David's Astronomy Pages
Images - Session 1063 (2022-11-27)

 Previous Imaging Session
Images
(S1062)		   Home
Images
Main		   Home
Home
Page		   Next Imaging Session
Images
(S1064)
Objects Session Notes
Bullet Mars - Planet
Bullet Jupiter - Planet

Bullet 29P/Schwassmann-Wachmann - Comet
Bullet 81/P Wild - Comet
Bullet C/2019 U5 (PANSTARRS) - Comet
Bullet C/2022 E3 (ZTF) - Comet

Bullet AT 2021aecv - CV Type Transient
Bullet AT 2021aeoz - CV Type Transient (Attempt)
Bullet AT 2022oar - Type ulens? Transient
Bullet AT 2022qnm - Type ulens? Transient
Bullet AT 2022why - Type Nova? Transient

Bullet EGB 6 - Planetary Nebula (Ellis Grayson Bond 6)  (Attempt)
Bullet IC 62 - Spiral Galaxy with Transient AT 2022wvj

Bullet M33 2022-11a? - Candidate Extragalactic Nova in M33
Bullet M105 - Elliptical Galaxy (Herschel I-17)

Bullet NGC 3371 - Elliptical Galaxy (Herschel I-18)
Bullet NGC 3859 - Spiral Galaxy with Transient AT 2022zia (Unconfirmed)
Bullet NGC 3938 - Spiral Galaxy with Type Ia-02cx Supernova 2022xlp

Bullet PN G054.2-03.4 - Planetary Nebula
Bullet SN 2022vod - Type Ia Supernova

Bullet UGC 8046 - Spiral Galaxy with Type II Supernova SN 2022zxr

  - HD1 Field, NGC 3479 w/AT2022abgf, NGC 4257 w/AT2022zzk, NGC 4714 w/AT2022rrp & NGC 5548 w/AT2022abcs attempts failed (due to cloud & bad guiding)

Bullet Variable Stars (photometric monitoring)
- RX And, U And, CI Cyg, SS Cyg, DY Per,

Bullet Nearby Stars (astrometric monitoring)
- None

- Attempted All Night session (10.7h), but hampered by cloud and a software bug (unable to resume from Suspended State)

- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: 6°C (min)
- CCD Temperature:  -15°/ -20° C
- Notes from 2022-11-27 >>




Mars - Planet

Mars
(passing through Taurus)
Sun Distance 1.52 AU
Earth Distance 0.55 AU (81.6 million km)
(Motion Ra -62.60 arcsec/hr, Dec 2.61 arcsec/hr)
Annotated CCD Image
(150% size, linear scale, cropped, unsharp masked)
Original images collected as 1/4 (one quater) frames
7 x 0.30s exposure (average combine), 1x1 binning, B Filter
2022-11-28 02:15 UT (#1063234-41)
12" LX200R (at f/10.4) + ST-10XME

Annotated CCD Image
(175% size, linear scale, cropped,unsharp masked))
Original images collected as 1/4 (one quater) frames
6 x 0.2s exposure (average combine), 1x1 binning, Ha Filter
2022-11-28 02:17 UT (#1063253-61)
12" LX200R (at f/10.4) + ST-10XME

Mars - Earlier Image (2020-11-05)
CCD Image
(100% size, linear scale, cropped, unsharp masked
0.15s exposure (single frame), 1x1 binning, Ha Filter
2020-11-05 22:52 UT (#827142-44)
12" LX200R (at f/10.4) + ST-10XME


Back to Top

Jupiter - Planet

Jupiter (passing through Pisces)
Sun Distance 4.95 AU
Earth Distance 4.38 AU (655.1 million km)

Jupiter
Approx Colour
Poor seeing
Approx Colour CCD Image (100% size, cropped, unsharp masked)
Combined BVR Image from 3 images (8 frames):

4 x 0.2s exposure (average combine), 1x1 binning, B Filter
2022-11-27 23:06.31 UT (#)
2 x 0.12s exposure (average combine), 1x1 binning, V Filter
2022-11-27 23:07:33 UT (#1)
2 x 0.12s exposure (average combine), 1x1 binning, R Filter
2022-11-27 23:08:34 UT (#1)
12" LX200R (at f/10.4) + ST-10XME


