David's Astronomy Pages
CCD Images - Session 759 (2020-03-04)

Objects Session Notes
Bullet 155P/Shoemaker - Comet
Bullet C/2019 Y4 (ATLAS)  - Comet

Bullet Rose 17 - Compact Galaxy Cluster (PGC 3089521 et al)

Bullet Variable Stars (photometric monitoring)
  - AM CVn, R CrB, U Gem, SS Her, U Her, RZ LMi, BL Lac, DY Per, GK Per, RR Tau

Bullet Nearby Stars (astrometric monitoring)
 -HH And, Barnards Srae, DX Cnc, CN Leo



- All night session (7.7 hours total).

- Main aims of the session was to  acquire images of a selection of deep sky and comet objects

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  -3°C (min)
(Dew heaters on auto)
- CCD Temperature:  -25°C  (65% av. power)
- Notes from 2020-03-04 >>



155P/Shoemaker - Comet

155P/Shoemaker - 2020-03-05
(passing through Leo)

Sun Distance 2.16 AU
Earth Distance 1.17 AU (175.5 million km)
   155P/Shoemaker  - 2020-03-05, Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra -22.30 arcsec/hr, Dec 10.42 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, linear scale)
3 x 60s exposure (average combine), 3x3 binning, C Filter
2020-03-05 00:16 UT (#759119-21)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, linear scale, cropped)
8 x 60s exposure (average combine), 3x3 binning, C Filter
2020-03-05 00:19 UT (#759119-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of 155P/Shoemaker on Comets 2020 Page >>

Back to Top


C/2019 Y4 (ATLAS)  - Comet

C/2019 Y4 (ATLAS) - 2020-03-05
(passing through Ursa Major)
Sun Distance 1.94 AU
Earth Distance 1.19 AU (178.0 million km)
   C/2019 Y4 (ATLAS)  - 2020-03-05, Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra -154.83  arcsec/hr, Dec 82.12 arcsec/hr)
Image   Image
CCD Image (50% size, square root scale)
2 x 60s exposure (average combine), 3x3 binning, C Filter
2020-03-05 04:22 UT (#759184-85)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, log scale, cropped)
7 x 60s exposure (average combine), 3x3 binning, C Filter
2020-03-05 04:24 UT (#759184-90)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2019 Y4 (ATLAS) on Comets 2020 Page >>

Back to Top


Rose 17 - Compact Galaxy Cluster (PGC 3089521 et al)

Rose 17 / PGC 3089521 et al (Bootes)
Rose Catalogue
[ Rose Compact Galaxy Groups ]
 Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-03-05 05:12 UT (#759209-13)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Rose 17 - Detail
PGC 3089521 (catalog mag +16.4), PGC 50694 (catalog mag +17.0),
 PGC 1720794 (catalog mag +16.7),  PGC 1720038 (catalog mag +17.2)
Annotated CCD Image (125% size, square root scale, cropped)
Image details as above

Negative CCD Image (125% size, square root scale, cropped)
Image details as above


Back to Top
