David's Astronomy Pages
CCD Images - Session 811 (2020-09-18)

Objects Session Notes
Bullet Abell 347  - Galaxy Cluster (NGC 910 et al)
Bullet Abell 370 - Galaxy Cluster
Bullet B110 - Dark Nebula

Bullet NGC 910 - Elliptical Galaxy
Bullet NGC 2782 - Spiral Galaxy with Type Ia Supernova 2020scc
Bullet NGC 7241 - Spiral Galaxy

Bullet UGCA 33 - Spiral Galaxy (PGC 9559)

Bullet UGC 6 - Spiral Galaxy (PGC 207)
Bullet UGC 542 - Spiral Galaxy (PGC 3133)
Bullet UGC 695 - Dwarf Galaxy, 30 mly
Bullet UGC 711 - Spiral Galaxy (PGC 4063)
Bullet UGC 1999 - Spiral Galaxy (PGC 9638)
Bullet UGC 6930 - Spiral Galaxy with Type Ia Supernova 2020rcq
Bullet UGC 11964 - Spiral Galaxy (PGC 68420)

Bullet Variable Stars (photometric monitoring)
- RX And, U And, Z And, SS Cyg, AM Her,CY Lyr, FO Ori, DY Per, GK Per, FG Sge, RR Tau

Bullet Nearby Stars (astrometric monitoring)
- HH And, 61 Cyg, Groombridge 34


- All night session (8.1 hours total)
- Main aims of the session were the acquisition of a selection of deep sky targets, together with some variable star, nearby starand comet targets
- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: 7.5°C (min)
- CCD Temperature:  -10°/-15°C
- Notes from 2020-09-18 >>

-


Abell 347  - Galaxy Cluster (NGC 910 et al)

Abell 347 Galaxy Cluster (Andromeda)
NGC 910 et al. Distance 250 mly

NGC 910 (catalog mag +12.2), PGC 9180 (catalog mag +15.5),
 PGC 212971 (catalog mag +16.7), PGC 9203 (catalog mag +15.1),
PGC 2188488 (catalog mag +16.9), PGC 2188914 (catalog +16.5),
PGC 2188161 (catalog mag +16.6), PGC 2186399 (catalog mag +17.3),
PGC 2186599 (catalog mag +16.0)


Annotated CCD Image (70% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-19 00:41 UT (#811128-32)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



 Negative CCD Image (70% size, square root scale, cropped)
Image details as above



Abell 347 Galaxy Cluster - Detail


CCD Image (70% size, square root scale, cropped)
Image details as above





Back to Top


Abell 370 - Galaxy Cluster

Abell 370 (Cetus)


Annotated CCD Image (50% size, square root scale)
8 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-19 03:12 UT (#811168-77)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



Abell 370 with foreground galaxies
PGC 175370 (catalog mag +16.1),  PGC 1116603 (catalog mag +17.1),
PGC 1116254 (catalog mag +17.5), PGC 1115693 (catalog mag +17.8),
PGC 1115955 (catalog mag +18.3)
Annotated CCD Image (100% size, square root scale, cropped)
Image details as above



Abell 370 - Detail
CCD Image (125% size, square root scale, cropped)
Image details as above



Abell 370 - HST Image
resized & rotated to match image above
 Space Telescope Image (HST)
(based on image at https://hubblesite.org/image/4229/gallery )



Back to Top


B110 - Dark Nebula

B110 (Scutum)
Barnards Dark Nebula
Near to Ast.Now Deep Sky Challenge B106/B107, Aug 2020)
3 x 3 Mosaic, FOV 43.0 x 29.0 arc min
Newly constructed mosaic including new frame (#811049)
 that was missing from the original attempt
CCD Mosaic, 3x3  (27% size, linear scale)
Frames  60s exposure (single frame), 3x3 binning, C Filter
2020-09-13 21:02 UT (#808022-35)
 2020-09-18 21:05 UT (#811049)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
[ Larger Image (70% size) ]

( See also Internet - http://www.astrosurf.com/buil/gallery/b110/img.htm )

B110 - Earlier Image 2020-09-13
3 x 3 Mosaic, FOV 44.4 x 29.3 arc min
 ( Note : Top right frame is missing from mosaic - it was cancelled to prevent
observation from overrunning its time slot )
CCD Mosaic, 3x3  (27% size, linear scale)
Frames  60s exposure (single frame), 3x3 binning, C Filter
2020-09-13 21:02 UT (#808022-35)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
[ Larger Image (70% size) ]

( See also Internet - http://www.astrosurf.com/buil/gallery/b110/img.htm )


Back to Top


NGC 910 - Elliptical Galaxy

NGC 910 (Andromeda)
Part of Abell 347 Galaxy Cluster


CCD Image (150% size, log scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-19 00:41 UT (#811128-32)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



 Negative CCD Image (150% size, log scale, cropped)
Image details as above



Back to Top


NGC 2782 - Spiral Galaxy (ARP 215) with Type Ia Supernova 2020scc

NGC 2782 with SN 2020scc (Lynx)
SN 2020scc (Type Ia, z=0.008483) discovered 2020/08/20.915 by Xingming Observatory Sky Survey (XOSS)
 ( Rochester Supernova site | Discovery image | )

NGC 2782 with SN 2020scc - 2020-09-19 (T+29.2d)
Annotated CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-19 02:21 UT (#811155-58)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 2782 with SN 2020scc - Detail, 2020-09-19 (T+29.2d)
Image below (2020-09-19.098) was taken 29.2 days after discovery of SN 2020scc
SN is shown by white cross hairs.  Measured SN magnitude +15.2
Annotated CCD Image (100% size, square root scale, cropped)
Image details as above

