C/2021 O3 (PANSTARRS) - 2024-10-02 (passing through Lyra) Sun Distance 9.95 AU (receeding) Earth Distance 9.82 AU (1,469.5 million km) Expected position of comet (not visible) is shown by white circle |
C/2021 O3 (PANSTARRS) - 2024-10-02, Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 2.24 arcsec/hr, Dec -12.53 arcsec/hr) Expected position of comet (not visible) is shown by white circle |
|
Annotated CCD Image (50% size, square root scale) 6 x 90s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 21:29 UT (#1250035-41) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, square root scale, cropped) Image details as left |
|
Images of C/2021 O3 (PANSTARRS) on Comets 2024 Page >> |
Back to Top
C/2021 S3 (PANSTARRS) - 2024-10-02 (passing through Cygnus) Sun Distance 3.32 AU (receeding) Earth Distance 2.95 AU (440.9 million km) |
C/2021 S3 (PANSTARRS) - 2024-10-02 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 30.68 arcsec/hr, Dec -39.76 arcsec/hr) |
|
Annotated CCD Image (50% size, square root scale) 6 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 20:38 UT (#1250013-18) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) Image details as left |
|
Images of C/2021 S3 (PANSTARRS) on Comets 2024 Page >> |
Back to Top
T CrB (Corona Borealis) Alias: GCVS T CrB, HIP 78322, SAO 84129, HD 143454 Max Magnitude 2.0 Min Magnitude 10.8 Spectral: M3III+pec(NOVA) ( VSX T CrB ) |
T CrB (V Band) - 2024-10-02 (S1250) | T CrB - Photometry - 2024-10-02 | |
2024-10-02 20:27 UT Altitude: 28.6°, Airmass: 2.088 T CrB : 10.12 (V Mag), 11.25 (B Mag), 1.13 (B-V) |
||
Annotated CCD Image (50% size, linear scale) 3 x 20s exposure (average combine), 3x3 binning, V Filter 2024-10-02 20:27 UT (#1250006-10) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (not shown) 3 x 30s exposure (average combine), 3x3 binning, B Filter 2024-10-02 20:26 UT (#1250005-09) |
|
More Images & Data for T CrB >> |
Back to Top
AT 2022bvd (Cygnus) AT 2022bvd (Type: CV) discovered 2022-02-08.386 UT by Gaia Alias: Gaia22anh Discovery Magnitude 14.39 (G-Gaia Filter) vs Historic Magnitude 14.70 +/- 0.06 SD ~0.3 mag rise in Gaia source ( TNS 2022bvd | Gaia22anh ) |
AT 2022bvd - 2024-10-02 (T+967.5d) Image below (2024-10-02.883) was taken 967.5 days after discovery of 2022bvd Position of earlier transient (faint but distinct) is shown by white cross-hairs Measured Magnitude +13.91 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 21:14 UT (#1250029-32) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2022bvd on Transients 2022 Page >> |
Back to Top
AT 2022dbd (Triangulum) AT 2022dbd (Type: CV) discovered 2022-02-21.847 UT by Gaia Alias: Gaia22ast Discovery Magnitude 16.46 (G-Gaia Filter) vs Historic Magnitude 17.99 +/- 0.09 SD 2 mag outburst in candidate CV ZTF18abunevo ( TNS 2022dbd | Gaia22ast ) |
AT 2022dbd - 2024-10-03 (T+954.2d) Image below (2024-10-03.035) was taken 954.2 days after discovery of 2022dbd Position of earlier transient (very faint) is shown by white cross-hairs Measured Magnitude +17.71 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 00:54 UT (#1250134-38) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2022dbd on Transients 2022 Page >> |
Back to Top
AT 2022req (Cygnus) AT 2022req (Type: YSO) discovered 2022-08-11.575 UT by Gaia Alias: Gaia22diw Alerting Mag +16.75 (vs historic magnitude 18.06) >2mag brightening in known EXOR variable MGAB-V336 ( TNS 2022req | Gaia22diw ) |
AT 2022req - 2024-10-03 (T+783.5d) Image below (2024-10-03.119) was taken 783.5 days after discovery of 2022req Position of earlier transient (faded / not visible) is shown by white circle |
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 03:00 UT (#1250199-203) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2022req - Detail (T+783.5d) Position of earlier transient (faded / not visible) is shown by white cross-hairs |
