David's Astronomy Pages
|
Images (S1169) |
Images Main |
Home Page |
Images (S1171) |
| 12P/Pons-Brooks - 2023-12-01 (passing through Lyra) Sun Distance 2.38 AU (approaching) Earth Distance 2.59 AU (388.1 million km) |
12P/Pons-Brooks - 2023-12-01 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 69.68 arcsec/hr, Dec -9.98 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, log scale) 90s exposure (single frame), 3x3 binning, Clear Filter 2023-12-01 21:21 UT (#1170101) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, log root scale, cropped) 7 x 90s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 21:27 UT (#1170101-07) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| 12P/Pons-Brooks - 2023-12-01 Detail | 12P/Pons-Brooks - 2023-12-01 Detail | |
 |
 |
|
| Annotated CCD Image (150% size, log scale, cropped) 7 x 90s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 21:27 UT (#1170101-07) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated false-colour CCD Image (50% size, log scale, cropped)) Image details as left |
|
| Images of 12P/Pons-Brooks on Comets 2023 Page >> |
Back to Top
| 73P/Schwassmann-Wachmann - 2023-12-01 (passing through Taurus) Sun Distance 4.10 AU (Receeding) Earth Distance 3.13 AU (468.8 million km) Forecast position of comet indicated by white circle |
73P/Schwassmann-Wachmann - 2023-12-01 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -33.25 arcsec/hr, Dec -3.84 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 3 x 90s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 22:46 UT (#1170149-51) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, log scale, cropped) 9 x 90s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 22:51 UT (#1170149-57) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 73P/Schwassmann-Wachmann on Comets 2023 Page >> |
Back to Top
| 103P/Hartley - 2023-12-02 (passing through Hydra) Sun Distance 1.27 AU AU (receeding) Earth Distance 0.57 AU (85.3 million km) |
103P/Hartley - 2023-12-02 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 8.08 arcsec/hr, Dec -50.01 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 03:49 UT (#1170288-90) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, log scale, cropped) 9 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 03:53 UT (#1170288-96) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 103P/Hartley on Comets 2023 Page >> |
Back to Top
| 144P/Kushida - 2023-12-02 am (passing through Aries) Sun Distance 1.53 AU (approaching) Earth Distance 0.58 AU (86.9 million km) |
144P/Kushida - 2023-12-02 am Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -4.78 arcsec/hr, Dec -19.47 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 9 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 02:02 UT (#1170231-39) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) Image details as left |
|
| Images of 144P/Kushida on Comets 2009 Page >> | ||
| Images of 144P/Kushida on Comets 2023 Page >> |
Back to Top
| C/2017 K2 (PANSTARRS) - 2023-12-02 (passing through Monoceros) Sun Distance 4.35 AU (receeding) Earth Distance 3.52 AU (526.9 million km) |
C/2017 K2 (PANSTARRS) - 2023-12-02 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -41.04 arcsec/hr, Dec 12.99 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 3 x 45s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 03:10 UT (#1170263-65) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, square root scale, cropped) 9 x 45s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 03:13 UT (#1170263-71) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C2017 K2 (PANSTARRS) on Comets 2021 Page >> | ||