Jupiter Moons
Annotated CCD Image (70% size, linear scale)
4 x 0.2s exposure (average combine), 3x3 binning, V Filter
2022-11-27 23:05 UT (#1063093-97)
12" LX200R (at f/10.4) + ST-10XME


Back to Top

29P/Schwassmann-Wachmann - Comet

29P/Schwassmann-Wachmann - 2022-11-27
(passing through Gemini)
Sun Distance 6.05 AU
Earth Distance 5.23 AU (782.3 million km)		    29P/Schwassmann-Wachmann - 2022-11-27 Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra -13.60 arcsec/hr, Dec 1.36 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
5 x 30s exposure (average combine), 3x3 binning, Clear Filter
2022-11-27 19:55 UT (#1063050-57)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2		   Annotated CCD Image (100% size, log scale, cropped)
5 x 30s exposure (average combine), 3x3 binning, Clear Filter
2022-11-27 19:55 UT (#1063050-57)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

29P/Schwassmann-Wachmann - 2022-11-27 Detail
(passing through Gemini)
 Coma diameter: 39"
Image   Sun Distance 6.05 AU
Earth Distance 5.23 AU (782.3 million km)
(Motion : Ra -13.60 arcsec/hr, Dec 1.36 arcsec/hr)
Detail (150% size)


Annotated CCD Image (150% size, log scale, cropped)
5 x 30s exposure (average combine), 3x3 binning, Clear Filter
2022-11-27 19:55 UT (#1063050-57)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

29P/Schwassmann-Wachmann
(passing through Gemini)
Sun Distance 6.05 AU
Earth Distance 5.23 AU (782.1 million km)		    29P/Schwassmann-Wachmann - 2022-11-28 am Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra -13.67 arcsec/hr, Dec 1.35 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
7 x 30s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 00:00 UT (#1063167-81)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2		   Annotated CCD Image (100% size, log scale, cropped)
7 x 30s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 00:00 UT (#1063167-81)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

29P/Schwassmann-Wachmann - 2022-11-28 am Detail
(passing through Gemini)
 Coma diameter: 47"
Image   Sun Distance 6.05 AU
Earth Distance 5.23 AU (782.1 million km)
(Motion : Ra -13.67 arcsec/hr, Dec 1.35 arcsec/hr)
Detail (150% size)


Annotated CCD Image (150% size, log scale, cropped)
7 x 30s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 00:00 UT (#1063167-81)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Images of 29P/Schwassmann-Wachmann on Comets 2022 Page >>

Back to Top

81/P Wild - Comet

81P/Wild - 2022-11-28
(passing through Virgo)
Sun Distance 1.61 AU  (approaching ?)
Earth Distance 2.05 AU (306.2 million km)		    81P/Wild - 2022-11-28 Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra 103.76 arcsec/hr, Dec -38.89 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
3 x 60s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 05:36 UT (#1063326-28)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2		   Annotated CCD Image (100% size, log scale, cropped)
15 x 60s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 05:42 UT (#1063325-39)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of 81/P Wild on Comets 2016 Page >>
Images of 81/P Wild on Comets 2022 Page >>

Back to Top

C/2019 U5 (PANSTARRS) - Comet

C/2019 U5 (PANSTARRS) - 2022-11-28
(passing through Virgo)
Sun Distance 3.79 AU
Earth Distance 4.41 AU (659.7 million km)
Comet position is indicated by white cross-hairs		    C/2019 U5 (PANSTARRS) - 2022-11-28 Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra 7.99 arcsec/hr, Dec -18.47 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
4 x 60s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 05:59 UT (#1063342-45)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2		   Annotated CCD Image (100% size, square root scale, cropped)
9 x 60s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 06:02 UT (#1063342-50)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2019 U5 (PANSTARRS) on Comets 2022 Page >>

Back to Top

C/2022 E3 (ZTF) - Comet

C/2022 E3 (ZTF) - 2022-11-28
(passing through Serpens)
 Sun Distance 1.33 AU (approaching
Earth Distance 1.80 AU (270.0 million km)		    C/2022 E3 (ZTF) - 2022-11-28 Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra 4.48 arcsec/hr, Dec 7.98 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
7 x 90s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 06:20 UT (#1063354-60)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2		   CCD Image (100% size, log scale, cropped)
Image details as left