Annotated CCD Image (175% size, linear scale, cropped) Images details as above |
Images of AT 2022req on Transients 2022 Page >> |
Back to Top
AT 2022vdr (Orion) AT 2022vdr (Type: CV) discovered 2022-09-20.378 UT by MASTER Alias: MASTER OT J052749.27+064639.1 Discovery Mag 14.8 (Clear Filter) ( TNS 2022vdr ) |
AT 2022vdr - 2024-10-03 (T+743.8d) Image below (2024-10-03.182) was taken 743.8 days after discovery of 2022vdr Position of reported transient (distinct) is shown by white cross-hairs Measured magnitude +13.37 |
Annotated CCD Image (100% size, linear scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 04:25 UT (#1250228-31) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2022vdr on Transients 2022 Page >> |
Back to Top
AT 2022abjt (Andromeda) AT 2022abjt (Type: unk) discovered 2022-11-21.181 UT by ZTF Alias: ZTF22abvnzrz Discovery Mag +15.9 (g-ZTF filter) ( TNS 2022abjt ) |
AT 2022abjt - 2024-10-03 (T+681.9d) Image below (2024-10-03.071) was taken 681.9 days after discovery of 2022abjt Position of transient (not visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +19.5 (Clear Filter) |
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 01:51 UT (#1250162-66) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2022abjt - Earlier Image 2022-11-29 (T+8.6d) Image below (2022-11-29.779) was taken 8.6 days after discovery of 2022abjt Position of transient is shown by white cross-hairs Measured magnitude +16.23 |
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 18:50 UT (#1065030-34) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2022abjt on Transients 2022 Page >> |
Back to Top
AT 2023ba (Vulpecula) AT 2023ba (Type: CV) discovered 2023-01-04.709 UT by Gaia Alias: Gaia23aci Discovery Magnitude 14.92 (G-Gaia Filter) vs Historic Magnitude 15.09 +/- 0.03 SD 0.2 mag brightening in previously constant source, candidate Be star outburst ( TNS 2023ba | Gaia23aci ) |
AT 2023ba - 2024-10-02 (T+637.2d) Image below (2024-10-02.927) was taken 637.2 days after discovery of 2023ba Position of earlier transient (faint) is shown by white cross-hairs Measured Magnitude +15.00 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 22:17 UT (#1250058-62) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023ba on Transients 2023 Page >> |
Back to Top
AT 2023in (Cygnus) AT 2023in (Type: YSO?) discovered 2023-01-11.955 UT by Gaia Alias: Gaia23afz Discovery magnitude 16.27 (G-Gaia filter) vs Historic Mag 16.82 +/- 0.10 SD Candidate YSO in 0.6 mag outburst ( TNS 2023in | Gaia23cse ) |
AT 2023in - 2024-10-02 (T+629.9d) Image below (2024-10-02.867) was taken 629.9 days after discovery of 2023in Position of earlier reported transient (faint) is shown by white cross-hairs Measured magntitude +16.72 (Clear Filter) |
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 20:57 UT (#1250022-26) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023in on Transients 2023 Page >> |
Back to Top
AT 2023cuj (Aquila) AT 2023cuj (Type: ulens?) discovered 2023-03-06.713 UT by Gaia Alias: Gaia23bad Discovery magnitude 14.83 (G-Gaia filter) vs Historic Mag 15.11 +/- 0.07 SD bright red gal.plane source candidate microlensing event or Be-type outburst rises by 0.3 mag ( TNS 2023cuj | Gaia23bad ) |
AT 2023cuj - 2024-10-02 (T+576.2d) Image below (2024-10-02.903) was taken 576.2 days after discovery of 2023cuj Position of earlier reported transient (faint but distinct) is shown by white cross-hairs Measured magntitude +14.98 (Clear Filter) |
Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 21:49 UT (#1250044-48) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023cuj on Transients 2023 Page >> |
Back to Top
