Images - Session 627 (2018-09-08)

Objects Session Notes
Bullet 37P/Forbes - Comet

Bullet Hickson 60 - Galaxy Cluster (PGC 38065 et al)
Bullet Hickson 81 - Galaxy Cluster (UGC 10319)

Bullet NGC 5676 - Spiral Galaxy (Herschel I-189, LGG 384 Member)

Bullet Variable Stars (photometric monitoring)
    - RX And, U And, DY Per, GK Per, RR Tau

Bullet Nearby Stars (astrometric monitoring)
  - EV Lac, Groombridge 34, Teegardens Star


- Night Session (7.2 hours duration).
Clear dark skies until 02:00 when cloud rolled in from SW ending the session early
- Generally Fully Automated operation, but dropping to Manual on occasions ( Session was monitored remotely from indoors to observe operations and spot any new or recurrent issues  )
- Main aim of the session was to test a new routine for taking Sky Flats before an observing session taking images of a selection of variable stars, nearby stars and deep sky targets.
-
- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding
- Ambient Temperature:  6°C (minimum)
- CCD Temperature:  -15°C (down to -19°C )
(82% av. power for -15°C, Sky Flats set)
(86% av. power for -15°C set)
(100% av power for -20°C set  (-18.7° to -19.2°C)
- Notes from 2018-09-08 >>


37P/Forbes - Comet

37P/Forbes (passing through star-field in Pisces)
Sun Distance 2.02 AU
Comet is marked by white cross hairs
Bright star is SAO 128092 (magnitude +9.5)
Annotated CCD Image (50% size)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-09-08 22:33 UT (#627002-06)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

37P/Forbes - Detail
Annotated CCD Image (100% size, cropped)
Image details as above

Negative CCD Image (100% size, cropped)
Image details as above

37P/Forbes - Earlier Image (2018-08-31)
Sun Distance 1.98 AU
Annotated CCD Image (100% size, cropped)
5 x 60 sec exposure (average combine), 3x3 binning, C Filter
2018-08-31 23:09 UT (#623111-15)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Negative CCD Image (100% size, cropped)
Image details as above (2018-08-31)

Back to Top


Hickson 60 - Galaxy Cluster (PGC 38065 et al)

Hickson 60 (Andromeda)
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2018-09-09 00:10 UT (#627133-37)
12" LX200R  (at f/10.4) + ST-10XME

Hickson 60 - Detail
PGC 38065 - Elliptical Galaxy (catalog mag +15.9),
PGC 38053 - Elliptical Galaxy (catalog mag +16.4),
PGC 38064 - Spiral Galaxy (catalog mag +16.7),
PGC 38072 - Spiral Galaxy (catalog mag +16.7)
Annotated CCD Image (125% size, square root scale, cropped)
Image details as above

Negative CCD Image (125% size, square root scale, cropped)
Image details as above

Hickson 60 & Adjacent Galaxies
Adjacent Galaxies including :
PGC 38092 - Elliptical Galaxy (catalog mag +16.1),
 PGC 38106 - Elliptical Galaxy (catalog mag +16.4),
PGC 2397741 (catalog mag +17.3),  PGC 2399005 (catalog mag +17.5),
 PGC 2399094  (catalog mag +17.7), PGC 2399581 (catalog mag +18.3)
Annotated CCD Image (50% size, square root scale)
Image details as above

Hickson 60 - Earlier Image (2018-07-26)
Attempted imaging of Hickson 60
NB Poor sky conditions
CCD Image (50% size)
3 x 90 sec exposure (average combine), 3x3 binning, C Filter
2018-07-26 01:16 UT (#616155-58)
12" LX200R  (at f/10.4) + ST-10XME


Back to Top


Hickson 81 - Galaxy Cluster (UGC 10319 et al)

Hickson 81 (Andromeda)
NB. Image suffers from star trailing due to poor/absent guiding
Target needs to be rescheduled once guiding issues have been sorted out
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2018-09-09 00:10 UT (#627133-37)
12" LX200R  (at f/10.4) + ST-10XME

Hickson 81 - Detail
Annotated CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


NGC 5676 - Spiral Galaxy (Herschel I-189, LGG 384 Member)

NGC 5676 / Herschel I-189 (Bootes)
CCD Image (50% size)
5 x 120 sec exposure (average combine), 3x3 binning, C Filter
2018-09-08 20:46 UT (#627085-89)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 5676 - detail
CCD Image (100% size, cropped)
Image details as above

Negative CCD Image (100% size, cropped)
Image details as above

NGC 5676 - Earlier Image (2018-09-04)
Annotated CCD Image (100% size, cropped)
3 x 120 sec exposure (average combine), 3x3 binning, C Filter
2018-09-04 20:45 UT (#626003-11)
12" LX200R  (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
