Images - Session 615 (2018-07-24)

Objects Session Notes
Bullet HIP 110661 - Star
Bullet RX And - Variable Star
Bullet Z And - Variable Star (Type ZAND)

Bullet M73 - Open Cluster

Bullet NGC 100 - Spiral Galaxy
Bullet NGC 6772 - Planetary Nebula
Bullet NGC 7009 - Planetary Nebula (Saturn Nebula)
Bullet NGC 7086 - Open Cluster (Herschel VI-32)

Bullet Photometric Monitoring - Variables
   - None
     (RX And &  Z And attempts due to centering issues)

Bullet Astrometric Monitoring - Nearby Stars
    - None

- Late Night Session (1.7 hrs duration).
- Session conducted as a Fully Automated Run, in which the Observatory Control Program opened the  Observatory, built and executed an optimised Observing Plan before finally closing the Observatory at the end of the night
(Session was monitored from both in the observatory and remotely to check that things were proceeding ok and intervene if necessary)
- Main aim of the session was to test the Clair 3 Observatory running in Fully Automated Mode.  Secondary aim was to acquire images of a selection of targets.

- 12" LX200 + ST-10XME for imaging
- Ambient Temperature:  8.5°C (minimum)
- Notes from 2018-07-24 >>


HIP 110661 - Star

Not sure why this star was targetted (the specification of spectral images may have just been a test when developing and testing the Targets Database)

HIP 110661 (Lacerta)
CCD Image (50% size)
5 sec exposure (single exposure), 3x3 binning, C Filter
2018-07-25 01:50hUT (#615138)
12" LX200R  (at f/10.4) + ST-10XME

HIP 110661  - spectral image
CCD Image (35% size)
7 x 2 sec exposure (average combine), 2x2 binning, S Filter
2018-07-25 01:55hUT (#615140-46)
12" LX200R  (at f/10.4) + ST-10XME

Back to Top


RX And - Variable Star

Attempted VR photometry imaging of RX And,  however the N/W offsets held in the Targets Database where not correctly imported with the Observing Plan, and caused the images to centre RX And within the frame but not contain the necessary comparison stars.

RX And (Andromeda)
Annotated CCD Image (50% size)
5 sec exposure (single frame), 3x3 binning, C Filter
2018-07-25 00:55 UT (#615100)
12" LX200R  (at f/10.4) + ST-10XME

RX And - Earlier Reference Image (2007)
Annotated CCD Image
45 sec exposure (single frame), 2x2 binning, V Filter
2007-10-22 23:59hUT (#224289)
8" LX200 + ST-7E

Back to Top


Z And - Variable Star (Type ZAND)

Attempted BVR photometry imaging of Z And,  however the N/W offsets held in the Targets Database where not correctly imported with the Observing Plan and caused the images to centre Z And within the frame but not contain the necessary comparison stars.

Z And (Andromeda)
Annotated CCD Image (50% size)
5 sec exposure (single frame), 3x3 binning, C Filter
2018-07-25 00:48 UT (#615013)
12" LX200R  (at f/10.4) + ST-10XME

Z And - Earlier Reference Image
Annotated CCD Image
30s exposure, 2x2 binning, C Filter
2006-11-18 03:07h UT (#153267)
8" LX200 + ST-7E

Back to Top


M73 - Open Cluster

M73 (Aquarius)
CCD Image (50% size)
8 x 10s exposure (average combine), 3x3 binning, C Filter
2018-07-25 01:30h UT (#615116-24)
12" LX200R  (at f/10.4) + ST-10XME

M73 - Earlier Image (2017)
CCD Image (50% size)
5 x 10s exposure (average combine), 3x3 binning, C Filter
2017-11-02 21:37h UT (#603235-43)
12" LX200R  (at f/10.4) + ST-10XME

M73 - Earlier Image (2005)
CCD Image
5 x 20 sec exposure (average), clear filter
2005-08-14 22:40 h UT (#92120-24)
8" LX200 + ST-7E

Back to Top


NGC 100 - Spiral Galaxy

NGC 100 (Pisces)
(taken under poor sky conditions)
CCD Image (100% size, cropped)
11 x 30 sec exposure (average combine), 3x3 binning, C Filter
2018-07-25 02:06hUT (#615149-61)
12" LX200R  (at f/10.4) + ST-10XME

NGC 100 - Earlier Images (2017)
CCD Image (100% size, cropped)
7 x 180s exposure (average combine), 3x3 binning, C Filter
2017-12-13 21:40h UT (#607041-47)
12" LX200R  (at f/10.4) + ST-10XME
(Autoguided using TS 80mm APO + ZWO ASI178MC)

Back to Top


NGC 6772 - Planetary Nebula

NGC 6772 (Aquila)
CCD Image (50% size)
4 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-07-25 00:44hUT (#615109-13)
12" LX200R  (at f/10.4) + ST-10XME

NGC 6772 - detail
CCD Image (100% size, cropped)
Image details as above

NGC 6772 - Earlier Images (2017)
CCD Image (50% size)
2 x 60s exposure (average combine), 3x3 binning, C Filter
2017-11-02 18:42h UT (#603022-25)
12" LX200R  (at f/10.4) + ST-10XME



Back to Top


NGC 7009 - Planetary Nebula (Saturn Nebula)

NGC 7009 (Aquarius)
CCD Image (50% size)
8 x 10 sec exposure (average combine), 3x3 binning, C Filter
2018-07-25 01:37hUT (#615127-35)
12" LX200R  (at f/10.4) + ST-10XME

NGC 6772 - detail
CCD Image (Logscale 100% size, cropped)
Image details as above

Negative CCD Image (Logscale 100% size, cropped)
Image details as above

NGC 7009 - Earlier Images (2002)
CCD Image (50% size)
3 x 2 min exposure (average combine), 1x1 binning, unfiltered
2002-09-23  21:56h UT (#27040-44)
8" LX200 + ST-7E

Back to Top


NGC 7086 - Open Cluster (Herschel VI-32)

NGC 7086 / Herschel VI-32 (Cygnus)
CCD Image (50% size)
9 x 15 sec exposure (average combine), 3x3 binning, C Filter
2018-07-25 00:44hUT (#615003-11)
12" LX200R  (at f/10.4) + ST-10XME
[ 100% Size ]

NGC 7086 - Earlier Image (2017)
CCD Image (50% size)
6 x 15s exposure (average combine), 3x3 binning, C Filter
2017-11-02 22:44h UT (#603358-66)
12" LX200R  (at f/10.4) + ST-10XME
[ 100% size ]