AT 2023rrr (Andromeda) AT 2023rrr (Type: QSO) discovered 2023-09-02.139 UT by Gaia Alias: Gaia23cfc Discovery Magnitude 16.04 (G-Gaia Filter) vs Historic Mag 18.43 +/- 0.778 SD Brightening in known QSO (QSO J0136+4751) Gaia, 2022-02-24 22:20, mag 18.78 Gaia, 2023-08-08 21:24, mag 17.19 Gaia, 2023-09-02 03:20, mag 16.04 Gaia, 2023-12-08 08:00, mag 17.15 Gaia, 2023-12-16 06:19, mag 17.80 ( TNS 2023rrr | Gaia23cfc ) |
AT 2023rrr - 2024-10-03 (T+397.0d) Image below (2024-10-03.151) was taken 397.0 days after discovery of 2023rrr Position of reported transient (very faint, fading) is shown by white cross-hairs Measured Magnitude +18.18 (Clear Filter) |
Annotated CCD Image (100% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 03:45 UT (#1250214-17) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2023rrr - Earlier Image 2023-11-15 (T+74.8d) Image below (2023-11-15.976) was taken 74.8 days after discovery of 2023rrr Position of reported transient (faint but relatively distinct) is shown by white cross-hairs Measured Magnitude +17.26 (Clear Filter) |
Annotated CCD Image (100% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-11-15 23:33 UT (#1167209-13) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023rrr on Transients 2023 Page >> |
Back to Top
AT 2023aanv (Cygnus) |
AT 2023aanv - 2024-10-02 (T+288.3d) Image below (2024-10-02.981) was taken 288.3 days after discovery of 2023aanv Position of reported transient (fading) is shown by white cross-hairs Measured Magnitude +15.45 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 23:35 UT (#1250102-05) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2023aanv - Earlier Image 2023-12-26 (T+7.1d) Image below (2023-12-26.742) was taken 7.1 days after discovery of 2023aanv Position of reported transient (distinct) is shown by white cross-hairs Measured Magnitude +12.65 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2023-12-26 17:51 UT (#1177019-23) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023aanv on Transients 2023 Page >> |
Back to Top
AT 2024qe (Vulpecula) AT 2024qe (Type: CV) discovered 2024-01-04.750 UT by Gaia Alias: Gaia24adm Discovery Magnitude 14.46 (G-Gaia Filter) vs Historic Magnitude 14.66 +/- 0.03 SD ~0.2 mag rise in Gaia source ( TNS 2024qe | Gaia24adm ) |
AT 2024qe - 2024-10-02 (T+272.2d) Image below (2024-10-02.919) was taken 272.2 days after discovery of 2024qe Position of earlier transient (visible) is shown by white cross-hairs Measured Magnitude +14.52 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 22:06 UT (#1250051-55) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024qe on Transients 2024 Page >> |
Back to Top
AT 2024vk (Vulpecula) AT 2024vk (Type: YSO?) discovered 2024-01-08.325 UT by Gaia Alias: Gaia24afb Discovery Magnitude 15.57 (G-Gaia Filter) vs Historic Magnitude 16.69 +/- 0.43 SD Brightening in candidate YSO ( TNS 2024vk | Gaia24afb ) |
Star field with AT 2024vk (T+268.6d) Transients lies within an area of overlapping dark nebula Dobashi 2053 & Dobashi 2055 |
|
Annotated CCD Image (70% size, linear scale) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 23:17 UT (#1250094-97) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024vk - 2024-10-02 (T+268.6d) Image below (2024-10-02.965) was taken 268.6 days after discovery of 2024vk Position of earlier transient (visible) is shown by white cross-hairs Measured Magnitude +17.89 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 23:17 UT (#1250094-97) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024vk on Transients 2024 Page >> |
Back to Top
AT 2024exg (Vulpecula) AT 2024exg (Type: CV) discovered 2024-03-20.837 UT by MASTER Alias: MASTER OT J210334.57+234127.7 Discovery Magnitude 14.8 (Clear Filter) vs Prior Non-Detection Limiting Magnitude 17.7 ( TNS 2024exg ) |
AT 2024exg - 2024-10-02 (T+196.2d) Image below (2024-10-02.989) was taken 196.2 days after discovery of 2024exg Position of earlier transient (not visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +18.6 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 23:47 UT (#1250108-12) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024exg on Transients 2024 Page >> |
