David's Astronomy Pages
CCD Images - Session 925 (2021-10-14)

Objects Session Notes
Bullet 67P/Churyumov-Gerasimenko - Comet
Bullet C/2019 L3 (ATLAS) - Comet

Bullet Nova Per 2020 - Nova (V1112 Per, AT2020abap)
Bullet Nova Cas 2021 - Nova (V1405 Cas)
Bullet V645 Cyg Stellar Group - Cluster of Stars

Bullet AT 2021xrf - Transient
Bullet AT 2021zkf - YSO Transient, V0645 Cyg

Bullet M31 - Spiral Galaxy with CV Type Transient AT2021aaxp

Bullet NGC 514 - Spiral Galaxy with Type Ia Supernova 2020uxz
Bullet NGC 1166 - Spiral Galaxy with Type II Supernova 2021zby

Bullet PGC 3792 - Local Group Galaxy (Pisces Dwarf), 3.0 mly  (Attempt)

Bullet VV37 - Interacting Galaxies (PGC 7894 & PGC 7901)

Bullet Variable Stars (photometric monitoring)
- BL Lac, RR Lyr

Bullet Nearby Stars (astrometric monitoring)
- DX Cnc, Groombridge 34


- Full night Session (8.8 hours).
- Clear skies all night but poor seeing and moonlit
- Main aims of the session were to acquire a selection of targets including  Comet 67P/Churyumov-Gerasimenko
- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: 12°C (min)
- CCD Temperature:  -10°C
- Notes from 2021-10-14 >>
   [ Local Files >> ]
-


67P/Churyumov-Gerasimenko - Comet

67P/Churyumov-Gerasimenko - 2021-10-15
(passing through Gemini)

Sun Distance 1.23 AU (approaching)
Earth Distance 0.44 AU (66.5 million km)
   67P/Churyumov-Gerasimenko - 2021-10-15, Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra 172.35 arcsec/hr, Dec 26.02 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
2 x 45s exposure (average combine), 3x3 binning, C Filter
2021-10-15 03:09 UT (#925140-41)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  Annotated CCD Image (100% size, log scale, cropped)
5 x 45s exposure (average combine), 3x3 binning, C Filter
2021-10-15 03:11 UT (#925140-44)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of 67P/Churyumov-Gerasimenko on Comets 2021 Page >>

67P/Churyumov-Gerasimenko - False Colour Image(s)
Inverse Spectrum

67P/Churyumov-Gerasimenko - 2021-10-15
False Colour CCD Image (70% size, log scale)
5 x 45s exposure (average combine), 3x3 binning, C Filter
2021-10-15 03:11 UT (#925140-44)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



Back to Top


C/2019 L3 (ATLAS) - Comet

C/2019 L3 (ATLAS) - 2021-10-15
(passing through Lynx)
Sun Distance 3.64 AU (approaching)
Earth Distance 3.47 AU (519.1 million km)
   C/2019 L3 (ATLAS) - 2021-10-15, Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra 21.55 arcsec/hr, Dec -12.59 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
45s exposure (single frame), 3x3 binning, C Filter
2021-10-15 00:26 UT (#925079)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, log scale, cropped)
45s exposure (single frame), 3x3 binning, C Filter
2021-10-15 00:26 UT (#925079)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2019 L3 (ATLAS) on Comets 2021 Page >>

Back to Top


Nova Per 2020 - Nova (V1112 Per, AT2020abap)

Nova Per 2020 (Perseus)
Nova in Perseus discovered 2020/11/25.807
[ Novae ]
Nova Per 2020 discovered independently by Seiji Ueda and Stanislav Korotkiy et al
AT2020abap (Type: CV) reported 2020/11/27.230 UT by PGIR
Alias: N Per 2020 , PGIR20fbf, TCP J04291888+4354233, TCP J04291884+4354232, V1112 Per

Nova Per 2020 - 2021-10-15 (T+323.3d)
Image below (2021-10-15.120) was taken 323.3 days after discovery of nova
Nova is shown by white cross hairs.  Measured magnitude +15.4 (flat / fading slowly)
Annotated CCD Image (100% size, linear scale, cropped)
3 x 90s exposure (average combine), 3x3 binning, C Filter
2021-10-15 02:58 UT (#925130-33)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of Nova Per 2020 on Novae Page >>


Back to Top


Nova Cas 2021 - Nova (V1405 Cas)

Nova Cas 2021 (Cassiopeia)
Nova in Cassiopeia discovered 2021-03-18.4236,  by Yuji Nakamura (Japan)
Magnitude at discovery +9.6 (unfiltered CCD)
AT2021hkn (Type: Nova) reported by 2021/03/30.055 UT by Gaia
Alias: Gaia21bpe, AT2021hkn, V1405 Cas

