Saturn - 2024-10-01 (passing through Aquarius) Sun Distance 9.66 AU Earth Distance 8.74 AU (1307.7 million km) Motion : (Ra -9.35 arcsec/hr, Dec -3.68 arcsec/hr) |
||||||||||||||||||||||||||||||||||||||||
Saturn with moons Image is shown with a contrast that highlights the main moons of Saturn however with this contrast setting Saturn appears significantly glared Saturn is 7.8 mag (~1300x) brighter than the brightest moon (Titann) Insert shows Saturn with a contrast that highlights the planet (at expense of the moons) |
||||||||||||||||||||||||||||||||||||||||
Annotated CCD Image (150% size, square root scale, cropped) 8 x 0.11s exposure (average combine), 3x3 binning, V Filter 2024-10-01 22:56 UT (#1249146-55) 12" LX200R (at f/10.4) + ST-10XME |
||||||||||||||||||||||||||||||||||||||||
Saturn with moons (annotated) - Composite Image Magnitudes from TheSky6
|
||||||||||||||||||||||||||||||||||||||||
Annotated CCD Image (50% size, square root scale, cropped) Image details as above |
||||||||||||||||||||||||||||||||||||||||
Annotated CCD Image (150% size, square root scale, cropped) Image details as above |
||||||||||||||||||||||||||||||||||||||||
Saturn | ||||||||||||||||||||||||||||||||||||||||
Annotated Colour CCD Image (150% size, linear scale, cropped) Colour Combined (approximate colour, BVR, Unsharp Masked - um5) Blue : 4 x 0.3s exposure (average combine), 1x1 binning, B Filter Green: 2 x 0.3s exposure (average combine), 1x1 binning, V Filter Red: 2 x 0.3s exposure (average combine), 1x1 binning, R Filter 2024-10-01 22:57 UT (#1249156-68) 12" LX200R (at f/10.4) + ST-10XME |
||||||||||||||||||||||||||||||||||||||||
Back to Top
C/2022 E2 (ATLAS) - 2024-10-01 (passing through Lynx) Sun Distance 3.67 AU (turning ?) Earth Distance 3.65 AU (546.7 million km) |
C/2022 E2 (ATLAS) - 2024-10-01 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -14.50 arcsec/hr, Dec 41.76 arcsec/hr) |
|
Annotated CCD Image (50% size, square root scale) 2 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 21:52 UT (#1249113-14) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) Image details as left |
|
Images of C/2022 E2 (ATLAS) on Comets 2023 Page >> | ||
Images of C/2022 E2 (ATLAS) on Comets 2024 Page >> |
Back to Top
T CrB (Corona Borealis) Alias: GCVS T CrB, HIP 78322, SAO 84129, HD 143454 Max Magnitude 2.0 Min Magnitude 10.8 Spectral: M3III+pec(NOVA) ( VSX T CrB ) |
T CrB (V Band) - 2024-10-01 (S1249) | T CrB - Photometry - 2024-10-01 | |
2024-10-01 21:45 UT Altitude: 18.8°, Airmass: 3.094 T CrB : 10.00 (V Mag), 11.15 (B Mag), 1.15 (B-V) |
||
Annotated CCD Image (50% size, linear scale) 3 x 20s exposure (average combine), 3x3 binning, V Filter 2024-10-01 21:45 UT (#1249106-10) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (not shown) 3 x 30s exposure (average combine), 3x3 binning, B Filter 2024-10-01 21:44 UT (#1249105-09) |
|
More Images & Data for T CrB >> |
Back to Top
AT 2023bsl (Cassiopeia) |
AT 2023bsl - 2024-10-02 (T+596.1d) Image below (2024-10-02.091) was taken 596.1 days after discovery of 2023bsl Position of reported transient (faint, fading) is shown by white cross-hairs Measured magnitude +17.93 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 02:20 UT (#1249269-73) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023bsl on Transients 2023 Page >> |
Back to Top
AT 2023egx (Cygnus) |
AT 2023egx - 2024-10-01 (T+556.2d) Image below (2024-10-01.872) was taken 556.2 days after discovery of 2023egx Position of reported transient (faint) is shown by white cross-hairs Measured magnitude +14.85 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 21:04 UT (#1249065-69) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023egx on Transients 2023 Page >> |
Back to Top
AT 2023abiw (Pegasus) |