Back to Top
AT 2024ger (Cygnus) AT 2024ger (Type: YSO) discovered 2024-04-02.736 UT by Gaia Alias: Gaia24beh Discovery Magnitude 15.57 (G-Gaia Filter) vs Historic Magnitude 16.69 +/- 0.43 SD Brightening in candidate YSO ( TNS 2024ger | Gaia24beh ) |
Star field with AT 2024ger (T+183.2d) Transients lies within an area of overlapping dark nebula |
|
Annotated CCD Image (70% size, linear scale) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 22:37 UT (#1250066-69) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024ger - 2024-10-02 (T+183.2d) Image below (2024-10-02.938) was taken 183.2 days after discovery of 2024ger Position of earlier transient (faint) is shown by white cross-hairs Measured Magnitude +17.39 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 22:37 UT (#1250066-69) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024ger on Transients 2024 Page >> |
Back to Top
AT 2024uxx (Gemini) AT 2024uxx (Type: CV?) discovered 2024-09-07.458 UT by GEOTS Alias: GEOTS-Balaji-2024-020, TCP J06090425+2552403, GOTO24fst, ATLAS24nzp Discovery Magnitude 15.4 (Clear Filter) ( TNS 2024uxx ) |
AT 2024uxx - 2024-10-03 (T+25.6d) Image below (2024-10-03.094) was taken 25.6 days after discovery of 2024uxx Position of earlier transient (not visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +18.7 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 02:22 UT (#1250180-83) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024uxx on Transients 2024 Page >> |
Back to Top
AT 2024woi (Pisces) Alias: In WISEA J001433.08+010055.6 AT 2024woi (Type: MP?) discovered 2024-09-25.158 UT by GOTO Alias: GOTO24ggm Discovery Magnitude 15.02 (L-GOTO Filter) vs Prior Non-Detection Limiting Magnitude 19.7 ( TNS 2024woi ) |
WISEA J001433.08+010055.6 - Galaxy with adjacent galaxies PGC 1183404 (catalog mag +16.4) & PGC 1183548 (catalog mag +16.8) |
|
Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 01:10 UT (#1250141-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024woi - 2024-10-03 (T+7.9d) Image below (2024-10-03.042) was taken 7.9 days after discovery of 2024woi Position of reported transient (not visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +18.7 (Clear Filter) |
|
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 01:10 UT (#1250141-45) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024woi on Transients 2024 Page >> |
Back to Top
AT 2024wqf (Pegasus) |
AT 2024wqf - 2024-10-03 (T+8.9d) Image below (2024-10-03.132) was taken 8.9 days after discovery of 2024wqf Position of reported transient (distinct, fading?) is shown by white cross-hairs Measured Magnitude +14.19 (Clear Filter) |
|
Annotated CCD Image (100% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 03:20 UT (#1250206-10) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024wqf on Transients 2024 Page >> |
Back to Top
AT 2024wxp (Gemini) |
AT 2024wxp - 2024-10-03 (T+6.5d) Image below (2024-10-03.190) was taken 6.5 days after discovery of 2024wxp Position of reported transient (faint, not totally distinguishable) is shown by white cross-hairs Measured Magnitude +15.32 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 04:35 UT (#1250233-35) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024wxp - Detail (T+6.5d) |
|
Annotated CCD Image (175% size, linear scale, cropped) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 04:35 UT (#1250233-35) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024wxp on Transients 2024 Page >> |
Back to Top
Dobashi 2055 (Vulpecula) |
|
Annotated CCD Image (70% size, square root scale) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 23:17 UT (#1250094-97) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
