T CrB (Corona Borealis) Alias: GCVS T CrB, HIP 78322, SAO 84129, HD 143454 Max Magnitude 2.0 Min Magnitude 10.8 Spectral: M3III+pec(NOVA) ( VSX T CrB ) |
T CrB (V Band) - 2024-10-14 (S1255) | T CrB - Photometry - 2024-10-14 | |
2024-10-14 19:44 UT Altitude: 28.0°, Airmass: 2.129 T CrB : 10.25 (V Mag), 11.54 (B Mag), 1.29 (B-V) Fading |
||
Annotated CCD Image (50% size, linear scale) 3 x 20s exposure (average combine), 3x3 binning, V Filter 2024-10-14 19:44 UT (#1255015-19) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
CCD Image (not shown) 3 x 30s exposure (average combine), 3x3 binning, B Filter 2024-10-14 19:43 UT (#1255014-18) |
|
More Images & Data for T CrB >> |
Back to Top
AT 2023vwf (Delphinus) |
AT 2023vwf - 2024-10-14 (T+362.6d) Image below (2024-10-14.917) was taken 362.6 days after discovery of 2023vwf Position of transient object (not longer visible or not distinguishable) is shown by white cross-hairs Non-Detection Limiting Magnitude +18.0 (Clear Filter) Since normal G-Gaia magnitude is 16.32 and Limiting Magnitude of Image is around 18.0 it suggests that Transient is not distinguishable in the glare from adjacent star GSC 1100:663 (mag 13.2) |
|
Annotated CCD Image (100% size, linear scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-14 22:08 UT (#1255040-43) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2023vwf - detail, 2024-10-14 (T+362.6d) Enlarging image to 250% size indicates that AT 2023vwf is just visible adjacent to GSC 1100:663 |
|
Annotated CCD Image (100% size, linear scale, cropped) Image details as above |
Images of AT 2023vwf on Transients 2023 Page >> |
Back to Top
AT 2024tde (Andromeda) |
AT 2024tde - 2024-10-15 (T+50.1d) Image below (2024-10-15.069) was taken 50.1 days after discovery of 2024tde Position of transient object (very faint) is shown by white cross-hairs Measured Magnitude +17.98 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 01:47 UT (#1255111-15) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024tde on Transients 2024 Page >> |
Back to Top
AT 2024uvw (Cassiopeia) |
AT 2024uvw - 2024-10-14 (T+38.2d) Image below (2024-10-14.994) was taken 38.2 days after discovery of 2024uvw Position of transient object (not visible) is shown by white cross-hairs Limiting Magnitude +19.4 (Clear Filter) Galaxies in same FOV are UGC 761 (PGC 4394. catalog mag 16.3) & PGC 212682 (catalog mag 17.7) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 00:02 UT (#1255076-80) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024uvw - Enlarged View, 2024-10-14 (T+38.2d) Report transient position is indicated by white cross-hairs and is offset from the adjacent, No object visible at reported position of transient in image below or on DSS2 Colour or PanSTARRS images in Aladin |
|
Annotated CCD Image (250% size, linear scale, cropped) Image details as above |
Images of AT 2024uvw on Transients 2024 Page >> |
Back to Top
AT 2024vhz (Cepheus) |
AT 2024vhz - 2024-10-15 (T+32.4d) Image below (2024-10-15.092) was taken 32.4 days after discovery of 2024vhz Position of reported transient (very faint, fading) is shown by white cross-hairs Measured magnitude +17.27 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 02:21 UT (#1255128-32) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
AT 2024vhz - Earlier Image, 2024-09-16 (T+3.3d) Image below (2024-09-16.054) was taken 3.3 days after discovery of 2024vhz Position of reported transient (faint) is shown by white cross-hairs Measured magnitude +15.22 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-09-16 01:27 UT (#1244169-73) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024vhz on Transients 2024 Page >> |
Back to Top
AT 2024wpc (Bootes) |
AT 2024wpc - 2024-10-14 (T+22.2d) Image below (2024-10-14.805) was taken 22.2 days after discovery of 2024wpc Position of reported transient (distinct, stable) is shown by white cross-hairs Measured Magnitude +14.93 (Clear Filter) |
|
Annotated CCD Image (125% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2024-10-14 19:19 UT (#1255007) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024wpc on Transients 2024 Page >> |