AT 2023abiw - 2024-10-01 (T+282.1d) Image below (2024-10-01.842) was taken 282.1 days after discovery of 2023abiw Position of reported transient (not visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +19.3 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 20:15 UT (#1249046-50) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023abiw on Transients 2023 Page >> |
Back to Top
AT 2023acim (Cygnus) |
AT 2023acim - 2024-10-01 (T+276.6d) Image below (2024-10-01.810) was taken 276.6 days after discovery of 2023acim Position of reported transient (faint) is shown by white cross-hairs Measured Magnitude +15.65 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 19:35 UT (#1249010-14) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023acim on Transients 2023 Page >> |
Back to Top
AT 2024uzm (Taurus) |
AT 2024uzm - 2024-10-02 (T+24.5d) Image below (2024-10-02.044) was taken 24.5 days after discovery of 2024uzm Position of reported transient (faint, fading) is shown by white cross-hairs Measured magnitude +17.93 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 01:13 UT (#1249247-51) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024uzm on Transients 2024 Page >> |
Back to Top
AT 2024vhf (Cassiopeia) |
AT 2024vhf - 2024-10-02 (T+21.2d) Image below (2024-10-02.106) was taken 21.2 days after discovery of 2024vhf Position of reported transient (not visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +19.0 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 02:42 UT (#1249276-80) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024vhf on Transients 2024 Page >> |
Back to Top
AT 2024vlc (Perseus) |
AT 2024vlc - 2024-10-02 (T+16.3d) Image below (2024-10-02.122) was taken 16.3 days after discovery of 2024vlc Position of reported transient (very faint, fading fast) is shown by white cross-hairs Measured Magnitude +18.45 (Clear Filter) Faint Galaxy in same FOV is WISEA J031519.88+443112.9 |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 03:04 UT (#1249283-87) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024vlc - Earlier Image 2024-09-19 (T+3.3d) Image below (2024-09-19.103) was taken 3.3 days after discovery of 2024vlc Position of reported transient (faint) is shown by white cross-hairs Measured Magnitude +16.30 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-09-19 02:37 UT (#1247074-78) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024vlc on Transients 2024 Page >> |
Back to Top
AT 2024wpc (Bootes) |
AT 2024wpc in PGC 1875557 (T+16.3d) |
|
Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 20:41 UT (#1249058-62) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024wpc - 2024-10-01 (T+9.2d) Image below (2024-10-01.856) was taken 9.2 days after discovery of 2024wpc Position of reported transient (distinct) is shown by white cross-hairs Measured Magnitude +14.94 (Clear Filter) |
|
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 20:41 UT (#1249058-62) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024wpc on Transients 2024 Page >> |
Back to Top
AT 2024wqf (Pegasus) |
AT 2024wqf - 2024-10-01 pm (T+7.7d) Image below (2024-10-01.921) was taken 7.7 days after discovery of 2024wqf Position of reported transient (distinct) is shown by white cross-hairs Measured Magnitude +14.13 (Clear Filter) |
|
Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 22:14 UT (#1249123-27) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024wqf on Transients 2024 Page >> |
Back to Top
AT 2024wxp (Gemini) |
AT 2024wxp - 2024-10-01 (T+5.3d) Position of reported transient (not totally separatable) is shown by white cross-hairs |
|
Annotated CCD Image (100% size, linear scale, cropped) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 23:12 UT (#1249177-79) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024wxp - 2024-10-01 (T+5.3d) Image below (2024-10-01.965) was taken 5.3 days after discovery of 2024wxp Position of reported transient (not totally separatable) is shown by white cross-hairs Measured Magnitude +15.45 (Clear Filter) Transient lies close to another star, and the magnitude quoted here is potentially a combined magnitude from both stars |
