquired using SharpCap
Processed using AIP4WIN
Larger Image (32% size)

M42 - closer view
Image   Image:

Details:

Other Formats:
CMOS Colour Image (33% size, cropped)

Image details a/a

Larger Image (67% size)

M42 - detail
Image   Image:

Details:
CMOS Colour Image (100% size, cropped)

Image details a/a

M42 - detail (12" LX200 + ST-10XME)
(recorded at the same time as the above image)

  Image:


Total Exposure:
Subs/Exposure

Date/Time:
Image Set:

Equipment:

Software:

CCD Image (70% size)
Linear Scale

36 seconds
18 x 2s, 3x3 binning, ROI Full

2017-01-18 19:08h UT
(#600008-27). Non-Guided.

12" LX200R + ST-10XME

Frames acquired and processed
using CCDSoft.
Displayed using CCDSoft

Image   Image:


Details:

Software:
CCD Image (70% size)
Log Scale

Image details a/a

Frames acquired and processed
using CCDSoft.
Displayed using FV


Back to Top


M44 - Open Cluster (Beehive Cluster)

M44 (Cancer)
northern frameset

Image   Image:


Exposure:
Details:
Date/Time:
Image Set:


Equipment:


Software:

CMOS Colour Image (16% size)
Live Stacking of 18 frames

3 min (18 x 10s)
1x1 binning, Gain 400, Raw16, ROI 3096x2080
2017-01-18 22:22h UT
(#22_22_16Z).   Non-Guided

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker


southern frameset
Image   Image:


Exposure:
Details:
Date/Time:
Image Set:

Equipment:


Software:

CMOS Colour Image (16% size)
Live Stacking of 18 frames

3 min (18 x 10s)
1x1 binning, Gain 400, Raw16, ROI 3096x2080
2017-01-18 22:28h UT
(#22_28_29Z)

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker

M44 - Mosaic (Manual/PaintShopPro)
(northern & southern framesets merged)

Image    Object:

Image:

Exposure:

Details:



Date/Time:

Equipment:


Software:



Notes:

Other Formats:
M44

Colour Mosaic (17% size, cropped)

3 min (18 x 10s)

Binning 1x1, Gain 400, Type Raw16
ROI 3096x2080 (x2)
ID #22_22_16Z (18), #22_28_29Z (18). Non-Guided.

2017-01-18 22:22 - 22:28h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R

Frames acquired using SharpCap (Live Stacking)
Processed using DeepSkyStacker
Assembled in PaintShopPro 5

Mosaic 1x2

Larger Image (35% size)
Smaller Image (13% size)

M44 - Mosaic (Automated/DeepSkyStacker)
(northern & southern framesets merged)

Image    Object:

Image:

Exposure:

Details:



Date/Time:

Equipment:


Software:



Notes:




Other Formats:
M44

Colour Mosaic (17% size, cropped)

3 min (18 x 10s)

Binning 1x1, Gain 400, Type Raw16
ROI 3096x2080 (x2)
ID  #22_22_16Z (18), #22_28_29Z (18). Non-Guided.

2017-01-18 22:22 - 22:28h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R

Frames acquired using SharpCap (Live Stacking)
Processed using DeepSkyStacker
Assembled using DeepSkyStacker

Two frames (each a Live Stacked Image of 18 sub-frames)
stacked (assembled) In DeepSkyStacker using
'Mosaic Mode' and 'Entropy Weighted Average)
Mosaic 1x2

Larger Image (35% size)



Back to Top


M45 - Open Cluster with Nebulosity (Pleiades)

M45 - Pleiades (Leo)
Image   Image:


Exposure:
Details:
Image ID:

Date/Time:

Equipment:



Software:



Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 60 frames

10 min (60 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080
#00_11_25Z

2017-01-19 00:19h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Autoguiding using ST-10XME + 12" LX200R f/10

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Autoguiding using CCDSoft

Larger Image (32% size)

Image    Image:

Exposure:
Details:
Image ID:


Date/Time:

Equipment:



Software:



Other Formats:

CMOS Colour Image (16% size)
Live Stacking of 66 frames

11 min (66 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080
#00_32_52Z

2017-01-19 00:32h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Autoguiding using ST-10XME + 12" LX200R f/10

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Autoguiding using CCDSoft5

Larger Image (32% size)

Image    Image:


Exposure:
Details:
Image ID:

Date/Time:

Equipment:



Software:




Other Formats:

