David's Astronomy Pages
CCD Images - Session 735 (2020-01-02)

Objects Session Notes
Bullet IC 3322 - Spiral Galaxy
Bullet IC 3474 - Spiral Galaxy

Bullet Rose 9 - Compact Galaxy Group (UGC 7114 et al)

Bullet Variable Stars (photometric monitoring)
  - SY

Bullet Nearby Stars (astrometric monitoring)
 - DX



- Post midnight session (5 hours total)


- Main aims of the session was to test new dual band filter and acquire selection of deep sky targets under moonless sky

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  Falling from 4°C to -1°C (min) before rising to +2°C by dawn
(Dew heaters on fixed setting 92%)
- CCD Temperature:  -20°C  (61% av. power)
- Notes from 2020-01-02 >>



IC 3322 - Spiral Galaxy

IC 3322 (Virgo)
Flat Galaxy Atlas
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-01-03 04:04 UT (#735084-88)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

IC 3322 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


IC 3474 - Spiral Galaxy

IC 3474 (Virgo)
Flat Galaxy Atlas
Annotated CCD Image (50% size, linear scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2020-01-03 04:21 UT (#735090-92)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

IC 3474 - Detail
CCD Image (100% size, linear scale, cropped)
Image details as above


Back to Top


 Rose 9 - Compact Galaxy Group (UGC 7114 et al)

Rose 9 / UGC 7114 et al (Virgo)
Rose Catalogue
[ Rose Compact Galaxy Groups ]
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-01-03 03:44 UT (#735078-82)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Rose 9 / UGC 7114 et al - Detail
UGC 7114A  (catalog mag +16.8), alias PGC 38518 / UGC 7114
 UGC 7114AB (catalog mag +16.9), alias PGC 38519 / MCG+2-31-34
PGC 38521 (catalog mag +16.7), alias MCG+2-31-32
PGC 38520 (catalog mag +17.3), alias MCG+2-31-35
Annotated CCD Image (150% size, square root scale, cropped)
Image details as above


Back to Top
