CCD Images - Session 786 (2020-05-29)

Objects Session Notes
Bullet GRB 200529A - GRB (Swift 974942)

Bullet M61 - Spiral Galaxy with Type II Supernova 2020jfo

Bullet NGC 3643 - Spiral Galaxy with Type Ia Supernova 2020hvf

Bullet UGCA 309 - Spiral Galaxy (PGC 44121)

Bullet Variable Stars (photometric monitoring)
- R CrB, TBA

Bullet Nearby Stars (astrometric monitoring)
- Barnards Star


- All Night Session (2.9 hours total).
- Main aims of the session was to test new version of AstroMain (3.22.3) and acquire useful images if possible.

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: Falling to 6°C (min) by dawn
- CCD Temperature:  -15°C  (71% av. power)
- Notes from 2020-05-29 >>



GRB 200529A - GRB (Swift 974942)

GRB 200529A (Libra)
Swift Trigger 974942 (T0 at 2020-05-29 00:56:35 UT)

Image of GRB Location taken 23.34 hours after GRB Trigger.
Limiting magnitude ~18.4 , T-Exp 540s, C Filter
CCD Image (70% size, linear scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2020-05-30 00:17 UT (#786055-57)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
[ more details on Observatory Reaction to GCN Alert, GRB Swift 974942 (GRB 200529A)  ]

GRB 200529A - Analysis (T0+23.34 hours)
 Image of GRB Location taken 23.34 hours after GRB Trigger
Limiting magnitude ~18.4 , T-Exp 540s, C Filter

No indication of optical afterglow at the location
reported by NOT/KAIT/Swift-XRT, marked by blue cross-hair
Annotated CCD Image (100% size, linear scale, cropped)
Image details as above

GRB 200529A - Earlier Image (2020-05-29, T0+21mins)
Image of GRB Location taken 21 minutes after GRB burst.
Limiting magnitude ~17.2, T-Exp 720s, C Filter
No indication of optical afterglow at the location reported by NOT/KAIT/Swift-XRT (marked by blue cross-hair)
CCD Image (70% size, linear scale, with corrective flattening)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-05-29 01:18 UT (#785090-93)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

GRB 200529A Location - Earlier Image (2020-05-29, T0+6mins)
Image of GRB Location taken 6 minutes after GRB burst.
Limiting magnitude ~16.0, T-Exp 30s, C Filter
No indication of early optical afterglow at the location reported by NOT/KAIT/Swift-XRT
CCD Image (70% size, linear scale)
30s exposure (single frame), 3x3 binning, C Filter
2020-05-29 01:02 UT (#785082)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



Back to Top


M61 - Spiral Galaxy with Type II Supernova 2020jfo

M61 with SN2020jfo  (Virgo)
SN2020jfo (Type II) discovered 2020/05/06.203 by Zwicky Transient Facility (ZTF))
 (Rochester Supernova site | Nico Montigiani and Massimiliano Mannucci image | SN 2020jfo images sub page |

M61 with SN2020jfo - 2020-05-29
Image below (2020-05-29.976) was taken 23.8 days after discovery of SN 2020jfo
SN is shown by white cross hairs.  Measured SN magnitude +14.6
Annotated CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-05-29 23:26 UT (#786030-33)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2020jfo (M61) on Supernovae 2020 Page >>

Back to Top


NGC 3643 - Spiral Galaxy with Type Ia Supernova 2020hvf

NGC 3643 with SN 2020hvf (Leo)
SN 2020hvf (Type 1a) discovered 2020/04/21.380 by ATLAS
 (Rochester Supernova site | Marc Deldman image | Robin Leadbetter image + spectra )

NGC 3643 with SN 2020hvf - 2020-05-29 (T+38.6d)
Image below (2020-05-29.963) was taken 38.6 days after discovery of SN 2020hvf
SN is shown by white cross hairs.  Measured SN magnitude +13.2
Annotated CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-05-29 23:06 UT (#786023-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2020hvf (NGC 3643) on Supernovae 2020 Page >>

Back to Top


UGCA 309 - Spiral Galaxy (PGC 44121)

UGCA 309 (Canes Venatici)
Alias : PGC 44121
Image shows poor S/N due to bright sky
(Target to be rescheduled)
Annotated CCD Image (100% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-05-29 23:50 UT (#786039-43)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