Back to Top
AT 2024xhn (Lynx) |
AT 2024xhn - 2024-10-15 (T+10.4d) Image below (2024-10-15.108) was taken 10.4 days after discovery of 2024xhn Position of reported transient (distinct, fading) is shown by white cross-hairs Measured Magnitude +13.76 (Clear Filter) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 02:44 UT (#1255135-39) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024xhn on Transients 2024 Page >> |
Back to Top
AT 2024xiq (Capricornus) |
AT 2024xiq - 2024-10-14 (T+13.0d) Image below (2024-10-14.826) was taken 13.0 days after discovery of 2024xiq Position of reported transient (not visible) is shown by white cross-hairs Non-Detection Limiting Magnitude +17.0 (Clear Filter) Transient has likely returned to its normal magnitude range +18.8 to +20.0 (Gaia) Image taken at Altitude 10.3°, Airmass: 5.468 |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-14 19:53 UT (#1255022-26) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024xiq on Transients 2024 Page >> |
Back to Top
AT 2024xiu (Leo Minor) |
AT 2024xiu - 2024-10-15 (T+12.7d) Image below (2024-10-15.146) was taken 12.7 days after discovery of 2024xiu Position of reported transient (very faint) is shown by white cross-hairs Estimated Magnitude +18.6 (Clear Filter) Transient has returned to its normal magnitude range (=17.7 to +19.7) |
|
Annotated CCD Image (100% size, linear scale, cropped) 5 x 60s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 03:34 UT (#1255154-58) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024xiu on Transients 2024 Page >> |
Back to Top
AT 2024xpy (Hercules) |
AT 2024xpy - 2024-10-14 (T+10.0d) Image below (2024-10-14.865) was taken 10.0 days after discovery of 2024xpy Position of reported transient (faint, fading) is shown by white cross-hairs Measured Magnitude +16.20 (Clear Filter) Relatively poor image (single frame) |
|
Annotated CCD Image (100% size, square root scale, cropped) 180s exposure (single frame), 3x3 binning, Clear Filter 2024-10-14 20:45 UT (#1255036) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024xpy on Transients 2024 Page >> |
Back to Top
Frosty Leo Nebula (Leo) Protoplanetary Nebula [ Planetary Nebula ] |
Annotated CCD Image (50% size, square root scale) 5 x 45s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 04:36 UT (#1255177-81) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Frosty Leo Nebula - Detail |
CCD Image (200% size, log scale, cropped) Image details as above |
Frosty Leo Nebula - Earlier Image (Jan 2021) |
CCD Image (200% size, log scale, cropped) 5 x 45s exposure (average combine), 3x3 binning, C Filter 2021-01-17 00:26 UT (#850195-99) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Spectra Spectra is noticeably unlike that of planetary nebulae |
Annotated CCD Image (50% size, square root scale) 5 x 120s exposure (average combine), 2x2 binning, S Filter 2024-10-15 04:45 UT (#1255182-86) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Back to Top
IC 2190 with SN 2024dhp (Auriga) SN 2024dhp (Type: Ia) discovered 2024-02-28.291 UT by ZTF Alias: ZTF24aagirej Discovery Magnitude 18.33 (r-ZTF Filter) vs Prior Non-Detection Limiting Mag 16.0 (g-ZTF Filter) ( TNS 2024dhp ) |
IC 2190 with SN 2024dhp - 2024-10-15 (T+229.9d) Image below (2024-10-15.154) was taken 229.9 days after discovery of 2024dhp Position of reported SN (faded & no longer visible) is indicated by white cross-hairs. |
Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 03:51 UT (#1255160-64) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
IC 2190 with SN 2024dhp - Earlier Image, 2024-03-04 (T+5.6d) Image below (2024-03-04.933) was taken 5.6 days after discovery of 2024dhp Position of reported SN (faint) is indicated by white cross-hairs. Measured Magnitude +16.38 (Clear Filter) |
Annotated CCD Image (150% size, square root scale, cropped) 3 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-03-04 22:29 UT (#1196077-79) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2024dhp (in IC 2190) on Supernova 2024 Page >> |
