| Mars (passing through Taurus) Sun Distance 1.52 AU Earth Distance 0.54 AU (81.5 million km) (Motion Ra -62.45 arcsec/hr, Dec 3.50 arcsec/hr) |
 |
| Approximate Colour CCD Image (175% size, linear scale, cropped, unsharp masked) Original images collected as 1/4 (one quater) frames Blue Channel: 10 x 0.3s exposure (average combine), 1x1 binning, B Filter 2022-11-28 21:04 UT (#1064112-21) Green Channel: 10 x 0.3s exposure (average combine), 1x1 binning, DB Filter 2022-11-28 21:06 UT (#1064132-41) Red Channel: 10 x 0.3s exposure (average combine), 1x1 binning, Ha Filter 2022-11-28 21:05 UT (#1064122-31) 12" LX200R (at f/10.4) + ST-10XME |
 |
| Annotated CCD Image (175% size, linear scale, cropped) 10 x 0.3s exposure (average combine), 1x1 binning, Ha Filter 2022-11-28 21:05 UT (#1064122-31) 12" LX200R (at f/10.4) + ST-10XME |
Back to Top
| Jupiter (passing through Pisces) Sun Distance 4.95 AU Earth Distance 4.49 AU (672.3 million km) (Motion: Ra 1.83 arcsec/hr, Dec 1.67 arcsec/hr) |
| Jupiter Approx Colour |
 |
| Approx Colour CCD Image (100% size, cropped, unsharp masked) Combined BVR Image from 3 images (30 frames): 10 x 0.2s exposure (average combine), 1x1 binning, B Filter 2022-11-28 21:10 UT (#1064149-58) 10 x 0.12s exposure (average combine), 1x1 binning, V Filter 2022-11-28 21:11 UT (#1064159-68) 10 x 0.12s exposure (average combine), 1x1 binning, R Filter 2022-11-28 21:12 UT (#1064169-78) 12" LX200R (at f/10.4) + ST-10XME |
 |
| CCD Image Montage (100% size, cropped) Image details as above |
| Jupiter Moons |
 |
| Annotated CCD Image (70% size, linear scale) 5 x 0.2s exposure (average combine), 3x3 binning, V Filter 2022-11-28 21:09 UT (#1064144-48) 12" LX200R (at f/10.4) + ST-10XME |
Back to Top
| 29P/Schwassmann-Wachmann - 2022-11-28 pm (passing through Gemini) Sun Distance 6.05 AU Earth Distance 5.22 AU (781.0 million km) |
29P/Schwassmann-Wachmann - 2022-11-28 pm Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -13.98 arcsec/hr, Dec 1.33 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 5 x 30s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 18:56 UT (#1064016-20) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, log scale, cropped) 15 x 30s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 18:59 UT (#1064016-30) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| 29P/Schwassmann-Wachmann - 2022-11-28 pm Detail (passing through Gemini) Coma diameter: 54" |
||
 |
Sun Distance 6.05 AU Earth Distance 5.22 AU (781.0 million km (Motion : Ra -13.98 arcsec/hr, Dec 1.33 arcsec/hr) Detail (150% size) Annotated CCD Image (150% size, log scale, cropped) 5 x 30s exposure (average combine), 3x3 binning, Clear Filter 2022-11-27 19:55 UT (#1063050-57) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 29P/Schwassmann-Wachmann on Comets 2022 Page >> |
Back to Top
| 61P/Shajn-Schaldach - 2022-11-28 (passing through Cetus) Sun Distance 2.14 AU Earth Distance 1.36 AU (203.7 million km) |
61P/Shajn-Schaldach - 2022-11-28 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 10.58 arcsec/hr, Dec 6.62 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 7 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 20:28 UT (#1064082-88) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 7 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 20:28 UT (#1064082-88) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 61P/Shajn-Schaldach on Comets 2022 Page >> |
Back to Top
| 81P/Wild (passing through Virgo) Sun Distance 1.61 AU (approaching) Earth Distance 2.04 AU (305.4 million km) |
81P/Wild - 2022-11-29 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 103.75 arcsec/hr, Dec -38.70 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 3 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 05:28 UT (#1064391-93) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 14 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 05:34 UT (#1064391-405) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of 81/P Wild on Comets 2016 Page >> | ||
| Images of 81/P Wild on Comets 2022 Page >> |
