CCD Images - Session 703 (2019-10-01)

Objects Session Notes
Bullet C/2017 T2 (PanStarrs) - Comet

Bullet NGC 777 - Elliptical Galaxy (LGG 42 Member)
Bullet NGC 925 - Spiral Galaxy
Bullet NGC 5693 - Spiral Galaxy (LCG 384 Member)

Bullet UGC 1577 - Spiral Galaxy (LGG 42 Member)
Bullet UGC 1641 - Spiral Galaxy (LGG 42 Member)
Bullet UGC 2614 - Spiral Galaxy with AT 2019pxo

Bullet Variable Stars (photometric monitoring)
  - None


Bullet Nearby Stars (astrometric monitoring)
 - None



- Night session (5.5 hours)

Session operated in fully automated mode with  monitoring during the first half of the session

- Main aim of the session was to test out new features in AdvMain / AstroGuard and to check stability of Programs after change. Conditons were forecast to be marginal so there were no specific observing aims. Several targets failed due to Cloud and/or poor transparency.

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  Falling  to 3.5°C (min).
Outdoors 3°C (min)
(Dew heaters on automated)
- CCD Temperature:  -20°C  (69% av. power)
- Notes from 2019-10-01 >>



C/2017 T2 (PanStarrs) - Comet

C/2017 T2 (PanStarrs)
(passing through Taurus)

Sun Distance 3.14 AU
Earth Distance 2.76 AU (412.8 million km)
   C/2017 T2 (PanStarrs) - Detail
Frames aligned on comet
Image   Image
CCD Image (50% size, linear scale)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2019-10-01 23:36 UT (#703042-44)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, square root scale, cropped)
8 x 45s exposure (average combine), 3x3 binning, C Filter
2019-10-01 23:35 UT (#703038-46)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2017 T2 (PanStarrs) on Comets 2019 Page

Back to Top


NGC 777 - Elliptical Galaxy (LGG 42 Member)

NGC 777 (Triangulum)
LGG 42 Member
CCD Image (50% size, log scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-01 22:14 UT (#703011-15)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 777 - Detail
CCD Image (100% size, log scale, cropped)
Image details as above


Back to Top


NGC 925 - Spiral Galaxy

NGC 925 (Triangulum)
For reference see. Ast. Now 2019, p72
CCD Image  (50% size, square root scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-01 22:57 UT (#703024-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 925 - False Colour
False Colour CCD Image (50% size, square root scale)
Inverse Spectrum Colour Scale
Image details as above

NGC 925 - Earlier Image (2009)
CCD Image (cropped)
60 sec exposure (single frame), 3x3 binning, C Filter
2009-12-10 23:48 h UT  (#403176)
12" LX200R  (at f/5.7) + ST-10XME


Back to Top


NGC 5693 - Spiral Galaxy (LCG 384 Member)

NGC 5693 (Bootes)
Part of LGG 384 Galaxy Group,
Associated with Ast. Now Challenge Object, May 2019
CCD Image (50% size)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-01 21:51 UT (#703003-07)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 5693 - Detail
CCD Image (100% size, linear scale, cropped)
Image details as above

NGC 5693 - Earlier Image (2019-09-22)
CCD Image (100% size, linear scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-22 22:26 UT (#699082-86)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 5693 - Earlier Image (2019-09-21)
CCD Image (100% size, linear scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-21 21:19 UT (#698078-81)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Back to Top


UGC 1577 - Spiral Galaxy (LGG 42 Member)

UGC 1577 (Triangulum)
LGG 42 Member
CCD Image  (50% size, linear scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-01 23:19 UT (#703031-35)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 1577 - Detail
CCD Image (100% size, square root scale, cropped)
Inverse Spectrum colour scale
Image details as above


Back to Top


UGC 1641 - Spiral Galaxy (LGG 42 Member)

UGC 1641 (Triangulum)
LGG 42 Member
CCD Image  (100% size, linear scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-01 22:31 UT (#703019-20)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 1641 - Later Image
Annotated CCD Image (100% size, linear scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-02 23:00 UT (#704057-61)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


UGC 2614 - Spiral Galaxy with AT 2019pxo

UGC 2614 (Perseus)
AT 2019pxo, discovered 2019/09/10.546
CCD Image (100% size, log scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-10-01 23:52 UT (#703049-53)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 2614  - Earlier Image (2019-09-28)
CCD Image (100% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-28 23:19 UT (#701022-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 2614 - Earlier Wider View (2019-09-28)
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-28 23:19 UT (#701022-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



Back to Top