| Images of C2017 K2 (PANSTARRS) on Comets 2022 Page >> | ||
| Images of C2017 K2 (PANSTARRS) on Comets 2023 Page >> |
Back to Top
| C/2022 A2 (PANSTARRS) - 2023-12-01 (passing through Aquarius) Sun Distance 3.80 AU (receeding) Earth Distance 3.73 AU (558.1 million km) |
C/2022 A2 (PANSTARRS) - 2023-12-01 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 8.14 arcsec/hr, Dec -14.17 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 17:30 UT (#1170007-11) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) Image details as left |
|
| Images of C/2022 A2 (PANSTARRS) on Comets 2023 Page >> |
Back to Top
| AT 2022qus (Cygnus) AT 2022qus (Type: CV) discovered 2022-08-05.137 UT by Gaia Alias: Gaia22dgk Outburst in known CV MGAB-V821 Discovery Magnitude 16.57 (vs Historic Mag 18.70 to 20.5) Gaia data shows CV has around 10 outburst during the last 8 years. (typical outburst magnitude +16.7 to +17.1) ( TNS 2022qus | Gaia22dgk ) |
| AT 2022qus - 2023-12-01 (T+483.7d) Image below (2023-12-01.789) was taken 483.7 days after discovery of 2022qus No indication of any object at reported position (shown by white cross-hairs) CV has most-likely faded to normal magnitude of +19 to +20 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 18:59 UT (#1170040-44) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022qus on Transients 2022 Page >> |
Back to Top
| AT 2022weo (Aries) AT 2022weo (Type: HPM) discovered 2022-09-27.698 UT by MASTER Alias: MASTER OT J025306.46+165128.4 ( TNS 2022weo ) |
| AT 2022weo - 2023-12-01 (T+430.2d) Image below (2023-12-01.849) was taken 430.2 days after discovery of 2022weo Position of reported transient is shown by white cross-hairs Measured Magnitude +12.70 (Clear Filter) |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 20:26 UT (#1170079-83) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022weo on Transients 2022 Page >> |
Back to Top
| AT 2023qt (Perseus) AT 2023qt (Type: CV) discovered 2023-01-14.916 UT by Gaia Alias: Gaia23ahb Discovery Magnitude 16.80 (G-Gaia Filter) (vs Historic Mag 20.58 +/- 0.23 SD) Outburst in candidate CV ASASSN-17oi ( TNS 2023qt | Gaia23ahb ) |
| AT 2023qt - 2023-12-02 (T+321.1d) Image below (2023-12-02.042) was taken 321.1 days after discovery of 2023qt No indication of any object at reported position (shown by white cross-hairs) Non-Detection, Limiting Mag +18.5 (Clear Filter) CV has most-likely faded to normal magnitude of +20 to +21 |
|
|
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 01:03 UT (#1170210-13) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023qt on Transients 2023 Page >> |
Back to Top
| AT 2023ru (Taurus) AT 2023ru (Type: CV) discovered 2023-01-15.090 UT by ATLAS Alias: ATLAS23aru, ZTF23aaamjwv, Gaia23alh Discovery Magnitude 14.95 (orange-ATLAS Filter) (vs Prior Non-Detection Limiting Mag 19.5) Hostless blue transient Gaia, 2023-01-26 23:11, mag 16.78 Gaia, 2023-03-02 14:50, mag 19.23 ( TNS 2023ru | Gaia23alh ) |
| AT 2023ru - 2023-12-02 (T+321.0d) Image below (2023-12-02.101) was taken 321.0 days after discovery of 2023ru No indication of any object at reported position (shown by white cross-hairs) Non-Detection, Limiting Mag +18.2 (Clear Filter) CV has most-likely faded to normal magnitude of > +19.5 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 02:30 UT (#1170249-51) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023ru on Transients 2023 Page >> |
Back to Top
| AT 2023ayf (Camelopardalis) AT 2023ayf (Type: CV) discovered 2023-01-26.640 UT by XOSS Alias: XM119HT, TCP J04361641+5628241, Gaia23aor Discovery Magnitude 15.13 (Clear Filter) UG candidate classified by XOSS Gaia detection of confirmed CV in 4.5 mag outburst (vs Historic Mag 20.01 +/- 0.25 SD) Gaia, 2023-02-04 22:14, mag 15.45 Gaia, 2023-04-19 20:56, mag 20.02 ( TNS 2023ayf | Gaia23aor ) |
