David's Astronomy Pages
CCD Images - Session 951 (2022-01-08)

Objects Session Notes
Bullet 67P/Churyumov-Gerasimenko - Comet
Bullet C/2017 K2 (PANSTARRS) - Comet
Bullet C/2019 L3 (ATLAS) - Comet

Bullet Nova Cas 2021 - Nova (V1405 Cas)

Bullet AT 2021agjs - Ulens? Transient
Bullet AT 2021agpw - CV Type Transient

Bullet IC 3322A - Spiral Galaxy with Type Ia Supernova 2021hiz

Bullet NGC 2761 - Spiral Galaxy with Type Ia Supernova 2021aggu
Bullet NGC 4165 - Spiral Galaxy
Bullet UGC 4671 - Spiral Galaxy with Type Ia Supernova 2021afsj

Bullet UGCA 233 - Spiral Galaxy (PGC 34670)
Bullet UGC 1971 - Galaxy with Type II Supernova 2021afkk
Bullet UGC 3855 - Spiral Galaxy with Type II Supernova 2021agco
Bullet UGC 5245 - Spiral Galaxy (PGC 28136)
Bullet UGC 5528 - Spiral Galaxy with Type Ia Supernova 2022B
Bullet UGC 8426 - Spiral Galaxy with Transient AT 2021knq
Bullet UGC 8975 - Spiral Galaxy with Type Ia Supernova 2021adpe

Bullet WISEA J095040.62+475756.9 - Galaxy with Type II Supernova 2021aalq

Bullet Variable Stars (photometric monitoring)
- U Her, BL Lac

Bullet Nearby Stars (astrometric monitoring)
- None


- Post-midnight session 6.3 hours
- Clear skies from 19:00 onwards but session not started to 00:30 due to software development / skies not noticed to have cleared after initial cloudy start.
- 12" LX200 + ST-10XME for imaging
- TS 80mm APO + ZWO ASI178MC for guiding & imaging
- Ambient Temperature: -2°C (min)
- CCD Temperature:  -25°C
- Notes from 2022-01-08 >>
   [ Local Files >> ]

- Aurora Images/Video from 2022-01-08 >>


67P/Churyumov-Gerasimenko - Comet

67P/Churyumov-Gerasimenko
(passing through Cancer)
Sun Distance 1.47 AU (receeding)
Earth Distance 0.51 AU (76.4 million km)
   67P/Churyumov-Gerasimenko - 2022-01-09, Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra -34.65 arcsec/hr, Dec 5.74 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2022-01-09 02:22 UT (#951035-37)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  Annotated CCD Image (100% size, log scale, cropped)
14 x 45s exposure (average combine), 3x3 binning, C Filter
2022-01-09 02:24 UT (#951031-45)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of 67P/Churyumov-Gerasimenko on Comets 2022 Page >>

67P/Churyumov-Gerasimenko - False Colour Image(s)
Inverse Spectrum

67P/Churyumov-Gerasimenko - 2022-01-09
False Colour CCD Image (70% size, log scale)
14 x 45s exposure (average combine), 3x3 binning, C Filter
2022-01-09 02:24 UT (#951031-45)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2



Back to Top


C/2017 K2 (PANSTARRS) - Comet

C/2017 K2 (PANSTARRS)
(passing through Ophiuchus)
Sun Distance 4.32 AU (approaching)
Earth Distance 5.03 AU (752.9 million km)
   C/2017 K2 (PANSTARRS) - 2022-01-09, Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra 30.31 arcsec/hr, Dec -9.23 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2022-01-09 06:38 UT (#951146-48)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, square root scale, cropped)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2022-01-09 06:40 UT (#951146-54)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C2017 K2 (PANSTARRS) on Comets 2021 Page >>

Back to Top


C/2019 L3 (ATLAS) - Comet

C/2019 L3 (ATLAS)
(passing through Gemini)
Sun Distance 3.55 AU (approaching)
Earth Distance 2.58 AU (386.2 million km)
   C/2019 L3 (ATLAS)  - 2022-01-09, Detail
Autoguided on offset star using PHD2 with Lock Shift
set at the comet's rate of motion
(Ra -38.29 arcsec/hr, Dec -29.09 arcsec/hr)
Image   Image
Annotated CCD Image (50% size, square root scale)
3 x 45s exposure (average combine), 3x3 binning, C Filter
2022-01-09 03:22 UT (#951062-64)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
  CCD Image (100% size, log scale, cropped)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2022-01-09 03:25 UT (#951062-70)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of C/2019 L3 (ATLAS) on Comets 2022 Page >>

