CCD Images - Session 770 (2020-04-19)

Objects Session Notes
Bullet C/2019 Y4 (ATLAS)  - Comet

Bullet AT 2020hat - Luminous Red Nova (LRN) in NGC 5068

Bullet NGC 5068 - Spiral Galaxy

Bullet UGC 4277 - Spiral Galaxy (PGC 23069)
Bullet UGC 6309 - Spiral Galaxy (PGC 34508)
Bullet UGC 7991 - Spiral Galaxy (PGC 43470)
Bullet UGC 7388 - Spiral Galaxy (PGC 39783)
Bullet UGC 8025 - Spiral Galaxy (PGC 43863)
Bullet UGC 8543 - Spiral Galaxy (PGC 47784)
Bullet UGC 8740 - Spiral Galaxy (PGC 49067)
Bullet UGC 9249 - Spiral Galaxy (PGC 51587)
Bullet UGC 9810 - Spiral Galaxy (PGC 54649)
Bullet UGC 10738 - Spiral Galaxy (PGC 59769)

Bullet Variable Stars (photometric monitoring)
  - AM CVn, SY Cnc, CI Cyg, U Her, ER UMa

Bullet Nearby Stars (astrometric monitoring)
 - Barnards Star, 61 Cyg



- All night session (6.3 hours total).
- Main aims of the session was to acquire images of a selection of deep sky and comet objects

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: 6°C (min)
(Dew heaters on auto)
- CCD Temperature:  -15°C  (61% av. power)
- Notes from 2020-04-19 >>



C/2019 Y4 (ATLAS)  - Comet

C/2019 Y4 (ATLAS) - 2020-04-19
(passing through Camelopardalis)
Sun Distance 1.11 AU (approaching)
Earth Distance 0.98 AU (146.5 million km))
   C/2019 Y4 (ATLAS)  - 2020-04-19, Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra -170.31 arcsec/hr, Dec -50.27 arcsec/hr)
Image   Image
CCD Image (50% size, square root scale)
2 x 45s exposure (average combine), 3x3 binning, C Filter
2020-04-19 21:32 UT (#770014-15)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, log scale, cropped)
25 x 45s exposure (average combine), 3x3 binning, C Filter
2020-04-19 21:42 UT (#770014-38)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2019 Y4 (ATLAS) on Comets 2020 Page >>


 C/2019 Y4 (ATLAS) - False Colour, 2020-04-19
 False Color CCD Image (50% size, log scale)
25 x 45s exposure (average combine), 3x3 binning, C Filter
2020-04-19 21:42 UT (#770014-38)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


 C/2019 Y4 (ATLAS) - 2020-04-19
Indications of comet fragmentation
CCD Image (150% size, linear scale, cropped)
Unsharp Masked (um4)
25 x 45s exposure (average combine), 3x3 binning, C Filter
2020-04-19 21:42 UT (#770014-38)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

 C/2019 Y4 (ATLAS) - Earlier Image (2020-04-18)
Indications of comet fragmentation
CCD Image (150% size, linear scale, cropped)
Unsharp Masked (um4)
13 x 45s exposure (average combine), 3x3 binning, C Filter
2020-04-18 23:47 UT (#769054-70)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

 C/2019 Y4 (ATLAS) - Earlier Image (2020-04-16)
Indications of comet fragmentation
CCD Image (150% size, linear scale, cropped)
Unsharp Masked (um4)
25 x 45s exposure (average combine), 3x3 binning, C Filter
2020-04-16 21:29 UT (#768003-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


AT 2020hat - Luminous Red Nova (LRN) in NGC 5068

Luminous Red Nova AT 2020hat  in NGC 5068 (Virgo)

AT2020hat (Type LRN, luminous red nova) discovered 2020/04/12.475 by ATLAS
 (Rochester Supernova site |  K. Itagaki image  mag +17.9 at 2020/04/14.618 |

Image (2020-04-19.941) taken 7.47 days after LRN discovery.
SN shown by white cross hairs. Magnitude ? (v. faint)

A LRN is is a stellar explosion thought to be caused by the merging of two stars.
The luminosity of the explosion occurring in luminous red novae is between that
of a supernova (which is brighter) and a nova (dimmer). The visible light lasts for weeks
or months, and is distinctively red in colour, becoming dimmer and redder over time. (
Wikipedia)
Annotated CCD Image (100% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-19 22:35 UT (#770052-56)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Annotated Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


NGC 5068 - Spiral Galaxy

NGC 5068 (Virgo)
Dec -21° 02'. Taken at Altitude 10.6°
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-19 22:35 UT (#770052-56)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 5068 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above

False Colour CCD Image (100% size, square root scale, cropped)
Inverse Spectrum Colour Bar
Image details as above

NGC 5068 - Detail (Dual Narrow Band)
CCD Image (100% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, DB Filter
2020-04-19 22:51 UT (#770057-61)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


UGC 4277 - Spiral Galaxy (PGC 23069)

UGC 4277  (Lynx)
Flat Galaxy Atlas
Alias: PGC 23069
Annotated CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-19 22:06 UT (#770041-45)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 4277 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


