Objects Session Notes
AT 2024uzm - Transient AT 2024wxp - CV Type Transient AT 2024xhn - Type Nova? Transient NGC 1383 - Spiral Galaxy PGC 1184747 - Galaxy SN 2024wak - Type Ia Supernova - PGC 143 attempt failed (due to cloud) - Frosty Leo Nebula attempt failed (incorrect coords) Variable Stars (photometric monitoring) - None Nearby Stars (astrometric monitoring) - Teegardens Star
- Night Session (6.2 hrs),. Delayed by and interupted by cloud & rain - 12" LX200 + ST-10XME for imaging - TS 80mm APO + ZWO ASI178MC for guiding & imaging - Ambient Temperature: 5°C (min) - CCD Temperature: -20°C - Notes from 2024-10-12 >> -
Back to Top
AT 2024uzm (Taurus) |
AT 2024uzm - 2024-10-13 (T+35.6d) Image below (2024-10-13.087) was taken 35.6 days after discovery of 2024uzm Position of earlier transient (faded & no longer visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +19.0 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 2 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-13 02:08 UT (#1254024-25) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024uzm - Earlier Image, 2024-09-16 (T+8.6d) Image below (2024-09-16.101) was taken 8.6 days after discovery of 2024uzm Position of earlier transient (faint) is shown by white cross-hairs Measured magnitude +16.80 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-09-16 02:34 UT (#1244205-09) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024uzm on Transients 2024 Page >> |
Back to Top
AT 2024wxp (Gemini) |
AT 2024wxp - 2024-10-13 (T+16.5d) Image below (2024-10-13.193) was taken 16.5 days after discovery of 2024wxp Position of reported transient (faint, not totally distinguishable) is shown by white cross-hairs Measured Magnitude +15.32 (Clear Filter) |
|
Annotated CCD Image (175% size, linear scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-13 04:43 UT (#1254045-47) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024wxp on Transients 2024 Page >> |
Back to Top
AT 2024xhn (Lynx) |
AT 2024xhn - 2024-10-13 (T+8.5d) Image below (2024-10-13.133) was taken 8.5 days after discovery of 2024xhn Position of reported transient (distinct) is shown by white cross-hairs Measured Magnitude +13.59 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2024-10-13 03:12 UT (#1254041) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024xhn on Transients 2024 Page >> |
Back to Top
Frosty Leo Nebula (Leo) Protoplanetary Nebula [ Planetary Nebula ] |
CCD Image (50% size, log scale) 5 x 45s exposure (average combine), 3x3 binning, C Filter 2021-01-17 00:26 UT (#850195-99) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Frosty Leo Nebula - Detail |
CCD Image (200% size, log scale, cropped) 5 x 45s exposure (average combine), 3x3 binning, C Filter 2021-01-17 00:26 UT (#850195-99) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Frosty Leo Nebula - Earlier Image (Jan 2021) |
CCD Image (200% size, log scale, cropped) 5 x 45s exposure (average combine), 3x3 binning, C Filter 2021-01-17 00:26 UT (#850195-99) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
NGC 1383 (Eridanus) |
|
Annotated CCD Image (100% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2024-10-13 02:17 UT (#1254030) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
PGC 1184747 (Hydra) |
|
Annotated CCD Image (70% size, square root scale) 3 x 45s exposure (average combine), 3x3 binning, Clear Filter 2024-10-13 04:54 UT (#1254051-55) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
SN 2024wak (Lepus) |
SN 2024wak - 2024-10-13 (T+20.6d) Image below (2024-10-13.124) was taken 20.6 days after discovery of 2024wak Position of reported supernova (distinct) is shown by white cross-hairs Measured Magnitude +15.07 (Clear Filter) |
|
Annotated CCD Image (100% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2024-10-13 02:59 UT (#1254035) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2024wak on Supernovae 2024 Page >> |
Back to Top
This Web Page: | Images - Session 1254 (2024-10-12) |
Last Updated : | 2024-10-15 |