Back to Top
| C/2019 U5 (PANSTARRS) (passing through Bootes) Sun Distance 3.78 AU (approaching) Earth Distance 4.40 AU (657.8 million km) Comet position is indicated by white cross-hairs |
C/2019 U5 (PANSTARRS) - 2022-11-29 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 7.72 arcsec/hr, Dec -18.32 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 04:52 UT (#1064373-81) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 04:52 UT (#1064373-81) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| C/2019 U5 (PANSTARRS) showing the problem posed by the ever increasing numbers of satellites being put into earth orbit Stacked image below (9 x 60s) records 5 satellite tracks in 9 minutes |
||
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 9 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 04:53 UT (#1064373-81) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Negative CCD Image (50% size, square root scale) Image details as left |
|
| Images of C/2019 U5 (PANSTARRS) on Comets 2022 Page >> |
Back to Top
| C/2021 Y1 (ATLAS) (passing through Taurus) Sun Distance 2.71 AU Earth Distance 1.73 AU (259.1 million km) |
C/2021 Y1 (ATLAS) - 2022-11-28 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra -62.37 arcsec/hr, Dec -74.81 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 2 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 20:12 UT (#1064072-73) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Annotated CCD Image (100% size, square root scale, cropped) 7 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 20:15 UT (#1064072-78) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2021 Y1 (ATLAS) on Comets 2022 Page >> |
Back to Top
| C/2022 E3 (ZTF) (passing through Serpens) Sun Distance 1.32 AU (approaching Earth Distance 1.79 AU (267.5 million km) |
C/2022 E3 (ZTF) - 2022-11-29 Detail Autoguided on offset star using PHD2 with Lock Shift set at the comet's rate of motion (Ra 4.50 arcsec/hr, Dec 8.75 arcsec/hr) |
|
 |
 |
|
| Annotated CCD Image (50% size, square root scale) 2 x 90s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 05:51 UT (#1064408-09) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (100% size, log scale, cropped) 7 x 90s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 05:56 UT (#1064408-14) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
|
| Images of C/2022 E3 (ZTF) on Comets 2022 Page >> |
| C/2022 E3 (ZTF) - False Colour Inverse Spectrum Images |
| C/2022 E3 (ZTF) - 2022-11-29 |
 |
| False Colour CCD Image (70% size, log scale) 7 x 90s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 05:56 UT (#1064408-14) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| Nova Per 2020 (Perseus) Nova in Perseus discovered 2020/11/25.807 [ Novae ] Nova Per 2020 discovered independently by Seiji Ueda and Stanislav Korotkiy et al AT 2020abap (Type: CV) reported 2020/11/27.230 UT by PGIR Alias: N Per 2020 , PGIR20fbf, TCP J04291888+4354233, TCP J04291884+4354232, V1112 Per |
| Nova Per 2020 - 2022-11-28 (T+733.1d) Image below (2022-11-28.910) was taken 733.1 days after discovery of Nova (fading) is shown by white cross hairs. Measured magnitude +17.22 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 3 x 90s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 21:54 UT (#1064196-98) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of Nova Per 2020 on Novae Page >> |
Back to Top
| AT2021agxs (Gemini) AT2021agxs (Type: CV) discovered 2021-12-28.532 UT by Tadashi Kojima Alias: TCP J07094936+1412280 Magnitude +13.6 at discovery. Possible CV [ TNS 2021agxs ] |
| AT 2021agxs - 2022-11-29 (T+335.5d) Image below (2022-11-29.032) was taken 335.5 days after discovery of 2021agxs Position of earlier transient (not visible) is shown by white cross hairs. |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 00:50 UT (#1064273-76) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| AT2021agxs - Earlier Image, 2022-01-21 (T+24.4d) Image below (2022-01-21.927) was taken 24.4 days after discovery of 2021agxs Reported transient is shown by white cross hairs. Measured magnitude +15.1 (fading) |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 60s exposure (average combine), 3x3 binning, C Filter 2022-01-21 22:18 UT (#957160-64) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2021agxs on Transients 2021 Page >> |