CMOS Colour Image (16% size)
Live Stacking of 60 frames

10 min (60 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080
#00_46_29Z

2017-01-19 00:46h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Autoguiding using ST-10XME + 12" LX200R f/10

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Assembled in PaintShopPro 5
Autoguiding using CCDSoft5

Larger Image (32% size)

 M45 - Composite of 3 above Images
Image    Image:


Exposure:
Details:
Image ID:

Date/Time:

Equipment:



Software:



Other Formats:

CMOS Colour Image Mosaic (9% size)
Live Stacking of 60 frames

10 min (60 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080 (x3)
#00_11_25Z , #00_32_52Z and #00_46_29Z

2017-01-19 00:19 to 00:46h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Autoguiding using ST-10XME + 12" LX200R f/10

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Autoguiding using CCDSoft5

Larger Image (32% size)


Back to Top


M51 - Spiral Galaxy (Whirlpool Galaxy)

M51 (Canes Venatici)
Image   Image:


Exposure:
Details:
Image ID:

Date/Time:

Equipment:



Software:



Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 180 frames

30 min (180 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080
#01_02_06Z

2017-01-19 01:02h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Autoguiding using ST-10XME + 12" LX200R f/10

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Autoguiding using CCDSoft5

Larger Image (32% size)

M51 - detail
Image   Image:

CMOS Colour Image (50% size, cropped)

Image details as above


Back to Top


M65 & M66 - Spiral Galaxies

M65 & M66 (Leo)
Image   Image:


Exposure:
Details:
Image ID:

Date/Time:

Equipment:



Software:



Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 60 frames

10 min (60 x 10s)
Binning 1x1, Gain 400, Raw16, ROI 3096x2080
#02_11_11Z. Guided

2017-01-19 02:11h UT

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Guiding using ST-10XME + 12" LX200R f/10

Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Autoguiding using CCDSoft5

Larger Image (32% size)

M65 - detail
Image   Image:

CMOS Colour Image (50% size, cropped)

Image details as above

M66 - detail
Image   Image:

CMOS Colour Image (50% size, cropped)

Image details as above


Back to Top


NGC 1981 - Open Cluster

NGC 1981 (Orion)
Image   Image:

Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:

Software:


Other Formats:
CMOS Colour Image (16% size)
P50 Stacking, Best 8 frames from 15
4 mins
8 x 30s, 1x1 binning
Gain 300, Raw16, ROI 3096x2080
2017-01-18 19:34h UT
(#19_34_54Z). Non-Guided.

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames acquired using SharpCap (FITS)
Stacked using DeepSkyStacker
Processed using AIP4WIN
Larger Image (32% size)


Back to Top


NGC 2024 - Nebula (Flame Nebula)

NGC 2024 / IC 434 / Herschel 28-5 (Orion)
Hidden Treasures H34
[ Hidden Treasures ]

Bright star is  Alnitak (mag +1.7)

Image   Image:

Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:

Software:

Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 101 frames
17 min
101 x 10s, 1x1 binning
Gain 400, Raw16, ROI 3096x2080
2017-01-18 21:10h UT
(#21_10_39Z). Non-Guided.

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Larger Image (32% size)

Image   Image:
CMOS Colour Image (16% size)
Live Stacking of 101 frames

First Processing attempt using AIP4WIN

NGC 2024 - detail (12" LX200 + ST-10XME)
(recorded at the same time as the above images)

Image   Image:


Total Exposure:
Subs/Exposure

Date/Time:
Image Set:

Equipment:

Software:

CCD Image (70% size)
Linear Scale

2 minutes
6 x 20s, 3x3 binning, ROI Full

2017-01-18 21:26h UT
(#600068-78). Non-Guided.

12" LX200R + ST-10XME

Frames acquired and processed
using CCDSoft.
Displayed using CCDSoft


Back to Top


NGC 2392 - Planetary Nebula (Eskimo Nebula)

NGC 2392 (Gemini)
Image   Image:

Total Exposure:
Subs/Exposure
Details:
Date/Time:
Image Set:

Equipment:

Software:

Other Formats:
CMOS Colour Image (16% size)
Live Stacking of 21 frames
3.5 min
21 x 10s, 1x1 binning
Gain 400, Raw16, ROI 3096x2080
2017-01-18 22:34h UT
(#22_34_52Z). Non-Guided.