IC 564 with SN 2023abqf (Sextans) SN 2023abqf (Type: Ia) discovered 2023-12-26.492 UT by ATLAS Alias: ATLAS23xws, Gaia24adb Discovery Magnitude 18.23 (orange-ATLAS Filter) Confirmed SN Ia Gaia, 2023-12-24 20:22 , 19.42 (pre-discovery) Gaia, 2024-01-04 08:30, 16.01 ( TNS 2024gy | Gaia24adb ) |
IC 564 with SN 2023abqf - 2024-10-03 (T+281.7d) Image below (2024-10-03.195) was taken 281.7 days after discovery of 2023abqf Position of reported SN (not visible) is indicated by white cross-hairs. Poor quality image (cloud/uneven sky background, low S/N ) Altitude: 16.0°, Airmass: 3.62 |
Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 04:50 UT (#1250238-42) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2023abqf (in IC 564) on Supernova 2023 Page >> |
Back to Top
LEDA 899041 with SN 2023pbf (Eridanus) SN 2023pbf (Type: II) discovered 2023-08-12.027 UT by ATLAS Alias: ATLAS23qsf, ZTF23abaebbd Discovery Magnitude 16.55 (orange-ATLAS Filter) vs Prior Non-Detection Limiting Magnitude 18.71 ( TNS 2023pbf ) |
LEDA 899041 with SN 2023pbf - 2024-10-03 (T+418.1d) Image below (2024-10-03.165) was taken 418.1 days after discovery of 2023pbf Position of reported SN (not visible) is indicated by white cross-hairs. Non-Detection Limiting Magnitude +18.6 (Clear Filter) |
Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 04:07 UT (#1250220-24) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2023pbf (in LEDA 899041) on Supernova 2023 Page >> |
Back to Top
M31 with Nova M31 AT 2023uiq (Andromeda) AT 2023uiq (Type: EGN) discovered 2023-10-07.766 UT by MASTER Alias: XM115MZ, MASTER OT J004148.67+413121.6, PNV J00414869+4131212, ZTF23abiwrwo, ATLAS23twx Discovery Magnitude 16.55 (orange-ATLAS Filter) ( TNS 2023pbf ) |
Nova M31 AT 2023uiq - 2024-10-03 (T+361.3d) Image below (2024-10-03.027) was taken 361.3 days after discovery of 2023uiq Position of reported SN (not visible) is indicated by white cross-hairs. Non-Detection Limiting Magnitude +18.5 (Clear Filter) |
Annotated CCD Image (125% size, square root scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-03 00:42 UT (#1250130-31) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023uiq (in M31) on Transients 2023 Page >> |
Back to Top
MCG -1-56-5 with SN 2022acxe (Aquarius) SN 2022acxe (Type: Ia) discovered 2022-12-15.214 UT by ATLAS Alias: ATLAS22bnrh, ZTF22abywkap, MASTER OT J221848.22-032921.2 Discovery Magnitude 18.19 (cyan-ATLAS Filter) vs Prior Non-Detection Limiting Magnitude 18.31 ( TNS 2022acxe ) |
MCG -1-56-5 - Spiral Galaxy MCG -1-56-5 (alias PGC 68549 catalog mag +14.2) with faint adjacent galaxies PGC 191900 (catalog mag +16.1), PGC 1070345 (catalog mag +16.4), PGC 191908 (catalog mag +16.7), PGC 1070754 (catalog mag +16.8) |
Annotated CCD Image (50% size, square root scale) 180s exposure (single frame), 3x3 binning, Clear Filter 2024-10-03 00:19 UT (#1250125) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
MCG -1-56-5 with SN 2022acxe - 2024-10-03 (T+657.8d) Image below (2024-10-03.013) was taken 657.8 days after discovery of 2022acxe Position of 2022 SN (not visible / very probably faded) is indicated by white cross-hairs. Non-Detection Limiting Magnitude +17.8 (Clear Filter) Poor quality image (cloud/ single frame) |
Annotated CCD Image (125% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2024-10-03 00:19 UT (#1250125) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2022acxe (in MCG -1-56-5) on Supernova 2022 Page >> |
Back to Top
WISEA J193608.91+454141.5 (Cygnus) |
Annotated CCD Image (100% size, square root scale, cropped) 6 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 20:38 UT (#1250013-18) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
WISEA J193608.91+454141.5 - Detail |
Annotated CCD Image (175% size, square root scale, cropped) Image details as above |
Back to Top