Back to Top
| AT 2022obq (Andromeda) AT 2022obq (Type: CV) discovered 2022-07-01.104 UT by Gaia Alias: Gaia22cti Alerting magnitude 13.15 (vs Historic magnitude 15.23) ( TNS 2022obq | Gaia22cti ) |
| AT 2022obq - 2022-11-28 (T+150.8d) Image below (2022-11-28.903) was taken 150.8 days after discovery of 2022obq Position of transient (distinct) is shown by white cross-hairs Measured Magnitude + 13.73 |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 21:43 UT (#1064189-93) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022obq on Transients 2022 Page >> |
Back to Top
| AT 2022rat (Taurus) AT 2022rat (Type: CV) discovered 2022-08-09.775 UT by Tadashi Kojima Alias: AT2022rba, ATLAS22zrb, TCP J04343348+0411387 Discovery Magnitude 13 (Clear Filter) ( TNS 2022rat ) |
| AT 2022rat - 2022-11-28 (T+111.2d) Image below (2022-11-28.942) was taken 111.2 days after discovery of 2022rat Position of earlier transient (not visible) is shown by white cross-hairs |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 22:41 UT (#1064227-29) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022rat on Transients 2022 Page >> |
Back to Top
| AT 2022rhv (Pegasus) AT 2022rhv (Type: CV) discovered 2022-08-14.849 UT by Gaia Alias: Gaia22dki Aleting Magnitude 16.46 (vs Historic magnitude 18.58) Outburst in candidate CV CRTS J233003.0+303300 ( TNS 2022ovb | Gaia22dki ) |
| AT 2022rhv - 2022-11-28 (T+106.0d) Image below (2022-11-28.811) was taken 106.0 days after discovery of 2022rhv Position of earlier transient (not visible) is shown by white circle |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 19:31 UT (#1064045-49) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022rhv on Transients 2022 Page >> |
Back to Top
| SN 2022taf (Auriga) Alias: In WISEA J062203.48+295041.0 SN 2022taf (Type: Ia) discovered 2022-09-01.456 UT by ZTF Alias: ZTF22abemgir Discovery Mag +16.0 ( TNS 2022taf ) |
| SN 2022taf (T+88.5d) |
 |
| Annotated CCD Image (50% size, square root scale) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 00:10 UT (#1064258-62) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| SN 2022taf - 2022-11-29 (T+88.5d) Image below (2022-11-29.002) was taken 88.5 days after discovery of 2022taf Position of reported SN (visible?) is shown by white cross-hairs Measured magnitude +15.64 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 00:10 UT (#1064258-62) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022taf (Unnamed Galaxy) on Supernova 2022 Page >> |
Back to Top
| AT 2022tos (Taurus) AT 2022tos (Type: CV) discovered 2022-09-03.668 UT by Gaia Alias: Gaia22dso Alerting magnitude 15.94 (vs Historic magnitude 20.35) ( TNS 2022ablr | Gaia22dso ) |
| AT 2022tos - 2022-11-29 (T+86.4d) Image below (2022-11-29.094) was taken 86.4 days after discovery of 2022tos Position of earlier transient (not visible) is shown by white cross-hairs |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 02:25 UT (#1064322-25) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022tos on Transients 2022 Page >> |
Back to Top
| AT 2022tqu (Auriga) AT 2022tqu (Type: Nova) discovered 2022-09-06.418 UT by Kumar Alias: GEOTS-2022-013 Discovery Magnitude +12.7 (Clear Filter) ( TNS 2022tqu ) |
| AT 2022tqu - 2022-11-29 (T+83.7d) Image below (2022-11-29.109) was taken 83.7 days after discovery of 2022tqu Position of earlier transient (no longer visible) is shown by white circle |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 02:46 UT (#1064328-32) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| AT 2022tqu - Earlier Image (2022-09-23, T+16.8d) Image below (2022-09-23.172) was taken 16.8 days after discovery of 2022tqu Position of Transient is shown by white cross-hairs Measured Magnitude +14.83 (aperture 8) Brightness has evidently faded by 2 mag since discovery |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-09-23 04:19 UT (#1040176-80) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022tqu on Transients 2022 Page >> |
