David's Astronomy Pages
CCD Images - Session 797 (2020-08-08)

Objects Session Notes
Bullet Berkeley 1 - Open Cluster
Bullet Berkeley 91 - Open Cluster
Bullet Berkeley 95 - Open Cluster
Bullet Berkeley 100 - Open Cluster
Bullet Berkeley 102 - Open Cluster

Bullet NGC 6741 - Planetary Nebula (Phantom Streak Nebula)

Bullet Variable Stars (photometric monitoring)
- RX And, S Cyg, SS Cyg, AM Her, U Her, FG Sge

- Z And attempt failed due to cloud

Bullet Nearby Stars (astrometric monitoring)
- HH And, 61 Cyg, Groombridge 34


- All Night Session (3.7 hours total).
- Main aims of the session was to test new AutoStart mode of Observatory Operations , test 'Foc2 Wide Range Auto-Focusing'  and acquire images of a selection of targets if conditions allowed.

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: 9°C (min)
- CCD Temperature:  -10°/-15°C
- Notes from 2020-08-08 >>
- Notes from Observing Attempt 2020-08-06 >>


Berkeley 1 - Open Cluster

Berkeley 1 (Cassiopeia)
Berkeley Catalogue
CCD Image (70% size, linear scale)
7 x 30s exposure (average combine), 3x3 binning, C Filter
2020-08-09 02:09 UT (#797142-49)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Berkeley 91 - Open Cluster

Berkeley 91 (Cygnus)
Berkeley Catalogue
CCD Image (70% size, square root scale)
6 x 30s exposure (average combine), 3x3 binning, C Filter
2020-08-08 22:40 UT (#797017-23)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Berkeley 91 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Berkeley 91 - Earlier Image (2020-05-06)
CCD Image (70% size, linear scale)
5 x 30s exposure (average combine), 3x3 binning, C Filter
2020-05-06 23:16 UT (#780078-84)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Berkeley 95 - Open Cluster

Berkeley 95 (Cepheus)
Berkeley Catalogue
CCD Image (70% size, linear scale)
5 x 30s exposure (average combine), 3x3 binning, C Filter
2020-08-09 01:45 UT (#797121-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Berkeley 100 - Open Cluster

Berkeley 100 (Cepheus)
Berkeley Catalogue
CCD Image (70% size, linear scale)
6 x 30s exposure (average combine), 3x3 binning, C Filter
2020-08-09 01:59 UT (#797134-39)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Berkeley 102 - Open Cluster

Berkeley 102 (Cassiopeia)
Berkeley Catalogue
CCD Image (70% size, linear scale)
3 x 30s exposure (average combine), 3x3 binning, C Filter
2020-08-09 01:12 UT (#797096-98)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


NGC 6741 - Planetary Nebula (Phantom Streak Nebula, PLN 33- 2.1)

NGC 6741 (Aquila)
Phantom Streak Nebula, PLN 33- 2.1
Annotated CCD Image (50% size, linear scale)
3 x 30s exposure (average combine), 3x3 binning, C Filter
2020-08-08 22:22 UT (#797003-06)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 6741 - Detail
The object looks very stellar-like in the image below - it appears similar to
the adjacent 'bright star', but may be slightly elongated, at least more
than the other stars in the image which are subject to some poor RA tracking/guiding)
CCD Image (150% size, linear scale, cropped)
Image details as above

NGC 6741 - Alternate Image
The object looks to be less stellar-like in the
square root scaled image below - it is larger in size and
has lower 'surface brightness' than the adjacent 'bright' star
CCD Image (150% size, linear scale, cropped)
Image details as above

NGC 6741 - through 'Star Analyser 100'diffraction grating
The object's true identity of NGC 6741 object is shown in image below where its
classic Pl.Neb spectrum allows it to be easily distinguished from the stellar spectrum
of the adjacent 'bright' star (GSC 5128:756, mag +12.7)
CCD Image (100% size, linear scale, rotated, cropped)
2 x 60s exposure (average combine), 2x2 binning, S Filter
2020-08-08 22:29 UT (#797010-11)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

CCD Image (100% size, linear scale, rotated cropped)
Image details as above