Back to Top
M31 with AT 2024xtk (Andromeda) AT 2024xtk (Type: unk) discovered 2024-10-10.689 UT by KNTraP Alias: PSP24X, PNV J00423476+4115351 Discovery Mag 16.46 (Clear Filter) ( Rochester Supernova site | TNS 2024xtk ) |
M31 with AT 2024xtk Image taking with secondary scope showing position of reported transient (blue circle) relative to outline of M31 galaxy (white ellipse) & M31 Galaxy centre (labelled) |
|
CMOS Image (16% size) 10s exposure, 1x1 binning 2024-10-14 22:26 UT (23:26:41 LT), Cam2_Ref TS 80mm APO, ZWO ASI178MC & PHD2 |
M31 with AT 2024xtk (T+4.2d) Position of reported transient is shown by white circle |
Annotated CCD Image (50% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-14 22:36 UT (#1255063-67) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
M31 with AT 2024xtk - 2024-10-14 (T+4.2d) Image below (2024-10-14.936) was taken 4.2 days after discovery of 2024xtk Position of reported transient (barely visible) is shown by white cross-hairs |
Annotated CCD Image (125% size, linear scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-14 22:36 UT (#1255063-67) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024xtk (in M31) on Transients 2024 Page >> |
Back to Top
NGC 1275 with SN 2024xav (Perseus) |
NGC 1275 with SN 2024xav - 2024-10-15 (T+15.0d) Image below (2024-10-15.021) was taken 15.0 days after discovery of 2024xav Position of reported transient (faint) is shown by white cross-hairs Estimated Magnitude +16.2 (Clear Filter) |
|
Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 00:38 UT (#1255088-92) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2024xav (in NGC 1275) on Supernovae 2024 Page >> |
Back to Top
NGC 2830 with AT 2024vsu (Lynx) |
NGC 2830 with AT 2024vsu - 2024-10-15 (T+25.3d) Image below (2024-10-15.124) was taken 25.3 days after discovery of 2024vsu Position of reported transient (very faint) is shown by white cross-hairs Estimated Magnitude +17.4 (Clear Filter) |
|
Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 03:06 UT (#1255142-46) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024vsu (in NGC 2830) on Transients 2024 Page >> |
Back to Top
PGC 29488 / Leo I (Leo) |
Annotated CCD Image (70% size, square root scale) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 05:05 UT (#1255190-94) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
PGC 29488 - Earlier Image (Dec 2004) Barely visible due to very low surface brightness, |
CCD Image 3 x 60 sec (average combine), C Filter 2004-12-11 05:28 h UT (#79003-06) 8" LX200 + ST-7E |
Back to Top
SN 2024ugc (Perseus) |
SN 2024ugc - 2024-10-14 (T+51.3d) Image below (2024-10-14.983) was taken 51.3 days after discovery of 2024ugc Position of reported supernova (faint, fading) is shown by white cross-hairs Measured Magnitude +17.69 (Clear Filter) |
|
Annotated CCD Image (125% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-14 23:43 UT (#1255070-73) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2024ugc on Supernovae 2024 Page >> |
Back to Top
SN 2024wak (Lepus) |
SN 2024wak - 2024-10-15 (T+22.5d) Image below (2024-10-15.050) was taken 22.5 days after discovery of 2024wak Position of reported supernova (distinct) is shown by white cross-hairs Measured Magnitude +15.24 (Clear Filter) |
|
Annotated CCD Image (100% size, square root scale, cropped) 4 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 01:19 UT (#1255096-99) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of SN 2024wak on Supernovae 2024 Page >> |
Back to Top
UGC 4957 with AT 2024vrq (Cancer) |
UGC 4957 with AT 2024vrq - 2024-10-15 (T+26.7d) Image below (2024-10-15.175) was taken 26.7 days after discovery of 2024vrq Position of reported transient (very faint) is shown by white cross-hairs |
|
Annotated CCD Image (150% size, square root scale, cropped) 5 x 180s exposure (average combine), 3x3 binning, Clear Filter 2024-10-15 04:21 UT (#1255170-74) 12" LX200R (at f/10.4) + ST-10XME Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2 |
Images of AT 2024vrq (in UGC 4957) on Transients 2024 Page >> |
Back to Top