UGC 6309 - Spiral Galaxy (PGC 34508)

UGC 6309 (Ursa Major)
Ring Galaxy, J.Lowrey List
Alias: PGC 34508
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-19 21:15 UT (#770007-11)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 6309 & adjacent galaxies
UGC 6309 /  PGC 34508 (catalog mag +14.0) with
 PGC 34483 (catalog mag +16.5),  PGC 2394357 (catalog mag +17.9)
& PGC 2394338 (catalog mag +18.1)
Annotated CCD Image (100% size, square root scale, cropped)
Image details as above

UGC 6309 - Detail
CCD Image (125% size, square root scale, cropped)
Image details as above

Negative CCD Image (125% size, square root scale, cropped)
Image details as above


Back to Top


UGC 7991 - Spiral Galaxy (PGC 43470)

UGC 7991 (Virgo)
Flat Galaxy Atlas
Alias: PGC 43470
Annotated CCD Image (50% size, square root scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-19 23:12 UT (#770064-67)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 7991 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


UGC 7388 - Spiral Galaxy (PGC 39783)

UGC 7388 (Canes Venatici)
Ring Galaxy, J.Lowrey List
UGC 7388 / PGC 39783 (catalog mag +16.2)
with adjacent galaxies:
 PGC 2035235 (catalog mag +18.4), PGC 2037375 (catalog mag +17.5),
PGC 2037257 (catalog mag +18.3), PGC 2820304 (catalog mag +18.6),
PGC 2037713 (catalog mag +18.1)
Annotated CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-20 00:21 UT (#770078-82)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 7388 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above

UGC 7388 - Earlier Image (2020-04-18)
Note: Single frame due to cloud & guiding issues
CCD Image (100% size, linear scale, cropped)
180s exposure (single frame), 3x3 binning, C Filter
2020-04-19 00:03 UT (#769073)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 7388 - Earlier Image (2020-04-13)
Note: Single frame due to developing cloud.
CCD Image (100% size, linear scale, cropped)
180s exposure (single frame), 3x3 binning, C Filter
2020-04-13 23:24 UT (#767050)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


UGC 8025 - Spiral Galaxy (PGC 43863)

UGC 8025 / PGC 43863 (Coma Berenices)
Flat Galaxy Atlas
Annotated CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-20 00:51 UT (#770089-93)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 8025 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above

UGC 8025 - Earlier Image (2020-04-18)
CCD Image (100% size, square root scale, cropped)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-18 23:19 UT (#769041-43)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


UGC 8543 - Spiral Galaxy (PGC 47784)

UGC 8543 (Virgo)
Flat Galaxy Atlas Object
UGC 8543 /  PGC 47784 (catalog mag +15.2)
with adjacent galaxies:
PGC 1273170 (catalog mag +17.9), PGC 1273445 (catalog mag +18.0)
Annotated CCD Image (50% size, square root scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-19 23:34 UT (#770071-74)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 8543 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


UGC 8740 - Spiral Galaxy (PGC 49067)

UGC 8740 (Virgo)
Ring Galaxy, J.Lowrey List
 [ Ring Galaxies ]
UGC 8740 / PGC 49067 (catalog mag +13.6)
with adjacent galaxies:
  PGC 1264174 (catalog mag +16.5), PGC 1264967 (catalog mag +17.7),
PGC 214158 (catalog mag +17.8), PGC 1265155 (catalog mag +18.1),
PGC 1264572 (catalog mag +18.4)
Annotated CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-20 01:16 UT (#770097-100)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 8740 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


UGC 9249 - Spiral Galaxy (PGC 51587)

UGC 9249 (Bootes)
Flat Galaxy Atlas
Alias: PGC 51587
CCD Image (50% size, square root scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-20 01:38 UT (#770102-06)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 9249 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


UGC 9810 - Spiral Galaxy (PGC 54649)

UGC 9810 / PGC 54649 (Serpens)
Ring Galaxy, J.Lowrey List
 [ Ring Galaxies ]
No indication of any ring structure. Inclusion of UGC 9810
in Ring Galaxy Atlas doesn't appear to be justified
CCD Image (125% size, square root scale, cropped)
6 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-20 02:03 UT (#770109-15)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Negative CCD Image (125% size, square root scale, cropped)
Image details as above

UGC 9810 - Earlier Image (2020-04-14)
Ring structure is not obviously discernable in image below
CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-14 02:07 UT (#767109-13)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 9810 / PGC 54649 - Earlier Wider Field Image (2020-04-14)
UGC 9810 / PGC 54649 (catalog mag +17.0)
with adjacent galaxies :
 PGC 54682 (catalog mag +15.5), PGC 1332280 (catalog mag +17.1)
 PGC 91430 (catalog mag +17.2),  PGC 1331691 (catalog mag +17.4),
PGC 1329914 (catalog mag +17.9)
Annotated CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-14 02:07 UT (#767109-13)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


UGC 10738 - Spiral Galaxy (PGC 59769)

UGC 10738 (Ophiuchus)
Flat Galaxy Atlas
Alias: PGC 59769
CCD Image (50% size, square root scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-20 02:39 UT (#770131-35)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 10738 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top
