CCD Session S00088
Bullet Notes from CCD Session
Bullet M13 - Globular Cluster
Bullet M57 - Planetary Nebula (Ring Nebula)
Bullet M92 - Globular Cluster
Bullet WDS ES 2234 - Double Star
Bullet Double-Double in Lyra - Multiple Star
Bullet NGC 6811 - Open Cluster
Bullet NGC 6826 - Planetary Nebula (Blinking Nebula)
Bullet NGC 6884 - Planetary Nebula
Bullet NGC 6910 - Open Cluster
Bullet Barnard's Star

Notes (S00088)

- 1 hr 50m imaging session  (June)
- Night skies in June in Aberdeenshire don't become astronomically dark
- The observing session was an attempt to see what could be seen in June.
- Whilst the observing window is small (local midnight +/- 1 hour) and there arent' too many stars to see with the naked eye, I hope the following images show that it can see be worthwhile to go out with a telescope even in middle of the Scottish summer.
- Seeing quality was excellent, with FWHM levels down to 2.5 arc secs (the best seen for months)
(see more notes from Session 88)

Back to Top


M13 - Globular Cluster

M13 (Hercules)
CCD Colour Image (LRGB,
Luminance 3x20s (average), Blue 3x30s (average) with  x1.8 weighting
Green 3x30s (average), Red 3x30s (average)
2005-06-06  23:19 h UT (#88004-15)

M13 (Hercules)
CCD Image
120s Clear Filter
2005-06-06  23:26 h UT (#88020)

Back to Top


M57 - Planetary Nebula

M57 (Lyra)
CCD Image ,
3 x 60 sec exposure (average combine), clear filter
2005-06-06  23:49 h UT (#88039-41)

Back to Top


M92 - Globular Cluster (NGC 6341)

M92 (Hercules)
CCD Colour Image (LRGB)
Luminance 3x20s (average), Blue 3x30s (average) with  x1.15 weighting
Green 3x20s (average), Red 3x20s (average)
2005-06-06  23:38 h UT (#88023-34)

Back to Top


WDS ES 2234 - Double Star

WDS ES 2234 (Lyra)
Separation 6 arc secs
CCD Image
20 sec , clear filter
2005-06-06  23:44 h UT (#88037)

Back to Top


Double-Double - Multiple Star

Double-Double (Lyra), HIP 91919, WDS STFA 37
CCD Colour Image
Luminance 10s , Blue 3x30s (average)
Green 20s, Red 20s
2005-06-07  00:06 h UT (#88066-73)

Double-Double (Lyra), HIP 91919, WDS STFA 37
CCD  Image
0.11s , clear filter (1x1 binning)
(no special image processing)
Inserts show detail at x3 enlargement
2005-06-07  00:12 h UT (#88077)

Double-Double (Lyra), HIP 91919, WDS STFA 37
CCD Image
60s , clear filter (2x2 binning)
2005-06-07  00:09 h UT (#88073)

Back to Top


NGC 6811 - Open Cluster

NGC 6811 (Cygnus)
CCD Image Mosaic (central portion)
20s, clear filter
2005-06-07  00:25 h UT (#88085-95)
[ Full Size]

Back to Top


NGC 6826 - Planetary Nebula (Blinking Nebula)

NGC 6826 (Cygnus)
[ Caldwell C15, Herschel H73-4 ]
CCD Image
2 x 60s (average combine), clear filter
2005-06-07  00:36 h UT (#88097-99)

NGC 6826
CCD Image as above
(alternative black/white range)

NGC 6826 - planetary nebula detail
CCD Image as above
(central portion enlarged x3)

Back to Top


NGC 6884 - Planetary Nebula

NGC 6884 (Cygnus)
small planetary nebula, no visible detail
CCD Image
3 x 60s (average combine), clear filter
2005-06-07  00:40 h UT (#88101-03)

NGC 6884
CCD Image (negative)
details as above
(#88101-03)

Back to Top


NGC 6910 - Open Cluster

NGC 6910 (Cygnus)
(no nebulosity is visible)
CCD Image
3 x 60s (average combine), clear filter
2005-06-07  00:45 h UT (#88105-07)

Back to Top


Barnard's Star

Barnard's Star, HIP 87937  (Ophiuchus)
(brightest star in image)
CCD Image
60s, clear filter
2005-06-07  00:54 h UT (#88111)
Barnard's Star, HIP 87937  (Ophiuchus)
CCD Image (Mag Limit +16.5)
3 x 60s (average combine), clear filter
2005-06-07  00:53 h UT (#88109-11)

Back to Top