Images of C/2022 E3 (ZTF) on Comets 2022 Page >>

C/2022 E3 (ZTF)  - False Colour
Inverse Spectrum Images

C/2022 E3 (ZTF) - 2022-11-28
False Colour CCD Image (70% size, log scale)
7 x 90s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 06:20 UT (#1063354-60)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top

AT 2021aecv - CV Type Transient

AT 2021aecv (Lacerta)
AT 2021aecv (Type: CV) discovered 2021-11-09.661 UT by XOSS
Alias: PSP21ad
Discovery Magnitude 13.99 (Clear Filter)
 ( TNS 2021aecv )

AT 2021aecv - 2022-11-27 (T+383.3d)
Image below (2022-11-27.992) was taken 383.3 days after discovery of 2021aecv
Position of transient (very faint) is shown by white cross-hairs
Measured Magnitude +17.85 (Clear Filter)
Annotated CCD Image (100% size, linear scale, cropped)
3 x 60s exposure (average combine), 3x3 binning, Clear Filter
2022-11-27 23:50 UT (#1063161-63)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2021aecv on Transients 2021 Page >>

Back to Top

AT 2021aeoz - CV Type Transient (Attempt)

AT 2021aeoz (Perseus)
AT 2021aeoz (Type: CV) discovered 2021-11-13.841 UT by XOSS
Alias: PSP21ah
Discovery Mag +16.86 (Clear Filter)
 ( TNS 2021aeoz )

AT 2021aeoz - 2022-11-28 (T+379.2d)
Image below (2022-11-28.059) was taken 379.2 days after discovery of 2021aeoz
Position of earlier transient (faded / not visible) is shown by white cross-hairs
Annotated CCD Image (100% size, linear scale, cropped)
60s exposure (single frame), 3x3 binning, Clear Filter
2022-11-28 01:25 UT (#1063206)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2021aeoz on Transients 2021 Page >>

Back to Top

AT 2022oar - Type ulens? Transient

AT 2022oar (Camelopardalis)
AT 2022oar (Type: ulens?) discovered 2022-06-30.664 UT by Gaia
Alias: Gaia22csu
Alerting magnitude 12.47 (G-Gaia filter) vs Historic mag 12.78 +/- 0.07
Bright gal.plane source candidate microlensing event
or Be-type outburst rises by 0.3 mag
 ( TNS 2022oar | Gaia22csu )

AT 2022oar - 2022-11-28 (T+150.4d)
Image below (2022-11-28.045) was taken 150.4 days after discovery of 2022oar
Position of earlier reported transient (still bright) is shown by white cross-hairs
Measured magntitude + 12.26 (C Filter)
Annotated CCD Image (100% size, linear scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 01:13 UT (#1063199-202)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2022oar on Transients 2022 Page >>

Back to Top

AT 2022qnm - Type ulens? Transient

AT 2022qnm (Vulpecula)
AT 2022qnm (Type: ulens?) discovered 2022-07-28.562 UT by Gaia
Alias: Gaia22ddh
Alerting Magnitude 13.64 vs Historic Magnitude 13.92(Clear Filter)
 ( TNS 2022qnm , Gaia22ddh)

AT 2022qnm - 2022-11-27 (T+122.2d)
Image below (2022-11-27.772) was taken 122.2 days after discovery of 2022qnm
Position of reported transient (distinct) is shown by white cross-hairs
Measured Magnitude +13.88 (Clear Filter)
Annotated CCD Image (100% size, linear scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-27 18:34 UT (#1063008-09)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2022qnm on Transients 2022 Page >>

Back to Top

AT 2022why - Type Nova? Transient

AT 2022why (Cassiopeia)
AT 2022why (Type: Nova?) discovered 2022-09-30.436 UT by Tadashi Kojima
Alias: TCP J23580957+5502503, TCP J23580961+5502508, Gaia22eci
 ( TNS 2022why , Gaia22eci )

AT 2022why - 2022-11-27 (T+58.5d)
Image below (2022-11-27.969) was taken 58.5 days after discovery of 2022why
Position of reported transient (very faint) is shown by white cross-hairs
Measured magnitude +17.41 (Clear Filter)
Annotated CCD Image (100% size, linear scale, cropped)
5 x 60s exposure (average combine), 3x3 binning, Clear Filter
2022-11-27 23:18 UT (#1063131-35)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