Images of SN 2020scc (NGC 2782) on Supernovae 2020 Page >>

NGC 2782 - Earlier Image, 2020-04-13 (T-129.0d)
Image below (2020-04-13.885) was taken 129.0 days before discovery of SN 2020scc
No sign of any object at location of the later supernova.
CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-04-13 21:15 UT (#767009-13)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


NGC 7241 - Spiral Galaxy

NGC 7241 (Pegasus)
NGC 7241 (catalog mag +12.7) with
adjacent flat galaxy UGC 11964 / PGC 68420 (catalog mag +15.0)
Annotated CCD Image  (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-18 21:45 UT (#811074-78)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 7241 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

 Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


UGCA 33 - Spiral Galaxy (PGC 9559)

UGCA 33  (Cetus)
Alias : PGC 9559


CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-19 02:39 UT (#811161-64)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



UGCA 33 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above



Back to Top


UGC 6 - Spiral Galaxy (PGC 207)

UGC 6 (Pegasus)
Ring Galaxy, J.Lowrey List
Alias : PGC 207


CCD Image (100% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-19 00:20 UT (#811122-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



UGC 6 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

 Negative CCD Image (100% size, square root scale, cropped)
Image details as above



UGC 6 - Earlier Image
Poor image, single frame

Annotated CCD Image (100% size, linear scale, cropped)
180s exposure (single frame), 3x3 binning, C Filter
2020-08-22 00:27 UT (#798062)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



Back to Top


UGC 542 - Spiral Galaxy (PGC 3133)

UGC 542 (Pisces)
Flat Galaxy Atlas
Alias:  PGC 3133
Image is quite noisy, only one frame was acquired.
Target to be rescheduled for a future session


CCD Image (100% size, square root scale, cropped)
180s exposure (single frame), 3x3 binning, C Filter
2020-09-19 01:05 UT (#811142)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



Back to Top


UGC 695 - Dwarf Galaxy (PGC 4013), 30 mly

UGC 695 (Cetus)
Isolated dwarf galaxy (30 mly).   Alias:   PGC 4013,  LEDA 4013

UGC 695 is a low-surface-brightness (LSB) galaxy which make is pretty faint.
These galaxies are so faint that their brightness is less than the background brightness of Earth’s atmosphere,
which makes them tricky to observe. This low brightness is the result of the relatively small number of stars within them.

UGC 695 / PGC 4013 (catalog mag +15.3)
with adjacent faint galaxies
PGC 135624 (catalog mag +17.3), PGC 1183501 (catalog mag +17.6),
PGC 1182951 (catalog mag +17.8),  PGC 212662 (catalog mag +18.2)
Annotated CCD Image  (70% size, square root scale, cropped)
6 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-17 00:09 UT (#809007-12)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

(cf.  Hubble Picture - Hubble Glimpses Faint Galaxy, Sep 2019 )

UGC 695 - Detail
CCD Image  (150% size, square root scale, cropped)
Image details as above

UGC 695 - Earlier Image (2020-09-17)
CCD Image  (100% size, square root scale, cropped)
6 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-17 00:09 UT (#809007-12)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



Back to Top


UGC 711 - Spiral Galaxy (PGC 4063)

UGC 711 (Cetus)
Flat Galaxy Atlas
Alias : PGC 4063
Bright foreground star is GSC 19:146 (magnitude +9.7)


CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-18 23:22 UT (#811092-95)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



UGC 711 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

 Negative CCD Image (100% size, square root scale, cropped)
Image details as above


UGC 711 - Earlier Image (2020-09-10)
Target poorly defined in image below (single frame, moonlit sky)
and needs to be rescheduled for a darker night


CCD Image (100% size, linear scale, cropped)
180s exposure (single frame), 3x3 binning, C Filter
2020-09-10 00:32 UT (#807044)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



Back to Top


UGC 1999 - Spiral Galaxy (PGC 9638)

UGC 1999 (Aries)
Flat Galaxy Atlas
Alias : PGC 9638


CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-18 23:42 UT (#811098-102)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



UGC 1999 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

 Negative CCD Image (100% size, square root scale, cropped)
Image details as above



Back to Top


UGC 6930 - Spiral Galaxy with Type Ia Supernova 2020rcq

UGC 6930 with SN 2020rcq (Ursa Major)
SN 2020rcq (Type 1a, z=0.002597) discovered 2020/08/09.168 by Zwicky Transient Facility (ZTF)
 (Rochester Supernova site | Giancarlo Cortini image | )

UGC 6930 with SN 2020rcq - 2020-09-18 (T+40.7d)
Annotated CCD Image (50% size, square root scale)
5 x 120s exposure (average combine), 3x3 binning, C Filter
2020-09-18 20:43 UT (#811034-38)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 6930 with SN 2020rcq - Detail, 2020-09-18 (T+40.7d)
Image below (2020-09-18.863) was taken 40.7 days after discovery of SN 2020rcq
SN is shown by white cross hairs.  Measured SN magnitude +12.9
Annotated CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above

Annotated CCD Image (100% size, linear scale, cropped)
Image details as above

Images of SN 2020rcq (UGC 6930) on Supernovae 2020 Page >>

Back to Top


UGC 11964 - Spiral Galaxy (PGC 68420)

UGC 11964 (Pegasus)
Flat Galaxy Atlas
UGC 11964 / PGC 68420 (catalog mag +15.0)
with adjacent spiral galaxy NGC 7241 (catalog mag +12.7)
Annotated CCD Image  (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-09-18 21:45 UT (#811074-78)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 11964  - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

 Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top