| AT 2023ayf - 2023-12-02 (T+309.5d) Image below (2023-12-02.092) was taken 309.5 days after discovery of 2023ayf No indication of any object at reported position (shown by white cross-hairs) Non-Detection, Limiting Mag +17.7 (Clear Filter) CV has most-likely faded to normal magnitude of +20.0 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 02:15 UT (#1170242-46) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023ayf on Transients 2023 Page >> |
Back to Top
| AT 2023elx (Canis Major) AT 2023elx (Type: CV) discovered 2023-03-30.837 UT by Gaia Alias: Gaia23bir Discovery Magnitude 13.26 (G-Gaia Filter) vs Historic Mag 13.65 +/- 0.08 SD ~0.3 mag rise in Be star Gaia, 2022-03-15 19:07, mag 13.65 Gaia, 2022-10-07 22:28, mag 13.56 Gaia, 2022-11-07 04:11, mag 13.32 Gaia, 2023-03-04 20:14, mag 13.26 Gaia, 2023-11-18 05:22, mag 13.28 ( TNS 2023elx | Gaia23bir ) |
| Open Cluster NGC 2345 with AT 2023elx (T+246.3d) |
 |
| Annotated CCD Image (50% size, linear scale) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 03:27 UT (#1170274-78) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| AT 2023elx - 2023-12-02 (T+246.3d) Image below (2023-12-02.142) was taken 246.3 days after discovery of 2023elx Position of reported transient (distinct) is shown by white cross-hairs Measured Mag +13.39 (Clear Filter) Continue to monitor |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 03:27 UT (#1170274-78) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023elx on Transients 2023 Page >> |
Back to Top
| AT 2023otv (Cassiopeia) AT 2023otv (Type: unk) discovered 2023-08-04.369 UT by ZTF Alias: ZTF23aavxpit, Gaia23cek Discovery Magnitude 15.67 (g-ZTF Filter) vs Prior Non-Detection Limiting Mag 20.02 Gaia, Apparently hostless transient Gaia, 2023-08-31 09:19, mag 17.83 ( TNS 2023otv | Gaia23cek ) |
| AT 2023otv - 2023-12-02 (T+119.6d) Image below (2023-12-02.006) was taken 119.6 days after discovery of 2023otv No indication of any object at reported position (shown by white cross-hairs) Non-Detection, Limiting Mag +18.5 (Clear Filter) Transient most-likely faded to normal magnitude of > +20.0 |
|
|
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 00:15 UT (#1170183-86) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023otv on Transients 2023 Page >> |
Back to Top
| AT 2023rrr (Andromeda) AT 2023rrr (Type: QSO) discovered 2023-09-02.139 UT by Gaia Alias: Gaia23cfc Discovery Magnitude 16.04 (G-Gaia Filter) vs Historic Mag 18.43 +/- 0.778 SD Brightening in known QSO (QSO J0136+4751) Gaia, 2022-02-24 22:20, mag 18.78 Gaia, 2023-08-08 21:24, mag 17.19 Gaia, 2023-09-02 03:20, mag 16.04 Gaia, 2023-12-08 08:00, mag 17.15 Gaia, 2023-12-16 06:19, mag 17.80 ( TNS 2023rrr | Gaia23cfc ) |
| AT 2023rrr - 2023-12-02 (T+90.9d) Image below (2023-12-02.032) was taken 90.9 days after discovery of 2023rrr Position of reported transient (faint but relatively distinct) is shown by white cross-hairs Measured Mag +17.13 (Clear Filter) Continue to monitor |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 00:49 UT (#1170205-06) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023rrr on Transients 2023 Page >> |
Back to Top
| AT 2023srv (Cassiopeia) AT 2023srv (Type: CV) discovered 2023-09-16.171 UT by GEOTS Alias: GEOTS-Balaji-2023-018, TCP J00452678+5512505 Discovery Magnitude 15.7 (Clear Filter) vs Prior Non-Detection Limiting Mag 18 Blue continuum dominated spectrum, with a potentially weak narrow absorption feature of H beta. Considering a probable past outburst in 2013, object is most likely a CV. ( TNS 2023srv ) |
