CCD Images - Session 753 (2020-02-20)

Objects Session Notes
Bullet C/2017 T2 (PanStarrs) - Comet

Bullet Abell 1689 - Galaxy Cluster

Bullet IC 3074 - Spiral Galaxy

Bullet Rose 5 - Compact Galaxy Group (PGC 36826 et al)
Bullet Rose 14 - Compact Galaxy Group (PGC 48433)
Bullet Rose 22 - Compact Galaxy Group (PGC 1387460 et al)
Bullet Rose 28 - Compact Galaxy Group (PGC 38421)
Bullet Rose 30 - Compact Galaxy Group (NGC 5058)

Bullet Segue 1 - Faint Dwarf Galaxy - 0.075mly

Bullet Variable Stars (photometric monitoring)
  - AM CVn, SY Cnc, U Gem, RZ LMi, U Mon, DY Per, RR Tau

Bullet Nearby Stars (astrometric monitoring)
 - DX Cnc, Groombridge 34, LAMOST-HVS1, Scholz's Star



- All night session (6.3 hours total).

- Main aims of the session was to  acquire images of a selection of deep sky and comet objects

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature:  1.5°C (min)
(Dew heaters on auto)
- CCD Temperature:  -20°C  (59% av. power)
- Notes from 2020-02-20 >>



C/2017 T2 (PanStarrs) - Comet

C/2017 T2 (PanStarrs) - 2020-02-20
 (passing through Cassiopeia)
Sun Distance 1.89 AU
Earth Distance 1.71 AU (256.1 million km)
   C/2017 T2 (PanStarrs) - 2020-02-20, Detail
Autoguided on an offset star using Lock Shift set at
the comet's rate of motion
(Ra 3.38 arcsec/hr, Dec 20.12 arcsec/hr)
Image   Image
CCD Image (50% size, square root scale)
2 x 45s exposure (average combine), 3x3 binning, C Filter
2020-02-20 21:07 UT (#753025-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, log scale, cropped)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2020-02-20 21:10 UT (#753025-33)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2017 T2 (PanStarrs) on Comets 2019 Page
Images of C/2017 T2 (PanStarrs) on Comets 2020 Page


False Colour Image of C/2017 T2 (PanStarrs) - 2020-02-20
False Colour CCD Image (70% size, log scale)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2020-02-20 21:10 UT (#753025-33)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Abell 1689 - Galaxy Cluster

Abell 1689 (Virgo)
Abell 1689 is one of the biggest and most massive galaxy clusters known
 and acts as a gravitational lens, distorting the images of galaxies that lie behind it.
It has the largest system of gravitational arcs ever found
CCD Image (70% size, square root scale)
CCD Image (50% size)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-21 02:27 UT (#753194-98)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Abell 1689  - Detail
CCD Image (125% size, square root scale, cropped)
Image details as above

Negative CCD Image (125% size, square root scale, cropped)
Image details as above

Abell 1689  - Central Area
CCD Image (125% size, square root scale, cropped)
Image details as above

Abell 1689  - Reference Image
Credit : ESA/Hubble
Rotated, cropped and converted to grey scale from original ESA/Hubble Image
https://commons.wikimedia.org/wiki/File:New_Hubble_view_of_galaxy_cluster_Abell_1689.jpg

Back to Top


IC 3074 - Spiral Galaxy

IC 3074 (Virgo)
Flat Galaxy Atlas
CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-21 00:47 UT (#753162-66)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

IC 3074 - Detail
CCD Image (100% size, square root scale, cropped)
Image details as above

IC 3074 - Earlier Detail (2020-01-27)
CCD Image (100% size, linear scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-01-27 02:26 UT (#746105-08)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Rose 5 - Compact Galaxy Group (PGC 36826 et al)

Rose 5 / PGC 36826 et al (Ursa Major)
Rose Catalogue
[ Rose Compact Galaxy Groups ]
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-13 22:46 UT (#752183-87)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Rose 5 - Detail
 PGC 36826 (catalog mag +15.5), PGC 36838 (catalog mag +15.7),
MAC 1148+3726, PGC 2100898
Annotated CCD Image (150% size, square root scale, cropped)
Image details as above

Negative CCD Image (150% size, square root scale, cropped)
Image details as above

Rose 5 - Earlier Image (2020-01-26)
Single frame
CCD Image (100% size, linear scale, cropped)
180s exposure (single frame), 3x3 binning, C Filter
2020-01-26 21:35 UT (#746008)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Rose 14 - Compact Galaxy Group (PGC 48433)

