David's Astronomy Pages
|
Images (S718) |
Images Sessions |
Home Page |
Images (S720) |
Objects Session Notes
C/2017 T2 (PanStarrs) - Comet C/2018 N2 (ASASSN) - Comet Schloz's Star - Hypervelocity Star NGC 2506 - Open Cluster (Caldwell 54) NGC 2548 - Open Cluster (H VI-22) NGC 3646 - Spiral Galaxy Variable Stars (photometric monitoring) - RX And, U And, Z And, TT Ari, SY Cnc, CI Cyg, S Cyg, SS Cyg, AM Her, BL Lac, CY Lyr, U Mon, DY Per, GK Per, RR Tau, SU Tau
- FO Ori, FU Ori attempts failed due to cloudNearby Stars (astrometric monitoring) - HH And, DX Cnc, 61 Cyg, Groombridge 34, DX Cnc, Scholz's Star, Teegardens Star
- Evening session (6.5 hours)
Session operated under automated control with remote monitoring to check progress of new features. 2 interventions to fix bugs and restart.
- Main aim of the session was to test a number of new program features and to acquire images of a selection of targets - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: Falling from 4.5° to 1°C (min)
(Dew heaters on new automated control)- CCD Temperature: -20°C (63% av. power) - Notes from 2019-11-07 >>
C/2017 T2 (PanStarrs) - 2019-11-07 (passing through Auriga) Sun Distance 2.79 AU Earth Distance 1.97 AU (294.6 million km) |
C/2017 T2 (PanStarrs) - 2019-11-07, Detail Frames aligned on comet, stars appear trailed due to motion of comet against background stars |
|
CCD Image (50% size, square root scale) 3 x 45s exposure (average combine), 3x3 binning, C Filter 2019-11-07 22:41 UT (#719164-66) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, square root scale, cropped) 8 x 45s exposure (average combine), 3x3 binning, C Filter 2019-11-07 22:43 UT (#719164-71) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
Images of C/2017 T2 (PanStarrs) on Comets 2019 Page |
Back to Top
C/2018 N2 (ASASSN) - 2019-11-07 (passing through Andromeda) Sun Distance 3.13 AU Earth Distance 2.29 AU (341.8 million km) Composite image below shows movement of the comet over an interval of 4.4 hours |
|
Composite CCD Image (100% size, square root scale) 2 sets of 3 x 45s exposure (average combine), 3x3 binning, C Filter 2019-11-07 20:27 UT (#719036-38) & 2019-11-08 00:51 UT (#719233-35) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
C/2018 N2 (ASASSN) - 2019-11-07 (passing through Andromeda) Sun Distance 3.13 AU Earth Distance 2.29 AU (341.8 million km) |
C/2018 N2 (ASASSN) - 2019-11-07, Detail Frames aligned on comet. Stars appear trailed due to motion of comet |
|
|
||
CCD Image (50% size, square root scale) 3 x 45s exposure (average combine), 3x3 binning, C Filter 2019-11-07 20:27 UT (#719036-38) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, square root scale, cropped) 8 x 45s exposure (average combine), 3x3 binning, C Filter 2019-11-07 20:29 UT (#719036-43) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
Images of C/2018 N2 (ASASSN) on Comets 2019 Page >> |
Back to Top
Schloz's Star (Monoceros) |
Annotated CCD Image (50% size) 3 x 120s exposure (average combine), 3x3 binning, C Filter 2019-11-08 03:01 UT (#719243-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Schloz's Star - Detail Star is highlighted by white cross-hairs. |
Annotated CCD Image (150% size, cropped) Image details as above |
Schloz's Star - Earlier Image (2019-10-25) Star is highlighted by white cross-hairs. (Image suffers from Poor Focus and/or Poor Seeing) |
Annotated CCD Image (150% size, cropped) 7 x 120s exposure (average combine), 3x3 binning, C Filter 2019-10-25 04:12 UT (#714356-62) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Schloz's Star - Reference Picture (generated using Aladin) |
Back to Top
NGC 2506 \ H VI-37 (Monoceros) |
CCD Image (70% size, linear scale) 5 x 60s exposure (average combine), 3x3 binning, C Filter 2019-11-08 04:01 UT (#719275-80) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 2506 - Detail |
CCD Image (100% size, square root scale, cropped) Image details as above |
NGC 2506 - Earlier Image (2019-10-25) |
CCD Image (70% size, linear scale) 7 x 60s exposure (median combine), 3x3 binning, C Filter 2019-10-25 03:54 UT (#714347-53) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 2506 - Earlier Image (2019-10-23) |
CCD Image (70% size, square root scale) 3 x 60s exposure (average combine), 3x3 binning, C Filter 2019-10-23 05:28 UT (#713316-18) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 2506 - Earlier Image (2010) |
CCD Image (75% size, linear scale) 3 x 45s exposure (average combine), 3x3 binning, C Filter 2010-03-09 20:26 hUT (#416110-12) 12" LX200R (at f/9.7) + ST-10XME |
Back to Top
NGC 2548 \ H VI-22 (Hydra) |
CCD Image (70% size, linear scale) 9 x 30s exposure (average combine), 3x3 binning, C Filter 2019-11-08 04:15 UT (#719283-91) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 2548 \ H VI-22 - Earlier Image (2019-10-25) |
CCD Image (70% size, linear scale) 6 x 45s exposure (average combine), 3x3 binning, C Filter 2019-10-25 04:27 UT (#714365-71) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
NGC 3646 (Leo) Ring Galaxy, J.Lowrey List [ Ring Galaxies ] |
CCD Image (50% size, linear scale) 3 x 180s exposure (average combine), 3x3 binning, C Filter 2019-11-08 04:49 UT (#719303-05) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 3646 - Detail |
CCD Image (100% size, square root scale, cropped) Image details as above |
Back to Top