| AT 2023srv - 2023-12-01 (T+76.7d) Image below (2023-12-01.913) was taken 76.7 days after discovery of 2023srv No indication of any object at reported position (shown by white cross-hairs) Non-Detection, Limiting Mag +17.5 (Clear Filter) Transient most-likely faded to normal magnitude around +20.0 to +21.0 Bright star in FOV is HIP 3544 (mag +5.4) |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 21:57 UT (#1170127-29) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Galaxies near AT 2023srv (T+76.7d) Faint galaxies in same FOV as AT 2023srv (faded & no longer visible) are PGC 137158 (catalog mag +17.0), PGC 137157 (catalog mag ?), PGC 1371691(catalog mag ?), PGC 137163 (catalog mag ?) Bright star in FOV is HIP 3544 (mag +5.4) |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 21:57 UT (#1170127-29) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023srv on Transients 2023 Page >> |
Back to Top
| AT 2023tws (Draco) AT 2023tws (Type: CV) discovered 2023-10-01.073 UT by Gaia Alias: Gaia23csd Discovery Magnitude 14.91 (G-Gaia Filter) vs Historic Mag 16.63 +/- 0.33 SD Outburst in known CV Gaia, 2023-10-01 01:45. mag 14.91 Gaia, 2023-10-30 21:15, mag 16.71 Gaia, 2023-12-31 18:43, mag 16.39 ( TNS 2023tws | Gaia23csd ) |
| AT 2023tws - 2023-12-01 (T+61.8d) Image below (2023-12-01.842) was taken 61.8 days after discovery of 2023tws Position of reported transient (faint but relatively distinct) is shown by white cross-hairs Measured Mag +16.30 (Clear Filter) Transient appears to have returned to close to historic mag range (16.30 to 16.99) |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 20:16 UT (#1170072-76) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023tws on Transients 2023 Page >> |
Back to Top
| AT 2023wox (Orion) AT 2023wox (Type: YSO) discovered 2023-10-28.899 UT by Gaia Alias: Gaia23dah Discovery magnitude 16.18 (G-Gaia Filter) vs Historic Magnitude 16.39 +/- 0.06 (SD) Long slow brightening in YSO ( TNS 2023wox | Gaia23dah ) |
| AT 2023wox - 2023-12-02 (T+34.2d) Image below (2023-12-02.066) was taken 34.2 days after discovery of 2023wox Position of reported transient (faint) is shown by white cross-hairs Measured magntitude, Transient + Adjacent Star : +15.38 (Clear Filter) |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 01:43 UT (#1170224-28) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023wox on Transients 2023 Page >> |
Back to Top
| AT 2023wvm (Lacerta) AT 2023wvm (Type: CV) discovered 2023-11-06.736 UT by XOSS Alias: KATS23V003, TCP J22020036+3949356 Discovery Magnitude 16.03 (Clear Filter) Spectrum of a CV, with Balmer lines in absorption, H-beta stronger than H-alpha ( TNS 2023wvm ) |
| AT 2023wvm - 2023-12-01 (T+25.1d) Image below (2023-12-01.797) was taken 25.1 days after discovery of 2023wvm No indication of any object at reported position (shown by white cross-hairs) Non-Detection, Limiting Mag +18.5 (Clear Filter) Transient most-likely faded to normal magnitude of > +20.0 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 19:09 UT (#1170047-51) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023wvm on Transients 2023 Page >> |
Back to Top
| AT 2023xvv (Cygnus) AT 2023xvv (Type: CV) discovered 2023-11-02.121 UT by ZTF Alias: ZTF23aboelln, Gaia23dkh Discovery Magnitude 15.92 (r-ZTF Filter) vs Prior Non-Detection Limiting Mag 17.31 Outburst in candidate CV Gaia, 2023-11-27 14:02, mag 17.82 Gaia, 2023-12-25 05:57, mag 19.99 Gaia, 2024-01-21 05:47, mag 20.76 ( TNS 2023xvv | Gaia23dkh ) |
