Images - Session 1044 (2022-10-01)

Objects Session Notes
Bullet Jupiter - Planet

Bullet C/2022 E3 (ZTF) - Comet

Bullet AT 2022kl - Variable Star Outburst (V0381 Lac)
Bullet AT 2022tru - CV Type Transient
Bullet AT 2022vxe - Type YSO? Transient
Bullet AT 2022why - Type Nova? Transient

Bullet IC 1132 - Spiral Galaxy with Type II Supernova 2022prv
Bullet LEDA 1409307 - Galaxy with Type Ia Supernova 2021ucm  (Attempt)

Bullet NGC 157 - Spiral Galaxy with Type Ic Supernova 2022jli
Bullet NGC 5894 - Spiral Galaxy with Type II Supernova 2022pgf
Bullet NGC 6745 - Spiral Galaxy with Type IIn Supernova 2022prr
Bullet NGC 7495 - Spiral Galaxy with Type II Supernova 2022ubb

Bullet UGC 2508 - Spiral Galaxy with Transient AT 2022trp (Attempt)
Bullet UGC 3923 - Spiral Galaxy with Transient AT 2022rqc
Bullet UGC 6983 - Spiral Galaxy with Type II Supernova 2022pru

AT2022tmq attempted failed (due to bad guiding)

Bullet Variable Stars (photometric monitoring)
- SS Cyg, BL Lac, FO Ori, RR Tau

Bullet Nearby Stars (astrometric monitoring)
- HH And, DX Cnc, Groombridge 34

- All Night session (7.8h). Opportunity to start session directly at dusk was lost (loosing 90mins). Session interrupted by cloud between 03:07 Start delayed due to cloud & rain, but sky then cleared and remained clear until dawn.

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: 6°C (min)
- CCD Temperature:   -15° C
- Notes from 2022-10-01 >>




Jupiter - Planet

Jupiter (passing through Pisces)
Sun Distance 4.95 AU
Earth Distance 3.96 AU (592.1 million km)

Jupiter
Approx Colour CCD Image (100% size, cropped, unsharp masked)
Combined BVR Image from 3 images:
9 x 0.2s exposure (average combine), 1x1 binning, B Filter
2022-10-01 23:00 UT (#1044060-69)
8 x 0.11s exposure (average combine), 1x1 binning, V Filter
2022-10-01 23:01 UT (#1044070-79)
5 x 0.11s exposure (average combine), 1x1 binning, R Filter
2022-10-01 23:02 UT (#1044080-86)
12" LX200R (at f/10.4) + ST-10XME

Jupiter Moons
Annotated CCD Image (70% size, linear scale)
5 x 0.2s exposure (average combine), 3x3 binning, V Filter
2022-10-01 22:59 UT (#1044055-59)
12" LX200R (at f/10.4) + ST-10XME


Back to Top


C/2022 E3 (ZTF) - Comet

C/2022 E3 (ZTF) - 2022-10-01
(passing through Corona Borealis)
Sun Distance 1.93 AU (approaching)
Earth Distance 2.26 AU (337.6 million km)
   C/2022 E3 (ZTF) - 2022-10-01 Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra -18.51 arcsec/hr, Dec -20.59 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
5 x 90s exposure (average combine), 3x3 binning, Clear Filter
2022-10-01 22:10 UT (#1044022-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  Annotated CCD Image (100% size, log scale, cropped)
5 x 90s exposure (average combine), 3x3 binning, Clear Filter
2022-10-01 22:10 UT (#1044022-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2022 E3 (ZTF) on Comets 2022 Page >>

Back to Top


AT 2022kl - Variable Star Outburst (V0381 Lac)

AT 2022kl (Lacerta)
AT 2022kl (Type: CV) discovered 2022-01-10.882 UT by MASTER
Alias: MASTER OT J221558.82+422247.1,   V0381 Lac (Carbon Star)
Pre-Print : The variable V381 Lac and its possible connection
with the R CrB phenomenon (https://arxiv.org/pdf/1512.00146v1.pdf)
Discovery Magnitude +13.6 vs pre-discovery mag > +20.2 (VegaMag)
 ( TNS 2022kl )

AT 2022kl / V0381 Lac - 2022-10-02 (T+264.2d), B  Band Image
Image below (2022-10-02.075) was taken 264.2 days after discovery of 2022kl
Measured magnitude  : 12.78
Note: Mag estimate is uncertain due to V0381 Lac's deep red (high B-V) colour)
Annotated CCD Image (100% size, linear scale, cropped)
5 x 60s exposure (average combine), 3x3 binning, B Filter
2022-10-02 01:51 UT (#1044161-65)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

AT 2022kl / V0381 Lac - 2022-10-02 (T+264.2d), R Band Image
Image below (2022-10-02.075) was taken 264.2 days after discovery of 2022kl
Measured magnitude  : 11.29
Note: Mag estimate is uncertain due to V0381 Lac's deep red (high B-V) colour)
Annotated CCD Image (100% size, linear scale, cropped)
60s exposure (single frame), 3x3 binning, R Filter
2022-10-02 02:01 UT (#1044171)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2022kl on Transients 2022 Page >>