ASI178MC (OSC) + TS 80mm f/6 APO
Mounted on 12" LX200R
Frames acquired using SharpCap (Stack FIT)
Processed using DeepSkyStacker
Larger Image (32% size)

NGC 2392 - detail
Image   Image:

CMOS Colour Image (50% size, cropped)

Image details a/a


Back to Top


SharpCap Files (S600)

SharpCap Session - 2017-01-18 S00600

ObjectFolderCapture
Area
Colour
Space
BinExpGainGammaTemp.
(C)
Subtract
Dark
Output
Format
Num
Frames
Stacked
Frames
Total
Exp
Num
.fits
Raw
.fits
Num
.png
Proc
.png
Num
.ser
Venus18_32_24Z320x240RGB2411.5ms05016.8SER31100001
  " 18_35_05Z3096x2080RGB2415.1ms05017.3PNG110100
M4218_47_19Z3096x2080RGB24110s300509.8PNG200200
  " 18_48_29Z3096x2080RGB2411s300509.7SER77+771.3m10010
  " 18_55_08Z3096x2080RGB2415s300509.3PNG10001000
  " 18_57_41Z3096x2080RAW1615s300509.2FITS15150000
  " 19_07_02Z3096x2080RAW1611s300509.1FITS222+2223.7m30020
  " 19_14_24Z3096x2080RAW16130s300509.3PNG220100
  " 19_14_39Z3096x2080RAW16130s300508.8FITS15150000
NGC 198119_34_28Z3096x2080RAW16130s300509.2PNG100100
  " 19_34_54Z3096x2080RAW16130s300509.2FITS16160000
B3319_54_40Z3096x2080RAW1611.52s4005010.5FITS436+43611m20010
M3320_09_08Z3096x2080RAW16110s4005010.0FITS215447.3m4215030
NGC 202420_54_31Z3096x208016110s10.1FITS13013000
  " 21_00_04Z3096x208016110s9.8FITS505000
  " 21_01_05Z3096x208016110s9.8FITS707000
  " 21_10_19Z3096x2080RAW16110s400509.3YesFITS110000
  " 21_10_39Z3096x2080RAW16110s400509.5YesFITS10910016.7m4109030
  " 21_31_15Z3096x2080RAW16110s400509.3YesFITS15150000
M121_52_10Z3096x208016110s10.7FITS202000
  " 21_52_11Z3096x2080RAW16110s4005010.7YesPNG100100
  " 21_54_21Z3096x2080RAW16110s4005010.5YesPNG100100
  " 21_54_42Z3096x2080RAW16110s400509.3YesFITS1468514.2m3146020
  " 23_59_25Z3096x2080RAW16110s400509.1YesFITS1049716.2m2104010
M4422_22_16Z (Nor..3096x2080RAW16110s4005010.6YesFITS23183m223130
  " 22_28_29Z (Sou..3096x2080RAW16110s4005010.6YesFITS19183m619020
NGC 239222_34_52Z3096x2080RAW16110s4005010.0YesFITS49213.5m249010
M3522_43_46Z3096x2080RAW16110s4005010.0YesFITS5861m258020
M3122_56_23Z3096x2080RAW16110s400509.0YesPNG200200
  " 22_56_43Z3096x2080RAW16110s400509.0YesPNG19818230.3m4198030
M3423_40_45Z3096x2080RAW16110s400509.2YesPNG867212m186010
M4500_19_25Z3096x2080RAW16110s400508.8YesFITS666010m166020
  " 00_32_52Z3096x2080RAW16110s400509.2YesFITS676611m167010
  " 00_46_29Z3096x2080RAW16110s400509.0YesFITS626010m162010
M5101_00_46Z3096x2080RAW16110s400509.0YesFITS110300
  " 01_02_06Z3096x2080RAW16110s400509.0YesFITS21118030m1211040
M301_40_56Z3096x2080RAW16110s400509.0YesFITS716010m171020
C2015 V2 (Johnson)01_56_24Z3096x2080RAW16110s400509.0YesFITS726110.2m172020
M6502_11_11Z3096x2080RAW16110s400508.5YesFITS636010m163010
Moon02_27_00Z3096x2080RGB24116ms05014.1SER10000001
  " 02_28_06Z3096x2080RAW16116ms05013.8FITS31310000
  " 02_31_00Z800x600RAW1612.5ms2005014.6SER20400001
  " 02_31_50Z800x600RAW1612.5ms2005014.7SER20700001
  " 02_33_04Z800x600RAW1613ms2005014.8SER20500001
  " 02_35_38Z800x600RAW1613ms2005014.5SER51000001
  " 02_37_16Z800x600RAW1613ms2005014.7SER51200001

Back to Top