| AT 2023xvv - 2023-12-01 (T+29.7d) Image below (2023-12-01.774) was taken 29.7 days after discovery of 2023xvv Position of reported transient (faint but relatively distinct) is shown by white cross-hairs Measured Mag +17.68 (Clear Filter) Transient appears to have fading and returning towards probable normal mag range (19.0 to 21.0) |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 18:41 UT (#1170033-36) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023xvv on Transients 2023 Page >> |
Back to Top
| AT 2023xzr (Orion) AT 2023xzr (Type: YSO) discovered 2023-11-08.655 UT by Gaia Alias: Gaia23dcm Discovery magnitude 16.18 (G-Gaia Filter) vs Historic Magnitude 16.39 +/- 0.06 (SD) Long slow brightening in YSO ( TNS 2023xzr | Gaia23dcm ) |
| AT 2023xzr - 2023-12-02 (T+23.4d) Image below (2023-12-02.056) was taken 23.4 days after discovery of 2023xzr Position of reported transient (distinct) is shown by white cross-hairs Measured Magntitude +12.79 (Clear Filter) |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 01:25 UT (#1170219-21) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023xzr on Transients 2023 Page >> |
Back to Top
| AT 2023yen (Canis Minor) AT 2023yen (Type: CV) discovered 2023-11-16.384 UT by Gaia Alias: Gaia23dfz Discovery Magnitude 16.47 (G-Gaia Filter) vs Historic Magnitude 17.64 +/- 0.33 SD Outburst in candidate CV ( TNS 2023yen | Gaia23dfz ) |
| AT 2023yen - 2023-12-02 (T+15.8d) Image below (2023-12-02.149) was taken 15.8 days after discovery of 2023yen Position of reported transient (faint but relatively distinct) is shown by white cross-hairs Measured Mag +17.44 (Clear Filter) Transient appears to have faded back to historic mag range (17.31 to 19.97) |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 03:38 UT (#1170281-85) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023yen on Transients 2023 Page >> |
Back to Top
| CGCG 478-048 with SN 2022xzm (Andromeda) SN 2022xzm (Type: Ic-BL) discovered 2022-10-18.284 UT by ATLAS Alias: ATLAS22bizg, ZTF22abnwpmq Discovery Magnitude 19.12 (cyan-ATLAS Filter) vs Prior Non-Detection Limiting Magnitude 19.63 ( TNS 2022xzm ) |
| CGCG 478-048 with SN 2022xzm - 2023-12-01 (T+409.6d) Image below (2023-12-01.874) was taken 409.6 days after discovery of 2022xzm Position of earlier supernova (faded & no longer visible) is shown by white cross-hairs Non-Detection Limiting Mag +18.5 (Clear Filter) |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 21:06 UT (#1170093-97) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022xzm on Supernova 2022 Page >> |
Back to Top
|
M33 with AT 2023nou (Triangulum) |
|
M33 with AT 2023nou - 2023-12-01 (T+134.4d) Image below (2023-12-01.821) was taken 134.4 days after discovery of 2023nou Position of reported transient (very faint) is shown by whiIte cross-hairs Measured Magnitude +17.07(Clear Filter) |
|
|
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 19:50 UT (#1170060-64) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023nou (in M33) on Transients 2023 Page >> |
Back to Top
| M101 with SN 2023ixf (Ursa Major) SN 2023ixf (Type: IIL) discovered 2023-05-19.727 UT by Koichi Itagaki Alias: ZTF23aaklqou, AT2023iyi, AT2023jgd, AT2023jfz, PSN J14033858+5418421, PS23dij Discoverer Mag 14.9 (Clear filter) ( Rochester Supernova site | TNS 2023ixf ) SN 2023ixf (Type: IIL) discovered 2023-05-19.727 UT by Koichi Itagaki at Mag 14.9 is located near M101's prominant star-forming region NGC 5461. The supernova resulted from a exploding red supergiant and lies just 21 million light years away. It's the closest core-collapse supernova to us since SN 1993J which lit up M81 (some 12 million ly away) in Spring 1993. The SN is designated of type II-L (L for 'linear') , which is characterised by a rapid rise to maximum brightness followed by a slow and gradual decrease, that is thought to be brought about by ejection of the dead stars' outer hydrogen shell. (from Article "Summer's Super Supernova", AstNow Magazine, Sep 2023, pp 36-39) |
