CCD Images - Session 702 (2019-09-30)

Objects Session Notes
Bullet IC 176 - Spiral Galaxy
Bullet IC 194 - Spiral Galaxy

Bullet M103 - Open Cluster

Bullet NGC 789 - Spiral Galaxy (LGG 43 Member)

Bullet Variable Stars (photometric monitoring)
  - None

- SY Cnc Attempt failed due to cloud

Bullet Nearby Stars (astrometric monitoring)
 - None



- Night session (5.9 hours)

Session operated in fully automated mode with  monitoring during the first half of the session

- Main aim of the session was to test out new features in AdvMain / AstroGuard and to check stability of Programs after change. Conditons were forecast to be marginal so there were no specific observing aims. Several targets failed due to Cloud and/or poor transparency.

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  Falling  to 3.5°C (min).
Outdoors 3°C (min)
(Dew heaters on automated)
- CCD Temperature:  -20°C  (69% av. power)
- Notes from 2019-09-30 >>



IC 176 - Spiral Galaxy

IC 176 (Cetus)
Flat Galaxy Atlas
CCD Image (50% size)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-01 00:23 UT (#702033-36)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

IC 176 - Detail
CCD Image (125% size, linear scale, cropped)
Image details as above


Back to Top


IC 194 - Spiral Galaxy

IC 194 (Pisces)
Flat Galaxy Atlas
CCD Image (50% size)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-01 00:07 UT (#702027-28)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

IC 194 - Detail
CCD Image (100% size, linear scale, cropped)
Image details as above

Negative CCD Image (100% size, linear scale, cropped)
Image details as above


Back to Top


M103 - Open Cluster

M103 (Cassiopeia)
CCD Image (70% size)
3 x 20s exposure (average combine), 3x3 binning, C Filter
2019-10-01 02:20 UT (#702073-79)
12" LX200R (at f/10.4) + ST-10XME

M103 - Earlier Image (2005)
CCD Image Mosaic (3x3 frames)
20 sec exposure, C filter
2005-09-02  22:32 h UT (#93039-49)
8" LX200 Classic + ST-7E


Back to Top


NGC 789 - Spiral Galaxy (LGG 43 Member)

NGC 789 (Triangulum)
LGG 42 Member
CCD Image (50% size, square root scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-01 02:34 UT (#702082-84)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 789 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above