C/2019 L3 (ATLAS)
Inverse Spectrum

C/2019 L3 (ATLAS)  - 2022-01-09
False Colour CCD Image (70% size, log scale)
9 x 45s exposure (average combine), 3x3 binning, C Filter
2022-01-09 03:25 UT (#951062-70)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2


Back to Top


Nova Cas 2021 - Nova (V1405 Cas)

Nova Cas 2021 (Cassiopeia)
Nova in Cassiopeia discovered 2021-03-18.4236,  by Yuji Nakamura (Japan)
Magnitude at discovery +9.6 (unfiltered CCD)
AT2021hkn (Type: Nova) reported by 2021/03/30.055 UT by Gaia
Alias: Gaia21bpe, AT2021hkn, V1405 Cas

Nova Cas 2021 - 2022-01-09 (T+296.9d)
Image below (2022-01-09.292) was taken 296.9 days after discovery of Nova
Nova is shown by white cross hairs.  Measured magnitude +9.32
(linked with Detection Threshold = 15)
Annotated CCD Image (100% size, linear scale, cropped)
5 x 30s exposure (average combine), 3x3 binning, C Filter
2022-01-09 07:02 UT (#951163-67)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Nova Cas 2021 (V1405 Cas) Spectra - 2022-01-09 (T+296.9d)

Spectra produced in AstroMain using Image taken with Star Analyser 200
5 x 30s exposure (average combine), 2x2 binning, S Filter
2022-01-09 07:05 UT (#951168-72)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of Nova Cas 2021 on Novae Page >>


Back to Top


AT 2021agjs - Ulens? Transient

AT 2021agjs (Puppis)
AT 2021agjs (Type: ulens?) discovered 2021-12-16.612 UT by Gaia
Alias: Gaia21fpg, GSC 5404:2476
Alert triggered at +10.55 (vs historic mag +10.82)
bright gal.plane source candidate microlensing event or Be-type outburst rises by 0.3 mag
 ( Rochester Supernova site | Gaia21fpg  )

AT 2021agjs - 2022-01-09 (T+23.4d)
Image below (2022-01-09.051) was taken 23.4 days after discovery of 2021agjs
Transient Object is shown by white cross hairs.
Measured Magnitude +11.17
Annotated CCD Image  (100% size, linear scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 01:22 UT (#951010-14)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2021agjs on Transients 2021 Page >>

Back to Top


AT 2021agpw - CV Type Transient

AT 2021agpw (Serpens)
AT 2021agpw (Type: CV) discovered 2021-12-27.275 UT by MASTER
Alias: MASTER OT J155629.78+090149.3
Discovery Mag 10.1 (red long variability ?)
[ TNS 2021agpw ]

AT 2021agpw - 2022-01-09 (T+13.0d)
Image below (2022-01-09.256) was taken 13.0 days after discovery of 2021agpw
Reported transient is shown by white cross hairs.
Measured magnitude +10.58
Annotated CCD Image (100% size, linear scale, cropped)
5 x 60s exposure (average combine), 3x3 binning, C Filter
2022-01-09 06:12 UT (#951125-29)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2021agpw on Transients 2021 Page >>

Back to Top


IC 3322A - Spiral Galaxy with Type Ia Supernova SN 2021hiz

IC 3322A with SN2021hiz (Virgo)
SN 2021hiz (Type: Ia) discovered 2021/03/30.359 UT by ZTF
Alias: ZTF21aaqytjr
 (Rochester Supernova site)
[ Supernovae 2021 ]

IC 3322A with SN2021hiz - 2022-01-09 (T+284.8d)
Image below (2022-01-09.194) was taken 284.8 days after discovery of 2021hiz
Position of SN (now only faintly visible) is indicated by white cross-hairs.
Annotated CCD Image  (100% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 04:47 UT (#951094-97)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2021hiz (IC 3322A) on Supernovae 2021 Page >>


Back to Top


NGC 2761 - Spiral Galaxy with Type Ia Supernova 2021aggu

NGC 2761 with SN2021aggu (Cancer)
SN 2021aggu (Type: Ia) discovered 2021-12-12.757 UT by ATLAS
Alias: ATLAS21bnhv, Gaia21fnr
 ( Rochester Supernova site | Gaia21dym ]