Back to Top
| AT 2022vry (Cancer) Alias: In SDSS J083055.71+071556.5 AT 2022vry (Type: unk) discovered 2022-09-22.505 UT by ZTF Alias: ZTF22abhjmfy, Gaia22ebv Discovery Magnitude +16.35 (r-ZTF filter) [ TNS 2022vry | Gaia22ebv ] |
| AT 2022vry - 2022-11-29 (T+67.5d) Image below (2022-11-29.016) was taken 67.5 days after discovery of 2022vry Position of earlier transient (not visible) is shown by white circle No indication of transient or its host galaxy SDSS J083055.71+071556.5 |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 00:30 UT (#1064265-68) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022vry (SDSS J083055.71+071556.5) on Transients 2022 Page >> |
Back to Top
| AT 2022wim (Cetus) AT 2022wim (Type: CV) discovered 2022-09-20.787 UT by XOSS Alias: KATS22S004, TCP J00301511-1350273 Discovery Magnitude 16.46 ( TNS 2022wim ) |
| AT 2022wim - 2022-11-28 (T+69.1d) Image below (2022-11-28.887) was taken 69.1 days after discovery of 2022wim Position of earlier transient (not visible) is shown by white circle |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2022-11-28 21:30 UT (#1064186) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022wim on Transients 2022 Page >> |
Back to Top
| AT 2022xao (Gemini) AT 2022xao (Type: QSO) discovered 2022-10-02.836 UT by Gaia Alias: Gaia22eda Alerting Magnitude 16.48 (vs Historic magnitude 15.20) Fading in known blazar QSO B0647+250 ( TNS 2022xao | Gaia22eda) |
| QSO B0647+250 - Blazer Position of QSO is shown by white cross-hairs |
 |
| Annotated CCD Image (50% size, square root scale) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 23:32 UT (#1064245-48) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| QSO B0647+250 - Blazer - Detail |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 23:32 UT (#1064245-48) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| AT 2022xao - 2022-11-28 (T+57.1d) Image below (2022-11-28.973) was taken 57.1 days after discovery of 2022xaot (this is about 3 years after fading actual started in late 2020, see Gaia Charts at Gaia22eda) Position of QSO (visible) is shown by white cross-hairs Measured magnitude +16.47 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 23:32 UT (#1064245-48) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022xao (QSO B0647+250) on Transients 2022 Page >> |
Back to Top
| AT 2022yse (Gemini) AT 2022yse (Type: CV) discovered 2022-10-26.441 UT by ZTF Alias: ZTF22abqhcvd ( TNS 2022yse ) |
| AT 2022yse - 2022-11-29 (T+33.6d) Image below (2022-11-29.040) was taken 33.6 days after discovery of 2022yse Position of earlier transient (no longer visible) is shown by white cross-hairs |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 2 x 60s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 01:00 UT (#1064279-82) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022yse on Transients 2022 Page >> |
Back to Top
| AT 2022ywv (Hydra) AT 2022ywv (Type: unk) discovered 2022-10-15.506 UT by ZTF Alias: ZTF22abrdbml Alerting magnitude 15.94 (vs Historic magnitude 20.35) ( TNS 2022ywv ) |
| AT 2022ywv - 2022-11-29 (T+44.7d) Image below (2022-11-29.156) was taken 44.7 days after discovery of 2022ywv Position of reported transient (not visible) is shown by white circle |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 03:51 UT (#1064352-55) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022ywv on Transients 2022 Page >> |
Back to Top
| AT 2022ablr (Taurus) AT 2022ablr (Type: unk) discovered 2022-11-24.245 UT by GEOTS Alias: GEOTS-2022-015, TCP J05411381+2739382 Discovery Mag 16.1 (Clear Filter) ( TNS 2022ablr ) |
| AT 2022ablr - 2022-11-29 (T+4.8d) Image below (2022-11-29.057) was taken 4.8 days after discovery of 2022ablr Position of reported transient (visible) is shown by white cross-hairs Measured magnitude +16.23 (Clear Filter) |
