David's Astronomy Pages (Image Gallery)
Image Highlights - 2010

See also Highlights from  | 200120022003 | 2004 | 2005 | 2006 | 2007 | 2008 | 2009 | 2010 |

Shown below are some of my favourite CCD images from 2010

Bullet | Stars | Clusters | Nebulae | Galaxies | Moon | Planets | Comets | Asteroids/MPL


New Years Day Visitor to Observatory  - Sparrowhawk

Canon EOS 400D, 300mm, 1/250s
2010-01-01 14:47 GMT

Stars

GK Per -  Variable Star, Nova (1901) : Outburst Mar 2010  (Perseus)
GK Per is star (NA + XP) which had a nova eruption in 1901, and undergoes occasional
minor outbursts since then,  for example the outburst in Sept 2008.

A new outburst in Mar 2010 is noted to have occurred between observations
at 2010-03-01 01:00h UT and 2010-03-09 20:00h UT


GK Per - 2010-03-03
Mag V +13.0
GK Per - 2010-03-24
Mag V  +11.4
Image Image
Annotated CCD Image (cropped)
3 x 15s exposure (average combine), 3x3 binning, V Filter
2010-03-03 00:57hUT (#415187-91)
12" LX200R  (at f/9.7) + ST-10XME
Annotated CCD Image ( cropped)
3 x 15s exposure (average combine), 3x3 binning, V Filter
2010-03-24 23:39hUT (#418071-75)
12" LX200R  (at f/9.7) + ST-10XME

Double -Double / Epsilon Lyrae (Lyra)

CCD Image (linear scale, 50% size)
5s exposure (single frame), 3x3 binning, C Filter
2010-08-20 22:18 hUT (#423085)
12" LX200R  (at f/9.7) + ST-10XME



 Epsilon Lyrae - detail
(image showing that each component of the double is itself a double).

Annotated CCD Image (cropped)
0.12s exposure (single frame), 2x2 binning, C Filter
2010-08-20 22:22 hUT (#423093)
12" LX200R  (at f/9.7) + ST-10XME



UU Aur - cool star (Auriga)

CCD Image (50% size)
3 x 5s exposure (average combine), 3x3 binning, C Filter
2010-12-25  20:41h UT (#439294-96)
12" LX200R  (at f/9.7) + ST-10XME





Back to Top


 Clusters

NGC 2506 - Open Cluster (Monoceros)
Caldwell 54 / Herschel VI-37

CCD Image (50%)
3  x 45s exposure (average combine), 3x3 binning, C Filter
2010-03-09 20:26 hUT (#416110-12)
12" LX200R  (at f/9.7) + ST-10XME
[larger image]

NGC 6791 - Open Cluster (Lyra)

CCD Image (Linear Scale, 75% size)
3 x 30s exposure (average combine), 3x3 binning, C Filter
2010-08-26 21:51hUT (#426057-60)
12" LX200R  (at f/9.7) + ST-10XME

Mayall II  - Globular Cluster in M31 (Andromeda)
Globular Cluster indicated by white cross hairs

Annotated CCD Image (cropped)
2 x 60s exposure (average combine), 3x3 binning, C Filter
2010-08-30 22:28hUT (#426108-09)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


Nebulae

NGC 7635 / Caldwell 11 / Bubble Nebula (Cassiopeia)


False Colour CCD Image (75% size, square root scale)
6x60 sec, 3x3 binning, C Filter
2010-02-20  21:39hUT (#414252-58)
12" LX200R  (at f/9.7) + ST-10XME



NGC 7023 / Caldwel 4 (Cepheus)

CCD Image (log scale, 50% size)
13 x 20s exposure (average combine), 3x3 binning, C Filter
2010-08-07 22:26 hUT (#421045-58)
12" LX200R  (at f/9.7) + ST-10XME

Jones 1 - Planetary Nebula (Pegasus)

CCD Image (60% size, cropped)
6  x 90s exposure (average combine), 3x3 binning, C Filter
2010-08-20 22:35 hUT (#424026-34)
12" LX200R  (at f/9.7) + ST-10XME


Pease I - Planetary Nebula in M15 (Pegasus)
Pease I - a planetary nebula in the globular cluster M15 - is the
small 'red' object whose position is indicated by the white cross-hairs
This false colour image uses Ha filter frame for red,
and V filter frame for blue and green.
The Pl. Neb. is highlighted due to its high excess of light at Ha wavelengths,
and appears 'red' compared to normal stars which appear whitish.