Nova Cas 2021 / AT2021hkn - 2021-10-15 (T+210.6d)
Image below (2021-10-15.049) was taken 210.6 days after discovery of Nova
Nova is shown by white cross hairs.  Measured magnitude +8.25
(linked with Detection Threshold = 30)
Annotated CCD Image (100% size, linear scale, cropped)
4 x 30s exposure (average combine), 3x3 binning, C Filter
2021-10-15 01:12 UT (#925098-101)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Nova Cas 2021 (V1405 Cas) Spectra - 2021-10-15 (T+210.6d)
Spectra produced in AstroMain using Image taken with Star Analyser 200
2 x 30s exposure (average combine), 2x2 binning, S Filter
2021-10-15 01:16 UT (#925103-06)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of Nova Cas 2021 on Novae Page >>

Back to Top


V645 Cyg Stellar Group - Cluster of Stars

V645 Cyg Stellar Group (Cygnus)
Annotated CCD Image (50% size, linear scale)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2021-10-14 22:09 UT (#925025-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Annotated CCD Image (100% size, linear scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2021-10-14 22:09 UT (#925025-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

V645 Cyg Stellar Group - Detail
Annotated negative CCD Image (150% size, log scale, cropped)
Image details as above


Back to Top


AT 2021xrf - Transient

AT 2021xrf (Perseus)
AT 2021xrf (Type: CV) discovered 2021-09-02.359 UT by Kumar
Alias: GEOTS-2021-022
Discovery Mag +13.5
 ( Rochester Supernova site | TNS 2021xrf )

AT 2021xrf - 2021-10-15 (T+42.8d)
Image below (2021-10-15.165) was taken 42.8 days after discovery of 2021xrf
Position of reported transient (not visible) is shown by white circle
Transient is presumed to have faded back to normal level
Poor quality image (poor sky transparency, single frame)
Annotated CCD Image  (125% size, square root scale, cropped)
180s exposure (single frame), 3x3 binning, C Filter
2021-10-15 03:57 UT (#925158)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2021xrf on Transients 2021 Page >>

Back to Top


AT 2021zkf - YSO Transient, V0645 Cyg

AT 2021zkf / V0645 Cyg (Cygnus)
AT2021zkf (Type: YSO) discovered 2021-09-13.232 UT by Gaia
Alias: Gaia21ego, GCVS V0645 Cyg
Triggering Magnitude 11.16 (G-Gaia Filter)
vs Historic Magnitude 12.14 +/- 0.29 SD
Slow rise of known YSO V645 Cyg, 1 mag in over 5 years
( TNS 2021zkf | Gaia21ego )

AT 2021zkf - 2021-10-14 (T+31.7d)
Image below (2021-10-14.921) was taken 31.7 days after discovery of 2021zkf
Position of transient (distinct) is shown by white cross-hairs
Measured Magnitude +11.49 (Clear Filter)
Annotated CCD Image (100% size, linear scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2021-10-14 22:09 UT (#925025-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2021zkf / V0645 Cyg on Transients 2021 Page >>

Back to Top


M31 - Spiral Galaxy with CV Transient AT2021aaxp

M31 with AT2021aaxp (Andromeda)
AT2021aaxp (Type: CV) discovered 2021-10-09.613 UT by Balam
Alias: PNV J00444033+4113068
Discovery Magnitude 17.77 (G-Gaia Filter)
Spectrum indicates this object is not a nova in M31 but a
CV in the Milky Way Galaxy (TNS 2021aaxp classification)
 Rochester EGN Page | Klaus Wenzel image |  TNS 2021aaxp )

M31 with AT2021aaxp
Image taken with secondary scope showing position of reported transient (blue circle)
relative to outline of M31 galaxy (white ellipse) & M31 Galaxy centre (labelled)


CMOS Image (16% size)
10s exposure (stacked), 1x1 binning
2021-10-15 01:30 UT (#Cam2_Ref)
TS 80mm APO, ZWO ASI178MC & PHD2

M31 with AT2021aaxp (T+5.4d)
Position of reported transient is shown by white cross-hairs
FOV of CCD Images is shown by yellow rectangle in wider view CMOS image above
Annotated CCD Image  (50% size, square root scale)
3 x 60s exposure (average combine), 3x3 binning, C Filter
2021-10-15 00:35 UT (#925084-86)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
M31 with AT 2021aaxp - 2021-10-15 (T+5.4d)
Image below (2021-10-15.023) was taken 5.4 days after discovery of 2021aaxp
Position of reported transient (faint) is shown by white cross-hairs
Annotated CCD Image (125% size, square root scale, cropped)
3 x 60s exposure (average combine), 3x3 binning, C Filter
2021-10-15 00:35 UT (#925084-86)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
Images of AT 2024aaxp (in M31) on Transients 2021 Page >>