AT 2022why - Earlier Image 2022-10-01 (T+1.5d)
Image below (2022-10-01.952) was taken 1.5 days after discovery of 2022why
Position of reported transient (distinctt) is shown by white cross-hairs
Measured magnitude +11.88 (Clear Filter)
Annotated CCD Image (100% size, linear scale, cropped)
5 x 60s exposure (average combine), 3x3 binning, Clear Filter
2022-10-01 22:54 UT (#1044047-51)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2022why on Transients 2022 Page >>

Back to Top

EGB 6 - Planetary Nebula (Ellis Grayson Bond 6), Attempted Sighting

EGB 6 (Leo)
Alias: Ellis Grayson Bond 6, PN G221.6+46.4, PK 221+46 1
Western (brightest) side of 20' x 20' Pln.Neb (Ast.Now, Jun 2022, p13)
 [ Planetary Nebula ]
Approximate position of Pl.Neb is indicated by white circle
with centre indicated by white cross-hairs
Poor quality image (single frame, ghost artefact (Mars) )
Annotated CCD Image (50% size, square root scale)
180s exposure (single frame), 3x3 binning, Clear Filter
2022-11-28 02:21 UT (#1063265)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top

IC 62 - Spiral Galaxy with Transient AT 2022wvj (Attempt)

IC 62 with AT 2022wvj (Pisces)
AT 2022wvj (Type: unk) discovered 2022-10-04.561 UT by ATLAS
Alias: ATLAS22bhyb
Discovery Mag +17.84 (cyan-Atlas Filter)
 ( TNS 2022wvj )

IC 62 with AT 2022wvj - 2022-11-28 (T+54.5d)
 Image below (2022-11-28.072) was taken 54.5 days after discovery of 2022wvj
Position of earlier transient (indistinguishable) is shown by white cross-hairs
Annotated CCD Image (150% size, square root scale, cropped)
180s exposure (single frame), 3x3 binning, Clear Filter
2022-11-28 01:44 UT (#1063216)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2022wvj (IC 62) on Transients 2022 Page >>

Back to Top

M33 2022-11a? - Candidate Extragalactic Nova in M33

M33 with Candidate Nova M33 2022-11a? (Triangulum)
Nova M33 2022-11a? (Type: unk) discovered 2022-11-20.575 UT by XOSS
Alias: TCP J01350893+3031503
Discovery Mag +13.4
 ( Rochester Latest Extragalactic Novae | TCP J01350893+3031503  | Discovery Image )

Nova M33 2022-11a? - 2022-11-27 (T+7.2d)
Image below (2022-11-27.803) was taken 7.2 days after discovery of Nova M33 2022-11a?
Position of reported nova (distinct) is shown by white cross-hairs
Measured magnitude +15.83 (Clear Filter)
Annotated CCD Image (100% size, square root scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-27 19:24 UT (#1063026-30)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of Nova M33 2022-11a? (M33) on Transients 2022 Page >>

Back to Top

M105 - Elliptical Galaxy (Herschel I-17)

M105 (Leo)
Alias :  Herschel I-17, NGC 3379
[ Messier Objects ]  [ Herschel 400 Objects ]

M105 - Elliptical Galaxy
with adjacent elliptical galaxy NGC 3371
Annotated CCD Image (50% size, log scale)
2 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 02:50 UT (#1063274-77)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

M105 - Detail
Annotated CCD Image (100% size, log scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 02:50 UT (#1063274-77)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

False-colour CCD Image (100% size, log scale, cropped)
Inverse Colour
Image details as above

M105 - Earlier Image (2010)
CCD Image (cropped)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2010-02-18 00:44 hUT (#413054-58)
12" LX200R (at f/9.7) + ST-10XME


Back to Top

NGC 3371 - Elliptical Galaxy (Herschel I-18)

NGC 3371 (Leo)
Alias :  Herschel I-18, NGC 3384

NGC 3371 & M105
Pair of Elliptical Galaxies
Annotated CCD Image (50% size, log scale)
2 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 02:50 UT (#1063274-77)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 3371 - Detail
Annotated CCD Image (100% size, log scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 02:50 UT (#1063274-77)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 3371 - Earlier Image (2004)
CCD Image
3 x 2 min (average combine),  C Filter
2004-12-11 06:20 h UT (#79026-28)
8" LX200 Classic + ST-7E


Back to Top

NGC 3859 - Spiral Galaxy with Transient AT 2022zia (Unconfirmed)