| M101 with SN 2023ixf - 2023-12-02 (T+196.5d) Image below (2023-12-02.252) was taken 196.5 days after discovery of 2023ixf Position of supernova (fading but still distinct) is shown by white cross-hairs Measured Magnitude +14.40 (Clear Filter) |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 06:11 UT (#1170342-46) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2023ixf (M101) on Supernova 2023 Page |
Back to Top
| NGC 899 (Cetus) Alias: UGCA 26 (PGC 8990, catalog mag +13.3) [ UGCA Galaxies ] [ Irregular Galaxies ] Poor quality image (poor seeing & bright sky background) Target to be rescheduled for a later session |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 23:12 UT (#1170161-65) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| NGC 1051 (Cetus) Alias: UGCA 40 ( PGC 10128, catalog mag +13.4 or +12.8 Low Surface Brightness (LSB) Galaxy [ UGCA Galaxies ] Poor quality image (uneven sky background) Target to be rescheduled for a later session |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 22:30 UT (#1170141-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| NGC 1145 (Eridanus) Alias: UGCA 45, PGC 10965 (catalog mag +13.7 or +12.9) Flat Galaxy Catalog Member [ UGCA Galaxies ] [ Flat Galaxies ] |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 23:34 UT (#1170168-72) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 1145 - Detail |
 |
| Annotated CCD Image (125% size, square root scale, cropped) Image details as above |
Back to Top
| NGC 2345 (Canis Major) [ Open Star Clusters ] |
 |
| Annotated CCD Image (70% size, linear scale) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 03:27 UT (#1170274-78) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 2345 with AT 2023elx (T+246.3d) |
|
|
| Annotated CCD Image (50% size, linear scale) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 03:27 UT (#1170274-78) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| NGC 3893 with AT 2023uhx (Ursa Major) AT 2023uhx (Type: LRN) discovered 2023-10-07.816 UT by Koichi Itagaki Discovery magnitude 17.2 (Clear filter) vs DSS Archival Image Luminous Red Nova based on its peak luminosity, and narrow Balmer and Fe II emission lines. ( TNS 2023uhx) |
| NGC 3893 with AT 2023uhx - 2023-12-02 (T+55.4d) Image below (2023-12-02.238) was taken 55.4 days after discovery of 2023uhx Position of reported transient (faint) is shown by white cross-hairs Measured magnitude +17.30 (Clear Filter) |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 05:52 UT (#1170335-39) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023uhx (NGC 3893) on Transients 2023 Page >> |
Back to Top
| NGC 4568 with SN 2023ijd (Virgo) SN 2023ijd (Type: II) discovered 2023-05-14.200 UT by ASAS-SN Alias: ASASSN-23du, PS23den, ZTF23aajrmfh Discovery Magnitude 16.8 (g-Sloan Filter) ( TNS 2023ijd ) |
| NGC 4568 with SN 2023ijd - 2023-12-02 (T+202.0d) Image below (2023-12-02.192) was taken 202.0 days after discovery of 2023ijd Position of earlier reported SN (very faint) is indicated by white cross-hairs. Estimated Magnitude +17.5 (Clear Filter) |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 04:44 UT (#1170313-16) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2023ijd (in NGC 4568) on Supernova 2023 Page >> |
Back to Top
| NGC 4605 (Ursa Major) Alias: Hidden Treasures 66 [ Hidden Treasures ] |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 23:57 UT (#1170176-80) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 4605 - Detail |
 |