NGC 2761 with SN2021aggu - 2022-01-09 (T+27.3d)
Image below (2022-01-09.107) was taken 27.3 days after discovery of 2021aggu
Position of reported SN (faint but distinct) is shown by white cross-hairs
Annotated CCD Image  (150% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 02:43 UT (#951048-52)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2021aggu (NGC 2761) on Supernovae 2021 Page >>


Back to Top


NGC 4165 - Spiral Galaxy with Type II Supernova 2021gno (faded)

NGC 4165 with SN 2021gno (Virgo)
SN 2021gno (Type: II) discovered 2021/03/20.235 UT by ZTF
Alias: ZTF21aaqhhfu
 ( Rochester Supernova site |  Claudio Balcon image | Giancarlo Cortini image  )

NGC 4165 with SN2021gno - 2022-01-09 (T+294.9d)
Image below (2022-01-09.179) was taken 294.9 days after discovery of 2021gno
Position of earlier SN (no longer visible) is shown by white cross hairs.
Annotated CCD Image  (125% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 04:27 UT (#951087-91)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

NGC 4165 with SN2021gno - Earlier image, 2021-04-01 (T+12.7d)
Image below (2021-04-01.940) was taken 12.7 days after discovery of 2021gno
SN is shown by white cross hairs.
Annotated CCD Image  (125% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2021-04-01 22:43 UT (#879054-58)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2021gno (NGC 4165) on Supernovae 2021 Page >>

Back to Top


UGC 4671 - Spiral Galaxy with Type Ia Supernova 2021afsj

UGC 4671 with SN2021afsj (Ursa Major)
SN 2021afsj (Type: Ia) discovered 2021-11-29.718 UT by Shuji Tokuoka
Alias: Gaia21flf, ZTF21acqstfo
 ( Rochester Supernova site | Gaia21flf  )

UGC 4671 with SN2021afsj - 2022-01-09 (T+40.4d)
Image below (2022-01-09.122) was taken 40.4 days after discovery of 2021afsj
Position of SN is shown by white cross-hairs
Measured magnitude ? (unable to measure)
Annotated CCD Image  (125% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 03:05 UT (#951055-59)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2021afsj (UGC 4671) on Supernovae 2021 Page >>

Back to Top


UGCA 233 - Spiral Galaxy (PGC 34670)

UGCA 233 (Ursa Major)
Alias: PGC 34670 (Catalog mag +14.9)
[ UGCA Galaxies ]

UGCA 233 with adjacent galaxies
 PGC 2469743 (catalog mag +16.2), PGC 34650 (catalog mag +16.4),
PGC 2470239 (catalog mag +16.4), PGC 2472564 (catalog mag +16.6)
PGC 2468434 (catalog mag +16.8), PGC 2468029 (catalog mag +16.9),
 PGC 2469444 (catalog mag +17.1), PGC 2468484 (catalog mag +17.5),
PGC 2472365 (catalog mag +17.8)
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 01:41 UT (#951017-21)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
Negative CCD Image (70% size, square root scale)
Image details as above
UGCA 233 - Detail
Annotated CCD Image (150% size, square root scale, cropped)
Image details as above
Negative CCD Image (150% size, square root scale, cropped)
Image details as above


Back to Top


UGC 1971 - Galaxy with Type II Supernova 2021afkk

UGC 1971 with SN 2021afkk (Triangulum)
SN 2021afkk (Type: II) discovered 2021-11-25.371 UT by ATLAS
Alias: ATLAS21bmvp.
Magnitude +18.2 at discovery.   Distance 196 Mly (60 Mpc)
 (Rochester Supernova site | Enrico Prosperi image )

UGC 1971 with SN2021afkk - 2022-01-09 (T+44.7d)
Image below (2022-01-09.035) was taken 44.7 days after discovery of 2021afkk
Supernova reported position is shown by white cross-hairs
Measured magnitude +15.38 (SN + Galaxy Nucleus)
Annotated CCD Image  (125% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 01:00 UT (#951003-07)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2021afkk (UGC 1971) on Supernovae 2021 Page >>

Back to Top


UGC 3855 - Spiral Galaxy with Type II Supernova 2021agco

UGC 3855 with SN2021agco (Lynx)
SN 2021agco (Type: II) discovered 2021-12-05.564 UT by XOSS
Alias: PSP21al
 ( Rochester Supernova site | Andrea Mantero image | Jordi Camarasa image)

UGC 3855 with SN2021agco - 2022-01-09 (T+34.6d)
Image below (2022-01-09.150) was taken 34.6 days after discovery of 2021agco
Position of reported SN (very faint or not visible) is shown by white cross-hairs
Annotated CCD Image  (125% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 03:45 UT (#951073-77)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2021agco (UGC 3855) on Supernovae 2021 Page >>