Back to Top


AT 2022tru - CV Type Transient

AT 2022tru (Pegasus)
AT 2022tru (Type: CV) discovered 2022-09-07.406 UT by ZTF
Alias: ZTF22abfjnpj
Discovery Magnitude +13.09 vs prior non-detection mag > +16.62 (ABMag)
Classification : 'The spectrum is blue continuum with Balmer lines
at z=0 and resembles that of a cataclysmic variable'
 ( TNS 2022tru )

AT 2022tru - 2022-10-01 (T+24.5d)
Image below (2022-10-01.931) was taken 24.5 days after discovery of 2022tru
Position of reported transient (distinct) is shown by white cross-hairs
Measured magnitude +18.04 (aperture 8)
Annotated CCD Image (100% size, linear scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-01 22:29 UT (#1044030-34)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

AT 2022tru - Reference Image
Position of transient object (not visible in PanSTarrs Image)
is indicated by faint purple cross-hairs
Pan STARRS Background Image captured via Aladin

Images of AT 2022tru on Transients 2022 Page >>

Back to Top


AT 2022vxe - Type YSO? Transient

AT 2022vxe (Cygnus)
AT 2022vxe (Type: YSO?) discovered 2022-09-24.523 UT by Gaia
Alias: Gaia22dzx
Brightening in candidate YSO
Alerting Magnitude 12.34 ( vs historic mag 12.65)
 ( TNS 2022vxe, Gaia22dzx )

AT 2022vxe - 2022-10-02 (T+7.5d)
Image below (2022-10-02.012) was taken 7.5 days after discovery of 2022vxe
Position of reported transient (bright) is shown by white cross-hairs
Measured magnitude +11.74
Annotated CCD Image (100% size, linear scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-02 00:25 UT (#1044117-21)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2022vxe on Transients 2022 Page >>

Back to Top


AT 2022why - Type Nova? Transient

AT 2022why (Cassiopeia)
AT 2022why (Type: Nova?) discovered 2022-09-30.436 UT by Tadashi Kojima
Alias: TCP J23580957+5502503, TCP J23580961+5502508, Gaia22eci
 ( TNS 2022why , Gaia22eci )

AT 2022why - 2022-10-01 (T+1.5d)
Image below (2022-10-01.952) was taken 1.5 days after discovery of 2022why
Position of reported transient (distinctt) is shown by white cross-hairs
Measured magnitude +11.88 (aperture 8)
Annotated CCD Image (100% size, linear scale, cropped)
5 x 60s exposure (average combine), 3x3 binning, Clear Filter
2022-10-01 22:54 UT (#1044047-51)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2022why on Transients 2022 Page >>

Back to Top


IC 1132 - Spiral Galaxy with Type II Supernova 2022prv

IC 1132 with SN 2022prv (Serpens)
SN 2022prv (Type: II) discovered 2022-07-27.320 UT by PS1
Alias: PS22gjh, ZTF22aavobvq, ATLAS22wpl
 ( Rochester Supernova site | TNS 2022prv )

IC 1132 with SN 2022prv - 2022-10-01 (T+66.6d)
Image below (2022-10-01.889) was taken 66.6 days after discovery of 2022prv
Position of SN (faint) is shown by white cross-hairs
Poor quality image (single frame)
Annotated CCD Image (150% size, square root scale, cropped)
180s exposure (single frame), 3x3 binning, Clear Filter
2022-10-01 21:20 UT (#1044006)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022prv (IC 1132) on SN 2022 Page >>

Back to Top


LEDA 1409307 - Galaxy with Type Ia Supernova 2021ucm (Attempt)

LEDA 1409307 with SN 2021ucm (Pegasus)
SN 2021ucm (Type: Ia) discovered 2021-07-25.473 UT by ATLAS
Alias: ATLAS21bchg, Gaia21dqg
Discovery Magnitude +18.607, Orange-ATLAS filter)
 ( TNS 2021ucm | Gaia21dqg)

LEDA 1409307
Annotated CCD Image (150% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-01 23:39 UT (#1044103-06)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

LEDA 1409307 with SN 2021ucm - 2022-10-01 (T+433.5d)
Image below (2022-10-01.981) was taken 433.5 days after discovery of 2021ucm
Position of earlier SN (no longer visible) is shown by white cross-hairs
Annotated CCD Image (150% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-01 23:39 UT (#1044103-06)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022ubb (NGC 7495) on Supernova 2022 Page >>

Back to Top


NGC 157 - Spiral Galaxy with Type Ic Supernova 2022jli

NGC 157 with SN 2022jli (Cetus)
SN 2022jli (Type: Ic) discovered 2022-05-05.170 UT by Berto Monard
Alias: ATLAS22oat, AT2022jzy, Gaia22cbu
Discovery Mag +14.4
 [  Herschel 400 Objects | TNS2022jli | Gaia22cbu  ]

