Stars This page summarises observations and images of stars, including doubles and variables. For a listing of all Asteroid Images, see Image Database - Stars
For Open and Globular Clusters, see Clusters
Double Stars Variable Stars Supernovae
Stars range in brightness and colour. The colour of star depends on what temperature its surface is at. The difference in star colours is something which can be appreciated by by looking at stars with naked eye, binoculars, telescope or camera. The following picture of Orion shows nicely the difference in colour between the Red Giant Betelgeuse and the blue stars such as Bellatrix.
"Star Trails of Constellation Orion" |
Back to Top
Lyra Epsilon
One of my favourite double stars is Lyra Epsilon. It's a lovely pair of
stars of approximately equal brightness, Mag +4.7 and +5.1, with separation of
3.5' (arc minutes). Together with 2 nearby fainter neighbours, the epsilon stars
form a small kite shape. Under high power the beauty of the
"double" become really apparent as both Epsilon 1 and Epsilon 2 are
both doubles themselves, see following sketch.
Lyra Epsilon, "Double", 1996-Nov-07 F10/8" LX200, x77 & x206, |
Double-Double in Lyra |
CCD Image 8 sec exposure 2001-09-25 23:16 h UT (#2014) |
Another of my favourite double stars is Cygnus Beta (Albireo), comprising a lovely pair of coloured starts, the brighter one gold and the other blue.
Cygnus Beta, Double Star, 1998-Oct-23
View through Illuminated Reticle Eyepiece,
x206,
Struve 817 (Orion) Star Pair, Mag 8.8 and 8.9, separation 18" |
CCD Image 20s exposure 2003-01-17, 22:38h UT (#39002) |
Back to Top
I have not tried tracking the brightness variability of Variable stars until recently (2002-Oct) when I started a CCD Imaging project to follow the variability of a number of stars. I began with variables in constellations Andromeda, Lacerata and Pegasus. See Variable Stars Project.
I've started by taking some baseline images. Some of which are shown below :
UZ And, Mira-type variable (Andromeda) |
EK And, SRa-type variable (Andromeda) |
UZ And/EK And, baseline image, 5 sec exposure
(north down) 2002-10-03 00:21h UT CCD Image, 3 x 5 sec exposure (2x2 binning) 11.4 x 7.6 arc min (#28227-29) |
RX And UGZ-type variable (Andromeda) |
NSV 00389 suspected variable (Andromeda) |
RX And, baseline image, 10 sec exposure
(north down) 2002-10-02 23:34h UT CCD Image, 3 x 10 sec exposure (2x2 binning) 11.4 x 7.6 arc min (#28160-62) |
R And Mira-type variable (Andromeda) |
R And, baseline image, 5 sec exposure (north down) |
2002-10-02 23:34h UT CCD Image, 3 x 5 sec exposure (2x2 binning) 11.4 x 7.6 arc min (#28160-62) |
Back to Top
Supernova 2001ib (in NGC 7242) |
CCD Image, 2 x 5 min (#13016-17) Image scaling 1.74 arc sec/pixel 2001-12-14, 20:55 to 21:05 UT, |
SN 2001ib was discovered independently by two U.K. Supernova hunters, |
Supernova 2005cf (in MCG-1-39-3 Galaxy, Libra) Supernova 2005cf, Measured Magnitude : +13.5 (C), Measured Distance from host galaxy: 2' 07" UCAC 2.0 Stars : (1) mag + 13.6, (2) mag +13.3 |
CCD Image, 6 x 2 mins (average combine) , clear filter 8" LX200 at f/10.3, ST-7e, CCDSoft/TheSky Twilight Conditions, Aberdeenshire, UK 2005-06-10 00:28 h UT (#89023-28) |
Notes : MCG-1-39-3 catalog mag +14.7, NGC
5917 catalog mag +13.2 Supernova 2005cf was discovered by Lick Observatory Supernova Search (USA) on 2005-05-28 It is understood to be a bright Type Ia Supernova. [ See 2005cf Images at Rochester Astronomy Site ] [ See 2005cf Light Curve on SNWeb ] |