NGC 3859 with AT 2022zia (Leo)
AT 2022zia (Type: unk) discovered 2022-11-01.612 UT by ATLAS
Alias: ATLAS22bldy
Discovery Magnitude 18.30 (orange-ATLAS Filter)
 ( TNS 2022zia )

NGC 3859 with AT 2022zia - 2022-11-28 (T+26.6d)
 Image below (2022-11-28.178) was taken 26.6 days after discovery of 2022zia
Position of transient (not distinguishable) is shown by white cross-hairs
Measured magnitude +14.67 (nucleus + transient)
Annotated CCD Image (150% size, square root scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 04:21 UT (#1063298-300)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2022zia (NGC 3859) on Transients 2022 Page >>

Back to Top

NGC 3938 - Spiral Galaxy with Type Ia-02cx Supernova 2022xlp

NGC 3938 with SN 2022xlp (Ursa Major)
SN 2022xlp (Type: Ia-02cx) discovered 2022-10-13.808 UT by Koichi Itagaki
Alias: ATLAS22bkeb
Discovery Magnitude 17.0 (Other Filter)
 ( TNS 2022xlp )

NGC 3938 with SN 2022xlp - 2022-11-28 (T+45.3d)
 Image below (2022-11-28.128) was taken 45.3 days after discovery of 2022xlp
Position of SN (faint, fading) shown by white cross-hairs
Measured magnitude +17.03
Annotated CCD Image (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 03:11 UT (#1063281-84)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022xlp (NGC 3938) on Supernova 2022 Page >>

Back to Top

PN G054.2-03.4 - Planetary Nebula

PN G054.2-03.4 (Sagitta)
cf. Ast. Now, Jul 2021, p11
 [ Planetary Nebula ]
Annotated CCD Image (50% size, square root scale)
5 x 30s exposure (average combine), 3x3 binning, Clear Filter
2022-11-27 20:13 UT (#1063071-75)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

PN G054.2-03.4 - Detail
Position of Pl.Neb (faint) is indicated by white circle
Annotated CCD Image (150% size, square root scale, cropped)
5 x 30s exposure (average combine), 3x3 binning, Clear Filter
2022-11-27 20:13 UT (#1063071-75)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Position of Pl.Neb (faint) is indicated by black cross-hairs
Negative CCD Image (150% size, square root scale, cropped)
Image details as above



Back to Top

SN 2022vod - Type Ia Supernova

SN 2022vod (Hydra)
SN 2022vod (Type: Ia) discovered 2022-09-21.604 UT by Gaia
Alias: Gaia22dzh, ZTF22abjbvnv
Discovery Magnitude 15.92 (G-Gaia Filter)
Declined to 18.6 on 2022-12-14
 ( TNS 2022vod | Gaia22dzh )

SN 2022vod - 2022-11-28 (T+67.5d)
Image below (2022-11-28.081) was taken 67.5 days after discovery of 2022vod
Position of SN (very faint) is shown by white cross-hairs
Measured Magnitude +17.99 (Clear Filter)
Annotated CCD Image (125% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, Clear Filter
2022-11-28 02:05 UT (#1063221-25)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022vod on Supernova 2022 Page >>

Back to Top

UGC 8046 - Spiral Galaxy with Type II Supernova SN 2022zxr

UGC 8046 with SN 2022zxr (Ursa Major)
SN 2022zxr (Type: II) discovered 2022-11-10.491 UT by ZTF
Alias: ZTF22abtcyhv
Discovery Mag +16.65
 ( Rochester Supernova site | TNS 2022zxr )

UGC 8046 with SN 2022zxr - 2022-11-28 (T+17.5d)
 Image below (2022-11-28.037) was taken 17.5 days after discovery of 2022zxr
Position of reported SN (distinct) is shown by white cross-hairs
Measured magnitude +15.83
Poor quality image (poor sky conditions, single frame)
Annotated CCD Image (150% size, square root scale, cropped)
180s exposure (single frame), 3x3 binning, Clear Filter
2022-11-28 00:53 UT (#1063195)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022zxr (UGC 8046) on Supernova 2022 Page >>

Back to Top

This Web Page: Images - Session 1063 (2022-11-27)
Last Updated : 2024-06-20
Site Owner : David Richards
Home Page : David's Astronomy Web Site