|
Annotated CCD Image (175% size, linear scale, cropped) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 23:12 UT (#1249177-79) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024wxp on Transients 2024 Page >> |
Back to Top
ESO 549-G29 with AT 2023cvj (Eridanus) |
ESO 549-G29 with AT 2023cvj - 2024-10-02 (T+573.1d) Image below (2024-10-02.152) was taken 573.1 days after discovery of 2023cvj Position of earlier transient (not visible) is shown by white cross-hairs |
|
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 03:48 UT (#1249300-04) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2023cvj (in ESO 549-G29) on Transients 2023 Page >> |
Back to Top
LEDA 918265 with SN 2022ypb (Eridanus) |
LEDA 918265 with SN 2022ypb - 2024-10-02 (T+714.8d) Image below (2024-10-02.138) was taken 714.8 days after discovery of 2022ypb Position of earlier transient (not visible) is shown by white cross-hairs |
|
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 03:28 UT (#1249292-96) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2022ypb (in LEDA 918265) on Supernova 2022 Page >> |
Back to Top
Nova M31 2024-03b? (Andromeda) |
Nova M31 2024-03b? - 2024-10-01 (T+202.1d) Image below (2024-10-01.940) was taken 202.1 days after discovery of Nova M31 2024-03b? Position of earlier transient (not visible) is shown by white cross-hairs Transient lies very close to the bright nucleus of M31 |
|
Annotated CCD Image (125% size, log scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 22:43 UT (#1249139-43) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of Nova M31 2024-03b? (in M31) on Transients 2024 Page >> |
Back to Top
NGC 827 Cetus) |
|
Annotated CCD Image (50% size, square root scale) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 23:31 UT (#1249183-86) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 827 - Detail |
|
Annotated CCD Image (150% size, square root scale, cropped) Image details as above |
NGC 827 with AT 2023zpf (Cetus) |
NGC 827 with AT 2023zpf - 2024-10-01 (T+297.6d) Image below (2024-10-01.975) was taken 297.6 days after discovery of 2023zpf Position of earlier transient (not visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +19.5 (Clear Filter) |
|
Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-01 23:31 UT (#1249183-86) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
NGC 1954 with AT 2024gwz (Lepus) |
NGC 1954 - Spiral Galaxy with nearby fainter galaxies NGC 1957 (catalog mag +13.9) & PGC 929166 (catalog mag +15.7) |
|
Annotated CCD Image (50% size, square root scale) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 04:33 UT (#1249315-19) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 1954 with AT 2024gwz - 2024-10-02 (T+165.4d) Image below (2024-10-02.183) was taken 165.4 days after discovery of 2024gwz Position of earlier transient (no visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +18.8 (Clear Filter) |
|
Annotated CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 04:33 UT (#1249315-19) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024gwz (in NGC 1954) on Transients 2024 Page >> |
Back to Top
NGC 2830 with AT 2024vsu (Lynx) |
NGC 2830 - Spiral Galaxy in ARP 315 (NGC 2830, 2831, 2832) NGC 2830 (catalog mag +15.2) NGC 2831 (catalog mag +14.4), NGC 2832 (catalog mag +11.8) NGC 2825 (catalog mag 14.4), NGC 2834 (catalog mag +14.5), NGC 2828 (catalog mag +16.0), PGC 2036350 (catalog mag +16.1) PGC 139185 (catalog mag +16.2), PGC 2037597 (catalog mag +17.3) [ ARP Galaxies ] |
|
Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 01:36 UT (#1249254-58) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 2830 with AT 2024vsu - 2024-10-02 (T+12.2d) Image below (2024-10-02.060) was taken 12.2 days after discovery of 2024vsu Position of reported transient (very faint) is shown by white cross-hairs Estimated Magnitude +17.6 (Clear Filter) |