Rose 14 / PGC 48433 et al (Virgo)
Rose Catalogue
[ Rose Compact Galaxy Groups ]

with adjacent galaxies :   PGC 1205933 (catalog mag +16.8),
, PGC 1204160 (catalog mag +18.0),  PGC 1205120 (catalog mag +18.4),
 PGC 1207534 (catalog mag +18.9), PGC 1203334 (catalog mag +19.0)
Annotated CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-21 02:47 UT (#753201-04)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Rose 14 - Detail
A) PGC 159377 / CGCG 17-59 (catalog mag +17.1),
 B)  PGC 48433 (catalog mag +16.0),
C) SDSS J13411.24+014634.9,
 D)  SDSS J13411.49+014640.9
CCD Image (150% size, square root scale, cropped)
Image details as above

Negative CCD Image (150% size, square root scale, cropped)
Image details as above


Back to Top


Rose 22 - Compact Galaxy Group (PGC 1387460 et al)

Rose 22 / PGC 1387460 et al (Bootes)
Rose Catalogue
[ Rose Compact Galaxy Groups ]

Adjacent Galaxies :  PGC 1386943 (catalog mag +18.6),
PGC 1387310 (catalog mag +18.1), PGC 1388019 (catalog mag +18.9),
  PGC 1387361 (catalog mag +19.0)
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-21 01:33 UT (#753176-80)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Rose 22 - Detail
  PGC 1387460 (catalog mag + 17.0), PGC 1387640 (catalog mag +17.7),
SDSS J144958.73+110015.8, MAPS-NGP O_502_0199428
CCD Image (100% size, square root scale, cropped)
Image details as above

Negative CCD Image (100% size, square root scale, cropped)
Image details as above


Back to Top


Rose 28 - Compact Galaxy Group (PGC 38421)

Rose 28 / PGC 38421 (Coma Berenices)
Rose Catalogue - Rose 28 / PGC 38421 (catalog mag +15.9)
[ Rose Compact Galaxy Groups ]

with adjacent galaxies :  PGC 1711696 (catalog mag +16.7)
and PGC 1713116 (catalog mag +17.2)
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-21 01:33 UT (#753176-80)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Rose 28 - Detail
  PGC 38421 (catalog mag +15.9)

 Rose 28 / PGC 38421  is an unresolved mass of several galaxies
CCD Image (150% size, square root scale, cropped)
Image details as above

Negative CCD Image (150% size, square root scale, cropped)
Image details as above


Back to Top


Rose 30 - Compact Galaxy Group (NGC 5058)

Rose 30 / NGC 5058 (Virgo)
Rose Catalogue,
Note: Image acquired with 2x2 binning / half frame
[ Rose Compact Galaxy Groups ]
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 2x2 binning (half-frame), C Filter
2020-02-21 01:09 UT (#753168-72)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Rose 30 - Detail
NGC 5058 is an unresolved mass of several galaxies
 around 0.6 arc min across
CCD Image (125% size, square root scale, cropped)
Image details as above

Negative CCD Image (125% size, square root scale, cropped)
Image details as above

Rose 30 / NGC 5058 - Earlier Image (2019-12-31)
CCD Image (70% size, square root scale)
3 x 180s exposure (average combine), 2x2 binning (half-frame), C Filter
2019-12-31 06:06 UT (#733325-27)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Segue 1 - Faint Dwarf Galaxy - 0.075 mly

Segue 1 (Leo)
Milky Way Dwarf Galaxy Satellite

Segue 1 is a dwarf spheroidal galaxy or globular cluster situated in the Leo constellation
and discovered in 2006 by Sloan Digital Sky Survey.
It is located at a distance of about 75,000 light years

Segue 1 is one of the smallest and faintest satellites of the Milky Way.
Its integrated luminosity is about 300 times that of the Sun which is
much smaller than the luminosity of a typical globular cluster.
Observations however indicate its mass is about 600,000 solar masses,
which suggest that it is dominated by dark matter.

In the image below the approximate area of Segue 1 dwarf galaxy
 is indicated by large white circle. By comparison with reference image
(Keck/Deimos image) the visible stars that are understood to
lie in Segue 1 are indicated by green circles
 [ Local Group Galaxies ]

Note: a longer exposure is required to detect more stars lying in the dwarf galaxy
Annotated CCD Image (70% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-20 23:58 UT (#753140-44)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Segue 1 - Keck/Deimos Reference Image
Credit: Marla Geha
Image has been rotated and resized to match own image

Segue 1 - Unannotated Images
Annotated CCD Image (70% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2020-02-20 23:58 UT (#753140-44)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Negative CCD Image (70% size, square root scale)
Image details as above