| Annotated CCD Image (125% size, square root scale, cropped) Image details as above |
 |
| Negative CCD Image (125% size, square root scale, cropped) Image details as above |
 |
| False Colour CCD Image (125% size, square root scale, cropped) Inverse Spectrum Image details as above |
Back to Top
| NGC 5532 with SN 2023omo (Bootes) SN 2023omo (Type: Ia-91bg) discovered 2023-08-04.267 UT by PS1 Alias: PS23gag Discovery magnitude 18.34 (r-P1 filter) ( TNS 2023omo) |
| NGC 5532 - Spiral Galaxy NGC 5532 (catalog mag +11.9) With other galaxies in FOV: NGC 5532A (catalog mag +13.3), NGC 5531 (catalog mag +13.3) PGC 3091164 (catalog mag +16.1), PGC 1385124 (catalog mag +17.1) PGC 1386037 (catalog mag +17.2), PGC 1384516 (catalog mag +17.2) PGC 1383698 (catalog mag +17.6), PGC 1383540 (catalog mag +18.2) |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 05:30 UT (#1170328-32) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 5532 with SN 2023omo - 2023-12-02 (T+120.0d) Image below (2023-12-02.223) was taken 120.0 days after discovery of 2023omo Position of reported supernova (not visible) is shown by white cross-hairs |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 05:30 UT (#1170328-32) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2023omo (NGC 5532) on Supernovae 2023 Page >> |
Back to Top
| NGC 6745 with SN 2023ucy (Lyra) SN 2023ucy (Type: II) discovered 2023-10-05.151 UT by ZTF Alias: ZTF23abhzxwm Discovery Mag +17.9 (r-ZTF filter) vs last non-detection image with 19.91 limiting mag It is noted that SN 2022prr (19:01:41.897, +40:45:03.67) occurred in Jul 2022 at approximately the same location as this newly reported transient 2023ucy (19:01:41.992, +40:45:05.89) (are they possibly related ?) ( TNS 2023ucy ) ( TNS 2022prr ) |
| NGC 6745 with SN 2023ucy - 2023-12-01 (T+57.6d) Image below (2023-12-01.735) was taken 57.6 days after discovery of 2023ucy Position of SN (distinct, brightening slightly?) is shown by white cross-hairs Measured magnitude +14.74 |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 17:46 UT (#1170014-18) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2023ucy (NGC 6745) on Supernovae 2023 Page >> |
Back to Top
| Tr 37 (Cepheus) Alias: Hidden Treasures 105 Surrounded by the nebulosity of an emission nebula (IC 1396) Note: Nebula feature near Cep V0390 on right hand side Bright star in centre of image is mutiple star HIP 106884 / Struve 2816 / HIP 106884 (mag +5.7) [ Hidden Treasures ] |
 |
| CCD Image Mosaic (26% size, linear scale) Mosaic 3x3, 90s exposure (single frame), 3x3 binning, Clear Filter 2023-12-01 18:16 UT (#1170021-29) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 [ Larger Image, 50% size ] |
| Later Image of GCVS V0390 Cep (Cepheus) Nebula feature identified from interesting Point 6 frame from TR 37 Mosaic (S1170) |
 |
| Annotated CCD Image (70% size, square root scale) 7 x 120s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 19:02 UT (#1171033-39) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Tr 37 Cam2 Reference Image Limits of Tr 37 is shown by blue circle |
 |
| Annotated CMOS Image (16% size) (10s exposure, 1x1 binning) 2023-12-01 18:14 UT TS 80mm APO, ZWO ASI178MC |
Back to Top
| UGC 68 with SN 2023xqn (Pegasus) SN 2023xqn (Type: Ia) discovered 2023-11-13.222 UT by ATLAS Alias: ATLAS23vno Discovery magnitude 18.17 (cyan-ATLAS Filter) ( TNS 2023xqn ) |
| UGC 68 with SN 2023xqn - 2023-12-01 (T+18.6d) Image below (2023-12-01.863) was taken 18.6 days after discovery of 2023xqn Position of reported SN (not clearly distinguishable) is shown by white cross-hairs Measure Magnitude +14.64 (Clear Filter) - Nucleus + SN Small adjacent galaxy PGC 73260 (catalog mag +17.0) |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 20:47 UT (#1170088-90) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2023xqn (in UGC 68) on Supernova 2023 Page >> |
