David's Astronomy Pages
CCD Images - Session 817 (2020-10-08)

Objects Session Notes
Bullet C/2020 Q1 (Borisov) - Comet (Attemp)

Bullet ARP 99 - Spiral & Elliptical Galaxy (NGC 7549 & 7550)
Bullet Caldwell 33 - Supernova Remnant (NGC 6992 , "Veil Nebula, East" )
Bullet Hickson 93 - Galaxy Group (NGC 7550 et al)

Bullet NGC 772 - Spiral Galaxy (ARP 78 / H112-1) with AT 2020ue (Unconfirmed)

Bullet UGC 122 - Spiral Galaxy (PGC 889)

Bullet Variable Stars (photometric monitoring)
- RX And, BL Lac

Bullet Nearby Stars (astrometric monitoring)
- None


- Night session (1.5 hours), excluding time spent focusing and testing /calibrating 'Cam1' Autoguiding.
- Main aims of the session were the testing new PHD2 messaging routines and acquisition of a selection of deep sky targets, together with some variable star, nearby star and comet targets (if conditions allowed)
- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: 3°C (min)
- CCD Temperature:  -20°C
- Notes from 2020-10-08 >>

-


C/2020 Q1 (Borisov) - Comet, Attempted Sighting

C/2020 Q1 (Borisov)
 (passing through Cepheus)

C/2020 Q1 (Borisov) (passing through Cygnus)
Sun Distance 1.54 AU
Earth Distance 0.88 AU (131.1 million km)
(forecast mag in TheSky6 +15.6)
No indication of a comet at the expected position (circled)
   C/2020 Q1 (Borisov) - 2020-09-29, Detail
Autoguided on offset star
without Lock Shift



No indication of a comet at the expected position (circled)
Image   Image
Annotated CCD Image (50% size, square root scale)
7 x 45s exposure (average combine), 3x3 binning, C Filter
2020-10-08 20:05 UT (#817003-09)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  Annotated CCD Image (100% size, square root scale, cropped)
Image details as left

Images of C/2020 Q1 (Borisov) on Comets 2020 Page >>


Back to Top


ARP 99 - Spiral & Elliptical Galaxy (NGC 7549 & 7550)

ARP 99 (Pegasus)
Spiral Galaxy (NGC 7549) with Elliptical Galaxy (NGC 7550) on arm
NGC 7550 is brightest member of Hickson 93 galaxy group
Annotated CCD Image  (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-10-08 20:26 UT (#817012-15)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

ARP 99 - Detail
Negative CCD Image (100% size, square root scale, cropped)
Image details as above

ARP 99 - Earlier Image (2009)
Annotated CCD Image (cropped)
2 x 60 sec exposure (average combine), 3x3 binning, C Filter
2009-12-04 20;14 h UT  (#402240-43)
12" LX200R  (at f/5.7) + ST-10XME
[larger image, 75% size]


Back to Top


Caldwell 33 - Supernova Remnant (NGC 6992 , "Veil Nebula, East" )

Caldwell 33 / NGC 6992 (Cygnus)
CMOS Colour Image (16% size), Live Stacking of 49 frames
49 x 10s (stacked, total exposure 490s), 1x1 binning
2020-10-08 19:52 UT , Gain 300, ROI 3096x2080 (Full)
TS 80mm f/6 APO + ASI178MC (OSC), Mounted on 12" LX200R
Autoguided using ST-10XME camera & PHD2
Frames acquired using SharpCap, Raw Frames (no Dark or Flat applied)
Larger Image (32% size)

Caldwell 33 / NGC 6992 - Detail
CMOS Colour Image (28% size, cropped)
Live Stacking of 49 frames, Total exposure 490s
Image details as above

Negative CMOS Black & White Image (16% size), Live Stacking of 49 frames
Image details as above

Caldwell 33 / NGC 6992 - Earlier Image (2005)
 Image Image
CCD Image Mosaic (3x6 frames)
60s exposure, C Filter
2005-09-03  01:18 h UT (#93170-87)
8" LX200 Classic + ST-7E
(Full Size)
CCD Image Mosaic (3x6 frames)
Negative
(details as left)

Back to Top


Hickson 93 - Galaxy Group (NGC 7550 et al)

Hickson 93 (Pegasus)
NGC 7550 is brightest member of Hickson 93 galaxy group
Annotated CCD Image  (70% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-10-08 20:26 UT (#817012-15)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Hickson 93 - Detail
Negative CCD Image (70% size, square root scale)
Image details as above

Hickson 93 - Earlier Image (2009)
Annotated CCD Image (cropped)
2 x 60 sec exposure (average combine), 3x3 binning, C Filter
2009-12-04 20;14 h UT  (#402240-43)
12" LX200R  (at f/5.7) + ST-10XME
[larger image, 75% size]


Back to Top


NGC 772 - Spiral Galaxy (ARP 78 / Herschel I-H112) with AT 2020ue (Unconfirmed)

ARP 78 / NGC 772 & NGC 770 (Aries)
Annotated CCD Image (50% size, square root scale)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2020-10-08 21:21 UT (#817035-37)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 772 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above

NGC 772 with AT 2020uex (unconfirmed)
AT 2020uex (Type Unkn), TNS discovered 2020/09/25.677 by Koichi Itagaki
 (Rochester Supernova site | Discovery Image | Jordi Camarasa image (unconfirmed) | TNS 2020uex )

Image below (2020-10-08.890) was taken 13.2 days after supposed discovery of AT 2020uex
AT 2020uex (position shown by white circle) is unconfirmed
Annotated CCD Image (100% size, square root scale, cropped)
Image details as above

Images of AT 2020uex (NGC 772) on Transients 2020 Page >>

NGC 772 - Earlier Wider View Image (2008)
Annotated CCD Image (100% size, square root scale)
5 x 180s sec exposure (average combine), 2x2 binning, C Filter
2008-11-27 21:20 h UT (#326243-47)
8" LX200 Classic + ST-7E

NGC 772 - Earlier Image (2001)
CCD Image (linear scale)
2001-11-26, 23:05h UT
5 min exposure (#11058)
8" LX200 Classic + ST-7E


Back to Top


UGC 122 - Spiral Galaxy (PGC 889)

UGC 122 (Pegasus)
Flat Galaxy Atlas
Alias: PGC 889
Annotated CCD Image  (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-10-08 20:45 UT (#817017-21)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

UGC 122 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top