 |
| Annotated CCD Image (100% size, linear scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 01:30 UT (#1064297-301) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022ablr on Transients 2022 Page >> |
Back to Top
| NGC 3738 (Ursa Major) ARP 234: Appearance of fission [ ARP Galaxies ] [ Irregular Galaxies ] |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 03:31 UT (#1064345-49) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
 |
| Annotated CCD Image (125% size, square root scale, cropped) Image details as above |
 |
| Negative CCD Image (125% size, square root scale, cropped) Image details as above |
| NGC 3738 - Earlier Image (Apr 2022) Stars elongated due to guiding failure (observatory roof obscured guidescope view) Target to be rescheduled for a later session |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, C Filter 2022-04-21 21:49 UT (#1002012-15) 12" LX200R (at f/10.4) + ST-10XME Unguided |
Back to Top
| M33 with Candidate Nova M33 2022-11a? (Triangulum) Nova M33 2022-11a? (Type: unk) discovered 2022-11-20.575 UT by XOSS Alias: TCP J01350893+3031503 Discovery Mag +13.4 ( Rochester Latest Extragalactic Novae | TCP J01350893+3031503 | Discovery Image ) |
| M33 with Nova M33 2022-11a? Cam2 Reference Image, Position of Nova M33 2022-11a? is shown by blue circle Limits of M33 Spiral Galaxy is shown by white ellipse line segment |
 |
| Annotated CMOS Image (16% size) (10s exposure, 1x1 binning) 2022-11-28 22:03 UT TS 80mm APO, ZWO ASI178MC |
| Nova M33 2022-11a? (T+8.3d) |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 22:15 UT (#1064203-07) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Nova M33 2022-11a? - 2022-11-28 (T+8.3d) Image below (2022-11-28.921) was taken 8.3 days after discovery of Nova M33 2022-11a? Position of reported nova (bright) is shown by white cross-hairs Measured magnitude +15.76 (Clear Filter) |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 22:15 UT (#1064203-07) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of Nova M33 2022-11a? (M33) on Transients 2022 Page >> |
Back to Top
| M43 (Orion) [ Messier Objects ] |
| M43 through Dual-Band Filter M43 at center, Part of M42 to lower right |
 |
| Annotated CCD Image (70% size, log scale) 7 x 90s exposure (average combine), 3x3 binning, DB Filter 2022-11-28 23:11 UT (#1064235-41) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
 |
| False-colour CCD Image (70% size, log scale) Inverse Spectrum Image details as above |
Back to Top
| NGC 3479 with AT 2022abgf (Crater) AT 2022abgf (Type: unk) discovered 2022-11-21.560 UT by ZTF Alias: ZTF22abvwcel Discovery Mag 16.89 (r-ZTF Filter) ( TNS 2022abgf ) |
| NGC 3479 - Spiral Galaxy |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 06:15 UT (#1064418-22) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 3479 with AT 2022abgf - 2022-11-29 (T+7.7d) Image below (2022-11-29.254) was taken 7.7 days after discovery of 2022abgf Position of reported transient (not visible) is shown by white circle |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 06:15 UT (#1064418-22) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022abgf (NGC 3479) on Transients 2022 Page >> |
Back to Top
| NGC 3938 with SN 2022xlp (Ursa Major) SN 2022xlp (Type: Ia-02cx) discovered 2022-10-13.808 UT by Koichi Itagaki Alias: ATLAS22bkeb Discovery Magnitude xx ( TNS 2022xlp ) |
| NGC 3938 with SN 2022xlp - 2022-11-29 (T+46.4d) Image below (2022-11-29.185) was taken 46.4 days after discovery of 2022xlp Position of SN (distinct) shown by white cross-hairs Measured magnitude +17.23 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 04:35 UT (#1064366-70) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022xlp (NGC 3938) on Supernova 2022 Page >> |
Back to Top
| NGC 4257 with AT 2022zzk (Virgo) AT 2022zzk (Type: unk) discovered 2022-11-12.533 UT by ZTF Alias: ZTF22abtkhwg ( Rochester Supernova site | TNS 2022zzk ) |