Back to Top


UGC 5245 - Spiral Galaxy (PGC 28136)

UGC 5245 (Sextans)
Alias: PGC 28136
 [ Flat Galaxies
Annotated CCD Image (50% size, square root scale)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 01:41 UT (#951017-21)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2
UGC 5245 - Detail
CCD Image  (100% size, square root scale, cropped)
Image details as above
Negative CCD Image (100% size, square root scale, cropped)
Image details as above

UGC 5245 - Earlier Image (Feb 2021)
Image quality rather poor, target was rescheduled for a later session
CCD Image  (100% size, square root scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2021-02-16 23:47 UT (#859134-35)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Back to Top


UGC 5528 - Spiral Galaxy with Type Ia Supernova 2022B

UGC 5528 with SN2022B (Sextans)
SN 2022B (Type: Ia) discovered 2022-01-01.494 UT by ATLAS
Alias: ATLAS22aab
Mag +17.63 at discovery
 (Rochester Supernova site | TNS 2022B )

UGC 5528 with SN2022B - 2022-01-09 (T+7.6d)
Image below (2022-01-09.078) was taken 7.6 days after discovery of 2022B
Position of SN (visible & distinct) shown by white cross-hairs
Measured magnitude +17.75
Annotated CCD Image  (125% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 02:03 UT (#951024-28)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of SN 2022B (UGC 5528) on Supernovae 2022 Page >>


Back to Top


UGC 8426 - Spiral Galaxy with Transient AT 2021knq

UGC 8426 with AT 2021knq (Canes Venatici)
AT 2021knq (Type: unk) discovered 2021/04/26.034 UT by MASTER
Alias: MASTER OT J132415.53+312019.0
 ( Rochester Supernova site )

UGC 8426 with AT 2021knq - 2022-01-09 (T+258.2d)
Image below (2022-01-09.210) was taken 258.2 days after discovery of 2021knq
Reported position of transient (very faint ?) is shown by white cross-hairs
Annotated CCD Image  (125% size, square root scale, cropped)
5 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 05:11 UT (#951103-07)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

Images of AT 2021knq (UGC 8426) on Transients 2021 Page >>

Back to Top


UGC 8975 - Spiral Galaxy with Type Ia Supernova 2021adpe

UGC 8975 with SN 2021adpe (Canes Venatici)
SN 2021adpe (Type: Type Ia, z=0.009) discovered 2021-11-04.975 UT by Gaia
Alias: Gaia21fas,  Mag +17.76 at discovery
 (Rochester Supernova site | Gaia21fas )

UGC 8975 with SN2021adpe - 2022-01-09 (T+65.3d)
Image below (2022-01-09.240) was taken 65.3 days after discovery of 2021adpe
Position of SN (very faint) shown by white cross-hairs
Annotated CCD Image  (150% size, square root scale, cropped)
2 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 05:49 UT (#951118-19)
12" LX200R (at f/10.4) + ST-10XME
Unguided

Images of SN 2021adpe (UGC 8975) on Supernovae 2021 Page >>

Back to Top


WISEA J095040.62+475756.9 - Galaxy with Type II Supernova 2021aalq

WISEA J095040.62+475756.9 with SN 2021aalq (Ursa Major)
SN 2021aalq (Type: II) discovered 2021-10-03.620 UT by ASAS-SN
Alias: ASASSN-21sj, Gaia21etp
[ TNS 2021aalq ]

WISEA J095040.62+475756.9 - Galaxy
Annotated CCD Image (50% size, square root scale)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 04:05 UT (#951080-84)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

WISEA J095040.62+475756.9 with SN 2021aalq - 2022-01-09 (T+97.5d)
Image below (2022-01-09.163) was taken 97.5 days after discovery of 2021aalq
Position of SN (faint) is indicated by white cross hairs.
Annotated CCD Image (125% size, square root scale, cropped)
4 x 180s exposure (average combine), 3x3 binning, C Filter
2022-01-09 04:05 UT (#951080-84)
12" LX200R (at f/10.4) + ST-10XME
Auto-guided using TS 80mm APO, ZWO ASI178MC & PHD2

WISEA J095040.62+475756.9 with SN 2021aalq - 2022-01-09, Detail (T+97.5d)
Annotated CCD Image (200% size, square root scale, cropped)
Image details as above

Images of SN 2021aalq (WISEA J095040.62+475756.9) on Supernovae 2021 Page >>

Back to Top
