CCD Images - Session 691 (2019-09-07)

Objects Session Notes
Bullet C/2018 W2 (Africano) - Comet

Bullet Abell 45 - Planetary Nebula (Attempt)

Bullet ARP 102 - Elliptical Galaxy connected to Spiral (UGC 10814 et al)
Bullet ARP 124 - Spiral Galaxy (NGC 6361 w/ MCG+10-25-3)
Bullet ARP 293 - Galaxy Pair (NGC 6285 & NGC 6286)
Bullet ARP 310 - Double Galaxies (IC 1259)
Bullet ARP 311 - Galaxy Group (IC 1258, IC 1259 & IC 1260)

Bullet IC 2233 - Spiral Galaxy

Bullet NGC 1817 - Open Cluster (H VII-4)
Bullet NGC 2424 - Spiral Galaxy
Bullet NGC 6960 - Nebula (Veil Nebula)

Bullet Variable Stars (photometric monitoring)
  - RX And, U And, Z And, CI Cyg, SS Cyg, BL Lac, FO Ori, FU Ori, V Sge, RR Tau

Bullet Nearby Stars (astrometric monitoring)
 - HH And, Barnards Star, 61 Cyg, Groombridge 34



- Full night session (7.7 hours)

Session operated in fully automated mode with some  interventions & monitoring during the first half of the session

- Main aim of the session was to aquire images of a range of deep sky targets and one or two comets

Conditions relatively good.  Some observing time was lost due to a stalled job queue where control didn't pass back to AdvMain from conducting a Telescope.jog

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  Falling  from 8°C to 3°C (min).
Outdoors 2°C (min)
(Dew heaters on manual,  63%)
- CCD Temperature:  -15°/-20°C  (61 / 66% av. power)
- Notes from 2019-09-07 >>



C/2018 W2 (Africano) - Comet

C/2018 W2 (Africano)
(passing through Perseus)
Sun Distance 1.45 AU
Earth Distance 0.80 AU (119.3 million km)
   C/2018 W2 (Africano) - Detail
Frames aligned on comet
(stars appear trailed due to movement of comet
and somewhat bloated due to an image quality issue)
Image   Image
CCD Image (50% size)
2 x 45s exposure (average combine), 3x3 binning, C Filter
2019-09-07 23:11 UT (#691106-07)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, square root scale, cropped)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2019-09-07 23:12 UT (#691104-12)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

    More Images of C/2018 W2 (Africano)

Back to Top


Abell 45 - Planetary Nebula (attempt)

Abell 45 (Scutum)
Ast. Now Challenge Object,  Jul 2016
Again no sign of Pl.Neb in this image (total exposure time 5 mins)
CCD Image (50% size)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2019-09-07 20:47 UT (#691052-56)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Abell 45 - Earlier Image (2019-09-01)
No sign of Pl.Neb in this image (total exposure time 5 mins)
Expected position of Abell 45 is shown by white circle
Annotated CCD Image (50% size)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2019-09-01 23:00 UT (#688118-22)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


ARP 102 - Elliptical Galaxy connected to Spiral (UGC 10814 et al)

ARP 102  (Hercules)
UGC 10814 & companions
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-07 22:47 UT (#691088-92)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

ARP 102 - Detail
UGC 10814 (PGC 60070) catalog mag +15.5,
MCG+8-31-41 (PGC 60067) catalog mag + 15.5,
VV 10b (PGC 60073) catalog mag +16.2
Annotated CCD Image (100% size, square root scale, cropped)
Image Details as above

NGC 6960 - Earlier Image (2005)
Negative CCD Image  (100% size, square root scale, cropped)
Image Details as above


Back to Top


ARP 124 - Spiral Galaxy (NGC 6361 w/ MCG+10-25-3)

ARP 124  (Draco)
NGC 6361 with MCG+10-25-3
CCD Image (50% size, square root scale)
10 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-07 23:41 UT (#691115-25)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

ARP 124 - Detail
CCD Image
(100% size, square root scale, cropped)
Image Details as above

ARP 124
NGC 6361 (catalog mag +13.9),
MCG+10-25-3 ( PGC 60040)  (catalog mag + 16.1)
Annotated CCD Image
(100% size, square root scale, cropped)
Image Details as above


Back to Top


ARP 293 - Galaxy Pair  (NGC 6285 & NGC 6286)

ARP 293 (Draco)
NGC 6285 & NGC 6286
CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-08 00:34 UT (#691135-38)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

ARP 293 - Detail
Stars trailed due to wind or poor guiding
Annotated CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


ARP 310 - Double Galaxies (IC 1259)

ARP 310 / IC 1259 (Draco)
Part of galaxy group ARP 311
CCD Image (50% size, log scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-08 00:14 UT (#691128-32)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

ARP 310 / IC 1259 - Detail
VV 101a, mag+15 & VV 101b, mag +15
Annotated CCD Image (150% size, log scale, cropped)
Image details as above

Negative CCD Image  (150% size, log scale, cropped)
Image details as above


Back to Top


ARP 311 - Galaxy Group (IC 1258, IC 1259 & IC 1260)

ARP 311  (Draco)
IC 1258, IC 1259  & IC 1260
CCD Image (50% size, log scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-08 00:14 UT (#691128-32)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

ARP 311  - Detail
IC 1258 (catalog mag +13.5), IC 1259 (catalog mag +14.9)
& IC 1260 (catalog mag +14.7)
Annotated CCD Image (150% size, log scale, cropped)
Image details as above

Negative CCD Image  (150% size, log scale, cropped)
Image details as above


Back to Top


IC 2233 - Spiral Galaxy

IC 2233 (Lynx)
Flat Galaxy Atlas Object
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-08 02:31 UT (#691215-19)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

IC 2233 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


NGC 1817 - Open Cluster (H VII-4)

NGC 1817 \ H VII-4 (Taurus)
CCD Image Mosaic (33% size, linear scale, cropped)
45s exposure frames, 3x3 binning, C Filter
2019-09-08 01:40 UT (#691183-205)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
[ Larger Image :  50% size, uncropped 3x4 Mosaic ]

NGC 1817 - Earlier Image (2019-01-31)
(Central part of Cluster)
CCD Image (70% size)
4 x 30s exposure (average combine), 3x3 binning, C Filter
2019-01-31 21:44 UT (#654157-63)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


NGC 2424 - Spiral Galaxy

NGC 2424 (Lynx)
Flat Galaxy Atlas Object
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2019-09-08 02:10 UT (#691208-12)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 2424 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image  (100% size, square root scale, cropped)
Image details as above

NGC 2424 -Earlier Image (2006)
CCD Image (100% size)
60s exposure (single frame), 2x2 binning, C Filter
2006-02-03 01:12h UT (#113069)
8" LX200 + ST-7E

Back to Top


NGC 6960 - Nebula (Veil Nebula)

NGC 6960 (Cygnus)
Alias: Veil Nebula
CCD Image (70% size)
5 x 120s exposure (average combine), 3x3 binning, C Filter
2019-09-07 23:23 UT (#691078-83)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 6960 - Detail
Negative CCD Image (70% size)
Image Details as above

NGC 6960 - Earlier Image (2005)
Negative CCD Image (100% size)
60s exposure, C Filter
2005-09-03 02:07 h UT (#93213-15)
8" LX200 + ST-7E