| NGC 4257 with AT 2022zzk - 2022-11-29 (T+16.7d) Image below (2022-11-29.212) was taken 16.7 days after discovery of 2022zzk Position of reported transient (not visible) is shown by white circle |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 05:14 UT (#1064384-88) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022zzk (NGC 4257) on Transients 2022 Page >> |
Back to Top
| NGC 4714 with AT 2022rrp (Corvus) AT 2022rrp (Type: unk) discovered 2022-08-19.735 UT by Gaia Alias: Gaia22dlv Discovery Mag +18.23 (G-Gaia Filter) ( TNS 2022rrp | Gaia22dlv ) |
| NGC 4714 with AT 2022rrp - 2022-11-29 (T+101.5d) Image below (2022-11-29.269) was taken 101.5 days after discovery of 2022rrp Position of reported transient (not visible) is shown by white cross-hairs |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 06:31 UT (#1064425-26) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT 2022rrp (NGC 4714) on Transients 2022 Page >> |
Back to Top
| UGC 5304 (Leo) Alias: Galaxy Pair, ARP 255, VV 342b/c [ ARP Galaxies ] |
 |
| Annotated CCD Image (70% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 04:15 UT (#1064359-63) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 5304 / ARP 255 - Detail |
 |
| Annotated CCD Image (150% size, square root scale, cropped) Image details as above |
 |
| Negative CCD Image (125% size, square root scale, cropped) Image details as above |
| UGC 5304 / ARP 255 - Earlier Image (Apr 2022) Single frame |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, C Filter 2022-04-02 23:54 UT (#998032) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
| NGC 5548 with AT 2022abcs (Bootes) AT 2022abcs (Type: AGN?) discovered 2022-11-16.541 UT by ZTF Alias: ZTF22abunqtv Discovery Mag -- (r-ZTF Filter) ( TNS 2022abcs ) |
| NGC 5548 with AT 2022abcs - 2022-11-29 (T+12.6d) Image below (2022-11-29.126) was taken 12.6 days after discovery of 2022abcs Position of reported transient (not distinguishable) is shown by white cross-hairs Measured magnitude +13.49 (nucleus + transient) |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 03:09 UT (#1064337-41) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of AT2022abcs (NGC 5548) on Transients 2022 Page >> |
Back to Top
| NGC 5631 with SN 2022aaiq (Ursa Major) SN 2022aaiq (Type: Ia) discovered 2022-11-15.057 UT by Patrick Wiggins Alias: 2022acsj Discovery Mag +16.0 (vs last non-detection, limiting mag +19) ( TNS 2022aaiq ) |
| NGC 5631 - Spiral Galaxy with SN 2022aaiq (T+13.9d) Alias H I-236 [ Herschel 400 Objects ] |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 23:50 UT (#1064251-55) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 5631 with SN 2022aaiq - 2022-11-28 (T+13.9d) Image below (2022-11-28.987) was taken 13.9 days after discovery of 2022aaiq Position of QSO (visible) is shown by white cross-hairs Measured magnitude +12.76 |
 |
| Annotated CCD Image (100% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 23:50 UT (#1064251-55) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| NGC 5631 - Earlier Image, Pre-SN (2019-09-02) Whilst NGC 5631 is catalogued as a spiral galaxy it looks more like an elliptical galaxy to me.. |
 |
| CCD Image (100% size, log scale, cropped) 4 x 120s exposure (average combine), 3x3 binning, C Filter 2019-09-02 00:16 UT (#688165-68) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022aaiq (NGC 5631) on Supernova 2022 Page >> |
Back to Top
| NGC 7495 with SN 2022ubb (Pegasus) SN 2022ubb (Type: II, z=0.01628) discovered 2022-09-13.498 UT by ATLAS Alias: ATLAS22bekt Discovery Magnitude +18.125 ABMag ( TNS 2022ubb ) |
| NGC 7495 with SN 2022ubb - 2022-11-28 (T+76.4d) Image below (2022-11-28.865) was taken 76.4 days after discovery of 2022ubb Position of SN (faint) shown by white cross-hairs |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 20:53 UT (#1064100-04) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022ubb (NGC 7495) on Supernova 2022 Page >> |
Back to Top
| UGC 8046 with SN 2022zxr (Ursa Major) SN 2022zxr (Type: II) discovered 2022-11-10.491 UT by ZTF Alias: ZTF22abtcyhv Discovery Mag +16.65 ( Rochester Supernova Site | TNS 2022zxr ) |