False Colour CCD Image (cropped)
Blue & Green : 3 x 45s exposure (average combine), 2x2 binning, V Filter
Red : 6 x 60s exposure (average combine), 2x2 binning, Ha Filter
2010-09-11 00:53hUT (#427158-66)
12" LX200R  (at f/9.7) + ST-10XME
[wider view]


M15 with Pease I - wider view

False Colour CCD Image
Image details as above


NGC 1501 / Herschel IV-53 / PLN 144+ 6.1 - Planetary Nebula (Camelopardalis)

CCD Image (Linear Brightness Scale, cropped)
6 x 30s exposure (average combine), 3x3 binning, C Filter
2010-09-11 01:03hUT (#427169-75)
12" LX200R  (at f/9.7) + ST-10XME


M27  - Planetarty Nebula /  Colour Image (Vulpecula)

 Colour CCD Image (LRGB)
3x3 binning, autoguided
Luminance : 3x60s, C Filter:    Red : 5x120s R Filter
Green : 5x120s, V Filter, Blue: 4x180s, B Filter
2010-11-10  18:24h UT (#435012-46)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


Galaxies



NGC 6946 - Spiral Galaxy / Caldwell 12 (Cygnus)

Colour CCD Image (LRGB, 75% size)
3x3 binning, average combine
L :  8 x 90s  (C Filter),  B : 8 x 90s (B Filter),
G : 5 x 60s (V Filter), R : 6 x 60s (R Filter)
2010-02-20 19:44h UT (#414129-56)
12" LX200R  (at f/9.7) + ST-10XME
[larger image]


MACSJ0717 - Massive Galaxy Cluster (Gemimi)
MACSJ0717.5+3745 (MACSJ0717 for short) is a 5.4 billion light years from Earth
and is one of the most complex galaxy clusters ever seen
http://chandra.harvard.edu/photo/2009/macs

A well publicised composite Chandra X-ray & HST Optical Image of MACSJ0717
shows the location of hot gas produced by multiple collisions from four separate galaxy clusters

The CCD Image below (total exposure 14 min) taken through 12" LX200 scope shows the
location of the massive galaxy cluster MACSJ0717 with at least
10 ?members of the galaxy cluster visible
(with area of Chandra/HST image marked by white square)

Annotated CCD Image (cropped)
7 x 120s exposure (average combine), 3x3 binning, C Filter
2010-02-20 23:02 hUT (#414357-63)
12" LX200R  (at f/9.7) + ST-10XME


HST Optical Image of MACSJ0717 reduced to same scale
(click on image to see larger image of this HST image)



PGC 34176 - Local Group Galaxy (Leo II / Leo B)   (Leo)
0.75 million light years distance

CCD Image (50% size)
5  x 120s exposure (average combine), 3x3 binning, C Filter
2010-02-21 00:05 hUT (#414417-21)
12" LX200R  (at f/9.7) + ST-10XME
[larger image, 75%]


NGC 5474 - Spiral Galaxy (Ursa Major)
Member of M101 Galaxy Group


CCD Image  (cropped)
7 x 120s exposure (average combine), 3x3 binning, C filter,
2010-03-09 22:43h UT (#416308-14)
12" LX200R  (at f/9.7) + ST-10XME


NGC 7331 / Caldwell 30 - Spiral Galaxy  (Pegasus)

Annotated CCD Image (linear scale, 75% size)
90s exposure (single frame), 3x3 binning, C Filter
2010-08-20 22:39 hUT (#423115)
12" LX200R  (at f/9.7) + ST-10XME


NGC 5981, NGC 5982, NGC 5985 - Galaxy Triplet  (Draco)
NGC 5981 (edge on spiral galaxy), NGC 5982 (elliptical galaxy),
NGC 5985 (face on spiral galaxy)

Annotated CCD Image (Linear Scale, 50% size)
3 x 90s exposure (average combine), 3x3 binning, C Filter
2010-08-26 22:28hUT (#425105-07)
12" LX200R  (at f/9.7) + ST-10XME