NGC 157 with SN 2022jli - 2022-10-01 (T+149.8d)
Image below (2022-10-01.995) was taken 149.8 days after discovery of 2022jli
Position of SN (distinct) is shown by white cross-hairs
Measured Magnitude +15.61 (aperture 5), +15.37 (aperture 8)
CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-02 00:02 UT (#1044110-14)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022jli (NGC 157) on Supernova 2022 Page >>

Back to Top


NGC 5894 - Spiral Galaxy with Type II Supernova 2022pgf

NGC 5894 with SN 2022pgf (Draco)
SN 2022pgf (Type: II) discovered 2022-07-22.285 UT by ZTF
Alias: ZTF22aauurbv, ATLAS22vul, PS22gvc
 ( Rochester Supernova site | TNS 2022pgf )

NGC 5894 with SN 2022pgf - 2022-10-01 (T+71.6d)
Image below (2022-10-01.905) was taken 71.6 days after discovery of 2022pgf
Position of reported transient (bright) is shown by white cross-hairs
Measured Magnitude +14.72
Annotated CCD Image (125% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-01 21:51 UT (#1044013-17)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022pgf (NGC 5894) on SN 2022 Page >>

Back to Top


NGC 6745 - Spiral Galaxy with Type IIn Supernova 2022prr

NGC 6745 with SN 2022prr (Lyra)
SN 2022prr (Type: IIn) discovered 2022-07-27.300 UT by ASAS-SN
Alias: ASASSN-22jne
Discovery Mag +17.3
 ( Rochester Supernova site | TNS 2022prr )

NGC 6745 with SN 2022prr - 2022-10-02 (T+66.7d)
Image below (2022-10-02.049) was taken 66.7 days after discovery of 2022prr
Position of SN (distinct) is shown by white cross-hairs
Measured magnitude +15.09
Annotated CCD Image (150% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-02 01:19 UT (#1044143-47)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022prr (NGC 6745) on Supernovae 2022 Page >>

Back to Top


NGC 7495 - Spiral Galaxy with Type II Supernova 2022ubb

NGC 7495 with SN 2022ubb (Pegasus)
SN 2022ubb (Type: II, z=0.01628) discovered 2022-09-13.498 UT by ATLAS
Alias: ATLAS22bekt
Discovery Magnitude +18.125 ABMag
 ( TNS 2022ubb )

NGC 7495 with SN 2022ubb - 2022-10-01 (T+18.5d)
Image below (2022-10-01.967) was taken 18.5 days after discovery of 2022ubb
Position of SN (very faint) shown by white cross-hairs
Annotated CCD Image (150% size, square root scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-01 23:16 UT (#1044094-95)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022ubb (NGC 7495) on Supernova 2022 Page >>

Back to Top


UGC 2508 - Spiral Galaxy with Transient AT 2022trp - Attempted Observation

UGC 2508 with AT 2022trp (Eridanus)
AT 2022trp (Type: unk) discovered 2022-09-07.627 UT by PS1
Alias: PS22iaq
Discovery Magnitude +17.86 ABMag
 ( Rochester Supernova site | TNS 2022trp )

UGC 2508 with AT 2022trp - 2022-10-02 (T+24.5d)
Image below (2022-10-02.153) was taken 24.5 days after discovery of 2022trp
Position of reported transient (indistinct) is shown by white cross hairs.
Annotated CCD Image  (175% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-02 03:49 UT (#1044184-88)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2022trp (UGC 2508) on Transients 2022 Page >>

Back to Top


UGC 3923 - Spiral Galaxy with Type Ia Supernova 2022rqc

UGC 3923 with SN 2022rqc (Lynx)
SN 2022rqc (Type: Ia)  discovered 2022-08-20.487 UT by ZTF
Alias: ZTF22abbozja
 ( Rochester Supernova site | TNS 2022rqc )

UGC 3923 - Spiral Galaxy

UGC 3923 with SN 2022rqc - 2022-10-02 (T+42.7d)
Image below (2022-10-02.177) was taken 42.7 days after discovery of 2022rqc
Position of reported supernova is shown by white cross-hairs
Measured magnitude +14.99 (nucleus + transient)  (aperture 8)
Annotated CCD Image (150% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-02 04:22 UT (#1044204-07)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022rqc (UGC 3923) on Supernova 2022 Page >>

Back to Top


UGC 6983 - Spiral Galaxy with Type II Supernova 2022pru

UGC 6983 with SN 2022pru (Ursa Major)
SN 2022pru (Type: II) discovered 2022-07-27.130 UT by ASAS-SN
Alias: ASASSN-22jo
 ( Rochester Supernova site | TNS 2022pru )

UGC 6983 with SN 2022pru - 2022-10-02 (T+66.9d)
Image below (2022-10-02.037) was taken 66.9 days after discovery of 2022pru
Position of SN (faint but distinct) is shown by white cross-hairs
Annotated CCD Image (125% size, square root scale, cropped)
3 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-10-02 00:58 UT (#1044137-39)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022pru (UGC 6983) on Supernovae 2022 Page >>

Back to Top