Back to Top
|
UGC 530 with SN 2023yma (Andromeda) |
|
UGC 530 with SN 2023yma - 2023-12-01 (T+6.4d) Image below (2023-12-01.803) was taken 6.4 days after discovery of 2023yma Position of reported supernova (faint but distinct) is shown by white cross-hairs Position of reported supernova (faint but distinct) is shown by white cross-hairs |
|
|
|
Annotated CCD Image (175% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-01 19:26 UT (#1170053-57) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2023yma (in UGC 530) on Supernova 2023 Page >> |
Back to Top
| UGC 3174 with SN 2023mut (Orion) SN 2023mut (Type: IIb) discovered 2023-07-11.180 UT by ASAS-SN / GOTO Group Alias: ASASSN-23fh Discovery Magnitude 15.2 (g-SLOAN Filter) ( TNS 2023mut ) |
| UGC 3174 with SN 2023mut - 2023-12-02 (T+143.9d) Image below (2023-12-02.120) was taken 143.9 days after discovery of 2023mut Position of reported SN (distinct, fading slightly?) is indicated by white cross-hairs. Measured Magnitude +16.01 (Clear Filter) |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 02:57 UT (#1170258-60) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2023mut (in UGC 3174) on Supernova 2023 Page >> |
Back to Top
| UGC 6265 with SN 2023wcw (Ursa Major) SN 2023wcw (Type: Ia-91T, z= 0.032834) discovered 2023-11-01.491 UT by ZTF Alias: ZTF23abnoilr Discovery Magnitude 17.14 (r-ZTF Filter) ( TNS 2023wcw ) |
| UGC 6265 with SN 2023wcw - 2023-12-02 (T+30.7d) Image below (2023-12-02.177) was taken 30.7 days after discovery of 2023wcw Position of reported supernova (fading) is shown by white cross-hairs Measured Mag +15.85 (Clear filter) |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 04:24 UT (#1170305-09) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2023wcw (in UGC 6265) on Supernova 2023 Page >> |
Back to Top
| UGC 8927 with AT 2023qzg (Bootes) AT 2023qzg (Type: unk) discovered 2023-08-28.719 UT by ATLAS Alias: ATLAS23rtj, Gaia23cgg Discovery Mag 17.50 (ornage-ATLAS filter) Candidate SN (not confirmed) near galaxy UGC 8927 Gaia: 2023-09-05 02:56 17.67 Gaia: 2023-11-30 03:45 20.32 Gaia: 2023-12-04 09:50 20.32 ( TNS 2023qzg | Gaia23cgg ) |
| UGC 8927 with AT 2023qzg - 2023-12-02 (T+95.5d) Image below (2023-12-02.269) was taken 95.5 days after discovery of 2023qzg Position of earlier transient (not visible, faded) is shown by white cross-hairs Non Detection, limiting magnitude +18.5 (Clear Filter) (Gaia reports mag +20.32 on 2023-12-02 ) |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 06:36 UT (#1170349-53) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2023qzg (UGC 8927) on Transients 2023 Page >> |
Back to Top
| UGC 9002 with SN 2023pls (Bootes) SN 2023pls (Type: II) discovered 2023-08-14.976 UT by ATLAS Alias: ATLAS23red, Gaia23cbq Discovery Magnitude 17.54 (cyan-ATLAS) z (redshift) = 0.0136 ( TNS 2023pls | Gaia23cbq ) |
| UGC 9002 with SN 2023pls - 2023-12-02 (T+109.2d) Image below (2023-12-02.208) was taken 109.2 days after discovery of 2023pls Position of reported SN (very faint & fading) is indicated by white cross-hairs. Measured Magnitude +17.52 (Clear Filter) |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-12-02 05:08 UT (#1170320-24) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2023pls (in UGC 9002) on Supernova 2023 Page >> |
Back to Top
| This Web Page: | Images - Session 1170 (2023-12-01) |
| Last Updated : | 2024-06-15 |
| Site Owner : | David Richards |
| Home Page : | David's Astronomy Web Site |