| UGC 8046 with SN 2022zxr - 2022-11-29 (T+18.6d) Image below (2022-11-29.072) was taken 18.6 days after discovery of 2022zxr Position of reported SN (bright) is shown by white cross-hairs Measured magnitude +15.88 |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 01:54 UT (#1064306-10) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022zxr (UGC 8046) on Supernova 2022 Page >> |
Back to Top
| UGC 11698 with SN 2022abik (Pegasus) SN 2022abik (Type: Ia) discovered 2022-11-23.201 UT by ATLAS Alias: ATLAS22bmqd Discovery Mag +18.43 (cyan ATLAS Filter) ( TNS 2022abik ) |
| UGC 11698 - Spiral Galaxy Pair Bright star in bottom right of image is HIP 104640 (catalog mag +7.76) |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 18:41 UT (#1064008-12) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 11698 with SN 2022abik - 2022-11-28 (T+5.6d) Image below (2022-11-28.773) was taken 5.6 days after discovery of 2022abik Position of supernova (faint) is shown by white pointer |
 |
| Annotated CCD Image (125% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 18:41 UT (#1064008-12) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 11698 with SN 2022abik - 2022-11-28 (T+5.6d) - Detailed
Image Image below (2022-11-28.773) was taken 5.6 days after discovery of 2022abik Position of supernova (faint) is shown by white cross-hairs |
 |
| Annotated CCD Image (175% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 18:41 UT (#1064008-12) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022abik (UGC 11698) on Supernova 2022 Page >> |
Back to Top
| UGC 12005 with SN 2022ovb (Lacerta) SN 2022ovb (Type: II) discovered 2022-07-14.409 UT by ZTF Alias: ZTF22aativsd, Gaia22ddj Discovery Mag +18.46 (r-ZTF Filter) ( TNS 2022ovb | Gaia22ddj ) |
| UGC 12005 - Galaxy |
 |
| Annotated CCD Image (50% size, square root scale) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 19:20 UT (#1064040-42) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 12005 with SN 2022ovb - 2022-11-28 (T+137.4d) Image below (2022-11-28.802) was taken 137.4 days after discovery of 2022ovb Position of earlier supernova (faint) is shown by white cross-hairs |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 19:20 UT (#1064040-42) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 12005 with SN 2022ovb - Earlier Image, 2022-09-18 (T+66.4d) Image below (2022-09-18.856) was taken 66.4 days after discovery of 2022ovb Position of SN 2022ovb is shown by white cross-hairs Measured magnitude +16.82 |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-09-18 20:41 UT (#1039014-18) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| UGC 12005 with SN 2022ovb - 2024-10-22 (T+830.6d) Image below (2024-10-22.053) was taken 830.6 days after discovery of 2022ovb Position of earlier supernova (no longer visible) is shown by white cross-hairs |
 |
| Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-22 01:25 UT (#1258032-36) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| Images of SN 2022ovb (UGC 12005) on Supernova 2022 Page >> |
Back to Top
| VV 187 (Pisces) Alias: PGC 71768 Vorontsov-Velyaminov Catalogue [ Vorontsov-Velyaminov Galaxies ] |
 |
| Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-28 19:57 UT (#1064064-68) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| VV 187 - Detail |
 |
| CCD Image (125% size, square root scale, cropped) Image details as above |
Back to Top
| VV 342 (Leo) a) PGC 28502, b) UGC 5304, c) LEDA 200253 [ Vorontsov-Velyaminov Galaxies ] |
|
|
| Annotated CCD Image (70% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2022-11-29 04:15 UT (#1064359-63) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
| VV 342 - Detail |
 |
| Annotated CCD Image (100% size, square root scale, cropped) Image details as above |
 |
| Negative CCD Image (125% size, square root scale, cropped) Image details as above |
Back to Top
| This Web Page: | Images - Session 1064 (2022-11-28) |
| Last Updated : | 2024-10-23 |
| Site Owner : | David Richards |
| Home Page : | David's Astronomy Web Site |