Back to Top


NGC 514 - Spiral Galaxy with Type Ia Supernova 2020uxz

NGC 514 (Pisces)
Spiral Galaxy with Type Ia Supernova
[ Supernovae ]

SN 2020uxz (Type 1a), discovered 2020/10/05.573 by Koichi Itagaki
 (Rochester Supernova site | Discovery Image | )

NGC 514 with SN 2020uxz - 2021-10-15 (T+374.5d)
Image below (2021-10-15.058) was taken 374.5 days after discovery of 2020uxz
Position of earlier SN (faded & no longer visible) is shown by white cross hairs.
Annotated CCD Image  (100% size, square root scale, cropped)
4 x 120s exposure (average combine), 3x3 binning, C Filter
2021-10-15 01:29 UT (#925109-13)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2020uxz (NGC 514) on Supernovae 2020 Page >>

Back to Top


NGC 1166 - Spiral Galaxy with Type II Supernova 2021zby

NGC 1166 with SN 2021zby (Aries)
SN 2021zby (Type: II) discovered 2021-09-17.453 UT by ATLAS
Alias: ATLAS21bixf
 (Rochester Supernova site | Enrico Prosperi image )

NGC 1166 with SN 2021zby - 2021-10-15 (T+27.7d)
Image below (2021-10-15.149) was taken 27.7 days after discovery of 2021zby
Position of SN (faint) is shown by white cross-hairs
Estimated Magnitude +16.7 (Clear Filter)
Annotated CCD Image  (150% size, square root scale, cropped)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2021-10-15 03:39 UT (#925150-52)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2021zby (NGC 1166) on Supernovae 2021 Page >>

Back to Top


PGC 3792 - Local Group Galaxy (Pisces Dwarf), 3.0 mly  (attempted observation)

PGC 3792 (Pisces)
20 min total exposure showing slight trace of  PGC 3792
[ Local Group Gaaxies ]
CCD Image (70% size, square root scale)
4 x 300s exposure (average combine), 3x3 binning, C Filter
2021-10-14 23:41 UT (#925070-74)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Annotated negative CCD Image (70% size, square root scale)
Image details as above

PGC 3792 - Earlier Image (Sep 2021)
20 min total exposure showing no trace of  PGC 3792
CCD Image (70% size, square root scale)
4 x 300s exposure (average combine), 3x3 binning, C Filter
2021-09-30 03:07 UT (#918277-80)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

PGC 3792 - Earlier Image (Jan 2021)
25 min total exposure showing no trace of PGC 3792
Despite longer exposure (25 min vs 9 min) poor sky transparency resulted in
a poorer quality image than picture taken in Dec 2020.
CCD Image (70% size, square root scale)
5 x 300s exposure (average combine), 3x3 binning, C Filter
2021-01-08 20:05 UT (#847093-97)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

PGC 3792 - Earlier Image (Dec 2020)
9 min total exposure
Expected location of PGC 3792 shown by white circle
Trace of some objects are just visible within circle and these might be part of the LG galaxy
CCD Image (70% size, square root scale)
3 x 180s exposure (summed), 3x3 binning, C Filter
2020-12-20 22:06 UT (#840107-11)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

PGC 3792 - Earlier Image (2012)
Expected location of PGC 3792 shown by white circle
Annotated CCD Image (50% size)
5 x 90s exposure (average combine), 3x3 binning, C Filter
2012-11-02  22:05 hUT (#520203-07)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


VV37 - Interacting Galaxies (PGC 7894 & PGC 7901)

VV 37 (Andromeda)
Vorontsov-Velyaminov Catalogue
Alias: PGC 7894 & PGC 7901
  [ Vorontsov-Velyaminov Galaxies ]

Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2021-10-15 02:39 UT (#925122-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

VV 37 -  Detail
PGC 7894 (catalog mag +14.7),
PGC 7901 (catalog mag +15.7) &
PGC 7895 (catalog mag +17.1)
Annotated CCD Image (150% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2021-10-15 02:39 UT (#925122-26)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

CCD Image (150% size, square root scale, cropped)
Image details as above

Negative CCD Image (150% size, square root scale, cropped)
Image details as above


Back to Top