|
Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 01:36 UT (#1249254-58) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 2830 - Earlier Image (Jan 2011) NGC 2830, 2831, 2832 / ARP 315 (Lynx) |
|
CCD Image (150% size, cropped) 120s sec exposure (single frame), 3x3 binning, C Filter 2011-01-17 22:25 h UT (#446196) 12" LX200R (at f/9.7) + ST-10XME |
Images of AT 2024vsu (in NGC 2830) on Transients 2024 Page >> |
Back to Top
NGC 3683 with AT 2024wny (Ursa Major) |
NGC 3683 - Spiral Galaxy |
|
Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 01:57 UT (#1249262-66) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 3683 with AT 2024wny - 2024-10-02 (T+9.9d) Image below (2024-10-02.075) was taken 9.9 days after discovery of 2024wny Position of earlier transient (not visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +18.4 (Clear Filter) |
|
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 01:57 UT (#1249262-66) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024wny (in NGC 3683) on Transients 2024 Page >> |
NGC 3683 with AT2022azb - Earlier Image 2022-03-15 (T+54.7d) Image below (2022-03-15.095) was taken 54.7 days after discovery of 2022azb Position of reported transient (not visible) is shown by white cross-hairs Earlier images of AT2022azb (NGC 3683) on Transients 2022 Page |
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, C Filter 2022-03-15 02:26 UT (#985046-50) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
NGC 7769 with SN 2022mxv (Pegasus) SN 2022mxv (Type: II) discovered 2022-06-18.546 UT by ATLAS Alias: ATLAS22qxp, ZTF22aaolwsd Discovery Mag +18.25 (orange-ATLAS Filter) ( TNS 2022mxv ) |
NGC 7769 with SN 2022mxv - 2024-10-01 (T+836.5d) Image below (2024-10-01.997) was taken 836.5 days after discovery of 2022mxv Position of earlier supernova (very faint) is shown by white cross-hairs |
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 00:04 UT (#1249207-11) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2022mxv (in NGC 7769) on Supernova 2022 Page >> |
Back to Top
NGC 7769 with SN 2022aedu (Pegasus) 2022aedu (Type: SN II) discovered 2022-12-31.384 UT by Koichi Itagaki Discovery Mag +16.9 (Clear Filter) ( TNS 2022aedu ) |
NGC 7769 with SN 2022aedu - 2024-10-01 (T+640.5d) Position of earlier supernova (not visible) is shown by white cross-hairs |
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 00:04 UT (#1249207-11) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
NGC 7769 with SN 2022aedu - Earlier Image, 2023-01-09 (T+9.4d) Image below (2023-01-09.814) was taken 9.4 days after discovery of 2022aedu Position of reported supernova (faint) is shown by white cross-hairs Estimated Magnitude +15.9 (by comparison) |
Annotated CCD Image (125% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2023-01-09 19:39 UT (#1084051-55) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2022aedu (in NGC 7769) on Supernova 2022 Page >> |
Back to Top
SN 2023eb (Eridanus) |
SN 2023eb - 2024-10-02 (T+635.9d) Image below (2024-10-02.167) was taken 635.9 days after discovery of 2023eb Position of earlier supernova (likely faded & no longer visible) is shown by white cross-hairs Image is crossed by 2 satellite tracks |
|
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 04:09 UT (#1249307-11) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2023eb (in WISEA Galaxy) on Supernovae 2023 Page >> |
Back to Top
SN 2024ugc (Perseus) |
SN 2024ugc - 2024-10-02 (T+38.3d) Image below (2024-10-02.028) was taken 38.3 days after discovery of 2024ugc Position of reported supernova (faint) is shown by white cross-hairs Measured Magnitude +17.20 (Clear Filter) Galaxy in same FOV is WISEA J024524.12+351628.9 |
|
Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-02 00:50 UT (#1249239-43) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2024ugc on Supernovae 2024 Page >> |
Back to Top