NGC 5985 - Spiral Galaxy (Draco)

CCD Image (Linear Scale, cropped)
3 x 90s exposure (average combine), 3x3 binning, C Filter
2010-08-26 22:28hUT (#425105-07)
12" LX200R  (at f/9.7) + ST-10XME


Part of M33 - Spiral Galaxy (Triangulum),
 showing IC137 region at centre of image

CCD Image (Linear Brightness Scale, 75% size)
3 x 180s exposure (average combine), 3x3 binning, C Filter
2010-10-07 00:51hUT (#430334-36)
12" LX200R  (at f/9.7) + ST-10XME
[Full Size Image]

Back to Top


Moon



Conjunction of Venus, Mercury and New Moon, 2010-04-15

Photo, Canon ED450D



Conjunction - detail

Annotated Digital Photo (details as above)
Click on image for larger picture



Mercury & New Moon - detail


Digital Photo (details as above)



Back to Top


Planets

Major Planets

Mars

CCD Image (with x2.5 enlarged insert)
0.3s sec exposure (single frame), 1x1 binning, B Filter
2010-01-19 00:05h UT  (#411458)
8" LX200 Classic (at f/10) + ST-10XME

Jupiter
Annotated CCD Image (cropped)
0.12s exposure (single frame), 1x1 binning, V Filter
2010-08-21 00:04 hUT (#423215)
12" LX200R  (at f/9.7) + ST-10XME

Jupiter

Colour CCD Image (cropped)
Red : av 5 x 0.3s exposure, R Filter , Green : av 5 x 0.3s exposure, V Filter
Blue : av 5 x 0.3s exposure, B Filter , Frames:  1x1 binning
2010-12-25 20:33 hUT (#439274-88)
12" LX200R  (at f/9.7) + ST-10XME
Frame registration/enhancement in AIP4WIN. Colour Combine in CCDSoft. Unsharp Masked


Jupiter - moons

Annotated CCD Image (cropped)
0.12s exposure (single frame), 3x3 binning, R Filter
2010-08-20 23:53 hUT (#423202)
12" LX200R  (at f/9.7) + ST-10XME


Saturn

CCD Image (cropped)
0.2 sec exposure (single frame), 1x1 binning, R Filter
Unsharp Masked
2010-02-21 00:41 h UT  (#414465)
12" LX200R  (at f/9.7) + ST-10XME


Saturn Moons (Titan, Tethys, Enceladus & Rhea)

CCD Image (cropped)
0.3 sec exposure (single frame), 2x2 binning, C Filter
2010-02-21 00:44 h UT  (#414480)
12" LX200R  (at f/9.7) + ST-10XME



Hyperion & Iapetus

CCD Image (cropped, 75% size)
20 sec exposure (single frame), 2x2 binning, C Filter
2010-02-21 01:25 h UT  (#414495)
12" LX200R  (at f/9.7) + ST-10XME


Uranus and moons

Annotated CCD Image (cropped)
6 x 3s exposure (average combine), 1x1 binning, C Filter
2010-09-10 23:56hUT (#427085-90)
12" LX200R  (at f/9.7) + ST-10XME

Back to Top


Comets

Comet 81P / Wild  on 2010-03-25
(passing through starfield in Virgo)

CCD Image (50% size, log scale)
5  x 45s exposure (average combine), 3x3 binning, C Filter
2010-03-25 00:23 hUT (#418120-24)
12" LX200R  (at f/9.7) + ST-10XME



Comet  103P/Hartley on 2010-09-10
passing through starfield in Andromeda


Annotated CCD Image (75% size, log scale)
CCD Image - average stack processed in AIP4WIN - aligned on comet
20  x 30s exposure (average combine), 3x3 binning, C Filter
2010-09-10 23:03 hUT (#427003-22)
12" LX200R  (at f/9.7) + ST-10XME



Comet  103P/Hartley -  motion over a 99 minute period

Animated CCD Image
2 frames each  3  x 30s exposure (average combine), 3x3 binning, C Filter , cropped
1) 2010-09-10 22:58 hUT (#427003-05)
2) 2010-09-10 00:37 hUT (#427145-47)
12" LX200R  (at f/9.7) + ST-10XME



Back to Top


Asteroids / Minor Planets

No images of asteroids/minor planets taken during 2010
