David's Astronomy Pages
Images - Session 1079 (2022-12-31)

Objects Session Notes
Bullet Jupiter - Planet
Bullet 73P/Schwassmann-Wachmann - Comet

Bullet AT 2021afdl - CV Type Transient (Attempt)

Bullet M31 2022-12a? - Candidate Extragalactic Nova in M31

Bullet Variable Stars (photometric monitoring)
- None

Bullet Nearby Stars (astrometric monitoring)
- None

- Short pre-dawn session (2.2h), start delayed by wind.

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: -1.5°C (min)
- CCD Temperature:  -25°-30 C
- Notes from 2022-12-31 >>




Jupiter - Planet

Jupiter (passing through Pisces)
Sun Distance 4.95 AU
Earth Distance 5.01 AU (749.0 million km)
(Ra 16.02 arcsec/hr, Dec 7.72 arcsec/hr)

Jupiter
Approx Colour
Approx Colour CCD Image (100% size, cropped, unsharp masked)
Combined BVR Image from 3 images (20 frames):
Blue Channel: 10 x 0.2s exposure, 1x1 binning, B Filter
Green Channel: 10 x 0.12s exposure, 1x1 binning, V Filter
Red Channel: 10 x 0.12s exposure, 1x1 binning, R Filter
2022-12-31 18:19 UT (#1079042-71)
12" LX200R (at f/10.4) + ST-10XME

Approx Colour CCD Image (150% size, cropped, unsharp masked)
Image details as above

Jupiter Moons
Annotated CCD Image (70% size, linear scale)
5 x 0.2s exposure (average combine), 3x3 binning, V Filter
2022-12-31 18:17 UT (#1079037-41)
12" LX200R (at f/10.4) + ST-10XME

Annotated CCD Image (70% size, linear scale)
5 x 0.2s exposure (average combine), 3x3 binning, V Filter
2022-12-31 18:57 UT (#1079177-81)
12" LX200R (at f/10.4) + ST-10XME

Io & Europa Moons
showing movement of moons over a 40 min period
Annotated CCD Image (70% size, linear scale)
5 x 0.2s exposure (average combine), 3x3 binning, V Filter
2022-12-31 18:17 UT (#1079037-41)
12" LX200R (at f/10.4) + ST-10XME

Annotated CCD Image (70% size, linear scale)
5 x 0.2s exposure (average combine), 3x3 binning, V Filter
2022-12-31 18:57 UT (#1079177-81)
12" LX200R (at f/10.4) + ST-10XME


Back to Top


73P/Schwassmann-Wachmann - Comet

73P/Schwassmann-Wachmann
(passing through Aquarius)

Sun Distance 1.89 AU (Receeding)
Earth Distance 2.12 AU (316.6 million km)
Forecast position of comet indicated by white circle
   73P/Schwassmann-Wachmann - 2022-12-31 Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra 82.55 arcsec/hr, Dec 44.62 arcsec/hr)
Poor quality image (poor sky transparency)
Image   Image
Annotated CCD Image (50% size, square root scale)
12 x 45s exposure (average combine), 3x3 binning, Clear Filter
2022-12-31 17:35 UT (#1079007-18)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  Annotated CCD Image (100% size, log scale, cropped)
12 x 45s exposure (average combine), 3x3 binning, Clear Filter
2022-12-31 17:35 UT (#1079007-18)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Images of 73P/Schwassmann-Wachmann on Comets 2022 Page >>

Back to Top


AT 2021afdl - CV Type Transient (Attempt)

AT 2021afdl (Pegasus)
AT 2021afdl (Type: CV) discovered 2021-11-22.240 UT by Gaia
Alias: Gaia21fgm
Alerting magnitude 15.22 (vs Historic magnitude 18.78)
Outburst in candidate CV, previous outburst reported in Gaia15abf
 ( TNS 2021afdl  | Gaia21fgm )

AT 2021afdl - 2022-12-31 (T+404.5d)
Image below (2022-12-31.739) was taken 404.5 days after discovery of 2021afdl
Position of earlier reported transient (not visible) is shown by white circle
Object is likely at it's normal (non-outburst) magnitude level
Annotated CCD Image (100% size, linear scale, cropped)
5 x 60s exposure (average combine), 3x3 binning, Clear Filter
2022-12-31 17:48 UT (#1079022-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2021afdl on Transients 2021 Page >>

Back to Top


M31 2022-12a? - Candidate Extragalactic Nova in M31

M31 with Nova M31 2022-12a? (Andromeda)
Nova M31 2022-12a? (Type: unk) discovered 2022-12-12.489 UT by Koichi Itagaki
Alias: TCP J00411172+4023211
Discovery Mag 17.5
 ( Rochester Latest Extragalactic Novae | Klaus Wenzel image )

Nova M31 2022-12a? - 2022-12-31 (T+19.3d)
Image below (2022-12-31.747) was taken 19.3 days after discovery of Nova M31 2022-12a?
Position of reported candidate nova (faint) is shown by white cross-hairs
Measured magnitude 17.55
Annotated CCD Image (100% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-12-31 18:05 UT (#1079029-33)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of Nova M31 2022-12d? (M31) on Transients 2022 Page >>

Back to Top
